KLIPSCH AUDIO TECHNOLOGIES
R-25C Center Speaker Service Manual
Table of Contents
SPECIFICATIONS.........................................................................................................................2
R-25C SPECIFICATIONS...................................................................................................................2
EXPLODED VIEW AND WARRANTY PARTS LIST..............................................................3
R-25C EXPLODED VIEW AND WARRANTY PARTS LIST ..................................................................3
TROUBLESHOOTING GUIDELINES .......................................................................................4
TWEETER REMOVAL FOR R-25C....................................................................................................4
WOOFER REMOVAL FOR R-25C...................................................................................................11
Product Type: R-25C Center Speaker
Manual Part #: 1061500
Model Line: Reference
Product Launch Year: 2014
The information contained in this document is solely intended for service and repair of Klipsch Group, Inc product;
use of this information to mimic or copy KGI designs is strictly prohibited and subject to prosecution.

Service Manual –Consumer
2
Specifications
Model: R-25C

Service Manual –Consumer
3
Part Number
1061363
1061361
1061359
1012824
60445
Synergy III Rubber Bumper
R-25C Horn With Tweeter
R-25C Woofer
R-25C Grill With Logo
R-25C/ KC-25 Network W/ Input Cup
Warranty Replacement Parts
Parts Description
Exploded View and Warranty Parts List

Service Manual –Consumer
4
Tweeter Removal for R-25C
Tools needed:
Small flat blade screwdriver
3mm hex (Allen) key
First, with a small flat blade screwdriver, gently pry the up the trim ring around the tweeter,
highlighted in red
Be sure to pry the trim ring up in between the tweeter horn and the trim ring as shown below.
Prying between the trim ring and the cabinet may cause damage to the cabinet.
Pry slowly around the edge of the tweeter horn to release all the clips.

Service Manual –Consumer
5
Once the trim ring is removed the speaker should look as shown below.
Next, begin removing the screws (highlighted below in red) from the perimeter of the tweeter
horn.
There will be six (6) total screws to remove, each using a 3mm hex key head

Service Manual –Consumer
6

Service Manual –Consumer
7
Once all the screws have been removed, the tweeter and tweeter horn should come free as shown
below.

Service Manual –Consumer
8
Once the tweeter is removed from the cabinet, slide back the silicone covers on the terminals, and
use a small flat blade screw driver to release the wire clips holding to the positive and negative
terminals of the tweeter.

Service Manual –Consumer
9
Once the tweeter is removed, the speaker will look as shown below.

Service Manual –Consumer
10
Next, plug the wires on to the new tweeter, and slide
the silicone covers back over the terminals.
Place the tweeter back into position, and replace the
screws.
Replace the trim ring by setting into position and gently
pressing the trim ring around the edge, verifying the
clips on the back are locking into place. Once this is
done, the trim ring should sit flush with the front of
the speaker

Service Manual –Consumer
11
Troubleshooting Guides
Woofer Removal for R-25C
Tools needed:
Small flat blade screwdriver
3mm hex (Allen) key
First, with a small flat blade screwdriver, gently pry the up the trim ring around the woofer,
highlighted in red

Service Manual –Consumer
12
Be careful when removing trim ring around the edge of the cabinet, rough handling may cause
damage to the cabinet
Pry slowly around the edge of the trim ring to release all the clips.

Service Manual –Consumer
13
Once the trim ring is removed the speaker should look as shown below.
Next, begin removing the screws (highlighted below in red) from the perimeter of the tweeter
horn.
There will be six (6) total screws to remove, each using a 3mm hex key head

Service Manual –Consumer
14

Service Manual –Consumer
15
Once all the screws have been removed, the woofer should come free as shown below.

Service Manual –Consumer
16
Once the woofer is removed from the cabinet, slide back the silicone covers on the terminals, and
use a small flat blade screw driver to release the wire clips holding to the positive and negative
terminals of the woofer.

Service Manual –Consumer
17
Once the woofer is removed, the speaker will look as shown below

Service Manual –Consumer
18
Next, plug the wires on to the new woofer, and slide
the silicone covers back over the terminals.
Place the woofer back into position, and replace the
screws.
Replace the trim ring by setting into position and gently
pressing the trim ring around the edge, verifying the
clips on the back are locking into place. Once this is
done, the trim ring should sit flush with the front of
the speaker
