Klipsch REFERENCE Theater 5.0 User manual

REFERENCE Theater 5.0
Owner's Manual

ENGLISH
IMPORTANT SAFETY INSTRUCTIONS!
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do NOT install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. ONLY USE attachments/accessories specified by the manufacturer.
10. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
11. DO NOT expose this apparatus to dripping or splashing and ensure that no objects
filled with liquids, such as vases, are placed on the apparatus.
The exclamation point, within an equilateral triangle, is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
The lightning flash with arrowhead symbol within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electrical shock to persons.
WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture.
WARNING: No naked flame sources – such as candles – should be placed on the product.
EU COMPLIANCE INFORMATION:
Eligible to bear the CE mark, Conforms to European Union EMC Directive
2004/108/EC.
WEEE NOTICE
Note: This mark applies only to countries within the European Union (EU) and Norway.
This appliance is labeled in accordance with European Directive
2002/96/EC concerning waste electrical and electronic equipment
(WEEE). This label indicates that this product should not be disposed
of with household waste. It should be deposited at an appropriate
facility to enable recovery and recycling.
AMPLIFIER REQUIREMENTS
Klipsch speakers are highly efficient and will work well with a wide variety of am-
plifiers. Due to the high output levels, Klipsch speakers are capable of reproduc-
ing, exercise caution with the volume control. Excessive volume over long periods
of time can permanently damage your hearing. Overdriving your amplifier could
also damage your speakers. Check with your dealer to make sure your particular
amplifier is best suited to your application. We want you listening for a lifetime.
CONVENTIONAL CONNECTION
Using 18-gauge or larger speaker wire, connect the RED “positive” (+) terminal of
the LEFT speaker to the RED “positive” (+) terminal of your amplifier’s LEFT
channel. Connect the BLACK “negative” (-) terminal of the LEFT speaker to the
BLACK “negative” (-) terminal of your amplifier’s LEFT channel. Repeat this proce-
dure for connecting all remaining speakers to the appropriate amplifier channels.
Make sure no bare wires from any of the connections touch any other bare wires
or terminals as this could cause a short and damage your equipment.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this
equipment are hazardous to life. No user-serviceable parts inside.
Refer all servicing to qualified service personnel.
CENTER CHANNEL
CENTER CHANNEL
HANG EXPOSED HEADS
ON “KEYHOLES” HANG EXPOSED HEAD ON “KEYHOLE”
CENTER CHANNEL
SATELLITES
SATELLITES
SATELLITES
¼”, 20 THREAD BOLT¼”, 20 THREAD BOLTS
THREADED INSERT
INSIDE “KEYHOLES”
THREADED INSERT
INSIDE “KEYHOLE”
OR
INSPECTION
We want your new speaker system to look as good as it did leaving the
factory! Please check promptly for any transit damage. Carefully unpack
your new speaker system and verify the components against the packing
list. In extreme circumstances, items may have become damaged in transit.
If any damage is discovered, notify the delivery service and dealer where
the system was purchased. Make a request for inspection, and follow their
instructions for evaluation. Be sure to keep the product’s original shipping
carton.
CARE & CLEANING
Your speakers have a durable finish that should only require dry dusting or
cleaning with a dry cloth. Avoid the use of abrasive or solvent-based cleaners
and harsh detergents. The brush attachment of your vacuum should remove
any dust from your speaker grilles.
REGISTRATION
Register your product online at www.klipsch.com/register
• Keep up-to-date on new products and promotions.
• Your personal information will never be resold.
• This registration information is not used for warranty purposes.
Please retain your receipt for warranty claims.
Push down terminal, insert wire, release terminal.
SPEAKER WALL MOUNTING - OPTION 1
SPEAKER WALL MOUNTING - OPTION 2

Sub
Front
Left
Front
Right
Surround
Left
Surround
Right
Center
AV Receiver
Front
Left
Front
Right
Surround
Left
Surround
Right
Center
Terminal
Posts on
Speakers
SPEAKER PLACEMENT IN LISTENING AREA
A is ideal. B or combo A, B is acceptable.
Optional Rear
Placement
Optional Sub
Placement
Sub
CENTER PLACEMENT
SPEAKER WIRE HOOKUP
AV RECEIVER
Above
Below
TERMINAL
POSTS ON
SPEAKERS
FRONT
LEFT
FRONT
LEFT
FRONT
RIGHT
FRONT
RIGHT
CENTER
CENTER
SURROUND
LEFT
SURROUND
LEFT
SURROUND
RIGHT
SURROUND
RIGHT
SUB
