Klipsch SB 120 User manual

SB 120
OWNER’S MANUAL

WHAT’S INSIDE
Klipsch SB 120 Remote
AC Power Cord Digital Optical Cable 3.5mm to Dual RCA Cable

POWER
ON
OFF
OPTICAL L
R
AC~100-240V
50/60Hz
80W
2
3
145
Optical
TV
Digital Audio Out
Klipsch SB 120
6
DIGITAL OPTICAL CONNECTION (PREFERRED - IF TV HAS NO OPTICAL OUT SEE NEXT PAGE)

Klipsch SB 120
POWER
ON
OFF
OPTICAL L
R
2
3
1
Headphone
TV
4
5
AC~100-240V
50/60Hz
80W
3.5mm TO DUAL RCA ANALOG CONNECTION (IF TV HAS NO HEADPHONE OUT SEE NEXT PAGE)
QUICK START

POWER
ON
OFF
OPTICAL L
R
2
3
1
Audio Out
Klipsch SB 120
TV
L
R
4
5
AC~100-240V
50/60Hz
80W
DUAL RCA TO DUAL RCA ANALOG CONNECTION (CABLES NOT INCLUDED)
RCA Cables not included.

1Solid Green 2Press and Hold
Solid Orange
One Foot
1 2 3
4 5 6
7 8
0
Mute
ChVol
9
Press Slowly x4
6
3Flashes Orange
5Flashing
Green to
Solid Green
7
Press Once x1
4
TV REMOTE PROGRAMMING
To program Volume Up and Volume Down buttons repeat the
steps shown and replace steps 4 and 6 with the button you
want to program.
If you are trying to program a cable/satellite box remote or
other universal remote without success, please try program-
ming your TV or Cable Box
remote instead.

BLUETOOTH
®
WIRELESS TECHNOLOGY
Bluetooth
Bluetooth
ON
SB 120
Devices
Connected
Settings
Bluetooth
Bluetooth
ON
SB 120 SB 120
Devices
Not Connected
Settings
1 2 3 You can pair a device equipped with
Bluetooth
at any time by activating it on your device.
Once your device equipped with
Bluetooth
is paired, the SB 120 will automatically switch to
the
Bluetooth input (SOLID BLUE LIGHT)
and you can stream your music. If you switch
inputs on the SB 120, the
Bluetooth connection
will automatically be terminated.
You must disconnect your device before pairing
another device equipped with
Bluetooth by either:
• Pressing and holding the SOURCE button on
the SB 120 control panel 3 seconds
• Turning off
Bluetooth on the paired device
• Pressing the
Bluetooth button (∞) on the
SB 120 remote
*Example only. Your device may differ.

BUTTONS
On / Off
3D Surround
Bluetooth
Status
Light
Status
Light
Source Mute
Volume
Down
Volume
Up
Source
Volume Up
Volume Down
Mute
Subwoofer
Volume Up
Subwoofer
Volume Down

STATUS LIGHTS (RIGHT STATUS LIGHT, UNLESS STATED)
STANDBY MODE
SOLID RED Power Off (Standby Mode) FLASHES BLUE QUICKLY Waiting to pair with
Bluetooth
device
SOLID GREEN Power On, Source is Optical Input FLASHES PURPLE SLOWLY SB 120 decoding Dolby Digital
SOLID ORANGE Power On, Source is Analog Input SOLID WHITE 3D Surround Mode On
(Left Status Light)
SOLID BLUE Power On, Source is Paired
Bluetooth device
FLASHES GREEN /
ORANGE / BLUE
Volume Up, Volume Down, Subwoofer Volume
Up or Subwoofer Volume
Down is pushed
You do not need to turn off the SB 120, just turn off your TV
(or Satellite / Cable Box) and the SB 120 will automatically go
into standby mode in approximately 10 minutes.
Standby mode is indicated by a red status light on the front
panel. When your TV (or Satellite / Cable Box) is turned back
on the SB 120 will automatically turn on again.

31” (78cm)
11” (28cm)
CRT
PLACEMENT
TV must weigh less than 100 lbs (45kg)
TV base must be smaller than
31” x 11” (78cm x 28cm)
Make sure the rear of the SB 120 is at least one inch away
from a back wall and there is at least one inch clearance
around the top and sides of the SB 120 for ventilation.
Make sure to center your TV on the SB 120.

TURN OFF TV SPEAKERS
CARE AND CLEANING
TV Speakers
TV Audio Settings Menu
(Recommended)
OR
Volume
Volume
On
TV Speakers Off
1
2
1
2

SB 120 will not Power On
• Is it plugged into a live outlet?
• Is the rear power switch on?
No sound
• Is it plugged into a live outlet and the rear power switch is on?
• Are all cables from the TV/Cable Box/Satellite Box plugged in tightly?
• If the optical cable is being used were the clear plastic caps from both ends
removed before connecting?
• Is the volume turned up?
• Is standby off (no SOLID RED status light)?
• Is the source input correct?
• Turn off the rear power switch, then back on.
TV/Cable/Satellite Box Remote will not program
• Carefully follow all remote programming instructions.
• Carefully go through the remote programming again, but use the original
remote that comes with the TV. You DO NOT need to then reprogram using
your cable/satellite/universal remote control.
• Program the original TV remote to the SB 120 (if original is a different one),
then use the universal remote without programming it.
• You may need to repeat programming of a function in some cases.
• There may be some cases the SB 120 is unable to learn certain remote codes.
Bluetooth does not work
• Is the device paired to the SB 120?
• Move your device closer to the SB 120 and make sure it is paired.
• If the status light blinks RED while attempting to pair, start the pairing
process over.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered
trademarks of Dolby Laboratories.
The
Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Klipsch Group, Inc. is under license.
TROUBLESHOOTING

3502 WOODVIEW TRACE, INDIANAPOLIS, IN, USA
klipsch.com
©2013, Klipsch Group, Inc.
Klipsch Group, Inc. is a wholly-owned
subsidiary of Voxx International Corporation.

•
I
58120
