KLING & FREITAG CS5 User manual

KLING&FREITAGCS5
User’s Manual
Important Information,
Please Read before Use!
KLING &FREITAG GmbH
Junkersstrasse 14
D-30179 Hannover
TEL [phone]
FAX [phone]
www.kling-freitag.de

User Manual
KLING & FREITAG GMBH ©2001 2
Speaker System CS 5
Content
Sections Page
User Manual Symbols 2
Information about this User Manual 2
1. General Advice for using Loudspeakers 3
2. Wiring and Pinning 4
5. Specifications 5
4. Mending of Damages to the Paintwork / Exchange of the
Front Foam 6
User Manual Symbols
The following symbols serve to better orientate the user through the installation and assembly instructions, as well
as advice in relation to safety regulations:
This symbol gives advice on the possible dangers
caused by improper use during assembly and/or
service.

Here you can find information about applications,
assembly, operations and the setting up of the de-
scribed products.
Information about this User Manual
User Manual CS 5 Version 1.0 02/2001
© by Kling & Freitag GmbH, Januar 2001; all rights reserved
All specifications, relating to the described products and to the safety procedures given, which appear in this
manual are based on the information that was available at the time of going to press.
Technical specifications, dimensions, weights and properties do not represent guaranteed qualities.
The manufacturer reserves the right to make alterations and modifications within the framework of legal provi-
sions, as well as changes aimed at improving product quality.
Please keep these instructions safely, so that you can use them for future reference!
We are looking forward to receive your ideas and suggestions for the further improvement of this manual. We
would like to ask you to send them to us at the following address:
[e-mail] or:
KLING & FREITAG GMBH Junkersstr.14 D-30179 Hannover Phone +49 (0) 511 - 96 99 70 Fax +49 (0) 511 -
67 37 94
We would like to thank you that you have decided to use a Kling & Freitag product! Before
commencing, we would like to ask you to read this manual carefully to guarantee an undis-
turbed operation and for your Kling & Freitag – Loudspeaker System to develop its full capac-
ity.
With the purchase of the CS 5 , you have acquired a loudspeaker of highest quality and per-
formance.
As the owner of a CS 5-system, you now have a multi-functional and professional tool, which
- if operated correctly - will give you a lot of joy.
CS 5

User Manual
KLING & FREITAG GMBH ©2001 3
Speaker System CS 5
1. General Advice for Using Loudspeakers
Erection of the Loudspeakers
To ensure that the loudspeakers do not topple or fall and cause damage or injury, please always
take care to mount the loudspeakers securely.
At all times hang up the speakers on at least 2 of the 6 threads available. The same goes for the
lifting and setting up of the speakers.
Do not hang more than three loudspeakers on top of each other without using special Kling &
Freitag installation fittings.
Please check whether the installation connections comply with applicable safety guidelines and if
they are of an adequate size or strength. You will find information about this in our Installation
Fittings User Manual.
For both mobile and fixed installations, please use only assembly fittings provided by Kling &
Freitag. Make sure to observe the installation instructions and safety notes shown in the Installa-
tion Fittings User Manual.
Assembly fittings and loudspeakers should undergo regular visual checks. At any sign of wear,
fittings should be replaced immediately. Furthermore, all screwed connections should be checked
regularly.
Do not Install Loudspeakers in any of the Following Places:
- Where the speakers are permanently subjected to direct sunlight (with the exception of the
‘All Weather’ versions, which have been specially developed for outdoor usage).
- Where the loudspeakers are subjected to dampness (with the exception of the ‘All Weather’
and ‘Outdoor’ versions, provided the latter are not subjected to direct weather conditions).
- Where the loudspeakers are subjected to strong vibrations and dust.
Damage Caused by Magnetic Fields of the Loudspeakers
Loudspeakers are surrounded by a permanent magnetic field even when they are not connected
up. Therefore, please take care especially during transport and installation that a distance of 1m
away from magnetic data carriers and computer/video monitors is kept.
Protection of the Loudspeakers
For the selection of Power Amplifiers, it should be made sure that their dimensions are sufficient.
Power Amplifiers which have a too low power output can cause damages to the loudspeakers
through their overload (clipping).
Power Amplifiers should never be overloaded. Especially for Power Amplifiers with a nominal
power higher than that of the loudspeaker, overload may cause damages to the loudspeakers.
The following Signals may damage the Loudspeakers
- Permanent high-pitched signals with high frequency and continuous tone through feedback.
- Permanently distorted signals with high power.
- Noises that occur when an appliance is disconnected or switched on while the amplifier is on.
Advice on Protection Circuits
The CS 5 is equipped with protection curcuits for the 1“ tweeter as well as the crossover, which
interrupt the signal flow in the case of extreme overload. If the loudspeaker switches off, de-
crease the volume and after a few seconds the loudspeaker will automatically switch itself on
again.
Avoid Ear Damage
Please do not risk damaging your ears, by staying too close to operating speakers even if you feel
that the volume is low enough.

User Manual
KLING & FREITAG GMBH ©2001 4
Speaker System CS 5
2. Wiring and Pinning

Wiring:
If you use two or more speakers, please observe the correct +/- polarity of the loudspeakers at
the amplifiers in order to guarantee an even-phased and therefore balanced sound.
We recommend you use the supplied Kling & Freitag connection cables. In order to avoid loss of
performance, wire gauges should be of at least 2.5mm2, and longer cables should have an even
greater diameter. An acceptable wire gauge can be calculated using the following formula:
Length of Cable Necessary (m)__
Length of Cable Necessary (m)__Length of Cable Necessary (m)__
Length of Cable Necessary (m)__
2 x Loudspeaker Impedance (
2 x Loudspeaker Impedance (2 x Loudspeaker Impedance (
2 x Loudspeaker Impedance (Ω
ΩΩ
Ω)
))
)
Pinning:
The loudspeaker is equipped with a spring terminal. Red = + ; black = -
If several loudspeakers are connected, the signal can be linked through from one loudspeaker to
the next. Please make sure that the total impedance of the loudspeakers R (Ω) is not lower than
the minimal impedance indicated on the power amplifier.
(1/R1 + 1/R2 + 1/R3 + ... = 1/RTotal)
Recommended Wire Gauge (mm²) =
Recommended Wire Gauge (mm²) =Recommended Wire Gauge (mm²) =
Recommended Wire Gauge (mm²) =

User Manual
KLING & FREITAG GMBH ©2001 5
Speaker System CS 5
9. CS 5 Specifications
Technical Specifications CS 5
Principle 2-way passive system, bassreflex tuning
Frequency response -10 dB 60 Hz - 20 kHz
Frequency response ±=3 dB 82 Hz - 20 kHz
Nominal coverage angles 90°x 60° (hor. x vert.)
Directivity index (DI) 8 (+2/-2) 1,2 kHz - 13 kHz
Power handling (nom.) 50 Watts
Sensitivity 1 W/1 m 88 dB
Max SPL 112 dB (SPL peak/1 m)
Components 5" woofer
Polycarbon dome tweeter with phase correction plug
5” speaker is magnetic shielded
5” speaker is magnetic shielded5” speaker is magnetic shielded
5” speaker is magnetic shielded
Impedance 8 Ω
Connectors Spring terminal
Enclosure A.BS. Trapeziodal enclosure in black or white
6 x M6 thread insert, compatible with
multiple mounting accessories.
Removable front frame with black or grey fabric-covering
on synthetic front grille .
Dimensions 163 x 238 x 160 mm (W x H x D)
Weight 2,6kg
Weight 100 Volt Version 8,2kg
Options 100 Volt version, symetreic input integrated power amp
mounting and flying hardware,
