KitchenAid KHWC160P User instructions

Hot Water Dispenser
OVERALL DIMENSIONS
KHWC160P
KHWG160P
KHWL160P
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 8578898
03-31-06
PRODUCT MODEL NUMBER
Electrical: A 120-volt, 60 Hz, AC-only 15 or
20 amp fused, grounded electrical supply is
required. It is recommended that a separate circuit
serving only your hot water dispenser be provided.
Use an outlet that cannot be turned on/off by a
switch.
Water supply requirements: If local codes
permit, the hot water dispenser feed line should be
connected to the cold water supply line using a
saddle tapping valve.
Important: If local codes do not permit the use of
saddle valves, special feed valves can be obtained
from your local plumbing supply distributor.
If a filter system is used, the water pressure to the
dispenser should not drop below 20 psi (138 kPa).
42" (106.7 cm) max. —
electrical outlet to hot
water dispenser tank.
Tank
must be
mounted
vertically.
Spout installed in spray hose
opening in sink.
If spout is not to be
installed in sink spray hose
opening, cut a 1-3/8"
(3.5 cm) dia. sink or
countertop cutout
Saddle
valve
1-3/4" (4.4 cm) max.
countertop or sink thickness
Important: Observe all governing
codes and ordinances.
Cold
water
supply
line
6-7/8"
(17.5 cm)
7-7/8"
(20.0 cm)
11-1/8"
(28.3 cm)
®
