KitchenAid KECC568RPB00 User manual

COOKTOP PARTS
1
For Models: KECC568RPB00, KECC568RPW00, KECC568RPS00, KECC568RPT00
(Black) (White) (S.Steel) (Biscuit)
3−06 Litho in U.S.A. (cre) Part No. 8186294
36" ELECTRIC
BUILT−IN
CERAN COOKTOP

COOKTOP PARTS
2
For Models: KECC568RPB00, KECC568RPW00, KECC568RPS00, KECC568RPT00
(Black) (White) (S.Steel) (Biscuit)
8186294
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8286066 Installation
Instructions
8285425 Wiring Diagram
8286064 Tech Sheet
8286067 Use & Care Guide
3191638 Safe Cooking Tips
2 Cooktop, Glass
8286194 Black
8286195 White
8286197 Stainless Steel
8286196 Biscuit
3 246119 Screw
4 8285982 Wall, Inside
3196160 Screw
6 9759094 Spring Locator(10)
7 8285817 Shield, Heat
8 3192439 Seal, Switch
9 8285242 Seal, Heat Shield
11 8285821 Box, Burner
13 8285919 Board, Power
4449745 Screw
14 3196537 Screw
15 8285924 Board, Control
16 8285708 Frame, Cooktop
(S.Steel Only)
17 8285534 Bracket, Bottom
3196160 Screw
18 8285323 Cable Ass’y
20 9756813 Rail, Element (2)
21 8286081 Rail, Element (1)
23 8286053 Box, Touch Control
3196160 Screw
24 Element, Surface
8285847 2500/1800/900W LF
8285230 1200W LR
8285849 4300W Center
4453907 1500W RR
25 4449868 Block, Terminal
26 3196163 Screw, 10−16 x 7/8
28 4456922 Support, Module
29 4455917 Bracket, Mounting
3400093 Screw

MISCELLANEOUS PARTS
3
For Models: KECC568RPB00, KECC568RPW00, KECC568RPS00, KECC568RPT00
(Black) (White) (S.Steel) (Biscuit)
8186294
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
3192408 Bracket,
Support (2)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
FE02313 Bushing
ACCESSORY PARTS
4456147 Cleaner, Glass
WIRING HARNESS PARTS
8285805 Harness, Main
3400015 Screw, Ground
8286379 Conduit
