KitchenAid IMPERIAL KEBI141YBL1 User manual

c1992 KITCHENAID
IMPERIAL
24" BUILT−IN ELECTRIC
Self Clean Oven
MODEL
KEBI141YBL1
BL−Black Glass
7−92 Litho in U.S.A Part No. 4174232

2
OVEN PARTS
For Model: KEBI141YBL1
4174232

Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
3
OPTIONAL PARTS (NOT INCLUDED)
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
SPLICING WIRES−−25FT.
LENGTH
18 Ga. 80 c Rating
350806 Yellow
16 Ga. 80 c Rating
242829 Blue
14 Ga. 150 c Rating
242820 Black
242821 Blue
242822 Brown
242823 Green
242824 Orange
242825 Red
242826 White
242827 Yellow
14 Ga. 200 c Rating
242830 Brown
242831 Red
242832 Yellow
12 Ga. 150 c Rating
242828 Black
242829 Red
PAINT, TOUCH−UP (1/2oz.)
72017 White
72107 Almond
72110 Harvest Gold
72112 Toast
72113 Platinum
72032 Black
261869 Citrine White
PAINT, PRESSURIZED SPRAY
(13 oz.)
350930 White
350956 Almond
261890 Harvest Gold
285365 Toast
285366 Platinum
830864 Black
350942 Primer
350941 Leveler (Primer)
PAINT, BULK (1 qt.)
799344 White
978883 Almond
261891 Harvest Gold
285367 Toast
285368 Platinum
ADHESIVE
482338 Sealer, Silastic
(3 Oz.)
591014 Adhesive, Loctite
(1/3 Oz.)
ACCESSORY PARTS
799832 Kit, Porcelain
Repair (White)
832985 Rack, Cooking
(Bi−Level)
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
OVEN PARTS
For Model: KEBI141YBL1
4174232
3177865 Insulation, Wrap
3177870 Insulation, Back
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
2 3177545 Bracket, Conduit
300890 Screw (2)
3 3177626 Cabinet, Back
300890 Screw (14)
6 3178139 Cabinet, Top
300890 Screw (5)
7 3183747 Top, Module
300890 Screw (8)
8 3177442 Side, Cabinet
(R.H. & L.H.)
300890 Screw (I0)
9 3181699 Tube, Vent
3185383 Screw (3)
10 3150505 Oven Light Assy.
12 311255 Bulb, Oven
Light
14 3177698 Frame, Front
3179776 Screw (4)
15 3179814 Seal, Door
16 3179848 Clip, Oven Seal
17 3177681 Bracket, Switch
18 3177923 Insulator, Switch
19 3177622 Bottom, Modual
20 3179220 Rail, Support (2)
300890 Screw (4)
22 3177434 Support, Oven
300890 Screw (2)
23 3178612 Shield, Radiation
3179795 Screw (6)
300890 Screw (2)
24 3177433 Bracket, Hinge
300890 Screw (2)
25 3177572 Side, Module
(R.H. & L.H.)
300890 Screw (2)
26 3177559 Back, Module
300890 Screw (8)
27 3177491 Liner, Oven
28 3178298 Hinge, Door
3178000 Screw (4)
29 3185109 Button, Plug
30 3185085 Button, Plug
31 4173553 Switch, Door
4159117 Nut (2)
313489 Screw (2)
33 3179587 Retainer, Seal
4159450 Screw
34 3177788 Vent, Lower Trim
3180022 Screw (4)
4168863 Screw (2)
35 3183791 Tube, Vent
39 4168203 Cover, Cap Tube
4159445 Screw
40 3177552 Bottom, Oven
41 3182584 Bracket, Control
Panel
3177991 Screw (4)

4
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
CONTROL PANEL PARTS
For Model: KEBI141YBL1
4174232
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3181773 Membrane, Switch
2 3183794 Bracket, Mounting
Switch Membrane
3 3181702 Microcomputer
3185383 Screw (2)
4 3183705 Retainer, Bracket
3182939 Screw (2)
5 3182985 Clip, Retainer (3)
6 3182162 Trim, Door (2)
7 3182150 Door, Latch Handle
3179847 Screw (2)
8 3183701 Trim, Panel
300890 Screw (3)
9 3184321 Bracket (2)
3182939 Screw (2)
10 3182147 Frame, Control
Panel
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT4174232 Repair Parts List
LIT3182129 Tech Sheet
LIT3183659 Installation
Instructions
LIT3182134 Use & Care Guide

Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
5
LATCH AND VENT PARTS
For Model: KEBI141YBL1
4174232
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3183747 Module, Top
2 258076 Block, Terminal
308043 Screw (2)
4 3183784 Switch, latch
5 3178185 Insulator, Switch
6 3177662 Guard, Latch
7 3177969 Handle, Latch
8 3184039 Knob, Latch Handle
3183294 Screw
9 3184040 Spacer, Latch
Handle
3184037 Screw (2)
10 3178410 Latch Mechanism
11 3177496 Plate, Mounting
3177991 Screw
13 3183954 Nozzle, Vent
Bottom
14 3183955 Nozzle, Vent Top
300890 Screw (6)
15 3183999 Box, Vent
16 3183964 End, Vent Box
300890 Screw (6)
17 3183533 Bracket, Mounting
3177991 Screw (4)
18 3183720 Blower, fan
300890 Screw (5)
19 3183791 Tube, Vent
300890 Screw
20 3149650 SPST Thermostat
300890 Screw (2)
21 3183799 Shield, Heat
3177991 Screw (2)
22 3183953 Box, Vent
23 4159035 Bushing
24 313755 Seal, foam

Illus. Part
No. No. DESCRIPTION
6
OVEN LINER PARTS
For Model: KEBI141YBL1
4174232
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3177470 Liner, Oven
2 661415 Element, Broil
3185383 Screw (4)
3 3147563 Grill, Broil
4 3147845 Pan, Broiler
5 3185309 Rack, Offset
6 3185310 Rack, Oven
7 661416 Element, Bake
8 3180694 Bracket, Element
3185383 Screw (4)
9 3148440 Sensor, Heat
3185383 Screw (2)

7
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
OVEN DOOR PARTS
4174232
For Model: KEBI141YBL1
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3177597 Liner, Door
4168863 Screw (6)
3178001 Screw, Black (2)
2 3178584 Seal, Window
3 3179694 Spacer, Window
4 3177831 Latch, Strike
300890 Screw (2)
5 3177719 Insulation
Retainer
300890 Screw (4)
6 4163855 Bracket, Glass Mtg.
300890 Screw (4)
7 3181549 Glass, Door
8 4164243 Glass, Reflective
9 3181403 Frame, Door
10 3182164 Handle, Door
3181637 Screw (2)
11 3182138 Spacer, Door
Handle
13 4164235 Window Pack
14 3180094 Insulation, Door
15 3181651 Bushing, Door
Handle
247326 Screw
4168863 Screw (5)
16 3181701 Bumper, Door
Glass

Illus. Part
No. No. DESCRIPTION
8
WIRING HARNESS PARTS
1 3183655 Harness Wire
(Door Switch)
4 3184220 Harness Wire
(Oven)
5 3179668 Standoff, Wire
300890 Screw (4)
7 4159037 Clamp, Wire
112432 Nut, Hex (3)
8 3183976 Harness, Wire
(Latch Assy.)
9 3183657 Harness, Wire
Blower, Fan
For Model: KEBI141YBL1
4174232
