Kitchener FP100 User manual

Instruction Manual
REV 01/09/18
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
Chicken Plucker

GENERAL SAFETY REGULATIONS
WARNING: The warnings, cautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions or situations that could occur. It
must be understood by the operator that common
sense and caution are factors that cannot be built into
this product, but must be supplied by the operator.
Please operate according to Operation Method and remain the proper operation
procedures before using. Please assemble and operate carefully, taking care
not to scratch skin. Please do not to put hands around the paddles to avoid any
possible hurt.
Please read instruction manual.
• Keep all lose clothing, away from moving parts when plucker is in use.
• Keep fingers and hair away from moving parts when plucker is in use.
• Turn plucker off before unplugging from outlet.
• Always unplug plucker when changing part on the plucker.
• Unplug when assembling or disassembling the unit.
• To keep supervision is necessary when any appliance is used near children.
• Never remove the unit when it is running.
• Do not disassemble the plucker or place anything in the plucker during
operation.
• Do not use the plucker if the power cord is broken. Please return the unit to
the customer service or the store where it was purchased.
• To protect against risk of electrical shock do not put (state specific part or
parts in question) in water or other liquid.
• Unplug the unit when not in use, before putting on or taking off parts, and
before cleaning.
• Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
electrical or mechanical adjustment.
• The use of attachments not recommended or sold by the manufacturer may
cause fire, electric shock or injury.
• Do not let cord hang over edge of table or counter.
• SAVE THESE INSTRUCTIONS

INTRODUCTION
Thank you and congratulations on purchasing a KITCHENER Chicken Plucker. Your plucker
comes complete with everything you need to safely and easily plucking feathers. Please take a
few minutes to read through this manual before installation and use.
Your chicken plucker is made of the finest materials to ensure extended use for all of your
de-feathering processing needs. Your plucker will provide many years of service upon your
care and proper operation.
TECHNICAL DETAILS
BEFORE USE
1. Read and follow all instructions in the manual and on the unit before starting.
2. Dress appropriately when operating the machine.
3. Removing all packing grease and oil from the surfaces.
4. Dry all parts before re-assemble.
5. Keep packing material for future storage of plucker.
6. Do not allow children to operate this machine.
Item No.
Power Type
Wheels Included
Rotational Speed (RPM)
Fingers
Box Dimensions(IN)
Assembled Dimensions(IN)
Voltage(V)
Wattage(W)
Rated current(A)
Gross Weight(LB)
Net Weight(LB)
Removable Tub
Drive Type
Finish
Primary Materials
Hardware Material
Hardware Finish
Water Resistant
Corrosion Resistant
UV Persistent
Antimicrobial
Auto power off protection
Safety Stop Feature
Outdoor Use
Commercial Use
Pieces included
FP100
Electric
Yes, 2
280
92
21.3x21.3x20.5
24.8x24.8x33.5
AC120V
1.2HP
2.6
68
64
Yes
Planetary gears
Brushed Stainless steel
Stainless steel
Carbon steel
Spray paint
IP54
Yes
Yes
Yes
Yes
Yes
Yes
No
PIECES INCLUDED
(1) TUB,
(1) FEATHERPLATE,
(1) SET HARDWARE,
(1) DRIVE ASSEMBLY,
(3) LEGS,(1) MANUAL
E1
TECHNICAL
DETAILS
BEFORE USE
ASSEMBLY
INSTRUCTIONS
AFTER USE
TROUBLE
SHOOTING
EXPLODED
AND PARTS LIST
Capacidad: 3/8"x50ft.(10x15m)
Presión de trabajo: 300psi/20bar
ENROLLADOR
HRP-1015N
NUNCA EXCEDA LA PRESIÓN MÁXIMA DE TRABAJO.
SUJETE LA MANGUERA MIENTRAS SE RECOGE.
Size:100.5 x77.28 mm REV 01/09/18
3.03.01.4148PVC覆亚膜+油性胶

E2
TECHNICAL
DETAILS
BEFORE USE
ASSEMBLY
INSTRUCTIONS
AFTER USE
TROUBLE
SHOOTING
EXPLODED
AND PARTS LIST
ASSEMBLY INSTRUCTIONS
1. Follow the instruction, install part #16, part #14, and part #10, align the M8 bolts part #17
and part #18 with threaded holes and screw them tightly.
2. Follow the instruction, install part #23 feather plate, then install part #29 through into part
#27 to lock the feather plate.
Flat washer (Part #27)
Feather plate (Part #23)
M8 bolt (Part #29)
Right leg with wheel (Part #14)
Leg (Part #16)
Left leg with wheel (Part #10)
Bolt 2 (Part #17)
Nut 1 (Part #18)

3. Please install the tub to the bottom plate according to the arrow direction, make the two
arrows be directed at each other, so that the proximity switch activated. Lock the tub and
fasten gourd buckle.
PLUCKING INSTRUCTIONS
1. Make sure all safety features are operational, including the power switch and proximity
switch.
2. Check that all nuts and bolts are secure.
NOTE: All hardware (nuts, bolts, etc) should be checked for tightness before each use.
Vibration of machine can cause them to loosen.
3. Keep electrical connections out of areas where water can pool.
4. Each time the chicken plucker is plugged in, you must press the reset button on the leakage
protector. The machine will not start without this step.
5. Put the bird into scalding water should be approximately 65 degrees Centigrade (140-150
degrees Fahrenheit), plunging the bird in and out of the water for about 1 minute. When the
bigger feather on wings can be pulled out easily by hand.
6. Recommend to mix the soap with scald water to make the oil on birds’ feathers easily broken
down, which allows the hot water to penetrate to birds skin.
7. Press the start button on power switch and put the birds into the plucker.
8. Drop the bird into plucker and let machine process until feathers are removed. A properly
scalded bird will pluck in about 15-30 seconds.
9. Turn off the chicken plucker when finished.
NOTE: Do NOT retrieve bird unless unit has come to a complete stop.
E3
TECHNICAL
DETAILS
BEFORE USE
ASSEMBLY
INSTRUCTIONS
AFTER USE
TROUBLE
SHOOTING
EXPLODED
AND PARTS LIST
Tub
Buckle
38mm Finger
Direct at each other

E4
TECHNICAL
DETAILS
BEFORE USE
ASSEMBLY
INSTRUCTIONS
AFTER USE
TROUBLE
SHOOTING
EXPLODED
AND PARTS LIST
AFTER USE
1. Turn off the machine, unplug before removing foreign matters.
2. Keep hands out of feather chute.
3. Disassemble all parts and wash thoroughly in soapy water.
4. You must remove all foreign material from all appliance parts.
5.
Do not use bleach or chlorine based chemicals to clean. Discoloration of plastic parts can
occur.
6. Wipe down all non stainless steel parts with a food grade spray. Alternatively, wipe down
with a salad oil to keep from rusting.
7. Do not immerse motor housing in water. Damage to motor can occur.
8. It is best to keep the unit stored indoors or covered, not exposed to water and sunlight.
WARNING: KEEP HANDS OUT OF FEATHER CHUTE. DO NOT ATTEMPT TO
CLEAR FEATHERS OR OTHER DEBRIS FROM FEATHER CHUTE WITH THE UNIT
PLUGGED IN. UNPLUG THE UNIT BEFORE CLEANING OR REMOVING FOREIGN
MATTER, SUCH AS BIRD HEADS, FROM THE PLUCKER.
TROUBLE-SHOOTING
Problems
Unit stop suddenly while working
Unit not start when press power
switch
Solutions
Press the over-current protector button (Part #8), and press power
switch on the motor (Part #13), to see if the unit works.
If not, please unplug the unit and re-plug it 10 seconds later. Press
the reset button on leakage protector (Part #7) and power switch on
the motor (Part #13).
Press the reset button on leakage protector (Part #7) everytime when
you plug in the unit.

E5
TECHNICAL
DETAILS
BEFORE USE
ASSEMBLY
INSTRUCTIONS
AFTER USE
TROUBLE
SHOOTING
EXPLODED
AND PARTS LIST
EXPLODED AND PARTS LIST
Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Qty.
4
1
4
1
1
1
1
1
2
1
2
2
1
1
3
Description
Buckle clamp
Reducer
Screw 2
Botten plate
Flat key
Wire nail
Leakage protector
Over-current protector
Clevis pin
Left leg with wheel
Flat washer
Wheels
Power Switch on Motor
Right leg with wheel
Plug of square tube
Part No.
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Qty.
1
6
6
1
4
1
4
1
1
1
2
1
1
1
4
Description
Leg
Bolt 2
Nut 1
Motor assembly
Screw 1
Proximity switch
Assy feather pan
Feather plate
Washer
Magnet
Nut 2
Flat washer
Tub
Bolt 1
Screw 3
