COOKTOP PARTS
1
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
02−07 Litho in U.S.A. (cre) Part No. 8186670
30" Freestanding
GAS OVEN
CONVECTION

COOKTOP PARTS
2
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literaturre Parts
9763460 Installation
Instructiions
9763457 Use & Care Guide
Tech Sheet
9762784 English
W10065210 French
9757680 Anti−Tip Instruct.
3191638 Safe Cooking Tips
9759133 Safe Cooking Tips
9763467 Guide Easy Set
2
W10110471 Burner Box
3 9761784 Bracket, Mounting
4 Cooktop
W10106330 Biscuit
W10106340 White
W10106320 Black
5 3196537 Screw
6 Trim−CkTop, SI
9761739WH White LH
9761739BT Biscuit LH
9761739BL Black LH
9761739SS S.Steel LH
9761738WH White RH
9761738BT Biscuit RH
9761738BL Black RH
9761738SS S.Steel RH
7 3400843 Screw
9 9763445 Bracket, Burner
10 9756821 Support, Wiring
12 Grate, Burner
9761625SD Satin Cumberland
9761625SN Satin Moleskin
9761625CB Coal Black
13 Grate, Brnr (TCB)
9761624SD Satin Cumberland
9761624SN Satin Moleskin
9761624CB Coal Black
14 9761577 Cover, Backsplash
15 Backsplash
W10109750 Black
W10109740 White
W10109760 Biscuit
W10109770 Nickel Plated
Gasket
9763483BL Black
9763483GY Gray
16 9759944 Thermostat (60c)
17 Vent, Center
9760225BL Black
9760225WH White
9760225BT Biscuit
18 Grate,Insert (TCB)
9761557SD Satin Cumberland
9761557SN Satin Moleskin
9761557CB Coal Black
19 Cap, Burner
12.5K (RR)
9761563SD Satin Cumberland
9761563SN Satin Moleskin
9761563CB Coal Black
6K (RF, LR)
9761562SD Satin Cumberland
9761562SN Satin Moleskin
8284669 Coal Black
20 4449809 Screw
21 3196160 Screw
22 Orifice Holder
W10110375 Small (2)
W10110376 Large
23 9759627 Cover, Cktp Rear
24 9763436 Cover, Top Rear
25 Head, Burner
8286182 Large
8286181 Small (2)
26
W10109920 Gasket (Tape)
27 Glass, Backsplash
9761749BL Black
9761749WH White
9761749BT Biscuit
28 9762768 Clip, Retainer

OVEN PARTS
3
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670

OVEN PARTS
4
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Side
(Right Hand)
W10109570 White
W10109550 Biscuit
W10109540 Black
W10109560 S.Steel
(Left Hand)
W10109520 White
W10109500 Biscuit
W10109490 Black
W10109510 S.Steel
2 8053971 Brace, Main Back
3 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
4 9760749 Bumper, Door
6 3400832 Screw
7 8303099 Top Chassis
9 9761666 Tube, Vent
10
W10067870 Lens, Light
11
W10009930 Oven Light Assy
12 4452166 Bulb, Light
13 9757732 Shield, Heat
14 9760756 Frame, Front
15
W10074200 Gasket, Door
16
W10105420 Deflector, Vent
Bottom
17 4452152 Bracket, Mounting
18 9757685 Guide, Side Panel
19 9757461 Bracket,Side Panel
20 Oven, Side Panel
9760723PB Black
9760723PW White
9760723PC Biscuit
21 9757811 Brace, Side Panel
22 9760888 Latch, Motorized
23 9757807 Thermostat SPST
(230)
24 9759890 Clip, Side Panel
25 4455641 Side, Chassis
(R.H. & L.H.)
26 9759762 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 9759945 Standoff, Rear
29 4455636 Sensor
30 9756454 Bracket, GOC
31 9760223 Slide, GOC
32
W10083460 Slide, GOC
33 9762774 Central, Appliance
34 3196537 Screw
37 9759242 Thermostat (TOD)
(Temp.) SPST 130C
41 4449743 Screw
43
W10110534 Base, Chassis
49 4448933 Retainer, Gasket
50 9758583 Cover, Back
51 4449809 Screw
54 Vent, Bottom Upper
9756481WH White
9756481BT Biscuit
9756481BL Black
9756481SS S.Steel
55 Trim, Btm Vent
W10104910 White
W10104900 Biscuit
W10104890 Black
W10104870 S.Steel
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
W10095400 Insulation, Wrap
W10095410 Insulation, Back

DOOR AND DRAWER PARTS
5
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670

DOOR AND DRAWER PARTS
6
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9758676 Support, Element
2 8054056 Element, Warming
3 8274149 Sensor
4 9762919 Cover, Access
5 Glass, Door Front
9762766BL Black
9762766WH White
9762766BT Biscuit
9762766SS S.Steel
6 9763456 Panel, Drawer
7 4449809 Screw
8 Handle, Door
8303774BL Black
8303774WH White
8303774BT Biscuit
8303774SS S.Steel
9 9759230 Bracket, Central
10 Hinge, Door
9760579 Orange RH
9760580 Orange LH
11 9761935 Foot, Rear
12 9759229 Bracket, Side
13 Nameplate
9763444BL Black
9763444WH White
9763444BT Biscuit
9763444SS S.Steel
14 3400832 Nut
15 9757706 Glass, Inner
16 4457114 Shield, Heat Btm
17 9759225 Glass, Inner (2)
18 4451722 Insulation, Door
19 9759413 Liner, Door
20 9757805 Drawer Assy
21 3196037 Foot, Front
23 4457132 Retainer, Glass
24 Front, Drawer
9761747WH White
9761747BL Black
9761747BT Biscuit
9761747SS S.Steel
25 Bracket, Handle
9763497 R.Hand
9763496 L.Hand
26 Handle, Drawer
9761573WH White
9761573BT Biscuit
9761573BL Black
9761573SS S.Steel
27 Side, Base
9759953 R.Side
9759954 L.Side
28 4449743 Screw
30 8533988 Screw
31 3196537 Screw
32 Slide−Drawer
4453718 L.Hand
4453719 R.Hand
33 4457103 Shield, Heat Top

TOP VENTING PARTS
7
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION
1 W10105780 Front, Air Duct
2 Top, Air Duct
W10068590 R.Hand
W10068600 L.Hand
3 9759320 Blower
4 4451758 Block, Foam
7 9757829 Bracket, Transfrmr
8 9760212 Transformer
9 3196537 Screw
10 4449040 Screw
11 4449809 Screw
13 8302390 Bracket, Support
(Air Stop)

INTERNAL OVEN PARTS
8
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9752980 Shield, Flame
2 4451583 Motor, Convection
3 4457277 Grill, Broiler
4 4457276 Pan, Broiler
5 9757779 Fitting, Broiler
6 4448717 Rack, Oven
7 9760776 Element, Broil
8 4453957 Pan Support, Bake
9 9760229 Electrode, Bake
10 9760228 Burner, Bake Log
11 9752737 Shield, Oven
12 4453984 Shield, Bake Flame
3196176 Screw
13 9763716 Valve, Assy
14 9756831 Tube, Broil
15 9757700 Burner, Broil
16 8054129 Ignitor, Broil
17 4454009 Cover, Ignitor
18 4453920 Pan, Oven Bottom
19 9760777 Element, Convect
20 W10104790 Cover, Fan
21 9755542 Probe, Meat
22 3181534 Rack, Roasting
25 4452226 Blade, fan
26 4452227 Nut
27 9754443 Jack, Meat Probe
28 9755547 Lock Washer
29 9755546 Hex Nut
30 3196176 Screw
31 4449154 Screw

COOKTOP BURNER PARTS
9
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 9761069 Tubing, Burner(RF)
3 9761070 Tubing, Burner(RR)
5 9761068 Tubing, Burner(LR)
7 4456816 Valve, Burner
Small (2)
8 4456817 Valve, Burner
Large
9 9756824 Spark Switch &
Harness Assembly
10 9761648 Tube, Manifold
11 Manifold
9761641 TCB
9761642 Cooktop
12 3196537 Screw
14 8523704 Bolt, Valve (4)
18 4453754 Tubing
GDS to Manifold

TRIPLE CROWN BURNER
10
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION
1 9761639 Burner Assy.,
Triple Crown Brnr
2 8285250 Plate, Closure
3 8285255 Internal Head,
Triple Crown Brnr
4 8285256 External Head,
Triple Crown Brnr
5 Cap, Burner Ext.
8285258SD Satin Cumberland
8285258SN Satin Moleskin
8285258 Matte Black
6 Cap, Burner Int.
9758829SD Satin Cumberland
9758829SN Satin Moleskin
9758829CB Coal Matte Black
7 3400702 Screw
8 3400843 Screw
9 9760519 Valve, T.C.B.
10 Tube, T.C.B. Gas
9761072 Outer
9761071 Inner

CONTROL PANEL PARTS
11
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Control Panel
9761786WH White
9761786BT Biscuit
9761786BL Black
9761786NP Nickel Plated
2 9761566 Switch, Membrane
3 9762794 Control, Interface
4
W10105370 Shield, Console
5 3196537 Screw
6 9757409 Support, Gas Valve
7 9761745 Brkt, Touchsensor
9 Knob
9761569BL Black
9761569WH White
9761569BT Biscuit
9761569NP Nickel Plated
10 9758080 Module, Spark
11 Knob
9761779BL Black
9761779WH White
9761779BT Biscuit
9761779NP Nickel Plated
12 9780271 Screw

OPTIONAL PARTS (NOT INCLUDED)
12
For Models: KGRS807SBL00, KGRS807SWH00, KGRS807SBT00, KGRS807SSS00
(Black) (White) (Biscuit) (S.Steel)
8186670
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
W10110532 Harness, Wire
(Main)
9762904 Harness, Wire
Bake/Broil Ignit.
W10110533 Harness, Wire
Warming Drawer
9756921 Harness, T.C.B.
9762921 Harness, Comm.
9763481 Harness, Ground
Strap
9762781 Harness, Wire
(Connector Cable)
313660 Clip, Ground Wire
4448664 Clamp
4449809 Screw
112432 Nut
4450800 Screw, Ground
4452222 Spacer, Harness
3400015 Screw, Ground
Miscellaneous
814381 Hinge Pin Kit
4455352 Bracket, Blower
(60mm)
9757426 Orific Kit
9759899 Bakeware, 5 pc
4448950 Screw, Install (4)
9756609 Gasket, 19 x 388
9758677 Power Cord
9782676 Anit−Tip Assy
9757427 Kit, Orific
Filler,Counter Top
9757785WH White
9757785BL Black
9757785BT Biscuit
