KitchenAid KICU508SBL0 User manual

COOKTOP PARTS
1
For Models: KICU508SBL0
06−07 Litho in U.S.A. (jac) Part No. W10131682 Rev. A
30" INDUCTON
COOKTOP
(Black)

COOKTOP PARTS
2W10131682
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10098720 Instruct, Install
W10098710 Owners Manual
2
W10122345 Cooktop, Glass
3
W10122355 Bracket, Mntg(Kit)
4
W10122356 Bracket, Mntg(Kit)
5
W10122347 Seal
6
W10122332 Hotplate (180−180)
7
W10122353 Harness, Wire
8
W10122348 Spring
9
W10134542 Box, Burner
10
W10122333 Cover (Mica 180)
11
W10122334 Hotplate (280−150)
12
W10122339 Display
13
W10122351 Bracket, Mounting
14
W10122336 Cover (Mica 280)
15
W10122338 Cover (Mica 80)
16
W10122349 Harness, Wire
17
W10122354 Harness, Wire
18
W10122341 Display (Lock)
19
W10122344 Display (Clock)
20
W10122343 Display (Timer)
21
W10122342 Display (Power ON)
For Models: KICU508SBL0
(Black)

INTERIOR PARTS
3
W10131682
For Models: KICU508SBL0
(Black)

4
INTERIOR PARTS
W10131682
Illus. Part
No. No. DESCRIPTION
1 W10122357 Cord, Power
2
W10122363 Fan, Blower
3
W10134543 Control, Elec
4
W10122364 Control, Elec
5
W10122380 Harness, Wire
6
W10122359 Harness, Wire
7
W10122375 Block, Fuse
8
W10122360 Bracket, Control
9
W10122368 Cover, Bottom
10
W10122365 Control, Elec
11
W10122377 Harness, Wire
(T Control)
12
W10122379 Block, Terminal
13
W10122374 Fuse
14
W10122370 Bracket, Mounting
15
W10122371 Conduit
16
W10122372 Bushing
For Models: KICU508SBL0
(Black)
