Kloben SKY 8 CPC 58 User manual

FORCED
CIRCULATION
SOLAR HEATING SYSTEMS
Vacuumm collectors
SKY 8 CPC 58
SKY 12 CPC 58
SKY 18 CPC 58
SKY 21 CPC 58
Reg. no. 011-7S124R

Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 2

1
INDEX
• Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 2
• Solar collectors technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 5
• Dimensioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 6
• Checks and parameters indispensable for dimensioning . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 7
• Connection example of collectors in series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 8
• Connection example of collectors in parallel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 9
• Preliminary warnings and checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 11
• Practical table for the choice of piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 13
• Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 15
• Flat roof kit assembly layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 16
• Sloped roof kit assembly layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 22
• Hydraulic connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 27
• Instructions for the assembly of the F1/PT 1000 probe . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 28
• Loading the system through the solar station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 29
• Inclinations of the solar collectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 30
• Orientation of the collectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 31
• Maintenance and repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 32
• Safety systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 33
• Indications regarding transport and handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 34
• For the user . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 35
• Grand Soleil Medium Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 36
• Grand Soleil Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 37
• Grand Soleil Plus Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 38
• Totalenergy Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 39
• Totalenergy Plus Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 40
• Data detection card for solar heating systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 41
• Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pag. 42
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 1

2
MAKING USE OF SOLAR ENERGY
Solar energy is among the most abundant and available free renewable energies on the earth’s surface. To have an idea of
the energy that the sun radiates onto the earth, according to the latitude, the average daily solar radiation in Italy varies
from 4 to 5.5 kWh on a surface of 1 square metre.
The use of a solar heat collector with vacuum technology is accredited, as shown by the experts in the solar sector and
by laboratory tests carried out according to EN European Standards, to be the most technically efficient system for captu-
ring the energy released by the sun through the entire year.
Considering the daily heat energy request per person for domestic hot water use, the use of solar collectors with vacuum
technology with CPC reflector, combined with a standard state-of-the-art designed system, allows energy saving regarding
domestic hot water of up to 80%. While, considering the global load of heat energy requested for domestic hot water and
heating, the total saving can exceed 40%.
This considerable energy saving constitutes an important contribution to the reduction of the emissions of noxious
substances, deriving from combustion, into the atmosphere and particularly to the reduction of CO2, the main reason for
environmental heating due to the greenhouse effect.
The functioning principle of a solar heating system can be described simply.
The solar vacuum collector with CPC reflector captures solar radiation and heats up. The heat gathered is transferred by
heat exchage to a water tank, which acts as a storage tank. The amount of solar energy that the collector can transfer to
the tank depends on its capacity to absorb solar radiation and on the level of insulation, which reduces the loss of energy
captured by the collector.
The creation of the vacuum by removing the air from the gap in the glass tube achieves a layer of the best heat insulating
material existing in nature. The principle has been known about for a century and is appreciated in the form of the
thermos.
Using this arrangement, the collectors optimise the use of solar energy also during the change of seasons and during the
winter.
ADVANTAGES OF CPC DIFFUSION VACUUM TECHNOLOGY
- High temperatures and yields even in unfavourable atmospheric conditions, e.g. with low external temperatures.
- High absorption even with diagonal light thanks to the circular shape of the absorbing device.
- Top quality and high efficiency solar vacuum tube, of our own production and with high level of forced vacuum.
- Duration through time: no delicate glass-metal couplings that degenerate the level of vacuum in the glass pipe through
time.
- Duration through time: high resistance and duration of the selective capturing layer also thanks to the protection of the
vacuum.
- Loss of load contained thanks to the circulation of the flow in parallel in the circuit with "U"-shaped pipes.
- Maximum yield with less requirement for surfaces (half of the absorbant surfaces are normally necessary with respect
to a traditional absorbing panel).
- Treated spacial aluminium concentrator reflector, with double CPC paraboloidal section (Compound Parabolic
Concentrator) with optimised optics for the solar collector, to convey the sun’s non-incident rays onto the vacuum tube.
- High efficiency all year round.
- Low assembly costs: collector already assembled and easy to fix.
- Easy and immediate tube replacement with the EASY CHANGE system.
- Excellent heat insulation performance of the heat-carrying circuit also at low temperatures.
- Modern and elegant design.
Introduction
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 2

3
Vacuum area
Multy-layer metal “CERMET” layer
Vacuum tube with double wall
Aluminium absorbing device
Copper pipe
THE VACUUM TUBE
AN OLD PRINCIPLE APPLIED TO AN INNOVATIVE TECHNOLOGY
The creation of the vacuum by removing the air from the gap in the glass tube achieves the best heat insulating material
possible. The principle has been known about for a century and is appreciated in the form of the thermos.
Using this arrangement, the collectors optimise the use of solar energy also during the change of seasons and during the
winter.
The internal surface of the vacuum gap is made selective to the absorption of the solar radiation by means of the laying,
by sputtering, of multiple metal layers with a micro-metric thickness, which is called CERMET and which cover the
absorption of the entire spectrum of electro-magnetic radiation of the sun.
The selective layer is designed especially to resist the high temperatures that are generated, through time. The presence
of the vacuum ensures the protection against infiltrations of humidity and atmospheric agents, thus guaranteeing unlimi-
ted duration and the maintenance of the capturing perfomance.
TRANSMISSION OF HEAT TO THE HEAT-CARRYING FLUID
The exchange of the heat collected takes place by a relevant absorbing device in aluminium, which on contact with a “U”
-shaped copper pipe transfers the heat to a heat-carrying fluid present in the solar collector circuit.
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 3

4
WHY CHOOSE KLOBEN
The research carried out to increase the yield of the Kloben solar collectors have allowed to discover efficient and
innovative solutions to make the best of the sun and its diffused light. For this reason particular direct and diffused light
capturers, with CPC, Compound Parabolic Concentrator, geometry have been studied and realised using materials able to
supply optimal yields in total reflection (> 90%) and in reflection with diffused light.
The combination of vacuum tube technology and CPC reflectors applied to the solar collectors, guarantee the best yields,
most of all in situations of little radiation and low external temperatures. The advantage of the Kloben system therefore
has an immediate effect also at an economical level.
Efficiency curve with radiation at 800 W and average temperature inside heat-carrying fluid of 50°C of the Kloben SKY
CPC 58 DIFFISION model (Test Report no. 07COL623/1 (according to EN 12975-2:2006), ITW Institute, Stuttgart - Solar
Keymark certification).
Efficiency curve with radiation at 800 W and average temperature inside heat-carrying fluid of 50°C of a Solar Keymark
certified flat solar panel (data from Solar Keymark Database - Estif site, (European Solar Thermal Industry Federation))
From the comparison it was seen that for an average T of heat-carrying fluid of 50°C, the Kloben SKY CPC 58 Diffusion
vacuum collector has greater efficiency that the flat collector, up to 35°C of environment T. The difference in efficiency
increases even more on the decrease of the external temperature.
Yiled µ%
Environment temperature [°C]
Summer Winter
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 4

5
Solar collectors technical data
MODEL SKY 8 CPC 58 SKY 12 CPC 58 SKY 18 CPC 58 SKY 21 CPC 58
AMOUNT OF VACUUM TUBES (pc): 8 12 18 21
GROSS SURFACES (m2): 1.48 2.16 3.22 3.75
NET SURFACES (m2): 1.27 1.89 2.84 3.31
EMPTY WEIGHT (kg): 29 43 65 76
DIMENSIONS (mm)
Height: 1603 1603 1603 1603
Width: 920 1358 2018 2348
Thickness: 140 140 140 140
FEATURES
Circuit of the solar collector with “U”-shaped copper pipes with circulation in parallel
Maximum working pressure: 6.0 bar
Load loss:
Optimal flow rate: 1 l/min per m2
Maximum working inclination: 90°
Minimum working inclination: 0°
Attachments: to tighten using soinner DN 18 mm
*Test Report no. 07COL623/1 (according to EN 12975-2:2006), ITW, Universität Stuttgart - SOLAR KEYMARK, Reg. no. 011-7S124R
SKY 8
SKY 12
SKY 18
SKY 21
Yield (square interpoling)*:
η0= 0.718%
a1= 0.974 [W·m-2·K-1]
a2= 0.005 [W·m-2·K-2]
(Taverage fluid - Tenvironmental) [K]
Volumetric flow rate [l/min]
Yiled µ%
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 5

6
Dimensioning
Kloben makes use of a complex software that allows quick, precise and customised calculation of the enrgy requirements
requested, the number of panels necessary and the solar integration supplied, in relation to the destination of use of the
solar system, the details of the structure on which it is to be applied and the climatic data referring to the area of
installation.
For the dimensioning of all components, it is recommended to contact Kloben-authorised staff. However, it is possible to
perform approximate dimensioning of the components necessary for small solar systems (systems up to max 10 m2of solar
collector surface, optimal exposure of collectors max 20° from South and inclination at 45°, average daily consumption
per person of about 60 litres at 45°C), using the data shown below:
MAXIMUM DIMENSIONING OF SOLAR PANELS
MAXIMUM DIMENSIONING OF SYSTEM COMPONENTS
Expansion vessel: An approximate measurement consists in considering 6 l for every m2of solar surface installed.
For more accurate dimensioning refer to the solar calculation software of the vessel
available in the Kloben Intranet area.
Anti-freeze liquid: add the following parameters (A + B + C + D)
A. 1/2 of the capcity of the expansion vessel installed
B. 10 l for every 40 m of line (20 delivery + 20 return)
C. 1.17 l for every SKY 8 CPC 58
1.74 l for every SKY 12 CPC 58
2.60 l for every SKY 18 CPC 58
3.07 l for every SKY 21 CPC 58
D. about 15 l for storage from 300 to 500 l
about 20 l for storage from 500 to 750 l
about 30 l for storage from 750 to 1000 l
Solar Station: LOW FLOW for the management of systems with flow rate from 2 to 16 l/min
BIG FLOW for the management of systems with flow rate from 10 to 80 l/min
For more accurate dimensioning refer to the solar calculation software available in the Kloben
Intranet area.
Flow rate adjuster: 1 l/min for every m2of solar surface installed.
NORTH CENTRAL SOUTH
ITALY ITALY ITALY
Water at 45°C produced
per m2of solar surface (litres) 80 90 100
Heatable radiant surface
(laying distance 10 cm) from 10 to 15 m2from 12 to 16 m2from 14 to 18 m2
for every m2of solar
Relation between solar and swimming pool sup.
(for summer use - ca. 35% ca. 30% ca. 25%
water 26°C - night cover use)
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 6

7
Checks and parameters indispensable for dimensioning
In order to start with a correct design, aimed at the realisation of the solar system that is the most suitable for maximising
the benefits of the final customer, some important preliminary checks must be carried out and indispensable data must be
gathered for correct dimensioning:
PROJECT LOCALITY:
The locality where the system is to be installed supplies precious indications for dimensioning, such as: average monthly
radiation, average monthly external temperature, mains water average monthly temperature, average relative humidity
temperature, average monthly wind speed.
METHOD OF CONSUMPTION AND PERIOD OF USE OF THE SYSTEM:
Consider the daily requirement of the family; an approximate consumption of hot water at 45°C variable from 50 to 70
l/day per person. Identify any simultaneous requests for the use of domestic hot water. Check the period of use of the
system (seasonal or months of use).
TYPE OF SYSTEM USE:
heating domestic hot water: identify the consumption and temperature of the water requested and the capacity
of the existing storage tank. For maximum dimensionimg of the capacity of the storage tank to be envisioned, it
is possible to refer to about the double of the daily consumption envisioned for the family or inhabitants.
heating non-domestic hot water: hotel, gym etc.-indicating that stated previously regarding the methods of
consumption and periods of use. For this type of system, therefore, an ad hoc design by designers or Kloben tech
nical staff is always necessary.
room heating: only radiating - identify surfaces to be heated, space between tubes and type of insulation.
swimming pool: specifies if covered or outdoor, any night cover use, requested temperature, period of use.
FEATURES OF THE INSTALLATION STRUCTURE:
The surfaces that house the field of solar collectors are an important restriction of the design, which must be considered
as the positioning of the solar collector affects the capturing efficiency of the sun’s radiation. The checks to be carried out
are: possibility of assembly on flat or sloped roof, availability of roof pitch with orientation towards the south or
alternatively with orientation towards east or west, inclination of the pitch, presence of obstacles, etc.
From the existing Standard, UNI 9182, the data inherent to flow rates and requirement of domestic hot water according
to the activity in question and the single appliances, are gathered.
The dimensioning indications stated above refer to maximum dimensioning and are relative to homes with the standard
consumtion of an average family. However, for the correct dimensioning of all parts of the system, it is necessary to
consider the preliminary checks indicated along with all of the details of use of the final user to then proceed with the
definition of the energy requested, the modes of distribution (flow rates, temperatures, period of request) and
successively with the correct dimensioning of all system components on the basis of powers and exchange yields of the
various components: solar surface, solar heat exchanges, storage, etc.
For this reason and for accurate dimensioning refer to Kloben specialised technical staff.
N.B. IF THE SOLAR INSTALLATION IS INTRODUCED ONTO SYSTEMS THAT ALREADY
FUNCTION, IT IS INDISPENSABLE TO HAVE THE DETAILED LAYOUT OF THE EXISTING
HEATING STATION, WITHOUT WHICH IT WILL NOT BE POSSIBLE TO SUPPLY ANY
PERFORMANCE GUARANTEE.
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 7

8
Example of connection of the collectors in series
ATTENTION: do not connect more than n° 4 collectors in series
Probe S1
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 8

9
Example of connection of the collectors in parallel
TICHELMAN SYSTEM: consists in the hydraulic balancing of the collector coils.
EXAMPLE 1
EXAMPLE 2
Probe S1
Probe S1
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 9

10
Example of connection of the collectors in parallel
TICHELMAN SYSTEM
EXAMPLE 3
Probe S1
Probe S1
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 10

11
Warnings and preliminary checks
The installer is asked to carefully follow the recommendations and indications that are listed successively; as well as
performing all controls requested before system start-up.
ANTI-FREEZE HEAT-CARRYING FLUID:
The heat-carrying fluid used and supplied consists in a special liquid with anti-freeze properties, TYFOCOR LS. This fluid
is specially for use in solar plants with high heat yield like vacuum tube collectors. It is totally pre-mixed and ready for
use. It guarantees protection from freezing to -28°C.
It contains corrosion inhibitors that guarantee efficient protection and duration of the copper pipes, (and all other metals
and alloys used) in particular from corrosion and deposits.
Warnings: In order to maintain the protective features of TYFOCOR LS unaltered, it must not be mixed with other
heat-carrying fluids and anti-freeze or diluted with water. Any top-up owing to the loss of fluid must be compensated
exclusively with TYFOCOR LS. Before loading always check that there is no water in the circuit.
The use of deposited metals is advised for soldering. For welding points the use of deposited metals is recommended for
brazing in silver and copper.
TYFOCOR LS does not attack the sealing materials normally used in solar systems. However, attention must be paid that
all sealing materials are resistant to the maximum temperature of the heat-carrying fluid. Failure to comply with these
checks can lead to the warranty of the solar collector becoming void.
LOADING:
- Before starting the system loading operation, make sure that the solar collectors are at low temperature.
The panels must be covered at least 3 hours before loading.
- The system must be loaded by carefully following the instructions given on page 25 of this manual. The use of the
supplied system loading pump is also recommended (code 101010045).
Correct loading allows the complete elimination of air in the solar circuit and its correct functioning.
- The system’s optimal functioning pressure, to be calibrated in the loading phase is 3/3.5 bar in the heating station and
at least 2/2.5 bar at the panels, with the system at a standstill.
DIMENSIONING:
- Before starting the solar system it is good practice to check that dimensioning and the adjustment of the individual
components ( panels, expansion vessel, glycol, flow rate adjuster, solar station) are in compliance with that indicated on
page 5 of this manual.
- It is indispensable that the diameter of the copper pipes making up the solar circuit are in compliance with that
indicated on page 11 of the following manual. If in doubt, refer to Kloben authorised staff or our technical dept.
INSTALLATION AND RESISTANCE TO LOADING STRESS, WIND AND SNOW:
The installation of solar collectors on flat and sloped roofs envisions indispensable preliminary checks that clarify the
following critical aspects:
- Static stability of the roof for assembly of the collectors
- Accessibility of the roof housing the system and sufficient access and freedom of movement in safety
- Fixing quality of the structure connections and support devices of the solar collectors to the building support (loft
structure, flat roof structure, etc.).
On the basis of the place of installation selected, the locality, the height from the ground, exposure, topography of the
land, the climatic conditions of the areas, etc. preliminary checks must be made of the loading conditions owing to the
wind (average, peaks due to gusts and the presence of storms) and snow on the basis of that envisioned by the
"Departmental Circular dated 4 July 1996, n. 156" regarding implementation "technical standards relative to the general
criteria regarding the safety checks of the constructions and loads and overloads", Legislative Decree dated 16 January
1996.
In the calculations regarding the evaluation of stress of individual and combined loads owing to wind and snowfall, a
maximum sustainable load must be considered, normal to the surface of the collector of 0.90 kN/m2.
The solar collector has been designed to suitably resist combined conditions of wind and snow, the most serious
features of the Italian territory. However, if phenomena of an exceptional nature should occur or situations or loads
exceeding the maximum load of the panel it is good practice to prepare additional protections, such as tie-rods and
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 11

12
reinforcements for stabilisation.
MATERIALS:
- All pipes making up the solar circuit must be in copper. The use of other materials such as zinc, stainless steel, plastic,
brass and similar is not recommended. If materials different from copper are used, it will be impossible to guarantee
correct functioning of the system.
- All joints must be welded or with tightening connections for copper pipes.
The use of any other materials can jeopardise the sealing of the joints through time.
- To prevent sealing problems of the hydraulic joints of the solar circuit owing to heat stress, always check the distance
at which the field of solar collectors is found with respect to the storage tanks. In all cases it is recommended always
to make the joints with high temperature Teflon.
- The copper pipes must be insulated using a sheath for high temperatures such as the Kloben Solare.
CHECKS:
- Check that, with the system unloaded, the expansion vessel is calibrated at 2 bar.
- Check the correct connection of the probes to the solar control unit.
- Check that the solar control unit is connected correctly to the mains.
- Check that the setting of the solar control unit parameters is in compliance with that prescribed in the design phase.
N.B.: The solar collectors cannot remain exposed to solar radiation for long periods of time without being
loaded (ten days).
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 12

13
Practical table for the choice of piping
FLOW RATE AND PIPING SECTION
(WITH MAXIMUM LENGTH OF 20 METRES FOR DELIVERY AND 20 METRES FOR RETURN)*
*IF THE CIRCUITS HAVE A LONGER LENGTH OR A CONSIDERABLE NUMBER OF BENDS, PLEASE CONTACT
KLOBEN AUTHORISED STAFF.
For further indications regarding the choice of piping combinations refer tot he Kloben calculation software, present in
the intranet area at: http://solar.kloben.it/impianto
N.B.: As well as the choice of piping, for correct functioning of the solar system correct dimensioning of all components
is necessary (page 5 of this manual).
N.B.: Page 12 of this manual must be consulted for the choice of the solar station.
N.B.: If a greater solar surface is required, more parallel rows will be constituted, each with the same surface area,
connected to each other using the TICHELMAN method (page 8 and 9 of this manual).
N.B.: For systems with particular dimensions and non-standard features, specific calculations must be made to
determine loss of load, pipe diameter, etc.
Cylinder [litres] Type and number collector Flow rate [l/min] Ø Piping [mm]
150 1 x SKY 8 1.27 Copper 14
150 1 x SKY 12 1.89 Copper 16
200 1 x SKY 12 1.89 Copper 16
200 1 x SKY 18 2.84 Copper 16
300 1 x SKY 18 2.84 Copper 16
300 1 x SKY 21 3.31 Copper 16
300 2 x SKY 12 3.78 Copper 18
500 1 x SKY 12 + 1 x SKY 18 4.73 Copper 18
500 2 x SKY 18 5.68 Copper 18
600 2 x SKY 21 6.62 Copper 18
750 3 x SKY 18 8.52 Copper 22
800 3 x SKY 18 8.52 Copper 22
1000 4 x SKY 18 11.36 Copper 22
1500 6 x SKY 18 17.04 Copper 28
2000 8 x SKY 18 22.72 Copper 35
3000 12 x SKY 18 34.08 Copper 35
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 13

14
LOW - FLOW STATION PUMP FEATURES Flow rate 2-16 l/min
BIG - FLOW STATION PUMP FEATURES Flow rate 10-80 l/min
For more accurate dimensioning, refer to the solar calculation software available in Intranet.
Current I: Onside thermal overload settings.
Measurements - Weight Motor Data
Single-phase motor (EM) 2 poles - 1 ˜230 V, 50 Hz
Nom. Power
P. max
W
Speed/N. of revs.
n.
1/min.
Absorbed power
P.
W
Current
I
A
Condenser
µF/VDB
Motor
Protection
Measurements - Weight Motor Data
Single-phase motor (EM) 2 poles - 1 ˜230 V, 50 Hz
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 14

15
Clearance
Model A B
SKY 8 983 mm 910 mm
SKY 12 1424 mm 1350 mm
SKY 18 2084 mm 2010 mm
SKY 21 2414 mm 2340 mm
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 15

Flat roof kit assembly layout
16
Position the fixing beams complete with base plate onto the ground,
taking care to respect the maximum distances indicated in the following figure.
Bolt the template support uprights to the fixing beams (see figure below)
ASSEMBLY LAYOUT FOR 1 SKY CPC 58 PANEL: 8 - 12 - 18 - 21
Model A max
SKY 8 300 mm
SKY 12 680 mm
SKY 18 1300 mm
SKY 21 1500 mm
Fixing beam with base plate
Small base plate
Template support uprights
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 16

17
Flat roof kit assembly layout
Fix the frame to the loft suitably. The nuts and bolts to use must be made in relation to the sub-base material. Each base
plate has 4 holes measuring 12 mm.
Position and fix the support templates according to that indicated in the figure
Solar Panel
support template
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 17

18
Flat roof kit assembly layout
ASSEMBLY LAYOUT FOR 2 SKY CPC 58 PANELS: 8 - 12 - 18
In the case of installation in series of 2 SKY CPC 58 8, 12, 18 panels, respect the distances indicated in the figure,
where P (support plate width) is a fixed measurement.
ASSEMBLY LAYOUT FOR 3 AND MORE SKY CPC 58 PANELS: 8 - 12 - 18
In the case of installation in series of 3 or more SKY CPC 58 8, 12, 18 panels, rrespect the distances indicated in the
figure where P (support plate width) and C are fixed measurements.
Model P B max
SKY 8 150 mm 535 mm
SKY 12 150 mm 970 mm
SKY 18 150 mm 1500 mm
Model P B max C
SKY 8 150 mm 535 mm 840 mm
SKY 12 150 mm 970 mm 1280 mm
SKY 18 150 mm 1500 mm 1940 mm
Manuale_03_03_08 UK.qxd:Manuale_18_04_07.qxd 26-05-2008 11:23 Pagina 18
