KitchenAid Pro Line Series Operating and maintenance manual

IMPORTANT:
Read and save
mMPORTANT:
Installer: Leave Installation Unstrucfions with
the homeowner.
Homeowner: Keep Installation Instructions for
future reference.
Save Installation Instructions for UocaUeUectricaU
inspector's use.
Part No. 4329454/8285147
Piece N° 4329454/8285147
Quick Reference
TabNeof Contents:
Pages
[] Before you start
[] Product dimensions
[] Cabinet dimensions
[] Venting requirements
[] EUectdcaUrequirements
[]-[] UnstaHation steps
[] Use and Care Information
[] Wiring diagrams
[] Accessories
[] Warranty
[_- [] Requesting Assistance
or Service

Your safety and the safety of
others is very important.
We haveprovided many important
safety messagesin this manualand
on your appliance. Always readand
obey atlsafety messages.
This is the safety aiertsymbol.
This symbol alerts you to
potential hazardsthat can kill
or hurt you and others. Aii safety
messageswiii foliow the safety alert
symboi and either the word "DANGER"
or "WARNING".Thesewords mean:
Youcan be killed or seriously injured
if you don't fellow instructions.
Aii safety messageswiii teli you what
the potential hazardis, teli you how to
reducethe chance of injury, and tell
you what can happenif the
instructions are not followed.
important: Observe all governing
codes and ordinances.
Proper installation is your responsibility:
, Have a qualified technician install this
range hood.
, Comply with installation clearances
specified on the model/serial rating
pUate.
The model/serial rating plate is Uocated
inside the range hood on the rear wall.
Rangehood tocation should be away from
strong draft areas, such aswindows, doors
and strong heating vents.
Cabinet opening dimensions that are
shown must be used. Given dimensions
provide minimum clearance. ConsuUt
your cooktop/range manufacturer
instaflation instructions before making
any cutouts.
Grounded electrical outlet is required.
See "Elec:trical requirements"
The canopy hood is factory set for
venting through the roof or wall.To vent
directly through the wall, the blower
must be rotated to face the rear of the
range hood.
All openings in seiJing and wall where
range hood wiii be installed must be
sealed.
WARNING -- TO REDUCE THE
RiSK OF FIRE, ELECTRIC
SHOCK, OR iNJURY TO
PERSONS, OBSERVE THE
FOLLOWING:
Installation work and electrical
wiring must be done by qualified
person(s) in accordance with all
applicable Codes and Standards,
including fire related construction.
Sufficient air is needed for proper
combustion and exhausting of
gases through the flue (chimney)
of fuel burning equipment to
prevent back drafting. Follow the
heating equipment
manufacturer's guideline and
safety standards such as those
published by the National Fire
Protection Association
(NFPA),and the American Society
of Heating Refrigeration and Air
Conditioning Engineers
(ASHRAE), and the local code
authorities.
When cutting or drilling into wall
or ceiling, do not damage
electrical wiring and other hidden
utilities.
Ducted fans must always be
vented to the outdoors.
WARNING --To reduce the risk
of fire, use only metal ductwork.
This unit must be grounded.
Tools needed:
1=1/4" ddH bit
// \,°°°°" XZ
tape or ruler
wire stripper
or utility knife
Parts needed:
• 2 U.L- or C.S.A.- listed, 1/2" (12.5 ram}
conduit connectors
• power supply sabine
•1 wall or roof cap
• metal vent system
Partssupplied:
Mounting screws
30" 17&2 am! = 2
Exhaust outlet cover 36" 191.4 sin) = 2
30" (76.2 am) = 1 42" (10&7 am} = 4
36" (91.4 sin) = 1 48" (121.9 am) = 4
42" (10&7 am) = 1 "_
48" (121.9 sin} = 2 \,
Damper screws: \\\
30" (7&2 sin) = 2 "\
36" (91.4 sin} = 2
42" (10&7sin) =2 _-_
48" (121.9am} 4
Damper:
30" (78,2sin) = 1
36" 191.4 sin) = 1 _,i-...............
42" (10&7am) = 1
48" (121.9 sin) = 2
Note: Backspmash, vent cover, discharge
transition, and chimney extension kits are
available from your dealer (see page 9).These
are required for some installations and must
be instalBed at time of hood installation as
shown in the Installation Instructions.
saber or
keyhole saw
screwdriver
screwdriver

12-1/32"
t3&6cm)
25=3/16" 30"(7&2cra)hood:29=7/8"(75,9era)
(64era) _1"436"(91.4cra)hood:35=7/8"(91.1era)
42"(10&7era)hood:41=7/8"(106.4cra)
48"(121,9era)hood:47=7/8"(121,6era)
Vent system must terminate to the outside.
Do not terminate the vent system in an attic or other
enclosed area.
Do not use 4-inch (10,2 cm) Uaundry-type wall caps.
Use metal vent only. Rigid metal vent ks recommended. Do
not use p_astic or meta_ foi_ vent.
For the most efficient and
quiet operation:
o The size of the vent shouH be uniform.
Use no more than three 90° eUbows.
Make sure there is a minimum of 24" (61 cm) of straight
vent between the eUbowsif more than one eUbowis used.
Do Not install two eUbowstogether.
The Uengthof vent system and number of eUbowsshouM
be kept to a minimum to provide efficient performance.
The vent system must have a damper. If roof or wall cap
has a damper, Do Not use damper suppUiedwith the
range hood.
o Use duct tape to seal all joints in the vent system.
Use caulking to seal exterior wall or roof opening around
the cap.
Determine which venting method is best for your
application and follow "Preparation" under "Installation
steps" on Page 5.
18" (45.7 cra)
rain.
clearaRce
upper
cabir_et to
countertop
30" (76.2 era) rain, bottom of
,p¥ to cooking surface
36" (91,4 era)
base cabinet
height
@ For installations with canopy only, minimum of
84-3/16" (213.8 cm).
® For installations with optional vent hood cover, minimum
of 96-3/16" (244.3 cm).
Ceiling height above canopy or canopy with optional vent
hood is unlimited.

Venting methods
This canopy range hood is factory set for
vertica] venting. For rear vent appUicafions, the
Mower must be turned inside the range hood so
that the Mower vents to the rear as indicated.
The Mower is turned by removing two screws
on each side of the Mower, rotating the Mower
with the exhaust opening facing the rear and
then repUacingthe screws.The exhaust cover(s)
must be moved to Nock the unused opening(s).
The Mower must be converted before installing
the range hood.
Vent system needed for installation is not
included. The 30" (76.2cm), 36" (91.4cm) and
42" (106.7cm) modeUshave one exhaust
opening. 3-1/4" x 10"(8.3 cm x 25.4 cm)
rectanguUar,7" (17.8cm) round, 8" (20.3 cm)
round, 9" (22.9 cm) round, or 10" (25.4 cm)
round vent may be used.The hood exhaust
opening is 3-1/4" x 10"(8.3 cmx 25.4 cm).
The 48" (121.9cm) modeUhas two 3-1/4" x 10"
(8.3 cmx 25.4 cm) exhaust openings. It is
recommended that VentTransifion Kit No.
8284757 be used to transition the two openings
into one 10" (25.4 cm) round vent. (Cannot be
used with Chimney Extension Kit No. 8284754.)
Vent system can terminate either through the
roof or wall.
The vent system ]ength shouM not exceed the
]engths shown in the chart.
Vertical venting
roof cap
3-1/4" x 10" /_
(8.3 cmx 25.4 cm)_ l _--_: _
(roof or vvaH) L_.._.,
Horizontal venting
3=1/4" ×10"
(8,3 cm × 25,4 crn)
horizontal venting
wall cap
Vent size Maximum length
3-1/4" x 10" (8.3 cm x 25.4 cm) 35 fL (10.7 m)
7" (17,8 cm) round 40 ft, (12,2 m)
8" (20.3 cm) round 50 ft. (15.2 m)
9" (22.9 cm) round 60 ft. (18,3 m)
10" (25,4 cm) round 60 ft, (18,3 m)
Calculating the vent system length
To calculate the length of the system you need, add the equivalent feet (meters)
for each vent piece used in the system.
Vent Piece
45° elbow
90° elbow
90° flat elbow
transition to round
wa[[ cap
3ol/4" x 10" (8.3cm x 25.4cm)
Rectangular
ZO feet
(2.1 m)
5.0 feet
(1.5 m)
12.0feet
(3.7 m)
5.0 feet
(1.5 m)
0.0 feet
(0.0 m)
7" (17.8cm), 8" (20.3 cm},
9" (22.9 cm}, !0" (25.4 cm)
Round
2.5feet _'
(0,8mt ...............
5.0 feet
(1.5m)
Example for 3ol/4" x 10"
(8.3 cmx 25.4 cm) vent system
3q/4" x 10" wall
(8,3 cr¢_x 25,4 era) cap
Maximum _ength = 35 ft. (10.7m)
1--90 ° elbow = 5ft, (1.5m)
8 if, (2.4 m) straight = 8 ft. (2.4 m)
1--wallcap = Oft. (Ore)
Length of 3-1/4" x 10"
(8.3 cmx 25.4 cm)
system = 13 ft. (3.9 m)
Note: FJexiMe vent is Not
recommended.
F[exib[e vent creates back pressure
and air turbu[ence that great[y
reduces performance.

Important: Observe all governing
codes and ordinances.
It is the customer's responsibility:
oTo contact a qualified electrical
installer.
oTo assure that the electrical
installation is adequate and in
conformance with Nationam
Emectdcal Code, ANSm/NFPA 70
-- latest edition% or CSA
Standards C22.1=94, Canadian
Electrical Code, Part 1 and
022.2 No.0=M91 =latest
edition _* and all mocalcodes
and ordinances.
if codes permit and a separate
ground wire is used, it is
recommended that a qualified
electrician determine that the
ground path is adequate.
A 120=volt, 60oHz,ACoonly, fused
emectdcal system is required on a
separate 15=amp circuit, fused on
both sides of the line.
Do not ground to a gas pipe.
Check with a qualified electrician if
you are not sure range hood is
Do not have a fuse in the neutral or
iMPORTANT:
Save installation instructions for
electricam inspector's use.
The range hood must be connected
with copper wire only.
The range hood should be
connected directly to the fused
disconnect (or circuit breaker) box
through flexible armored or
nonmetallic sheathed copper cable.
A U.L- or C.S.A.disted strain relief
must be provided at each end of the
power supply came. Wire sizes
(COPPERWIRE ONLY) and
connections must conform with the
rating of the appliance as specified
on the model/serial rating plate.
Wire sizes must conform to the
requirements of the National
Electrical Code ANSI/NFPA 70 --
latest edition% or CSA Standards
C22.1=94, Canadian Electrical Code
Part 1 and C22.2 No. O=M91=latest
edition *_ and all local codes and
ordinances.
A U.L- or C.S.A.q[sted conduit
connector must be provided at each
end of the power supply cable (at the
range hood and at the junction box).
Copies of the standards listed may be
obtained from:
* National Fire Protection Association
Oee Batter,/marsh Park
Quincy, Massachusetts 02269
** CSA IntemationaU
8501 East PUeasant Valley Road
CieveUand, Ohio 44131°5575
it is recommended that the vent system be installed
before hood is installed.
Do not cut a joist or stud unless absolutely necessary. If a
joist or stud must be cut, then a supporting frame must
be constructed.
Before making cutouts, make sure there is proper
clearance within the ceiling or wall for exhaust vent.
Check that all the installation parts and the box with
filters have been removed from the shipping carton.
® [f possible, disconnect and move freestanding or
slidedn range from cabinet opening to provide easier
access to rear wall. Otherwise put a thick, protective
covering over countertop, cooktop or range to protect
from damage or dirt. Select a flat surface for assembling
the unit. Cover that surface with a protective covering and
place all hood parts and hardware in it.
® Determine and mark the centerline on the wall
where the hood will be installed. If the vent system is
already installed, use center[ine of vent opening.
® If venting horizontally out the back of hood and vent
system is not installed, mark and cut vent opening now.
® Important: If used, Backsplash Kit must be
installed before installing the hood.
If a backsplash is not used, go to Step 5.
Backspiash installation: (The hardware package
supplied with the kit includes 4 plastic wall anchors
and mounting screws.)
.The height of the backsplash will determine the height
3i8"(&5mm
29-7/8" (7&9 cm}
35=7/8" (91,I cm)
41=7/8" (10&4 cm)
47=7/8" (I21_6 cm
Extends from
19=23/32" (5&1 cm}
to 39" (99,1 cm}
of the hood. Note: The minimum height of the hood
above the cooktop, as shown on Page 3, is 30"
(76.2 cm). The backsplash can be extended from
19-23/32" (50.1 cm) to 39" (99.1 cm). Note: As the 30"
(76.2 cm) installation height increases, the hood's
capture area decreases.
Determine the height of the hood.
Position the hood on the wall so that the top of the
backsplash is at the height of the bottom edge of
hood. Mark the [ocation of the four corner ho[es. [tis
recommended that the backsplash be attached to the
wall at all four corners. However, the lower flange
can be secured between the wall and backsplash,
countertop or cabinet base without using the bottom
corner screw's.
.Drill 5/16" (8 mm) holes.
.Push the plastic wall anchors all the way into the holes.
° Position the holes in the backsplash over the wall
anchors and attach using the screws supplied. 5

Vent and E_ectrica_ openings
1-1/8"
(2.9 cm)
Electrical (24.6 cm)
opening
30" (76.2 cm) hood
36" (91.4 cm) hood
42" (106.7 cm) hood
2-7/8"
(7.5 cm)
2-7/8"
(7,5 cm) All vent openings are
3-1/4" x 10" (8.3 cm x 25,4 cm)
48" (121.9 cm) hood
6-3/32"
(15.5 cm)
6-3/32" ,
(15.5 cm)
iElectrical opening
10-1/2"
(26.7 cm)
2-7/8"
(7.5 cm)
2-7/8"
(7.5 cm',
®The hood attaches to the wall
with the mounting screws Uocated
as shown. For the 30" (76.2 cm) and
36" (91.4 cm) modeUs, there are two
mounting screws. For the 42"
(106.7 cm) and 48" (121.9 cm)
modeUs, there are four mounting
screws. UnstaHthe screws into the
wall untiUthe screw heads are tight
against the wall and horizontal
Note: The screws provided for
mounting this range hood must be
fastened into solid wood. Do Not
fasten into sheet rock only.
top of hood
\
top of hood
top of hood
/
1°1/16" 7" 7"
(17=5 era} (17=8 era} (17=8 era)
48" (121=9 era}
rain= to cooking
surface
48" (121.9era) hood •
V
5_ ® Optional vent cover
installation: Attach the fuIFwidth vent
cover to the top of the range hood
with the screws provided.The vent
cover must be attached to the top of
the range hood before mounting the
range hood to the wall.
I\ I /I
\/of o%
Mounting brackets /
--r ................ I
A
30" (76.2 cm) hood: 13-15!32" (34.2 cm)
36" (91.4 cm) hood: 16-15/32" (41.8 cm)
42" (106.7 cm) hood: 19-15/32" (49.4 cm)
48" (121.9 cm) hood: 22-15/32" (57.1 cm)
B
30" (76.2 cm) hood: 26-15116" (68.4 cm)
36" (91.4 cm) hood: 32-15116" (83.7 cm)
42" (106.7 cm) hood: 38-15/16" (98.9 cm)
48" (121.9 cm) hood: 44-15/16" (114.1 cm)
Install each bracket on the wall as
shown. Make sure that the screws
and brackets are securely fastened to
the wall.
Install onlythe brackets. Do not
instammthe hood.

b []if chimney extension is
used: Attach the extension brackets
as shown.
105/8" ceiling
(27 cm} /
84/8" _1_ _ 8ol/8"
(20 6 cm} // I {20.6 cm}
23" (58.4 c_} max,
12"" {30.5 cm) min. top of hood
Make sure that the screws are
secureiv fastened to the wall.
Excessive Weight Hazard
Use two or more people to move
and install range hood.
Failure to do so can result in
back or other injury.
m if roof or wail cap does not
have a damper, attach damper to
exhaust opening(s) on top of the
hood using two PhiUUips-head
screws.
lore if 48" (121.9 cm) hood is to
be connected to 10" (25.4 cm) round
vent system, install the vent
transition piece now'.
2m The brackets are also used
to adjust the level of the canopy.
Using a Phillips screwdriver, rotate
the screw V2 to adjust the level of
the canopy.
13m Connect vent system to
hood. Seal all joints with duct tape.
14m if your installation uses the
optional vent cover, fit the cover
flanges over the brackets, if
installation uses the chimney
extension, fit the extension over the
brackets. Install the upper section
first, then fit the lower section over
the upper section. Seal extension to
hood with duct tape.
Determine and make all
necessary cuts in the wall for the
vent system. Install the vent system
before the canopy hood. See venting
methods on Page 4, and hood vent
opening dimensions on Page 6.
7_ Determine the required height
for the power supply cable and cut
a 1-1/4" (3.2 cm) hob at this
location. Run wire through hole
according the National Electrical
Code or CSA Standards and local
codes and ordinances.There must
be enough power supply cable
from the fused disconnect (or
circuit breaker) box to make the
connection in the hood's electrical
box.
Use caulking to seal all openings.
Do Not turn on power until
installation is completed.
8m Remove the terminal box
cover from the canopy hood.
Remove the power supply cable
knockout using a flat-blade
screwdriver. Attach conduit
connector into power supply cable
opening so that conduit connector
clamping screws are inside of
canopy hood.
bracket
waU
hood mounting
screw
30" (76.2 cm} hood has two brackets
36" (91.4 cm) hood has two brackets
42" (106,7 cm) hood has four brackets
48" (t21.9 cm) hood has four brackets
11m The hood attaches to the
wall by screws discussed earlier in
the installation instructions at
Step 5.The hood hangs from these
screws by brackets inside the
range hood. Before attempting to
hang the hood, use a Phillips
screwdriver to rotate the
adjustment screw marked Vl
counterclockwise to extend the
brackets from the canopy.
Hang the range hood by inserting
the brackets into the mounting
screws as shown. Note: These
screw's must be installed into solid
wood to support the weight of the
hood as described in Step 5. Rotate
the screws marked V1 to tighten
the range hood against the wail.
Make sure that the range hood is
securemy tightened against the
wail.
Electrical 8hock Hazard
Disconnect power before making
electrical connections.
Connect ground wire to green
ground screw in terminal box.
Failure to do so can resutt in
death or electrical shock.
5 m Make electrical connection:
E3
E3
E3
E3
E3
Connect the power supply cable
to hood terminal box through
the U.L.- or C.S.A.qisted conduit
connector.
Connect the white wire of the
power supply cable with the
white lead in the hood using a
twist-on connector; connect the
black wire of the power supply
cable with the black lead in the
hood using a twist-on
connector.
Connect the power supply green
ground wire under the green,
ground screw.
Tighten conduit connector
screws.
Replace the terminal box cover.

6m Install the filters.
oRemove the filters from the box
and remove the white protective
coating from the filters.
Note: Use two hands to install
filter, one to pull and turn the
knob, the other to hold the filter
in place so that it doesn't fall
onto the cooktop.
oGrasp one of the filters so that
the knob faces down and toward
the back of the hood.
oinsert the filter end without the
knob into the retaining channel
in the front of the hood.
oPull and turn the knob to the left
(counterclockw, ise) so that the
locking lever does not protrude
from the filter.
oinsert the knob end of the filter
into the retaining channel in the
back of the hood.
°Turn the knob to the right
(clockwise) to lock the filter in
place.
oRepeat for remaining filters.
Check operation
17o Turnpoworon.
8° The canopy hood
controls are located on the right-
hand underside of the canopy.
9° Checkthe operation of
the range hood:
E3 Move light switch to
"1" position. The light should
turn on.
[_ Move blower switch to
"1" position. The blower
should operate.
[_ Move the blower speed switch
to: "1" position for low speed,
"2" position for medium
speed, or "3" position for high
speed.
[_ Move blower and light
switches to "0" position to
turn blower and light off.
if range hood does not operate:
[_ Check that the circuit breaker
is not tripped or the house
fuse blown.
[_ Disconnect power supply.
Check that wiring is correct.
To get the most efficient
use from your new range
hood, read the "Use and
Care hformation" section.
Keep your KitchenAid
Installation Instructions and
Use and Care Guide close
to range hood for easy
reference.
WARNING --To reduce the risk of
fire or electrical shock, do not use
this fan with any solid-state speed
control device.
WARNING--TO REDUCETHE
RiSK OF FIRE, ELECTRIC SHOCK,
OR INJURYTO PERSONS,
OBSERVETHE FOLLOWING:
Use this unit only in the manner
intended by the manufacturer, if
you have questions, contact the
manufacturer. Before servicing or
cleaning unit, switch power off at
service panel and lock the service
disconnecting means to prevent
power from being switched on
accidentally. When the service
disconnecting means cannot be
locked, securely fasten a
prominent warning device such as
a tag to the service panel
CAUTION: For general ventilating
use only. Do not use to exhaust
hazardous or explosive materials
and vapors.
WARNING --TO REDUCE THE
RiSK OF A RANGETOP GREASE
FIRE:
Never leave surface units
unattended at high settings.
Boilovers cause smoking and
greasy spillovers that may ignite.
Heat oils slowly on Iovv or
medium settings.
AIw,ays turn hood ON when
cooking at high heat or when
cooking flaming foods.
Clean ventilating fans frequently.
Grease should not be allowed to
accumulate on fan or filter.
Use proper pan size. Always use
cookware appropriate for the size
of the surface element.
WARNING --TO REDUCE THE
RiSK OF INJURYTO PERSONS iN
THE EVENT OF A RANGETOP
GREASE FIRE, OBSERVETHE
FOLLOWING:
SMOTHER FLAMES with a close-
fitting lid, cookie sheet, or metal
tray, then turn off the burner. BE
CAREFULTO PREVENT BURNS. if
the flames do not go out
immediately, EVACUATE AND
CALLTHE FiRE DEPARTMENT.
NEVER PiCK UP A FLAMING PAN
--You may be burned.
DO NOT USE WATER, including
wet dishcloths or towels -- a
violent steam explosion will
result. Use an extinguisher ONLY
if:
You know' you have a Class ABC
extinguisher, and you already
know' how' to operate it.
The fire is small and contained in
the area where it is started.
The fire department is being
called.
You can fight the fire with your
back to an exit.

Replacing the HaUogen
lamps:
36" (91,4 sin) and 42" (1063 srn) hoods
shown,
Before you begin, make sure that
the range hood is turned off and
that the other lamps have had
sufficient time to cool Halogen
bulbs burn extremely hot.
To replace a halogen lamp:
o Remove 2 screws from the
circular metal trim around the
lamp assembly.
o Pull the trim with the lamp
assembly attached down far
enough so that the lamp can be
pushed out of the socket.
, insert the new lamp into the
socket and push the lamp and
trim assembly back up into the
hood.
o Replace the trim.
The canopy hood is designed to
remove smoke, cooking vapors
and odors from the cooktop area.
For best results, start the hood
before cooking and allow it to
operate several minutes after the
cooking is complete to clear all
smoke and odors from the kitchen.
Opening the canopy hood
control panel:
The hood controls are located on
the right-hand underside of the
canopy.
controls
,\\\
might blower blower speed
switch switch switch
Operating the light:
ON: Move the Hght switch to the
"1" position.
OFF: Move the light switch to the
"0" position.
Operating the blower:
ON: Move the blower switch to
the "1" position.
OFF: Move the blower switch to
the "0" position.
Adjusting the bUower speed:
The blower has three speed
control.
Move the blower speed switch to:
"1" position for low speed,
"2" position for medium speed,
or "3" position for high speed.
Filters:
The filters should be washed
frequently. Place metal filters in
dishwasher or hot detergent
solution to clean.
To remove filters:
Note: Use two hands to remove
filters, one to pull and turn the
knob, the other to hold the filter
so that it doesn't fall onto the
cooktop.
° Pull knob forward, toward the
front of the hood, while turning
the knob to the left (counter-
clockwise) to release the locking
lever.
To reinstall filters, see Step 16.
Exterior surfaces:
oDo not use steel wool or soap-
filled scouring pads.
oRub in direction of the grain line
to avoid marring the surface.
oAlways wipe dry to avoid water
marks.
oKitchenAid C6Professional
Formula Stainless Steel Cleaner
& Polish is the cleaner
recommended for cleaning
stainless steel surfaces on this
product.To order call our
Customer Service Center at
1-800-442-9991 or order onqine at
vvww.a pplia nceaccessories.com
and ask for part number
8171420.To order from Canada,
call 1-800-807-6777.
oif commercial cleaners are used,
follow label directions. Do not
use products that contain
chlorine (bleach). Chlorine is a
corrosive substance.
For routine cleaning and
fingerprints, use liquid detergent
soap and water, or alPpurpose
cleaner. Wipe with damp cloth or
sponge, then rinse with clean
water and wipe dry.
Optional Installation Kits available from your dealer.
Note: Kits are available in stainless steel only.
Backsplash: Must be installed before hood is installed.
30" (76.2 cm) hood: Kit No. 8285148
36" (91.4 cm) hood: Kit No. 8284756
42" (1063 cm) hood: Kit No. 8284827
48" (121.9 cm) hood: Kit No. 8284755
Vent covers: 12" (30.5 cm) high, 12" (30.5 cm) deep.
30" (76.2 cm) hood: Kit No. 8285149
36" (91.4 cm) hood: Kit No. 8284753
42" (106.7 cm) hood: Kit No. 8284828
48" (121.9 cm) hood: Kit No. 8284752
Chimney extensions: extends from 12" (30.5 cm) to
23" (58.4 cm) high. For use with 30" (76.2 cm), 36"
(91.4 cm), 42" (106.7 cm) and 48" (121.9 cm) hoods:
Kit No. 8284754
Vent transition: transitions from two 3-1/4" x 10"
(8.3 x 25.4 cm) vents to one 10" (25.4 cm) round vent.
Not for use with chimney extension Kit No. 8284754.
30" (76.2 cm) hood: Not available
36" (91.4 cm) hood: Not available
42" (106.7 cm) hood: Not available
48" (121.9 cm) hood: Kit No. 8284757

3OO
For 30" (76.2 sin), 3@' (91.4 sin)
vAc and 42" (10&7 cm) hoods vAc For 48" 1121.9 sin) hoods
U_ IN
KitchenAid ®Range Hood Warranty
LENGTH OFWARRANTY KitchenAid WiLL PAY FOR
LiMiTED ONE-YEARWARRANTY Labor and any parts of your range hood (except light bulbs and
From Date of Purchase filters) which are defective in materials or workmanship.
KitchenAid WiLL NOT PAY FOR
A. Consumable parts such as light bulbs and filters.
B. Service calls to:
1. Correct the installation of the range hood.
2. instruct you how to use the range hood.
3. Replace house fuses or correct house wiring.
C. Repairs when range hood is used in other than normal, single-family household use.
D. Pickup and delivery.This product is designed to be repaired in the home.
E. Damage to range hood caused by accident, misuse, fire, flood, act of God or use of products not approved
KITCHENAmD AND KITCHENAmD CANADA DO NOT ASSUME ANY RESPONSmB&mTYFOR iNCiDENTAL OR
CONSEQUENTmAL DAMAGES. Some states or provinces do not allow the exclusion or limitation of incidental or
consequential damages, so this exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which may vary from state to
state or province to province,
Outside the United States and Canada, a different warranty may applv. For details, please contact your
authorized KitchenAid dealer.
if you need service, first see the "Check Operation" section of this book. After checking the "Check Operation;'
additional help can be found by checking the "Requesting Assistance or Service" section or by calling our
KitchenAid Customer interaction Center, 1-800-235-0665 (toll-free), from anywhere in the U.S.A. or Canada.
10

To avoid unnecessary service calls, please
check the "Check Operation" section. It may
save you the cost of a service call. If you still
need help, follow the instructions below.
If you need assistance or service in U.S.A.
Call the KitchenAid Customer interaction
Center toHofree at 1o800o235o0665.
Our consultants are available to assist you.
When calling: PUeaseknow the purchase date, and
the compUete mode] and senaU number
of your appUiance This information wH]
heUpus better respond to your request.
Our consultants provide assistance with:
• Features and specifications on our full line
of appliances
Installation information
Use and maintenance procedures
Accessory and repair parts sales
® Specialized customer assistance (Spanish
speaking, hearing impaired, limited vision, etc.)
Referrals to local dealers, service companies, and
repair parts distributors
KitchenAid designated service technicians are
trained to fulfill the product warranty and provide
after-warranty service, anywhere in the United
States.
To locate the designated KitchenAid service
company in your area, you can also look in your
telephone directoryYellow Pages.
If you need replacement parts
if you need to order replacement parts, we recom-
mend that you only use factory-authorized parts.
These parts will fit right and work right, because
they are made to the same exacting specifications
used to build every new KitchenAid _ appliance.
To locate factory-authorized parts in your area, call
our Customer interaction Center telephone number,
your nearest authorized service center, or KitchenAid
Factory Service at 1-800-442-1111.
For further assistance
if you need further assistance, you can write to
KitchenAid with any questions or concerns at:
KitchenAid Brand Home Appliances
Customer interaction Center
c/o Correspondence Dept.
2000 North M-63
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your
correspondence.
11

Before calling for assistance or service, pJease
check the "Check Operation" section. Jt may save
you the cost of a service call. Jf you stilt need
help, foItow the instructions below.
If you
1. if the problem is not due to one of the items
listed in "Check Operation"f_.
Contact the deaUer from whom you
purchased your appliance, or cab the
need assistance or service in Canada
KitchenAid Canada Customer
interaction Center toll-free,
8:30 a.m.- 6 p.m. (EST),
at 1-800-235-0665.
2. if you need servicer...
Contact your nearest KitchenAid Canada Appli-
ance Service branch or authorized servicing
outlet to service your appliance. (See Hst beUow,.)
Make sure the service company you contact is
authorized to service your appliance during the
warranty period.
1"When asking for assistance or service, please
provide a detailed description of the problem,
your appliance's complete model and serial
numbers, and the purchase date.This
information will help us respond properly to
your request.
KitehenAid Canada Appliance Service - ConsumerServices
Direct service branches:
BRmBB COLUMBIA 1-800-665-6788
ALBERTA 1-800-661-6291
ONTARIO Ottawa area 1-800-267-3456
(except 807 area code) Outside the Ottawa area 1-800-807-6777
MANITOBA, SASKATCHEWAN 1-800-665-1683
and 807 area code in ONTARBO
QUEBEC Montreal (except South Shore) 1-800-361-3032
South Shore Montreal 1-800-361-0950
Quebec City 1-800-463-1523
Sherbrooke 1-800-567-6966
ATLANTIC PROVINCES 1-800-565-1598
For further assistance
If you need further assistance, you can write to
KitchenAid Canada with any questions or concerns at:
Consumer Relations Department
KitchenAid Canada
1901 Minnesota Court
Mississauga, Ontario L5N 3A7
Please include a daytime phone number in your
correspondence.
Part No. 4329454/8285!47
Piece N° 4329454/8285147
© 2002 KitchenAid
® Registered trademark/TM trademark of KitchenAid, U.S.A., KitchenAid Canada licensee in Canada 1/2002
Printed in U.S.A.

IMPORTANT:
Life et conserver
ces instructions.
IMPORTANT:
Jnstaliateur : Remettre Uesinstructions
d'instaHation au propdetake de U'appareik
Proprietaire : Conserver Uesinstructions
d'instaHation pour consuUtafion uUtedeure.
Conserver Uesinstructions d'instaHation
Hntenfion de Hnspecteur UocaUdes installations
eUectdques.
Piece N° 4329454/8285147
Reference rapide
Table des matieres :
Pages
[] Avant de commencer...
[] Dimensions du produit
[] Dimensions des placards
[] Circuit de decharge de I'air
[] Alimentation 61ectrique
[]- [] Les etapes de Hnstallation
[] Utilisation et entretien
[] Schema de c_blage
[] Accessoires
[] Garantie
[_-[] Demande d'assistance ou
de service

Votre s_curit_ et ce[le des autres
est tr&s [mportante.
Nous donnons de nombreux
messages de securit6 importants dans
ce manuel, et sur votre appareil
menager. Assurezovous de toujours lire
tousles messages de securit6 et de
vous y eonformen
Voici le symbole d'alerte de
securit6.
Ce symbole d'alerte de
securit6 vous signale les dangers
potentiels de dec6s et de blessures
graves a vous et & d'autres.
Tousles messages de seeurit6
suivront le symbole d'alerte de
securit6 et le mot <<DANGER>> ou
<<AVERTISSEMENT>L Ces roots
signifient :
Risque possible de d_c_s ou de
blessure grave si vous ne suivez
pas imm_diatement les instructions.
Risque possible de d_c&s ou de
b[essure grave si vous ne suivez
pas [es instructions,
Tousles messages de s6curite vous
diront qua[ est le danger potentiel et
vous disent comment reduire le risque
de blessure et ce qui peut se produire
en cas de non-respect des
instructions,
Important : Observer [es
dispositions de tous [es cedes et
regmements en vigueur.
C'est a vous qu'incombe [a
responsabilite de :
. Demander _ un technicien qualifie
d'installer cette hotte.
. Respecter Iors de I'installation les
degagements de separation sp@ifi_s
sur la plaque signaletique de I'appareil.
La plaque signa[etique {avec numero de
modele et num_ru de serie} est situee
['interieur de la hotte, sur la paroi arriere.
La hotte d'aspiration devrait toujours
_tre install_e a distance des sources de
courants d'air comme fen_tres, pores et
bouches de chauffage.
On doit respecter [es dimensions
[nd[quees pour I'ouverture dans le
placard. Les dimensions indiquees
tiennent compte des degagements de
s6paration n@essaires. Avant
d'effectuer un d@oupage, consulter
les instructions d'installation fournies
par le fabricant de la cuisini6re ou
table de cuisson.
Une prise de sourant e[ectrique re[iee
[a terre est n@essaire. Voir
<<Sp@ifications de Finstallation
ebctrique >).
La hotte d'aspiration est configures
Fusine pour la decharge _ travers le
toit ou un tour. Pour la d@harge
directe atravers un tour, on doit
changer Forientation du ventilateur
pour le placer face _ Farri_,rede la
hotte.
Assurer ['_tansheite au niveau de
chaque ouverture decoupee darts [e
plafond ou le tour pour ['installation
de [a hotte.
AVERTISSEMENT - POUR
MINIMISER LES RISQUES
DINCENDIE, CHOC ELECTRIQUEOU
DOMMAGES CORPORELS,
OBSERVERLES PRESCRIPTIONS
SUIVANTES :
Le travail d'installation et de c&biage
electrique doit 6tre ex@ute par des
personnes competentes et en con°
formite avec les prescriptions des
normes et codes appiicabies, cec[
inciuant les normes de resistance au
feu des elements de construction. La
disponibilite d'un volume d'air
approprie pour I'alimentation de
['equipement a combustion et ['e-
vacuation des gaz de combustion
par la chemin6e pour qu'il n'ait pas
de reflux est n@essaire. Respecter
les directives du fabricant de
I'equipement de chauffage etles
normes de securite, publiees par des
organismes somme la National Fire
Protection Association (NFPA}, et la
American Society of Heating
Refrigeration and Air Conditioning
Engineers (ASHRAE), et par les
autorites regiementaires locales.
Lots de toute operation de
decoupage ou de percage dans une
cloison ou un plafond, veiller a ne
pas endommager les cables eleco
triques et canalisations qui peuvent
s'y trouver.
Le conduit de d@harge associe aun
ventilateur doit se terminer a I'ex°
t6rieur.
AVERT[SSEMENT - Pour reduire le
risque d'incendie, utiliser unique-
ment des conduits metalliques.
Cet apparei[ doit 6tre relie a [a terre.
Pieces necessaires :
2 connecteurs do conduit 12,5 mm
(1/2 po} - homologation U.L ou
CSA
c&ble d'alimentation
1 bouche de decharge pour toit ou
m_r
conduit d'evacuation metal[ique
Pieces foumies :
Vis de montage:
P[aquettes d'obturation
(orifices de so,tie) :
76,2 am (30 po} =1
91,4 cm (36 po) = 1
106,7_m ,42po)= 1__
121,9cm (4gpo) = 2_
Vis pour volet de
76,2 am (3g pal = 2
91,4 cm (36 po) =2
106,7cm (42po) = 2_
121,9cm (48po) = 4 _-
Volet de rag[age:
76,2 am (30 po} =1
91,4_m (g6po! 1
106,7am (42po) = 1
121,9 cm (48 po} = 2
76,2 cm (30 po) = 2
91,4 cm (36 po) = 2
106,7 am (42 po) = 4
121,9 am 148 po] = 4
J
Note : D'autres pieces sont disponibies
chez [e revendeur local {voir page 9) :
dosseret, garniture cache=conduit (pour [e
sommet de [a hotte), raccord de transition
et ensemble d'extension de cheminee. Ces
pieces peuvent _tre necessaires darts
certaines installations, et e[[es doivent
a[ors _tre uti[isees [ors de ['installation de
[a hotte conformement aux instructions
d'instalIation.
Outillage necessaite :
niveau
rn_che a bois
1 1/4 po
pistolet d'appHcation
pour produits de
calfeuttage et
d'_tanch_it_

30,6 cm
f12 1/32 po)
64 cm
(25 3/16 po) _ 75,9 sm (29 7/8 po)
harts 91,4 cm (36 po) :
91,1 sm 135 7/8 po)
hotte 106,7 sm (42 po) :
10&4 cm (41 7/8 po)
hotte 121,9 cm (48 po) :
121,6 em (47 7/8 po)
profondeur
du placard
33 sm (13 po)
Le systeme doff d_charger ['air a ['exter[eur.
Ne pas terminer [e conduit d'evacuation au-dessus d'un
plafond ou dans autre espace ferm&
Ne pas utiliser une bouche de decharge murale de 10,2cm
(4 po) normalement utilis_e pour un appare[I de buanderie.
Uti[iser uniquement du conduit metaHique. On recommande
['emp[oi de conduit meta[lique rigide. Ne pas uti[iser des
conduits de p[astique ou de metal mince/flexible.
Pour un fonctionnement
efficace et silencieux :
La tai[[e du conduit d'_vacuat[on doit 8tre unfforme.
Ne pas uti[[ser plus de trois coudes a 90°.
S'i[ est necessa]re d'[nsta[[er p[usieurs coudes, ceux-ci
devront _tre separes par une section rectiligne d'au moins
61 cm (24 po).
Ne pas raccorder deux coudes ensemble.
Pour maximiser ['efficacite, minimiser la Iongueur effective
totale du systeme de decharge et le nombre de coudes.
Le systeme de decharge doit comporter un volet de
r_glage. Si la bouche de d_charge (sur letoit ou a travers
le tour) comporte un volet de reglage, ne pas utiliser le
volet de r_glage fourni avec la hotte.
Au niveau de chaque jointure du systeme de decharge,
assurer I'_tancheite avec du ruban adhesif pour conduit.
Autour de la bouche de decharge a I'ext_rieur, assurer
I'etancheite avec un produit de calfeutrage.
Determiner la methode d'evacuation de I'air la plus
appropriee pour I'application, et executer la preparation
decrite dans les instructions d'installation a la page 5.
hauteur des
placards
i_f_rieurs
91,4 sm
(36 po)
@ Pour installation avec hotte seu[ement - minimum de
213,8 cm (84 3/16 po).
® Pour installation avec garniture cache-conduit (option) -
minimum de 244,3 cm (96 3/16 po).
Pas de limitation pour la hauteur du plafond au-dessus de la
hotte ou de la hotte avec garniture.

Configurations de
circuit de decharge
La hotte d'aspirafion est configur_e a U'usinepour Ua
decharge atravers Uetoit ou un tour. Pour
U'evacuafion par U'ard_.re,il faut modifier I'orientation
du ventilateur a Hnterieur de la hotte pour que le
ventilateur rejette I'air par I'arriere. Pour ceD, 6ter bs
deux vis de chaque c6te du ventilateur, changer
I'orientation du ventilateur pour placer la decharge
face a I'arriere, puis reinstdbr bs vis. On doit ensuite
depDcer bs plaquettes d'obturation pour obturer bs
ouvertures non utilis6es. On doit effec:tuer cette
conversion avant d'instalbr la hotte.
Le conduit d'_vacuation necessaire n'est pas inclus.
Les modebs de 76,2cm (90 po), 91, 4 cm (96 po) et
106,7cm (42 po) comportent une ouverture de
decharge. On peut utiliser un conduit d'_vacuation
rectanguhire de
8,9 x 25 cm (3 1/4x 10 po), ou un conduit circulaire de
17,8cm (7 po), 20,9 cm (8 po), 22,9 cm (9 po) ou
25,4 cm (10 po} de diam_.tre. La hotte comporte un
orifice de d@harge de 8,9 x 25 cm (3 1/4x 10po).
La hotte de 121,9cm (48 po) comporte deux
ouvertures de d@harge de 8,3 x 25 cm (9 1/4x 10 po).
On recommande I'utilisation de I'ensemble de
transition de conduit d'evacuation n° 8284757 pour
connecter bs deux ouvertures _ un conduit circulaire
de 25,4 cm (10 po) de diam_.tre. (Ne peut _tre utilise
avec I'ensembb d'extension de cheminee
n° 8284754.)
Le circuit de decharge peut d@harger I'air
I'ext6rieur atravers le tour ou a travers le toit.
La Iongueur effective du circuit ne doit pas 6tre
Decharge atravers le toit
conduit de _ __
(31/4 x 10p . "-:%_.....
d_eharge a I _ _,_-']7 conduit de
travers le to[t L_ _ 8,3 x 25 cm _ I
== (3 1/4x 10 po) = "_-\_
d_charge a / _
TaiHedes conduits Longueur maximale
8,9 x 25 cm (3 1/4x 10po) 10,7m (35 pi)
Rond, dia. 17,8cm (7 po) 12,2m (40 pi)
Rond, dia. 20,3 cm (8 po) 15,2m (50 pi)
Rond, dia. 22,9 cm (9 po) 18,9m (60 pi)
Rond, dia. 25,4 cm (10 po) 18,3m (60 pi)
bouche
de
d_charge
murale
Calcul de
Pour calcubr la Iongueur effective du systeme de decharge, on doit tenir
compte de la Iongueur equivabnte de chaque composant du syst_.me.
Composant
coude a 45°
coude a 90°
coude a 90° plat
raccord de transition
bouche de d_charge
murale
la longueur effective du systeme de decharge
Conduit rectangulaire
8,3 x 25 cm {3 1/4 x 10 po)
2,1m
(7 pb
1,5 m
(5 pb
3,7 m
(12 pi)
1,5 m
(5 pb
Conduit fond, dia
!7,8 cm (7 po}, 20,3cm (8 po)
22,9 cm (9po), 25,4cm (10po)
0,8 m
(2,5 pi}
1,5 m
(5 pb
Om
(0 pi)
Exemple pour conduit d'evacuation de
8,3 cmx 25 cm (3 1/4 pox 10 po}
Coude 8,3 x 25 cm bouehe de
(3 1/4 x 10 po) d_charge mutate
0,era I I
Longueur maximab = 10,7 m(35 pi)
1--coudei_90 ° = 1,5m (5pi)
Section droite 2,4 m (8 pi) = 2,4 m (8 pi)
1 -- bouche de d@harge
murale : Om (Opi)
de conduit de 8,3 x 25 cm
(3 1/4x10po) = 4m (13pi)
Note : On deconseille t'emploi de conduit
d'evacuation flexible.
Un conduit d'@acuation flexible cree une
contre°pression et une turbulence de I'air
qui reduisent consid_rabbment la

Important : Respecter _esprescriptions
de tous _escodes et reg_ements en
vigueur.
C'est au client qu'incombe la
responsabilite de :
, Contacter un electrician qualifie pour
_'installation.
, Veil_er a ce qua l'installatien
electdque soit rea_isee d'une maniere
adequate et en conformite avec Jes
prescriptions du Code national des
installations electdques ANSI/NFPA
70 -demi_re edition% ou des hermes
CSA C22.1.94 /Code canadien de
_'e_ectricite, l_re partie et C22.2 N°
O=M91 -demiere edition_% etavec
les prescriptions de tous Jescodes et
reglements _ocaux en vigueur.
Si un cenducteur distinct de _iaison a ta
terra est utilise Iorsque _ecode le
permet, on recommande qu'un
electrician qualifie vedfie que la liaison
ta terra eat adequate.
L'apparei_ doit _tre a_imente par un
circuit de 120 volts, 60 Hz, CA
seu_ement, 15A, avec un fusiMe sur
chaque conducteur.
Ne pas uti_iser one tu\/autede de gaz
pour _aliaison a ta terra.
En cas d'incertitude quanta Ja qua_ite
de la liaison & _aterra de la hette,
consulter un electScien qua_ifi&
Ne pas installer un fusiMe en saris avec
te cenducteur neutre eute conducteur
de _iaisen a _aterra.
IMPORTANT :
Conserver _esinstructions d'instaHation
_'intentien de l'inspecteur local des
installations e_ectdques.
La hotte doit _tre raccordee au reseau
e_ectdque uniquement avec des
conducteurs de cuivre.
La hotte doit 8tre raccordee
directement au coupe-circuit avec
fusibbs ou aux disjoncteurs par
Hnterm_diaire de cSble
conducteurs de cuivre, _ blindage
metallique flexible ou a gains non
m_tallique. Un passe-fil
(homologation UL ou CSA) doit _tre
install_ _ chaque extremite du c_ble
d'alimentation. Le calibre des
conducteurs (CUIVRE SEULEMENT} et
bs pieces de connexion doivent _tre
compatibles avec la demands de
courant de I'appareil sp@ifiee sur la
plaque signdetique.
La tailb des conducteurs doit satisfaire
bs prescriptions du Code national des
installations ebctriques ANSI/NFPA 70
-derni_re edition _, ou des normes
CSA C22.1.94/Code canadien de
I'electricite, 1_r÷pattie et C22.2 N°
O-M91- derniere 6dition _, etavec los
prescriptions de tous los codes et
reglements Iocaux en vigueur.
Un connecteur de conduit
(homologation UL ou CSA) doit 6tre
installs a chaque extr6mit6 du cable
d'alimentation (sur la hotteet sur la
boite de connexion).
On peut obtenir aux adresses suivantes des
exemplaires des normes mentiolrn_es :
* National Fire Protectio_ Association
One Batterymarch Park
Quint% _assashosotts 02269
** CSA _otematiooal
8501 East PleasantVallov Road
Cleveland, Ohio 44131°5575
tl est preferable qua _ecircuit d'evacuation soit installs
avant l'instaHation de _a hotte. On ne doit cooper one
so_ive ou un poteau de colombage qua _orsque cola est
abso_ument n_cessaire. S'il est necessaire de cooper one
solive ou un poteau du colombage, on doit constmire one
structure de support appropd_e.
Avant d'effectuer _edecoupage, vedfier qua _esdistances
de separation appropriees seront respect_es autour du
conduit d'evacuation, darts _ep_afond ou _acavit_ du tour.
Verifier qua routes _espieces necessaires pour _'instaHation
et la bo_te comportant tes filtres ont eta retirees de
t'emballage.
® Si c'est possible, debrancher la cuisiniere (autonome
ou mobile), et retirer la cuisiniere de son encastrement
entre les placards pour pouvoir acceder au tour artiste.
Sinon, placer un epais materiau de protection sur le plan de
travail, la table de cuisson ou la cuisiniere, pour la
protection centre la poussi_,reetles dommages eventuels.
Choisir one surface plane pour I'assemblage de I'appareil.
Recouvrir cette surface d'un materiau de protection
approprie avant d'y placer tousles composants de la hotte
etles accessoires.
. Sur lemur, marquer la ligne qui correspondra a I'axe
central de la hotte apr6s son installation. Sile circuit
d'@acuation est deja installs, utiliser I'axe central de
I'ouverture du conduit.
sommet d_ dosseret
75,9cm (297/8 po)
91,1 cm (35 7/88 po)
106,4 cm 41 7/8 po
6cm (47 7/8 po)
Hauteur da dosseret :
50,1 ¢m (19 23/32 po)
•99,1 cm (39 po)
9,5 _rll
(3iS psi
25,4 mm (1 po)_
® Pour une d@harge par I'arriere/horizontabment, sile
circuit d'evacuation n'est pas installs, tracer et decouper
maintenant I'ouverture de passage du conduit.
® Important :Si un dosseret doit _tre utilise (option), on
doit I'installer avant la botts.
Si aucun dosseret n'est utilise, passer a I'etape 5.
Installation du dosseret : (Set ensemble comporte 4
chevilles de plastique pour I'ancrage mural, et 4 vis de
montage.)
,La hauteur du dosseret determinera la hauteur de la hotte.
Note : La hauteur minimale de la hotte au-dessus de la
table de cuisson est de 76,2 cm (30 po) (voir page 3). Le
dosseret pout _tre prolongs de 50,1 cm (19 23/32 po)
99,1 cm (39 po). Note : L'augmentation de la hauteur de
76,2 cm (30 po) s'accompagne d'une diminution de
I'aire de capture de la hotte. 5

oDeterminerHahauteurdqnstaHHation
deHahotte.
oPositionnerHahottecentreHetouren
faisantcoinciderHeherdinfedeurde
HahotteavecHesommetdudosseret.
MarquerHapositiondesquatretrous
desangHes.OnrecommandequeHe
dosseretsoitfixeautourdansHes
quatreangHes;cependantonpeut
aussinepaspHacerHesvisdes
angHesinf6rieursetcallerHaH_,vre
inf6rieureentreHetouretun
dosseretexistant,HepHandetravail
ouHepHacardinfedeur.
oPercerdestrousde8mm(5/16po).
oEnfoncercompHetementHescheviHHes
depHastiquedansHestrous.
oFairecounciderHestrousdu
dosseretavecHescheviHHes
d'ancrageetinstaHHerHesvisde
fixationfournies.
Ouvertures pour conduit d'evacuation et c ble electrique
2,9 cm
1/8 po).
Ouverture pour 6 em
e&ble eleetdque (9 11/16 po)
hotte de 76,2 cm (30 po)
hotte de 91,4 cm (36 po)
hotte de 106,7 cm (42 po)
7,5 em
(2 7/8 po)
7,5 em
(2 7/8 po) Diruensions des ouvertures
de deebarge 8,3 × 25,4 em
(3 1/4 x 10 po)
15,5 cm
(6 3/32 po}
15,5 cm ,
(6 3/32 po} i
_ uverture pour
e&ble e_eetdque
¢
29,7 em
(10 1/2 po)
7,5 em
(2 7/8 po)
hotte de 121,9 cm (48 po)
® La hotte doit _tre fixee au tour
avec [es vis de montage
conformement aux indications de
['iHHustration.[[ y a deux vis de
montage pour [es modeHesde 76,2 cm
(30 po) et 91,4 cm (36 po). [[ y a
quatre vis de montage pour [es
mod_Hesde 106,7cm (42 po) et 121,9
cm (48 po).Visser chaque vis
horizonta[ement dans [e tour jusqu'a
ce que HatSte de vis soit bien serree
centre Hetour.
Note : Lesvie de fixation de }a hotte
doivent _tre viss_es darts du bois
massif. Ne pas visser darts }e panneau
de gypse seulement.
eommet de
la hotte
17,5 em 121,9 em (48 pc)
(11/16 pc) au-dessus de {a
table de euissen
76,2 cm (30 po)hotte de
aommet de
la hotte
39,5 em 39,5 cm
\\ 1(159/16 po},(15 9/16 PN
17,5 em 121,9 em (48 po)
(1 1/16 po) au-dessus de {a
table de euisson
hotte de 91,4 cm (38 po) J_
sommet de
{a hotte
,\ 47,2 em 47,2 em
,
17,5em 10,8em
16,8 em
(11/16 pc) (41/4 pc)
(4-1/4 po)
121,9 em (48 po)
au dessus de }a
hotte de 106,7em (42 po) tab{e de euisson
semmet de
la hotte 54,9 em 54,9 em
17,5 em 17,9 em 17,8 em
(1-1/16 po) (7 po) (7 po)
121,9 em (48 po)
au dessus de la
table de euissen
hotte de 121,9 era (48 po) j,
T
5C1_. Installation de la garniture
cache-conduit (option) : PHacerHa
garniture au sommet de Hahotte; fixer
avec Hesvis fournies. La garniture doit
_tre fixee au sommet de Hahotte avant
H'instaHHationde Hahotte sur Hetour.
-E:z_:_...... 4- ---__.... _2:mm- --
T i\ /i
27,9 cm _ _ _ sommet
(11 po) \/de la hotte
,_ brides de montage /
--h"................ I
A
hotte 76,2 cm (30 po) :34,2 cm (13 15/32 po)
hotte 91,4 cm (36 po) :41,8 cm (16 15/32 po)
hotte 106,7 cm (42 po) : 49,4 cm (19 15/32 po)
hotte 121,9 cm (48 po) : 57,1 cm (22 15/32 po)
B
hotte 76,2 cm (30 po) :68,4 cm (26 15/16 po)
hotte 91,4 cm (36 po) :83,7 cm (32 15/16 po)
hotte 106,7 cm (42 po) : 98,9 cm (38 15/16 po)
hotte 121,9 cm (48 po) : 114,1 cm (44 15/16 po)
HnstaHHerchaque bride sur Hetour semen
H'iHHustration.Vei}ier ace que }es brides
soient sotidement flxees sur le m_r.
}nstaller seulement tes bddes. Ne pas
installer }a hotte.
b. Utiiiaation d'une extension
de cheminee : Fixer Hesbrides de
H'extension seHonH'iHHustration.
27 cm plafond
i i brides
20,6 cm h4 _ 20,6 cm
(8 1/8 po) --' ' (8 1/8 po)
58,4 cm (23 po) max.
30,5 cm (12 po) rain, sommet de {a hotte
VeiHer ace que }es vis soient
solidement fixees darts }e mur.
Tracer et decouper H'ouverture
necessaire dans Hetour pour He
conduit d'evacuation. HnstaHHerHe
circuit de decharge avant Hahotte. Voir
Hesconfigurations de decharge a Ha
page 4.Voir a Hapage 6 Hes
dimensions des ouvertures de sortie.

,, D6terminerHahauteurappropd6e
pour['orificedepassageduc&bHe
d'aUimentation;perceruntroude32
mm(11/4po)acetendroit.Faire
passerUec&bUeatraversUetrouseUon
UesprescriptionsduCodenationaUdes
instaUUations6Uectriquesou de Ua
norme CSA, ou des codes ou
regUements Uocauxen vigueur. La
Uongueurdu c&bUedevra _tre
suffisante pour qu'iUsoit possibUede
reaUiserUesconnexions adequates
dans Uabo]te de connexion de Uahotte.
Assurer H'6tanch6it6 avec un produit
de cdfeutrage au niveau de chaque
ouverture.
Ne pas mettre le circuit seus tension
avant d'avoir acheve t'installation.
. Oter Hecouverde de Habo]te de
connexion de Hahotte./_, H'aided'un
tournevis _ lame plate, arracher
H'opercuHede H'orificede passage du
c_bHed'dimentation. Installer un
connecteur de conduit dans cette
ouverture; Havis de bridage du
connecteur de conduit doit 6tre
Hnt6rieur de Hahotte.
Danger - poids excessif
Deux personnes ou plus doivent
intervenir pour d_placer et
installer la hotte.
Le non-respect de cette
instruction peut causer une
blessuce au dos ou d'autres
blessutes.
9m Si aucun voHetde regHagen'est
associ6 a Habouche de decharge
(muraHeou sur Hetoit}, installer He
voHetde regHagedans H'ouverture de
decharge au sommet de Hahotte, avec
deux vis Phillips.
lore Si on doit raccorder Hahotte
de 121,9cm (48 po} _ un conduit
d'evacuation de 25,4 cm (10 po},
installer maintenant Heraccord de
transition.
hotte is de
montage
La hotte de 76,2 cm (30 po} eompocte
deu× ttingles,
La hotte de 91,4 em (36 po) comporte
deu× tringles,
La hotte de 106,7 am (42 po} comporte
quatre tringles,
La hotte de 121,9 cm (48 po} comporte
quatre tringles,
11m La hotte se fixe au tour au
moyen des vis mentionnees a I'etape
5 des instructions d'installation. La
hotte est suspendue aces vis par des
tringles a I'int6rieur de la hotte de la
cuisiniere. Avant d'essayer de
suspendre la hotte, utiliser un
tournevis Phillips pour tourner la vis
d'ajustement marqueeVl dans le
sens antihoraire pour deployer les
tringles de la hotte.
Suspendre la hotte de la cuisiniere en
inserant les tringles darts les vis de
montage tel qu'illustre. Remarque :
Ces vis doivent 6tre install6es darts
du bois massif pour supporter le
poids de la hotte tel que decrit a I'eo
tape 5. Visser les vis marqu6es V1
pour serrer la hotte contre le tour.
S'assurer que Jahotte est fixee
aotidement au tour.
2 m On utiHise_gaHementHes
brides pour regHerH'apHombde Ha
hotte. Pour HeregHagede H'apHomb,
faire tourner HesvisV2 (vis Phillips}.
m Raccorder Heconduit
d'evacuation a Hahotte. Assurer
H'_tancheit_des jointures avec du
ruban adhesif pour conduit.
4 mSi Hagarniture cache-conduit
(option) est utiHisee,ajuster HesHevresde
Hagarniture sur Habride. Si H'extension
de cheminee est utiHisee,ajuster
H'extensionsur Hesbrides. Assurer
H'etancheiteentre extension et hotte
avec du ruban adhesif pour conduit.
Raccordement au
ceseau electcique
Risque de choc _lectcique
Interrompre I'a!imentation
_lectrique avant d'effectuer des
raccocdements.
Connecter le conducteur de
liaison a la terre avec la vis verte
darts la bo_te de connexion.
Le non-respect de ces
instructions peut provoquer un
choc _lectrique ou un accident
mortel.
5,, Execution des
raccordements eHectriques
[_ Hntroduire Hec_bHed'dimentation
dans Habolte de connexion
travers Heconnecteur de conduit
(homoHogation UL ou CSA}.
[_ Raccorder ensemble avec un
connecteur de ills Heconducteur
blanc du c_bHed'dimentation et He
conducteur blanc de Hahotte;
raccorder ensemble avec un
connecteur de ills Heconducteur
noir du c_bHed'dimentation et He
conducteur noir de Hahotte.
[_ Connecter sous Havis verte He
conducteur vert du cSbHe
d'aHimentation, utiHisepour Ha
liaison a Haterre.
[_ Serrer Hesvis de bridage du
connecteur de conduit.
[_ ReinstaHHerHecouverde de Habo_te
de connexion.

6,, Instalbrbsflltres.
oSortirlesflltresdelaboiteetenbver
Ispellicubdeprotectionblanchedes
filtres.
Note:LorsdeHnstdlafiondufiltre,
firer/fairetournerb boutonavecune
main,ettenirlefiltreenplaceavec
I'autremainpourquqlnetombepas
surlatabbdecubson.
oSaisirI'undesfiltresdetellesorte
queleboutonsoitodenteversb bas
etversI'ard_,redeIshotte.
oInsererI'extremitedufiltrenecom-
portantpasb boutondansIsrainure
deretenueaI'avantdeIshotte.
oTirersurleboutonetletournervers
Isgauche(sensantihoraire)detelle
sortequelelevierdeverrouillagene
fassepassailliehorsdufiltre.
oIns6rerI'extr6mit6comportantlebou-
tondansIsrainurederetenueaI'ar-
rieredeIshotte.
oTournerb boutonversIsdroite(sens
horaire)pourverrouilbrlefiltreen
place.
oRepeterIsprocedurepourbsautres
filtres.
Contr61e du
7,, Mettre la hotte sous tension.
Les commandes de Is hotte
sont plac6es sous Is hotte, a droite.
9,, Contr61erlebon
fonctionnement de la hotte.
[_ Placer I'interrupteur d'eclairage
la position _ 1 ));la lampe doit
s'allumer.
[_ Placer le commutateur du
ventilateur a la position _ 1 ));le
ventilateur doit se mettre en
marche.
[_ Placer le bouton de selecteur de
vitesse a la position, 1 _ (basse
E3
vitesset, puis a la position _ 2 _
(vitesse moyenne), pub a la
position _ 3 )) (haute vitesse).
Placer les commutateurs
d'@lairage et du ventilateur a la
position _ 0 )) pour commander
I'arr6t du ventilateur et I'extinction
de la lampe.
Si les composants de la hotte ne
fonctionnent pas correctement,
[_ Determiner si le circuit
d'alimentation de la hotte est
alimente (disjoncteur ouvert ou
fusible grill6?).
[_ Deconnecter la hotte du circuit
d'alimentation. Verifier que le
c&blage a ete correctement realis&
Pour obtenir la plus grande
effieaeke de eette nouveHe
hotte, lire la section
_ Uti_isation et d'entretien _,
Conserver en lieu s_r les
instructions d'instaHation et le
Guide d'utilisation et entretien
KitehenAid, pour pouvoir
faeilement les consuker,
AVERTISSEMENT - Pour reduire le
risque d'incendie ou de choc
electrique, ne pas utiliser ce
ventilateur en conjonction avec un
dispositif de r6glage de la vitesse
semi-conducteurs.
AVERTISSEMENT- POUR MINIMISER
LEERISQUE DqNCENDIE, CHOC
ELECTRIQUEOU DOMMAGES
CORPORELS,RESPECTERLES
iNSTRUCTIONS SUIVANTES :
Utiliser cet appareil uniquement de la
maniere pr6vue par le fabricant. Pour
toute question, contacter le fabricanL
Avant d'entreprendre des operations
de r@aration ou nettoyage de I'ap-
pareil, interrompre I'alimentation elec-
trique au niveau du tableau de distrib-
ution et verrouiller le disjoncteur pour
emp6cher un retablissement acciden-
tel de I'alimentation. S'il n'est pas
possible de verrouiller le disjoncteur
ou autre coupe-circuit, veiller a bien
fixer sur le tableau de distribution une
etiquette proeminente interdisant le
retablissement de I'alimentation.
MISE EN GARDE : Cet appareil est
concu uniquement pour la ventilation
genersle. Ne pas I'utiliser pour
I'extraction de mati6res ou vapeurs
dangereuses ou explosives.
AVERTISSEMENT- POUR MINIMISER
LE RISQUE D'UN FEU DEGRAISSE
SUR LATABLE DECUISSON :
Ne jamais laisser un element de la
table de cuisson fonctionner sans sur-
veillance a la puissance de chauffage
maximale; un renversement/d6borde-
ment de matiere graisseuse pourrait
provoquer une inflammation et le
g,_neration de fumee.
Utiliser toujours une puissance de
chauffage moyenne ou basse pour le
chauffage d'huile.
Veiller a toujours faire fonctionner le
ventilateur de ia hotte iors d'une cuis-
son avec une puissance de chauffage
elevee ou Iors de Is cuisson d'un mets
fiamber.
Nettoyer frequemment les ventila o
teurs d'extraction. Veiller a ne pas
laisser de la graisse s'accumuler sur
les surfaces du ventilateur ou des fil-
tres.
Utiliser toujours un ustensile de taille
appropriee. Utiliser toujours un usteno
sile de taille adapte a la taille de I'eleo
ment chauffant.
AVERTISSEMENT°POUR REDUIRELE
RISQUEDE D,OMMAGES CORPORELS
APRESLE DECLENCHEMENT D'UN
FEU DE GRAISSE SUR LA
CUI%NIERE,APPLIQUERLES
RECOMMANDATIONS SUIVANTES :
Placer sur le r@ipient un couvercle
bien ajuste, une t61e a biscuits ou
un plateau metallique POUR
ETOUFFERLES FLAMMES, puis
eteindre le br_leur. VEILLERA
EVFER LES BRULURES.Si les
flammes ne s'eteignent pas
immediatement, EVACUERLA
PIECEET CONTACTERLES
POMPIERS.
N.EJAMAIS PRENDREEN MAiN UN
RECIPIENTENFLAMME - le risque
de brQlure est elev&
NE PAS UTILISERD'EAU ni un
torchon humide- ceci pourrait
provoquer une explosion de vapeur
brQlante. Utiliser un extincteur
SEULEMENT si :
II s'agit d'un extincteur de classe
ABC, dont on connait le
fonctionnement.
II s'agit d'un petit feu encore limite
I'endroit ou ii s'est deciar&
Les pompiers ont 6te contactes.
II est possible de garder le dos
orient6 vers une sortie pendant
I'op6ration de lutte contre le feu.
