KitchenAid KHLU162MSS1 User manual

1
HOOD PARTS
For Model:KHLU162MSS1
(Stainless)
11−05 Litho in U.S.A. (jac) Part No. 8191097
36" HOOD LINER

HOOD PARTS
2
For Model:KHLU162MSS1
(Stainless)
8191097
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
9763389 Instructions,
Installation /
Use & Care Guide
8190549 Wiring Diagram
2 8190541 Filter, Grease
3 8190550 Support, Light
4 8189593 Bulb, Halogen (4)
5 8190542 Holder, Bulb (4)
6 8189598 Support, Bulb (4)
7 8190551 Support, Light
8 8190545 Blower
9 8190411 Nut
10 8189856 Transformer
11 8190414 Nut
12 8190552 Hoodliner
13 4360147 Relief, Strain
14 4360146 Nut
15 4360006 Screw
16 4360303 Cover, Dist Box
17 4360161 Connector, Male
18 4360162 Connector, Female
19 4360252 Control, Motor
20 8190403 Screw
21 8189618 Button, On/Off
22 8190547 Box, Control
23 4360028 Lens, Light
24 8189620 Button, Mtr Speed
25 8189621 Switch, On/Off
26 8190548 Switch, Mtr Speed
27 8189623 Support
28 8189624 Cover, Switch
