HOUSING AND CONTROL PARTS 30" AND 36"
RETRACTABLE DOWN DRAFT
VENT SYSTEM
For Models: KIRD802XSS1, KIRD862XSS1
1Part No. 4174306 Rev.B
9−93 Litho In U.S.A.
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
HOUSING AND CONTROL PARTS
VENTILATION PARTS
Illus. Part
No. No. DESCRIPTION
For Models: KIRD802XSS1, KIRD862XSS1
4174306 2
1 Cover,
Controls (Top)
4360130 KIRD802XXS1
4360131 KIRD862XSS1
2 4360209 Button, Push
3 4360134 Housing, Switch
4 4360135 Switch, Fan
5 4360136 Shield, Support
Bracket (2)
6 4360137 Knob
7 4360138 Panel, Control
8 4360139 End Cap (2)
9 4360140 Plate, Support
(Upper) (2)
10 Housing,
Non−Serviceable
11 Bracket, Support
4360141 Lower R.H.
4360170 Lower L.H.
12 4360142 Nut
13 4360143 Arm, Gear Motor
14 4360144 Arm, Cavity
15 4360145 Bolt
16 4360062 Strain Relief
17 4360006 Screw
18 4360146 Nut
19 4360147 Strain Relief
20 4360148 Screw
21 Cover, Housing
Non−Serviceable
22 4360149 Cover, Wiring Box
23 4360150 Nut
24 Guide, Housing
Non−Serviceable
25 4360152 Box, Wiring
26 4360153 Clamp
27 4360156 Nut
28 4360157 Spring
29 4360158 Washer
30 4360159 Bolt
31 4360160 Trim, R.H.
32 Cavity
Non−Serviceable
33 Filter, Grease
4360193 KIRD802XSS1
4360194 KIRD862XSS1
34 4360005 Washer
35 4360165 Terminal
36 4360196 Micro Switch (2)
37 4360166 Actuator,
Micro Switch (2)
38 4360167 Spring (2)
39 4360168 Cover, Switch
40 4360169 Housing, Switch
41 Support
4360171 L.H.
4360172 R.H.
42 4360173 Guide,
Housing (Back)
43 4360174 Spacer, Cavity (2)
44 4360044 Clamp, Cable
45 4360211 Connection, Wire
46 4360210 Switch
47 4360163 Bolt
48 4360164 Nut
Following Parts Not Illustrated
4360198 Installation Kit
LITERATURE PARTS
LIT4360199 Installation
Instructions/
Use And Care Guide
1 4360192 Box, Blower
2 4360154 Motor, Gear
3 4360035 Micro Switch (3)
4 4360155 Bracket,
Motor Gear
5 4360059 Bracket, Capacitor
6 4360191 Cover, Blower Box
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
EXTERIOR VENTILATION PARTS
4174306 3
1 Power Unit
Complete
Model KPED890T
2 4173295 Roof Mounting Kit
(Dome cover
And Flashing)
5 4173414 Motor (Includes
Capacitor & Cap)
6 4173415 Blade, Fan
7 4173417 Cover, Motor
(Wall Mount)
8 4173416 Impeller
9 4173456 Plate, Adaptor
(With Damper)
10 Housing,
(Non−Serviceable)
11 Housing, Ring
(Non−Serviceable)
13 9" Elbow
(Not Included,
Purchase Locally)
OPTIONAL PARTS NOT INCLUDED
4360205 Trim Kit−White
(KIRD802)
4360207 Trim Kit−Black
(KIRD802)
4360206 Trim Kit−White
(KIRD862)
4360208 Trim Kit−Black
(KIRD862)
For Models: KIRD802XSS1, KIRD862XSS1

This manual suits for next models

1
