Klëarvue Cabinetry 478-3923 User manual

Sliding Base x1
Socket Head Screw x6
SS-10.1297
Handle x2
SS-10.1292
Basket Rack x1
Washer x6
SS-10.1298
Handle Screw x2
SS-10.1293
Exterior Basket x2
SS-10.1295
Basket Clip x10
SS-10.1294
Drill Template x1
SS-10.1291
Interior Basket x2
SS-10.1296
Mounting Screw x6
SS-10.1299
Hex Wrench x1
THISEDGE ON CABINET INTERIOR WALL
THIS SIDE UP
THISEDGE ON CABINET INTERIOR WALL
FORRIGHT HAND SWING DOOR
CABINET
OPENING
THISEDGE ON CABINET INTERIOR WALL
FORLEFT HAND SWING DOOR
CABINET
OPENING
SKU 478-3923
BLIND CORNER PULLOUT
SS-10.1291
DRILLTEMPLATE
FOR
17-15/16"16-9/16"
Instructions for SKU 478-3923
BLIND CORNER PULLOUT
KIT INCLUDES:
QUESTIONS?
Contact Customer Care
1-800-721-4191
Monday – Friday 8-5 Central Time
ADJACENT
BASE CABINET
ADJACENT
BASE CABINET
28-1/4"
18-3/4"
FILLER
BLIND CORNER
BASE CABINET
ADJACENT
BASE CABINET
EXTERIOR
BASKET
INTERIOR
BASKET
EXTERIOR
BASKET
INTERIOR
BASKET
ADJACENT
BASE CABINET
28-1/4"
FILLER
BLIND CORNER
BASE CABINET
WALL
WALL
18-3/4"
ADJACENT
BASE CABINET
ADJACENT
BASE CABINET
28-1/4"
18-3/4"
FILLER
BLIND CORNER
BASE CABINET
ADJACENT
BASE CABINET
EXTERIOR
BASKET
INTERIOR
BASKET
EXTERIOR
BASKET
INTERIOR
BASKET
ADJACENT
BASE CABINET
28-
1
/4"
FILLER
BLIND CORNER
BASE CABINET
WALL
WALL
18-3/4"
LEFT HAND SWING DOOR
RIGHT HAND SWING DOOR
IMPORTANT: Please read before you begin the blind corner pullout installation.
!
SIX PILOT HOLES
PILOT HOLES
Open Slots
STEP 1:
● Place the drill template (SS-10.1291) on the bottom of the cabinet so that the black arrows
are facing towards the opening and against the side of the cabinet as shown below.
● Using a 1/16"drill bit, drill a pilot hole at all six mounting locations on the template. Make sure
to not drill completely through the bottom of the cabinet.
● Remove the template from the cabinet.
To nd all Klëarvūe Cabinetry® installation instructions and installation videos, visit www.klearvuecabinetry.com
NOTE:
● Blind Corner Pullout (478-3923) is intended for use with the Klëarvūe Blind Corner Base
Cabinet (478-0079).
● Check the diagrams below for dimensions of the unit when opened. Make sure no island
cabinets or appliances will intrude in this space.
● Before installing the pullout, install the blind corner cabinet hinges (478-9838 included with
the cabinet box) to the cabinet. Do not install the door front until the blind corner pullout is
completely installed.
STEP 2:
● Remove four socket head screws (SS-10.1217) and washers (SS-10.1298) from the top plate on
the sliding base as shown below.
STEP 3:
● Place the sliding base on the bottom of the cabinet. Make sure the four open slots in the top
plate are on the same side as the cabinet opening.
● Attach the sliding base to the cabinet using the six mounting screws (SS-10.1299).

INSERTING CLIPS
ROTATING CLIPS
LEFT HAND SWING DOOR RIGHT HAND SWING DOOR
LEFT HAND SWING DOOR RIGHT HAND SWING DOOR
CHECK OPERATION
STEP 4:
● Place the basket rack on the top plate of the sliding base. Make sure the slides will open
outward from the cabinet.
● Using the included hex wrench, attach the basket rack to the sliding base with the washers
(SS-10.1298) and socket head screws (SS-10.1297).
STEP 5:
● Extend one sliding portion of the basket rack and attach one of the handles (SS-10.1292) to the
sliding portion using the provided handle screw (SS-10.1293).
● Close the sliding portion and attach the handle on the opposite side sliding portion in the same
manner.
STEP 6:
● On each side of the basket rack install a basket clip (SS-10.1294) into each of the bottom slots.
● Insert a basket clip into each bottom slot, then rotate each clip a quarter turn so that the hook is
facing upwards.
● On each side of the basket rack install basket clips in either the top slots, or the middle slots.
STEP 7:
● For left hand swing doors, exterior baskets are installed on the right side of the basket rack.
● For right hand swing doors, exterior baskets are installed on the left side of the basket rack.
● Install an exterior basket (SS-10.1295) onto the lower basket clips by inserting the top wire in
the basket into each hook. Make sure the clips are located on the exterior basket as shown in the
diagrams.
● Install an exterior basket onto the upper basket clips in the same manner.
● Pull the handle so that the baskets come out of the cabinet and slide the basket rack over to
expose the interior side of the basket rack.
STEP 8:
● Install an interior basket (SS-10.1295) onto the lower basket clips by inserting the top wire in
the basket into each hook. Make sure the clips are located on the interior basket as shown in the
diagram.
● Install an interior basket onto the upper basket clips in the same manner.
● Verify that the interior baskets will not collide with front interior cabinet wall when moving the
blind corner pullout to fully closed position.
● Verify that the exterior baskets will not collide with any adjacent installed cabinet door, including
pulls or handles when moving the blind corner pullout to fully open position.
● If any collisions occur, remove all baskets from the basket rack. Adjust the location of the basket
rack forward or back as required by loosening the socket head screws and sliding the basket rack.
● Re-tighten the socket head screws, reinstall the baskets, and recheck for collisions.
