KitchenAid KPWB100NP0 User manual

c2007 KITCHENAID
PRO LINE WAFFLE BAKER
MODELS:
7−07 Litho in U.S.A. (skr) Part No. 8204590 Rev. D
KPWB100PM0 (Pearl Metallic)
KPWB100NP0 (Nickel Pearl)
KPWB100OB0 (Onyx Black)

CONTROL PANEL PARTS
2
For Models: KPWB100_ _0
8204590
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10158016 Guide, Use & Care
8204590 Repair Parts List
8204592 Wiring Diagram
2 8211489 Lens, Led
3 8211487 Button, Power
4 8211486 Button, Start
5 8211485 Knob
6 8211490 Screw
7 8211508 Cover, Button
8 8211488 Bezel
9 8211514 Spring
10 8211513 Bracket, Knob
11 8211491 MCU PCB Assembly
12 8211493 Holder, PCB

CRADLE PARTS
3
For Models: KPWB100_ _0
8204590
Illus. Part
No. No. DESCRIPTION
1 8211494 Bracket
2 Base
8211496 Pearl Metallic
8212148 Nickel Pearl
W10157757 Onyx Black
3 8211492 Nameplate
4 8211495 Screw
5 8211505 Cover, Bottom
6 8211504 Cover, Spring
7 8211498 Clamp
8 Cap
8211497 Pearl Metallic
8212149 Nickel Pearl
W10157758 Onyx Black
9 8211499 Holder, Axle
10 8212256 Cord, Power
(Incl. Mov Board
and PCB)
11 8211503 Clamp, Cord
12 8211501 Foot
13 8211502 Screw
