KM KMi heater X175 Specification sheet

1
KMi
Instructions for use and
maintenance

2
1TABLE OF CONTENTS
1 Table of contents............................................................................................................................. 2
2 Introduction..................................................................................................................................... 3
2.1 Induction heating principal ..................................................................................................... 3
3 Safety instructions........................................................................................................................... 3
3.1 General safety rules................................................................................................................. 3
3.2 Electrical safety rules............................................................................................................... 4
3.3 Fire safety rules ....................................................................................................................... 5
3.4 Safety rules for personal protection……………………………………………………………………………………6
3.5 Safety rules for using the device ............................................................................................. 7
4 Technical data.................................................................................................................................. 9
5 Use................................................................................................................................................... 9
5.1 Detachable coils .................................................................................................................... 10
5.2 Flat coil .................................................................................................................................. 11
5.3 Customized fixed coils........................................................................................................... 11
5.4 Flexible coil............................................................................................................................ 12
5.5 Focus coil............................................................................................................................... 12
6 Device indicators ........................................................................................................................... 13
7 Possible problems and troubleshooting........................................................................................ 13
8 Storage and maintenance ............................................................................................................. 14
8.1 Cooling, dismantling and storage.......................................................................................... 14
8.2 Proper cleaning and maintenance ........................................................................................ 14
9 Warranty conditions...................................................................................................................... 15
9.1 Conditions of non-acceptance of the guarantee................................................................... 15
10 Warranty service ....................................................................................................................... 15
11 Disposal of used equipment...................................................................................................... 16
12 Type of coils............................................................................................................................... 16
13 Consumable spare parts............................................................................................................ 18
14 Meaning of used symbols.......................................................................................................... 19
15 Possible problems and troubleshooting.................................................................................... 20
16 Warranty.................................................................................................................................... 21
17 Certificates of Quality................................................................................................................ 21
18 Declaration of Conformity......................................................................................................... 22

3
INDUCTION HEATER - KMi
2INTRODUCTION
This device generates alternating current of high frequency. The current passing through a heat-
ing coil creates an alternating magnetic field which by using the principle of electromagnetic
induction vibrates electrons inside the heated material. The energy of moving electrons is dissipated
as heat, which heats the metal in the work field of the instrument. The more easily magnetizable
material, the more heat it generates. The device heats easily ferrous metals and their alloys, but has
no effect on glass, plastics, wood, textiles and other non-conductive materials.
2.1 INDUCTION HEATING PRINCIPAL
Induction heating is the process of heating an electrically conducting object (usually a metal) by
electromagnetic induction, through heat generated in the object by eddy currents. An induction
heater consists of an electromagnet, and an electronic oscillator that passes a high-frequency
alternating current (AC) through the electromagnet. The rapidly alternating magnetic field penetrates
the object, generating electric currents inside the conductor called eddy currents. The eddy currents
flowing through the resistance of the material heat it by Joule heating. In ferromagnetic (and
ferrimagnetic) materials like iron, heat may also be generated by magnetic hysteresis losses. The
frequency of current used depends on the object size, material type, coupling (between the work coil
and the object to be heated) and the penetration depth.
An important feature of the induction heating process is that the heat is generated inside the
object itself, instead of by an external heat source via heat conduction. These objects can be heated
very rapidly. In addition there need not be any external contact, which can be important where
contamination is an issue. Induction heating is used in many industrial processes, such as heat
treatment in metallurgy, Czochralski crystal growth and zone refining used in the semiconductor
industry, and to melt refractory metals which require very high temperatures. It is also used in
induction cooktops for heating containers of food; this is called induction cooking.
3SAFETY INSTRUCTIONS
3.1GENERAL SAFETY RULES
Read carefully all instructions in the manual. Failure to follow these instructions
may result in electric shock or burns, fire and / or serious personal injury!
Users are responsible for installing and using the system in accordance with the instructions provided
in this manual. The contractor shall not be liable for damages resulting from improper use and
handling.

4
The device may be operated only by persons properly trained and appropriately qualified. Do not
operate KMi heater X175 under the influence of drugs, alcohol or medications.
Bystanders should be kept safely away when operating with the device, even when cooling the
heated material.
Avoid working in the rain, water and moist environments. Keep work area well ventilated and dry,
clean and well lit.
This device cannot be used by children, people of any physical or mental disabilities, non trained
persons and people of little or no knowledge of the usage of the device. The induction heater KMi
heaterX175 must be used only for the purposes of the induction heating. The device KMi heaterX175
cannot be used for the welding or charging purposes.
3.2 ELECTRICAL SAFETY RULES
This is a safety class I device, which may be supplied with power only from the power
outlet with a protective conductor, which must be connected to the device as first and
in any case must not be interrupted /e.g. by an extension cord/. Any interruption of the
protective earth conductor, or its disconnection will cause a potential electric shock
hazard that can cause injury. Make sure that the device /device chassis/ is properly
grounded.
Do not twist or sharply bend the power cord, as it may damage the internal wiring.
Never use KMi heater X175 if the power cord shows any signs of damage. Keep the
power cord away from heat, oil, sharp edges or moving parts. Never repair the power
cord if damaged, the power cord must be replaced. Damaged cords create a risk of
electric shock.
It is necessary to tight the screws for coil /9/ properly after every changing. Free screws can harm
damages on the machine and sparking which causes the overheating of the contacts – the working
current is 300A!!! The material of the heating coil is being expanded and contracted while working.
Therefore it is necessary to check all the time the tightened of the screws on the handle.
I tis forbidden to use the device if the cover, handle, coil or cable is damaged or not in a 100% fit –
there is a danger of injury or death by the electrical current or a fire. Keep the cables, working coils
and the device itself off the another heat devices, acetone, colours, dope, hydroxides, the other
chemicals, sharp edges or moving parts. The red isolation to the handle /4/ and the isolation of the
coils /10/ is resistant for the oils, acids only for a little. If the cord, isolation or the isolation of the
working coil is damaged, must be replaced only by the manufacturer or responsible person trained by
the manufacturer to prevent any injury or harm.
The manufacturer and the seller are not responsible for the consequences of an inappropriate usage
of the device written in this manual.
Do not touch the working coil while in process of heating. Do not switch on the machine without the
working coil. There are high current peaks while the machine is ON without the working coil and
therefore the device can be damaged by that because of the damaging the overvoltage protection.
Do not use the working coils with damaged isolation or no isolation.

5
Before replacing the applicator /coil/, disconnect KMi heater X175 from the power source /wall
outlet.
If you are not using KMi heater X175, unplug the power cord from the outlet.
CAUTION
This product is for class A industrial use. It may cause radio interference in
residential, commercial and light industrial environments. This product is not
intended for installation in residential environment, business environment
and light industry with connection to the public supply network; user may
be required to take adequate measures to reduce the interference.
Caution! High voltage danger 1600V on the primary side of the transducer.
Caution! High current 300A on the secondary side of the transducer and on
the output of the device.
Do not open the cover of the KMi heaterX175 while working process.
3.3 FIRE SAFETY RULES
Do not use the device if suspecting the gas leaking or flammable or blowing up materials.
Do not heat aerosol or other cans, metal containers, and any pressure vessel used for
the storage of fuel, compressed gases and liquids. The heat generated by KMi heater
X175 may cause them to explode and their con-tents may ignite.
Do not use the heating spiral /coil/, if the isolation is damaged. A defect in the isolation may cause
sparks in contact with metal objects or between the turns of the coil. In particular, when working on /
or near gas pipes and / or gas tanks it may pose a danger of explosion or fire. Using coils with
damaged isolation will void the warranty.
Always have the fire extinguisher near to the device while working which is able to extinguish the
electrical devices under the voltage – CO2 or dust extinguishers.
The water or foam extinguishers are absolutely inappropriate.
The fire under the voltage always extinguish from the distance at least 2m.
If possible switch off the power.

6
3.4 SAFETY RULES FOR PERSONAL PROTECTION
Persons with pacemakers or other metal or electronic surgical implants must not
operate with the device KMi heater X175 and must keep a safe distance of at least 1m
from the device.
When working with KMi heater X175 do not wear any metal objects such as jewellery,
rings, watches, necklaces, identification tags, belt buckles, piercing and even clothing
with metal parts such as metal rivets, buttons and zippers, etc. KMi heater X175 can
heat up these metal objects quickly and cause serious burns or clothing ignition.
ATTENTION: Coil applicator and heated object can reach high temperatures and
cause burns or cause a fire.
When using the device KMi heater X175 always wear safety goggles or face shield.
When using the device KMi heater X175 hazardous fumes may be produced by
burning old paint, lubricants, sealants, adhesives, etc.
These exhalations can be toxic. Always wear appropriate protective masks or
respirators.
When working with the device KMi heater X175 always wear protective gloves with
corresponding thermal resistance. High temperatures generated by the use of KMi
heater X175 may cause serious burns in the case of touching the heated part. Always
keep proper footing and balance for safe control of the device even in un-expected
situations. The isolation of the working coils consists of glass fibres so while
manipulating always use the protective gloves. The cable from the device to the
handle van be overheated for some reason so always use the non flammable
protective gloves. Do not touch the components of the device by the non protected
skin. Do not wear the clothes from oils, grease or petrol. There is a risk of fire or
burning.
The working space always kept in a fresh air condition.
While working with the KMi heaterX175 do not wear on you and do not get close with the red cable
/4/ or the working coil /10/ to the electronical devices like cell phones, USB media etc.... There is
areal risk of damaging such a devices.
While working close to the sensitive electronical devices always unplug them from the source of
power or from batteries. Always stay on a flat, dry and non electrical ground.
Do not use KMi heater X175 near the device with pyrotechnics /e.g. airbag/. The resulting heat can
cause their unexpected explosion. Keep a minimum distance of 10-20 cm from these devices.

7
3.5 SAFETY RULES FOR USING THE DEVICE
Do not leave KMi heater X175 unattended when switched on. Make sure that the power supply
unit and the handle has an adequate supply of air for cooling.
After finishing the work with the KMi heaterX175 do not switch it off immediately but keep it on
6,5minutes to cool down properly. After that you can switch off the device from the source of power.
The working coils always let cool down on the non flammable surface before putting them to the
case.
Make sure the vents are clean and free of dust and dirt not to impede the flow of cooling air.
Do not attempt to repair KMi heater X175. The device does not contain any user-serviceable
components, except for replaceable heating coils.
Before connecting KMi heater X175 to the wall outlet make sure the outlet voltage
corresponds to the voltage on the rating plate. If the wall outlet voltage does not
match the voltage indicated on the rating plate, it may result in a serious risk of
damage to KMi heater X175.
Do not exceed the operating cycle KMi heater X175 – 1,5 minutes heating (on) and
1,5 minutes cooling (off). The main equipment is protected against device
overheating, but heating coils are not, which may cause their damage.
EXTENSION CORDS:
Extension cords – if necessary, you may use only the following extension cords:
•up to 5m with 2.5 mm2 diameter
•up to 15m with 4 mm2 diameter
Use only one extension cord – do not connect two or more extension cords. Do not use any other
extension cords than those mentioned above. Unpack the extension cords - tightly packed extension
cords may overheat and cause fire.
GENERATORS:
When using the device with an alternate source of power – e.g. with mobile electric generator, it is
necessary to use a quality alternate source of sufficient power and AVR quality control. Use a
generator with a power output of at least 3-4 kW, or DC / AC inverter with a power output of 2-3 kW
and only with a sine wave – do not use the inverter with a square or quasi-sine wave. Failure to
comply with the above requirements may result in damage to the device and void the warranty.
The device must be protected from rain and moisture, mechanical damage and possible ventilation of
neighbouring machines, excessive overloading and rough handling.

8
Components
1. Cover of the machine
2. Ergonomic handle for the coils
3. Electric supply cord
4. Connection cord
5.
6. Ventilator
7. LED working light
8. LED info indicator
9. On/OFF button
10. Coil pull in screw
11. Coils –various types

9
4TECHNICAL DATA
5USE
Before usage of the device, check the incoming cable, handle and the handle cable to assure that
they are not damaged.
1. Disconnect the device from the electric network and loosen the screws on the handle. (9.).
2. Insert the working coil into the holes /handle 2/ in the clamping holder of the coils and
tighten the locking screws on the sides/9/.
3. Connect the supply cable of the device into a properly grounded standard socket ~230V,
50/60Hz and turn on the device using the main switch. Before turning on, make sure that the
handle is laid in a safe place and that the heating button is not pressed down/8/.
4. Attach or put the working coil on the material you want to warm up and press the button on
the handle. Heating remains activated during the pressing of the button - do not exceed the
operating cycle of 1,5 minutes of heating and 1,5 minutes of cooling.
After finishing the cycle, release the button on the handle /8/ and remove the heating coil/10/ from
the heated material.
While working with the KMi heaterX175 slowly move with the working coil to prevent the sticking to
the heated material. You can hear a little buzz during the operation or small vibrations which is
absolutely normal features of the induction procedure.
Always check the tightened of the working coils.
NOTE: During heating there should be a gap of around 3-5mm between the coil and
the heated material to avoid excessive wear of the heating coil. A gap larger than 3-
5mm decreases heating efficiency and extends the heating time
After finishing heating, place the handle with the heating coil in a safe, inflammable
place until the heating coil is completely cooled. Then turn off the device using the
main switch and disconnect it from the electric network.
ATTENTION: The coil and the heated object can reach a high temperature and/or
cause burns or result in fire.
TECHNICAL DATA
Input voltage
230V +10% -15% 50 Hz
Input current
max. 8A
Input
max. 2 kW
Power
max. 1,75 kW
PF (power factor)
0,99
Load factor
1,5 min. 100 %
Cover
IP 20
Dimensions cm
23,5x18x9,6
Total length cm
140
Weight kg
4,5

10
5.1 HEATING COILS
FRONT ATTACHABLE COILS
SIDE ATTACHABLE COILS
NOTE: The service life of the coils can be increased by cleaning rust, paint, oil etc.
from the heated material. During heating, there should be a gap around 3-5mm
between the coil and the heated material to avoid excessive wear of the heating coil.
Holding of the coil directly on the hot material can cause the burning of the coil
insulation, thereby shortening the service life of the coils. We recommend limiting
direct contact of the coil with the hot material to the minimum.
The standard supplied
diameters of the side
attachable coils are
14-47mm
The standard supplied
diameters of front
attachable coils are
14-47mm

11
TIP! For loosening nuts, screws etc., it is not necessary to heat the material until it is red hot. Heat the
nut for 5-10 seconds and try to loosen it using a wrench. If it is not possible, heat again for 5-10
seconds and then try loosening using the wrench again.
5.2 FLAT COIL
The flat coil shaped coil is intended for the heating of flat sheet metals and for the straightening of
small dents in car bodies by heating. The flat coil is also in-tended for easy peeling off of stickers,
sealants, putties etc by heating of the base material - steel sheet metal.
1. Connect the coil to the coil handle
2. Place the coil with its area over the material
3. Press the button and guide the coil above the material in a gyratory movement
4. After heating of the material, allow the coil to cool off for at least 2 minutes.
NOTE: It is possible to use the coil to remove various adhesive stickers, seal-ants and
gaskets which are stuck to sheet metal or metal – for example in automotive, services
etc.
The coil is used heating of the base material and thus softening, or alternatively,
hardening of the glue, putty, etc. We recommend holding the coil around 5-15mm far
from the heated material - it is possible to regulate the required temperature and
heating time by changing the distance.
5.3 CUSTOMIZED FIXED COIL
User shaped solid coils can be shaped and adapted directly by the user according to
requirements of the individual application. They can be used for the same purposes as attachable
coils.

12
5.4 FLEXIBLE COIL
The flexible coil is used for the loosening of axle fitments, stiffened sensors, ball joints etc and in
applications where is not possible to use attachable coils.
Applications:
1. Connect one end of the coil to the coil holder and secure it by the locking screw
Wrap the free end of the conductor over the part which needs to be heated. Make around 1-
3 turns.
2. Connect the second - free end of the coil into the coil holder and secure it by the locking
screw
3. Pressing of the key activates the heating.
4. After finishing heating, one end of the coil will be release and the coil will be unwound from
the heated material
If the overload of the device occurs /the LED warning light on the handle is flashing
red/, unwind one loop and repeat the procedure until the heating is carried out
without overload and turning off.
If the heating has a low intensity, on the contrary, try adding one loop.
5.5 FOCUS COIL
They allow a higher intensity heating on a small area and are especially used for attaching to the
heated material.
1. Connect the coil into the coil holder

13
2. Attach the coil on the material with the circular area of the coil
3. Press the button for a max. of 10-15 seconds.
4. After heating the material, let the coil cool off for at least 50 seconds.
6DEVICE INDICATORS
Colour
Meaning of colour
Troubleshooting
green
stand by/ready
If the Green light is on
while working and the
machine is not heating
the thermal fuse
deactivated the
current circle to
protect the machine.
OK
Wait for 1,5minute to cool down the thermal fuse under the
70C and the current circle will be activated again.
If the induction heater is not working after that, please call the
service.
orange
heating in progress /
device is working
OK
red flashing
device is overloaded
by the outgoing power
Use another working coil or keep the distance between the
coil and material around 3mm.
red light on
the temperature of
the device is
overloaded
Keep the device ON to cool down by its own ventilators
approx. 1,5min.
Red and white
light is flashing
Missing coil /
Damaged coil
Check if the coil is in the handle or i fit is properly tightened
or if the working coil is not damaged of the isolation.
White light is
on
Working light
Working light for better visibility of the working material and
space.
7POSSIBLE PROBLEMS AND TROUBLESHOOTING
KMi heater X175 is designed and constructed so that when an overload occurs, there is a
temporary turning off, which is indicated by the flashing of the LED on the handle.

14
The induction coils do not have any thermal protection and thus they are not protected against
overload. The operating cycle of the induction coils is set for 1,5 minutes of activity - heating and 1,5
minutes of cooling.
If the device stops working, check that it is properly connected with the electric network and also
check the plug connector and socket, the fuses or breaker. Check the value of the supplied network
current. Also make sure that the incoming and connection cable (if you use it) is not damaged. Let
the device cool off for at least 10 minutes and then reconnect it. If the problem persists, contact your
supplier.
Usage of an inappropriate extension cable (too long, small diameter of wires) can cause insufficient
power of the device - see the safety regulations.
In case of other problems contact your supplier.
8STORAGE AND MAINTENANCE
8.1 COOLING, DISMANTLING AND STORAGE
After completion of heating, make sure that the coil holder and coils used are placed in a safe
place. Handling the device or its parts before letting it cool down can result in injury, damage to the
equipment or fire.
After completion of heating, leave the device turned on for 10 more minutes – the device will be
cooled down by fans until cooled off completely and then will turn off the fans. Then shut it down by
the main power switch and disconnect it from the power supply.
If you unplug the unit immediately, let all working coils cool down for at least 15 minutes.
After cooling, place the device and its accessories in the case. Place the cords so as to avoid their
sharp bending or twisting – it could cause their damage.
Always use the air pressure device to blow up all the dust and small parts of the metal to prevent any
damage of the induction heater. Do not open the cover of the device! Only person after the training.
8.2 PROPER CLEANING AND MAINTENANCE
Make sure the device is turned off, unplugged and cooled. Use a dry, clean cloth or paper towel
to remove grease, oil and other impurities from the machine. Use freely available non-volatile
cleaning agents for grease, oil and dirt that is difficult to remove. Before the first reuse of KMi heater
X175 allow all components to air dry.
Do not immerse any part of the device in water or other liquids. Do not clean the components with
volatile organic compounds such as gasoline, benzene, kerosene, methyl ethyl ketone (MEK), fuel oil,
brake parts cleaners, paint and thinner remover, varnish removers, self-adhesive solvents, etc. These
substances cause fire and cause hardening or dissolving of polymeric materials used in the device.
Do not use heat sources, heaters, burners, microwave ovens or gas furnaces, etc. for drying the
device and its parts after cleaning.

15
9WARRANTY
Machine warranty period is determined by the manufacturer for 12 months from the sale of
machinery buyer.
Warranty period begins on the date of de-livery of the machine to the purchaser, or the possible
delivery date.
The warranty period does not cover expendable parts –coils. Warranty period does not include the
period from the application of a legitimate complaint until the machine is repaired.
Content of the guarantee is responsible for the delivery of machines at the time of delivery, and the
warranty period will have the characteristics laid down by mandatory specifications and standards.
Responsibility for defects that occur after the machine sold under warranty, consists in the obligation
of free defect removal machine supplier, or service organization authorized by the machine.
Condition of warranty is that the machine is used in a manner and for the purposes for which it is
intended. Such defects are not recognized extraordinary wear and damage due to insufficient care or
neglect seemingly insignificant defects.
For example, the defect cannot recognize:
Equipment damage due to inadequate maintenance,
Mechanical damage due to rough handling, etc.
The warranty does not cover damage due to failure to meet the obligations of the owner, his
inexperience, of impairments, failure to comply with the provisions referred to in the instructions for
use and maintenance, the use of machines for the purposes for which it is not intended, overloading
the ma-chine, even if temporary. Maintenance and repairs must be exclusively used by original
equipment manufacturer.
During the warranty period are not allowed any modifications or changes to the machine, which can
affect the function of each part of the machine. Otherwise the warranty will not be recognized.
Warranty claims must be applied immediately upon detection of manufacturing defects or material
defects, and that at the retailer.
If a warranty repair will replace the defective part, transferred ownership of the defective part to the
manufacturer.
9.1 NON WARRANTY CONDITIONS
1. The usage of the KMi heaterX175 in other way that is allowed by the manufacturer.
2. The usage of inappropriate working coils which are not being supplied by the
manufacturer.
3. The usage of another isolation than is recommended by the manufacturer.
4. The damage due to the overloading the device.
5. Manual damage of the device and its components by the user.
6. The other non specified manual or technical damages made by the user.
7. Damaging of the overvoltage protection components.

16
10 WARRANTY SERVICE
Warranty service can be performed only by a trained service technician authorised by KM
Equipment s.r.o.
Before performing warranty repairs it is necessary to check the data of the machine –the date of
purchase, serial number, machine type. If the data are not consistent with the conditions for the
recognition of warranty repairs, for example, expiry of the warranty period, improper use of the
product contrary to the instructions for use, etc., it is not a warranty repair. In this case, all costs
associated with the repair shall be borne by the customer.
11 DISPOSAL OF USED EQUIPMENT
These machines are built with materials that do not contain substances that are toxic
or poisonous to the user. For the disposal of waste equipment use the collection
points for the abstraction of used EEE. Do not dispose of the used equipment in
common waste.
12 TYPE OF COILS
Name
Metric
Code info
Code
induction coil direct
M6
14/M6
KMIC-006-D
induction coil direct
M8
21/M8
KMIC-008-D
induction coil direct
M10
23/M10
KMIC-010-D
induction coil direct
M12
26/M12
KMIC-012-D
induction coil direct
M16
32/M16
KMIC-016-D
induction coil direct
M20
38/M20
KMIC-020-D
induction coil direct
M22
47/M22
KMIC-022-D
induction coil side
M6
14/M6
KMIC-006-S
induction coil side
M8
21/M8
KMIC-008-S
induction coil side
M10
23/M10
KMIC-010-S
induction coil side
M12
26/M12
KMIC-012-S
induction coil side
M16
32/M16
KMIC-016-S
induction coil side
M20
38/M20
KMIC-020-S
induction coil side
M22
47/M22
KMIC-022-S
induction coil PAD
PAD60
PAD60
KMIC-PAD60
induction coil flexi 800
Flexi 800
FLEXI 800
KMIC-FLX800
induction coil flexi 1000
Flexi1000
FLEXI 1000
KMIC-FLX1000

17
Induction coil direct Induction coil side
PAD coil Focus coil Flexi coil Heating wire

18
13 CONSUMABLE SPARE PARTS
Number
Name
Ordering code
1
Induction coil
KMI-coil
2
Fastening screws
KMI-bolts
3
Handle for the induction coil
KMI-handle
4
Cable
KMI-cable
5
Cover
KMI-side cover

19
14 THE MEANING OF USED SYMBOLS
▪Usage restriction of the persons with the cardiac stimulator
or any other metal or electrical implant!
▪Usage only by the trained persons!
▪Danger of explosion!
▪Danger of fire!
▪Caution very strong intensity of magnetic field!
▪Caution strong heat device!
▪Before usage read the manual carefully.
▪Use the protective equipment –gloves, glasses.
▪Always use the protective clothes.
▪Use the protective respirators.
▪Use the protective working gloves.
▪Switch OFF the device while not in use and unplug from the
power of supply.
Caution! High voltage danger 1600V on the primary side of the transducer.
Caution! High current 300A on the secondary side of the transducer and on the
output of the device.
Do not open the cover of the KMI heaterX175 while working process.

20
15 POSSIBLE DEFECTS AND THE SOLUTIONS
Defect
Feature of the defect
Solution
The heated
material is not
being heated.
LED light on the handle is
flashing on RED.
When pushing the trigger on the
handle with the coil without any
load. Wrong coil or damaged coil,
coil without the exact number of
rounds or bad connection of the
coil.
Use the standard coil supplied by the manufacturer
and check the correct connection.
LED light on the handle is flashing
on RED.
When the device is being heating
with the working coil the
material, the protection of the
overloading is being activated.
Increase the distance between the material and the
working coil by using the bigger coil or getting the
coil slowly away from the material. When using the
flexi coil take of one round.
Heated material
is being heated
slowly.
The temperature of the heated
material is increasing slowly or
not at all.
Use another working coil approx. 10.. bigger than the
heated material. Check if the heated material is
ferromagnetic.
Check the connector where is the device plugged in if
there is enough power of 230V. Check if the power is
not from another power source such as generator or
DC/AC power device where is not the sinus current
but only quasi-sinus current or the power supply
device is not powerful enough!
Plug the device into another power of supply.
Check the prolonger cable for the interference.
If sorted out this issue the LED light on the handle
must be switched ON orange.
The orange cable
from the device
to the handle is
overheated.
The temperature of the cable is
higher than normal.
Check the induction heater KMi heaterX175 if i tis not
being overloaded for a very long period of time. Keep
the working time on 1,5min and the cooling time for
1,5min.
The heated
material is not
being heated.
LED light is flashing on RED. The
device is overheated.
Let the device KMi heater X175 to be cooled down
and control it all the time.
The LED light is switched on RED
even after the time 1,5min of
cooling down. LED light is not
being ON at all. The ventilators of
the device are being stopped. The
induction heater KMi heaterX175
has no reaction on the trigger.
There is some defect on the
device KMi heaterX175.
Send the induction heater KMi heaterX175 to the
service centre or directly to the manufacturer. Do not
use the device!
