Klëarvue Cabinetry BLIND CORNER User manual

1
®
BLIND CORNER
Instructions for Door Installation
KIT INCLUDES:
Bumper
x2
Mounting plate
x2
To find all Klëarvue Cabinetry®installation instructions and installation videos, visit www.klearvuecabinetry.com.
For use with blind
corner cabinets.
Blind corner hinge
x2
Cover cap
x2

2
STEP 1:
• Place the hinge cup into the pre-drilled hole on the back of the door front.
• Use a mallet to tap in the hinge to the door as shown in the illustration. Place a piece of cardboard between the
mallet and door as needed to protect the door finish. To secure, tighten the screws with a Phillips screwdriver.
STEP 2:
• Mounting plate for hinges will be installed on the back side of the cabinet next to the cabinet opening. Mounting
plates will install, horizontally, in the row of pre-drilled holes 2nd from the top and bottom.
• Line up the 2 screws horizontally with the pre-drilled cabinet box holes. Secure the base plate into place using a
Phillips screwdriver.
CLASP
HINGE CUP
DOOR FRONT

3
STEP 3:
• To attach your door front to the cabinet box, wrap and snap the hook on the hinge arm around the post of the
hinge mounting plate. Press the back of the hinge arm into the mounting plate clasp until you hear a “click”.
STEP 5:
• Attach the bumpers to the door back.
TOP VIEW
CLICK!
ROCK
FRONT TO
BACK AND
PUSH
DOOR FRONT DOOR FRONT
CABINET
BOX
CABINET
BOX
HOOK
POST
STEP 4:
• Attach the cover caps to the hinges by pressing firmly into place until you hear a “click”.
• Remove the cover caps from the hinges by gently pulling on the edge, as shown in the illustration.
CLICK!

4
DOOR ADJUSTMENT AND REMOVAL
ADJUSTMENT:
You may find that adjustment is needed with the
hinges to line up the door properly. Using a Phillips
screwdriver you can adjust the hinges in six
directions.
A) To adjust the door up and down in height, rotate
the same adjuster in the center of the mounting
plate as shown in the illustration.
B) To adjust the door in and out in depth, rotate the
same adjuster on the front of the mounting plate
as shown in the illustration.
C) To adjust the door left and right, rotate the
screw on the back of the mounting plate as
shown in the illustration.
You many have to make adjustments to both
hinges (top and bottom) on the door to see results.
REMOVAL:
To remove the door, press down on the base plate
clasp inside the cabinet box to release the door
hinge from the base plate. You may have to wiggle
the hinge slightly to remove it from the base plate.
To remove the hinge from the door, use a Phillips
screwdriver to loosen the hinge cup from the bore
hole.
C-left/right adjustment
A-up/down adjustment
B-in/out adjustment
