Product Specification
Name: High-voltage DMX controller with LCD display
Model: DMX300
I. Summarization
High-voltage DMX controller with LCD display is a kind of controller with LCD digital
display interface, used for control the RGB color change of 4 line 3 channels(common
anode) LED lamps, up to 34kinds of change programs to choose, at the same time can
accept DMX-512 international standard digital control. Controller can be stand-alone
operation, automatically online, accept standard DMX512 console control signal etc.
method to work. According to the customer's actual demand, can achieve jumpy changing,
gradual changing, stroboscopic such change effect.
II. Technical Parameters
● Working temperature: -20-60℃
● Power supply voltage: AC 100～240V 50/60HZ
● Output voltage: DC 100～240V
● Output connect way: common anode 4 line 3 channels
● External dimension: L203ΧW134ΧH50 mm
● Packing size: L310ΧW170ΧH60 mm
● Net weight: 0.77kg
● Gross weight: 1.22kg
● Static power consumption: <3.96W
● Maximum output current: 3*2A
● Dimming frequence: 800Hz
● Maximum output power: 660W(input voltage 110V), 1320W（input voltage 220V）

www.KiwiLighting.com BY-CON-DMX300
https://www.kiwilighting.com/dmx300-high-voltage-led-controller-common-anode-3-channel-2a-ch
Page 2of 6
III. External Dimension
IV. Interface instruction:
①power supply interface: input AC100～240V
②Insurance block: when short circuit, can protect the whole circuit
③Switch: control whole controller power on/off
④,⑤DMX512 signal input/output interface: interface sequence and detailed see below picture
⑥Load output interface: load output, interface detail instruction see below picture.

www.KiwiLighting.com BY-CON-DMX300
https://www.kiwilighting.com/dmx300-high-voltage-led-controller-common-anode-3-channel-2a-ch
Page 3of 6
+——Load
common positive pole
R——Load red output pole
G——Load green output pole
B——Load blue output pole
V. Product packing schematic diagram
VI. Direction for use
1. Connect the load wire at first, following by the power wire; Please ensure short circuit
can not occur between connecting wire before you turn on the power.
Controller have 4 function setting key: MODE, PARA, UP, DOWN.
2. MODE key choose in turn or press UP, DOWN key to choose:
No.
Display content
Instruction
0
BLACK
Static black
1
STATIC RED
Static red
2
STATIC GREEN
Static green
3
STATIC BLUE
Static blue
4
STATIC YELLOW
Static yellow
5
STATIC PURPLE
Static purple
6
STATIC CYAN
Static cyan
7
STATIC WHITE
Static white
8
COLOR CHANGE
Seven color jumpy changing
9
COLOR CHANGE2
Jumpy changing (flicker)
10
SIX COLOR CHANGE
Six color jumpy changing
11
SIX COLOR CHANGE2
Jumpy changing (flicker)
12
RGB CHANGE
Three color jumpy changing
13
RGB CHANGE2
Jumpy changing (flicker)
14
RG CHANGE
RG jumpy changing

www.KiwiLighting.com BY-CON-DMX300
https://www.kiwilighting.com/dmx300-high-voltage-led-controller-common-anode-3-channel-2a-ch
Page 4of 6
15
RB CHANGE
RB jumpy changing
16
GB CHANGE
GB jumpy changing
17
WHITE CHANGE
White stroboflash
18
COLOR SMOOTH
Seven color gradual changing
19
4 COLOR SMOOTH
Four color gradual changing
20
RG SMOOTH
RG gradual changing
21
RB SMOOTH
RB gradual changing
22
GB SMOOTH
GB gradual changing
23
COLOR GRADUAL
Seven color fade in and out
24
RGB GRADUAL
Three color fade in and out
25
WHITE GRADUAL
White fade in and out
26
RG GRADUAL
RG fade in and out
27
RB GRADUAL
RB fade in and out
28
GB GRADUAL
GB fade in and out
29
R GRADUAL
R fade in and out
30
G GRADUAL
G fade in and out
31
B GRADUAL
B fade in and out
32
ADJUST MODE
0-255 level adjusted color
33
AUTO PROGRAM
Auto operation selecting result of changing
34
DMX512 MODE
DMX512 control order
35
DMX512 DECODER
DMX512 decoder
3. Press PARA to adjust in turn: (1－8 is static state, do not have adjust function)
No.
Parameters display
Instruction
Maximum
Minimum
1
RUN SPEED
100
0
2
RUN TIMES
100
0
3
LOAD DEFAULT
Restore the factory parameter
4. UP: increase parameter key/preset parameter.
5. DOWN: decrease parameter/preset parameter.
6. AUTO PROGRAM mode is repeatedly cycle running part or all of 6-31 patterns run,you
can set whether participating in repeated cycle of operation or not in RUN TIMES.
7. RUN TIMES: compiling the run times of the pattern under 33 AUTO PROGRAM, if the
run times is 0, you can skip the pattern,that means not running the pattern.
8. Preset parameter: each form has independent factory preset parameter, which is kept
in controller separate. LOAD DEFAULT can recover the factory parameter of the form. If
under AUTO PROGRAM mode, using LOAD DEFAULT can unified recover the parameter
of all forms to factory parameter.
9. 32 ADJUST MODE is manual dimming, it can adjust the brightness of RGB 0-256 level
respectively.
10. 34 DMX512 MODE is controlling all patterns (the first address) and speed（the second
address).

www.KiwiLighting.com BY-CON-DMX300
https://www.kiwilighting.com/dmx300-high-voltage-led-controller-common-anode-3-channel-2a-ch
Page 5of 6
11. 35 DMX512 DECODER is DMX decoder, completely accepting outside DMX512
signal to work. Taking 4 addresses, R(the first address), G(the second address), B(the
third address), reserved channel(the fourth channel), in need of setting address（by
pressing PARA).
VII. Typical Applications
Typical application 1---do not have DMX function:
Typical application 2---with DMX function:
