Kitchensource 5411-76 User manual

IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
Home Styles ConsumerAssistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Hardware List
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
Spring Washer
60 Pcs. (+1 extra)
Flat Washer
60 Pcs. (+1 extra)
Wood Screw
8 Pcs. (+1 extra)
Metal Bracket
2 Pcs.
88 5411 76
Cabin Creek Storage
Multi Function Shelf
A.
Top
1 Pc.
F.
Front Rail
1 Pc.
G.
Shelf
2 Pcs.
H.
Base
2 Pcs.
Tools recommended for assembly : Level
B.
Side Frame
1 Pc.
I.
Back Frame
1 Pc.
D.
Side Frame
1 Pc.
K.
Back Frame
1 Pc.
C.
Side Frame
1 Pc.
J.
Back Frame
1 Pc.
E.
Side Frame
1 Pc.
L.
Back Frame
1 Pc.
Head Cap Bolt (short)
50 Pcs. (+1 extra) Head Cap Bolt
for Metal Bracket
8 Pcs. (+1 extra)
Head Cap Bolt
for Back Frame
4 Pcs. (+1 extra)
Head Cap Bolt (long)
2 Pcs. (+1 extra)

Assembly Instructions 2
IMPORTANT
* Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Do not tighten up all the screws until each part is properly assembled.
* Use a soft cloth between these parts and the floor.
STEP 2
Attach Back Frame (I) and (J) in Step 1,
Front Rail (F) and Shelf (G) to Side Frame (B) with
Head Cap Bolts (short), Spring Washers and Flat Washers.
Attach Side Frame (C) to unit with
Head Cap Bolts (short), Spring Washers and Flat Washers.
B
I
B
I
B
G
B
KB
L
B
F
B
J
B
J
B
B
B
C
Head Cap Bolt (short)
Spring Washer
Flat Washer
STEP 1
Attach Back Frame (J) to Back Frame (I)
with Head Cap Bolts (short),
Spring Washers and Flat Washers.
(see Figure 1)
Attach Back Frame (L) to Back Frame (K)
with Head Cap Bolts (short),
Spring Washers and Flat Washers.
Figure 1
/4

Assembly Instructions 3
STEP 3
Place Top (A) upside down on a soft cloth.
Attach unit to Top (A) with Head Cap Bolts
(long), Spring Washers, Flat Washers and
Wood Screws.
STEP 4
Attach Back Frame (K)
and (L) from Step1,
Bases (H) and
Shelf (G) to
Side Frame (D)
with Head Cap Bolts (short),
Spring Washers and Flat Washers.
Attach Side Frame (E) to unit with
Head Cap Bolts (short), Spring Washers and Flat Washers.
Attach the Metal Brackets to unit with Head Cap Bolts for Metal Bracket,
Spring Washers and Flat Washers.
B
A
B
H
B
E
B
G
B
H
/4
Head Cap Bolt (long)
Spring Washer
Flat Washer
Wood Screw
Metal Bracket
Flat Washer
Spring Washer
Head Cap Bolt
for Metal Bracket
B
K
B
L
B
D

Assembly Instructions 4
Figure 2
STEP 5
Turn the unit to its’ upright position.
Place unit from Step 3 onto
unit from Step 4.
Attach the units together with
Head Cap Bolts (short),
Head Cap Bolts for Back Frame,
Spring Washers and Flat Washers.
To the level the unit, adjust
the adjustable levelers on the
bottom of leg. (See figure 2)
/4
Head Cap Bolt
for Back Frame
