SHORTCUT Button
Used to restore the current settings or
resume previous settings.
On the first time connecting to the power,
if push the SHORTCUT button, the unit
will operate on AUTO mode, 26°C, and fan
speed is Auto.
Push this button when remote controller is
on, the system will automatically revert
back to the previous settings including
operating mode, setting temperature, fan
speed level and sleep feature(if activated).
If pushing more than 2 seconds, the system
will automatically restore the current
operation settings including operating mode,
setting temperature, fan speed level and
sleep feature (if activated).
SHORT
CUT

Swing Button
Used to stop or start vertical louver movement
and set the desired left/right air flow direction.
The vertical louver changes 6 degree in angle
for each press. And the temperature display
area of indoor unit displays ' ' , for one
second. If keep pushing more than 2 seconds,
the vertical louver swing feature is activated.
And the display area of indoor unit displays
' IIII ', flashes four times, then the temperature
setting reverts back. If the vertical louver
swing feature is stopped, it displays 'LC' and
remains on for 3 seconds.
NOTE: For some units , the indoor units
display 'ON' when the swing feature is
activated, and display 'OF' when the
swing feature is stopped.
Swing Button
Used to stop or start horizontal louver move-
ment or set the desired up/down air flow
direction. The louver changes 6 degree in
angle for each press. If keep pushing more
than 2 seconds, the louver will swing up and
down automatically.
SHORT
CUT

SHORT
CUT
SHORT
CUT

Adjusting air flow direction
Use the SWING & button to adjust
the desired airflow direction.
1. Up/Down direction can be adjusted with the
button on the remote controller. Each
time when you press the button, the louver
moves an angle of 6 degree. If pressing more
than 2 seconds the louver will swing up and
down automatically.
2. Left/Right direction can be adjusted with the
button on the remote controller. Each
time when you press the button, the louver
moves an angle of 6 degree. If pressing more
than 2 seconds the louver will swing up and
down automatically.
NOTE: When the louver swing or move to a
position which would affect the cooling
or heating effect of the air conditioner,
it would automatically change the
swing/moving direction.
