COOKTOP PARTS
1
For Models: KECC562GBL05, KECC562GWH05, KECC562GBT05
(Black) (White) (Biscuit)
10−03 Litho in U.S.A. (cre) Part No. 8186136
36" ELECTRIC
BUILT−IN
COOKTOP
COOKTOP PARTS
2
For Models: KECC562GBL05, KECC562GWH05, KECC562GBT05
(Black) (White) (Biscuit)
8186136
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT8285316
Installation
Instructions
LIT4456013
Wiring Diagram
LIT8285368
Use & Care Guide
LIT3191638
Brochure,
Tips−Safe Cooking
COOKTOP PARTS
2 Cooktop, Glass
4455556 Black
4455557 White
4455555 Biscuit
3 246119 Screw
4 4455420 Bracket, Switch
3183956 Seal, Switch
Bracket
Mounting
6 3191791 Spring Locator(10)
246119 Screw (8)
7 Switch, Infinite
3191049 LR − CR − RF
4456027 RR − LF
8 3192439 Seal, Switch Shaft
311865 Screw
9 3191945 Light, Indicator
10 Knob, Control (5)
9750372FF
Black
9750372FW
White
9750372FC
Biscuit
11 4456521 Box, Burner
14 3196537 Screw
15 8285469 Seal, Switch (5)
17 311865 Screw
18 4455917 Bracket, Mounting
20 8285104 Rail, Element (2)
21 3192269 Rail, Element (1)
22 3192222 Lamp, Hot
Surface Indicator
24 Element, Surface
8523693 1000/2400W − LF
8523698 1200W − RF
8523697 1500W − LR & CR
4452741 1000/1800W − RR
MISCELLANEOUS PARTS
3
For Models: KECC562GBL05, KECC562GWH05, KECC562GBT05
(Black) (White) (Biscuit)
8186136
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
3172515 Mtg. Hardware Kit
3192737 Seal, Burner Box
3191239 Tape, Foam
4455364 Bracket,
Support (4)
3192408 Bracket,
Support (2)
SPLICING WIRES−−25FT.
LENGTH
4456028 Wire, Jumper
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
CLEANER, COOKTOP
3191048 Cleaner, Glass
WIRING HARNESS PARTS
4456764 Harness, Main
313438 Clip, Harness
3400015 Screw, Ground
4456513 Conduit, Harness
