MEDIUM DRAWER KIT
Instructions for SKUs: 478-3822, 478-3824
KIT INCLUDES:
Drawer support
bracket x1
478-9831
Drawer box x1
Bracket A x2
478-9804
Left glide x1
478-9810
Right glide x1
478-9811
1/4" x 1/2"
Euro screw x12
478-9835
Rail adapter x2
478-9829
Left top rail
x1
478-9824
Right top rail
x1
478-9825
Drawer box cover
cap x2
478-9830
Bumper x2
478-9833
3/16" x 5/8"
Short screw x3
478-9803
3/16" x 1-3/16"
Long screw x1
478-9832
Drawer back
x1
To find all Klëarvue Cabinetry®installation instructions and installation videos, visit www.klearvuecabinetry.com.

2
STEP 1:
• Install bracket A (478-9804) to the back of the drawer front. Be sure that the tab of the bracket with the two holes is
facing toward the bottom of the drawer front, as pictured below.
• Line up the holes on the bracket with the pre-drilled holes on the drawer front and secure with the euro screws
(478-9835) as shown in the illustration.
• Using the euro screw (478-9835) secure the rail adapter (478-9829) to the drawer front. Ensure the opening in the
rail adapter is facing up toward the top of the drawer front as shown in the illustration.
STEP 2:
• Slide the drawer back into the slot at the back of the drawer until you hear a “click” on the left and right sides. You
may find that you need to push the metal drawer sides out to fit the back in square.
BRACKET A

3
STEP 3:
• Install the long screw (478-9832) through the back of the drawer box into the drawer bottom. This helps to add
stability to your drawer kit.
STEP 4:
• Attach the drawer front to the drawer box by lining up the brackets with the slots in the drawer box. Push until you
hear a “click” on both the left and right side. If the drawer front does not “click” into place, verify that the spring
loaded latch is in the open position by placing a Phillips screwdriver into the drawer removal hole and turning
towards the back of the drawer. See page 7 for drawer front removal.

4
STEP 6:
• Insert the cylinder end of the side rail into the opening of the rail adapter. If the cylinder does not perfectly line up
with the opening of the rail adapter, you can adjust how far the cylinder protrudes by rotating it with your finder.
Slide the square cover towards the drawer front to hide the cylinder and rail adapter.
• If the cylinder is too tight to rotate, remove the square cover to allow a better grip.
STEP 5:
• Line up the back of the side rail (478-9824/478-9825) with the back of the drawer. To attach the side rail and
drawer together, push into place.

5
STEP 8:
• Use a Phillips screwdriver and the three short screws (478-9803) to fasten the bracket to the drawer bottom.
STEP 7:
• Turn the drawer box upside down and mark the center of the drawer front.
• Use a center punch to make an indent within the three moulded holes on the bracket as shown in the illustration.

6
STEP 9:
• For the installation location of the drawer glides, reference the “Drawer Configuration Guide” that was packaged
with your drawer kit.
• Line up the holes of the glide (478-9810/478-9811) with the holes in the cabinet box and secure with euro screws
(478-9835).
• The drawer glides should be marked left (L) and right (R).
STEP 10:
• Fully extend both the left and right drawer glide.
• Align and set the drawer box onto the glides. The drawer box should be able to support itself.
• Quickly and firmly push the drawer into the cabinet box. You should hear a “click” noise as this action will
automatically attach the drawer box to the glides. If the drawer box does not “click”, repeat Step 10. You may not
have pushed the drawer glides hard enough.
• Drawer kits are rated to hold 70 lbs. of weight.
Quick, firm push

7
DRAWER ADJUSTMENT AND REMOVAL
ADJUSTMENT:
A1) Turn the metal adjustment
screw to adjust the drawer
front up and down.
A2) If the drawer is not adjusting
in position, turn the right
screw to unlock the hinge
and retry step A1.
B) Adjusting your drawer fronts to
the left and right can be a little
tricky. To make adjustments,
you will adjust the white
adjustment screw inward and
outward of your drawer kit by
using a Phillips screwdriver.
Protrude both adjustment
screws to the right to force the
drawer front to move to the
left. Protrude both adjustment
screws to the left to force the
drawer front to move to the
right.
REMOVAL:
C) To release the drawer box
from the drawer glides, begin
by placing your hands under
the center of the drawer front.
Be careful not to place hands
under the drawer glides. From
the closed position, use gentle
force to extend the drawer
completely out and then lift
upwards in one fluid motion.
D) To remove the drawer front,
use a Phillips screwdriver into
the hollowed-out location
(looks like a + symbol) and
rotate towards the back of the
drawer box until the bracket is
released. Repeat on both left
and right sides of the drawer.
Note: If the white screw on the
mounting bracket has been
adjusted and is protruding out,
you may need to un-adjust the
screw to remove or re-install
the drawer front.
B-left/right
adjustment
C- release the
drawer box
from the
glides
D- remove the
drawer front
A1 & A2-up/down
adjustment
A1 A2
