Smith's Heating First Caspian EC Series Guide

Issue 001 - April 2020 | SmithsEP.co.uk | 1
Issue 001 | April 2020
ENGLISH | UK | IRL | SmithsEP.co.uk
Caspian-EC variants
with Smart Controls
Installation, commissioning
and user manual
60 | 90 | 120 | 150 | 180
EC Series Fan Convectors

2 | SmithsEP.co.uk | Issue 001 - April 2020
Introduction
These heaters must not be installed in wet rooms
or other high humidity areas.
These heaters are designed for use on standard
two-pipe pumped central heating systems with
a maximum water temperature of 86°C and a
maximum pressure of 6 bar (88lbs/in.).
Pipe connections to heat-exchanger are 22mm.
Flow and return connection must be observed,
see labelling.
These heaters are classied as a xed appliance
and the electrical connection should be via a 3A
fused spur. The fused spur must not be directly
below the heater but should be accessible after
completion of the installation. All heaters must
be earthed.
To avoid the possibility of vibration these units
must be tted to a at even surface.
Please note that the guarantee may be invalidated
if this product is not installed and used in
accordance with these instructions.
Note: 15mm pipe may be used for heating
capacities of up to 12kW. (This is subject to
compliance with CIBSE recommendations)
Contents
Introduction 2
Declaration of conformity 3
Symbols used in this guide 3
Important safety and installation instructions 4
Product dimensions 6
Control mounting 8
Wiring diagrams 9
Product performance 10
Mounting options 12
Installation 14
Installation - Remote smart controller 15
Commissioning 16
User guide for Wi-Fi thermostat 14
Getting started - programming
your thermostat 18
Maintenance 22
Fault nding 22
Accessories 23
Registering your product 23
Disposal 23
After sales and spares 23

Issue 001 - April 2020 | SmithsEP.co.uk | 3
Declaration of conformity
EC Declaration of conformity
We, Smith’s Environmental Products Limited
1-2 Blackall Industrial Estate
South Woodham Ferrers
Chelmsford
Essex CM3 5UW
Tel: [phone] Fax: [phone]
Declare under sole responsibility that the products:
Product name:
Caspian
Product range:
Caspian Smart Control Range - Caspian UV,
Caspian FF, Caspian EXT, Caspian SL, Caspian
TT, Caspian UVC sizes 60, 90, 120, 150 & 180
Conform to the following European
Union directives:
Low Voltage Directive 2014/35/EU
Safety of household electrical appliances:
EN 60335-2-80:2003, +A1:04 +A2:09
EN 60335-1:2012 +A11:14 +A13:17 +A14:19
+A1:19 +A2:19
Electromagnetic compatibility (EMC)
EN 55014-1:2017
ETSI EN300 328: V2.1.1:2016
EN55014-2:2015
This Declaration is made on behalf of Smith’s
Environmental Products Limited.
Salus controller
The Salus controller independently complies with
the essential requirements and other relevant
provisions of Directives 2014/30/EU, 2014/35/EU,
2014/53/ EU and 2011/65/EU. The full text of the
EU Declaration of Conformity is available at the
following internet address: www.saluslegal.com.
Symbols
This manual contains information and
prescriptions marked by the following symbols.
Ignoring these safety provisions
marked by the symbol “caution:
hazard” may endanger the safety
of people.
Ignoring these safety provisions
marked by the symbol “caution:
electricity” may endanger the
safety of people, as well as the
integrity of things.
The removal of the screws can
cause the output of hot uids
under high pressure from heating
system. Drain the system or close
the isolating valves.
High temperature surface. Take
utmost care to prevent people
from getting in contact with the
hot surfaces of the appliance.

4 | SmithsEP.co.uk | Issue 001 - April 2020
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
To guard against injury, basic safety precautions should be observed, including the
following:
1. Read and follow all safety instructions and all the important notices on the appliance
before installing, using and maintaining the appliance. Failure to do so may cause
personal injury or damage to the appliance or installation.
2. Always disconnect electrical supply before putting on or taking off parts and whilst the
equipment is being installed, maintained or handled. Never work with bare feet and/or
with wet hands.
3. A risk assessment should always be carried out prior to work, Correct PPE should
be worn.
4. To avoid possible electric shock, special care should be taken since water is used with
electrical equipment. Carefully examine the appliance before and after installation.
Do not operate the appliance if it has a damaged supply cord or enclosure, or if it
is malfunctioning or it is dropped or damaged in any manner. Inspect the appliance in
accordance with manufacturers instructions.
The appliance should not be electrically supplied if there is water on parts not intended to
be wet.
5. Risk of scalding. To avoid injury before any servicing operation wait until the water has
cooled inside the appliance. Do not touch the uid or the appliance when temperature
is higher than 60°C.
6. Improper use.
This is an appliance to be used in heating systems with clean water without
abrasive particles.
Do not use this appliance:
• With liquids other than water (e.g. ammable liquids, etc.) (EN60335-2-51);
• In locations where special conditions prevail, such as the presence of a corrosive or
explosive atmosphere (dust, vapour or gas) (EN60335-2-51);
• For other than intended use.
7. Installation.
The appliance must be mounted in a stable/xed position in a dry, well ventilated,
frost-free, waterproof and protected place, with sufcient ventilation around it. Make
sure that the appliance is securely and correctly installed before operating it and that
there is enough room around it for maintenance operations, dismantling, checking for
free inspection.
The maximum ambient temperature at which the appliance is to be used is 40°C
(EN60335-2-51).
Important safety and installation instructions
Prior to installation, read these installation and operating instructions. The installation and operation should
also be in accordance with national regulations and accepted codes of good practice.

Issue 001 - April 2020 | SmithsEP.co.uk | 5
8. Electrical connection
Important: Connection to the power supply must be effected by means of a xed
power cable via a two pole isolating switch (fused spur) with a minimum contact
opening of 3mm.
The fused spur must not be directly below the heater but should be accessible after
completion of the installation. All heaters must be earthed.
Electrical connection must be carried out by a qualied electrician and in
accordance with local regulations and both data on the name-plate and the
appropriate diagram inside the terminal box cover.
Follow all safety standards.
9. Connect the appliance only to a mains supply protected by a Residual Current Device
(RCD or Ground-Fault Circuit-Interrupter) with a rated residual operating current not
exceeding 30mA.
10. Prior to any modication being made to the equipment, it must be agreed with and
authorised by the manufacturer. Original spare parts and accessories authorised by the
manufacturer are integral part contributing to the safety of the equipment and of the
appliance. The use of non original components or accessories may endanger the
safety and causes the termination of the warranty. Safe operation is only assured for
the applications and conditions described in Application of this manual.
Non-observance of the safety instructions results in the loss of any claims to damages.
The indicated limit values are binding and cannot be exceeded for any reason whatsoever.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

6 | SmithsEP.co.uk | Issue 001 - April 2020
Product dimensions
11065 45
245
660
270
A
Electrical supply in this side
Model A
60 595
90 895
120 1195
150 1495
180 1795
Pipe centres
11065 45
235
660
270
A
Electrical supply in this side
Model A
60 595
90 895
120 1195
150 1495
180 1795
Pipe centres
Caspian UV Caspian SL
11066 45
235
660
135
A
Electrical supply in this side
Model A
60 595
90 895
120 1195
150 1495
180 1795
Pipe centres
480
140
176
11065 45
235
660
270
A
Electrical supply in this side
Model A
60 595
90 895
120 1195
150 1495
180 1795
Pipe centres
Caspian TTCaspian FF

Issue 001 - April 2020 | SmithsEP.co.uk | 7
11065 45
235
1800
270
A
Electrical supply
in this side
Model A
60 595
90 895
120 1195
150 1495
180 1795
Pipe centres
Caspian EXT

8 | SmithsEP.co.uk | Issue 001 - April 2020
Control mounting options/congurations
Predetermined at time of order
Internally mounted
(tamper proof)
Wall mounted
(remote)
Flush mounted

Issue 001 - April 2020 | SmithsEP.co.uk | 9
Wiring diagram
MAINS SUPPLY
ENL
L3 NEL1 L2
WAGO Series
Connection
862 Block
EC DC
Filter
LTC
COM NO NC
A1
A2 RELAY
HF105F-4
M
PSU(230VAC/24VDC)
DRIVER
LN V2V1 F3F2F1
S1 CS2
MOTORISED
VALVE
GREEN
GREEN
GREEN
GREEN
GREEN
BLUE
BLUE
BLUE
BLUE
BLUE BLUE
BLUE
BLUE
BLUE BLUE
BLUE
BLUE
BLUE
BLUE
BLUE
RED
RED
RED
RED
GREY
GREY
GREY
WHITE
WHITE
WHITE
BROWN
BROWN
BROWN
BROWN
BROWN
BLUE
BLUE
BLACK
BLACK
BLACK
BLACK
BLACK BLACK
BLACK
BLACK
BLACK BLACK
BLUE
YELLOW
YELLOW
RED
GREY
GREEN
RED
RED
BLACK
RED
BROWN
0 10V
FAN
BROWN
BROWN
BROWN
BROWN
BROWN
BROWN
BROWN
BROWN
BROWN BROWN
Master Slave
0
10V MASTER SLAVE
CONNECTION

10 | SmithsEP.co.uk | Issue 001 - April 2020
Product performance
Heat output - EC
Model
Control Voltage VDC Heat Output at 80° Heat Output at 75° Heat Output at 70°
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
CASPIAN 60 3.80 5.65 7.50 3.2 4.5 5.9 2.9 4.0 5.0 2.6 4.0 5.0
CASPIAN 90 3.40 5.45 7.50 5.2 7.7 10.3 5.0 7.0 10.0 4.0 7.0 9.0
CASPIAN 120 4.94 6.77 8.60 9.0 11.8 14.5 8.0 11.0 13.0 7.0 10.0 12.0
CASPIAN 150 4.70 6.65 8.60 11.7 15.6 19.6 11.0 14.0 18.0 10.0 13.0 16.0
CASPIAN 180 4.70 6.65 8.60 16.3 21.3 26.2 15.0 19.0 24.0 14.0 17.0 21.0
Model
Heat Output at 65° Heat Output at 60° Heat Output at 55° Heat Output at 50°
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
CASPIAN 60 2.3 3.2 4.2 2.0 3.0 4.0 1.7 2.0 3.0 1.4 1.9 2.5
CASPIAN 90 3.9 5.9 8.0 4.0 5.0 7.0 3.0 5.0 6.0 2.6 3.9 5.3
CASPIAN 120 6.6 8.6 10.6 6.0 8.0 9.0 5.0 6.0 8.0 3.9 5.4 6.9
CASPIAN 150 8.8 11.8 14.7 8.0 10.0 13.0 7.0 9.0 12.0 5.9 7.9 9.9
CASPIAN 180 12.3 15.2 18.2 11.0 13.0 16.0 9.0 11.0 13.0 7.7 9.4 11.2
Model
Heat Output at 45° Heat Output at 40°
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
CASPIAN EXT 60 1.1 1.5 1.9 0.8 1.0 1.2
CASPIAN EXT 90 2.0 3.0 4.1 1.5 2.2 2.9
CASPIAN EXT 120 3.0 4.2 5.4 2.1 3.0 3.9
CASPIAN EXT 150 4.9 6.6 8.3 3.9 5.3 6.8
CASPIAN EXT 180 6.1 7.5 9.0 4.4 5.6 6.8

Issue 001 - April 2020 | SmithsEP.co.uk | 11
Heat output - EC
Model
Air Volume (m3/h) Air Volume (l/s) Total Power Consumption
Flow & return
connections
Fused
spur
Low
(kW)
Med
(kW)
High
(kW)
Low
(kW)
Med
(kW)
High
(kW)
Low
(Watts)
Med
(Watts)
High
(Watts)
CASPIAN 60 22mm 3A 201.0 290.5 380.0 55.9 80.7 105.6 8.0 24.0 40.0
CASPIAN 90 22mm 3A 297.0 450.5 604.0 80.7 124.4 168.0 15.0 42.5 70.0
CASPIAN 120 22mm 3A 512.0 692.0 872.0 142.2 192.2 242.2 41.8 75.9 110.0
CASPIAN 150 22mm 3A 566.7 789.9 1013.0 157.4 219.4 281.4 59.2 118.1 177.0
CASPIAN 180 22mm 3A 656.0 914.1 1172.2 182.2 253.9 325.6 74.5 147.2 220.0
Heat output testing based on BS EN442 using
mean water temperature, 18°C entering air
temperature, 10° temperature drop.
Mean water temperature °C
EAT°C 80 to 40
15 1.10
21 0.93
Correction factors
Temperature drop °C
20 15 10 5
Factor 0.89 0.95 1.00 1.04
How to calculate Mass Flow Rate (L/S) How to calculate Mean Water Temperature (∆T)
Flow temperature +
Return temperature
2
M = H / CP x (Flow °C – Return °C)
M = Mass ow rate (L/S)
H = Output of product (W)
CP = Specic heat capacity [J/(kg·ºC)]. Varies upon system
temperature, Approx. 4187 if uid is water.
Mean water
temperature (∆T)
- Ambient
Temperature
Model
Water
Capacity
(Litres)
Hydraulic resistance (KPA)
Low
(kW)
Medium
(kW)
High
(kW)
CASPIAN 60 0.92 1.4 1.7 2.0
CASPIAN 90 1.50 4.7 5.8 7.0
CASPIAN 120 2.08 17.8 20.6 23.4
CASPIAN 150 2.58 22.2 36.7 51.2
CASPIAN 180 3.18 47.8 73.7 99.6

12 | SmithsEP.co.uk | Issue 001 - April 2020
➠
➠
➠
➠
➠
➠
Floor
Wall
Ceiling (centre)
Caspian UV Caspian SL
Caspian FF Caspian TT
Floor
Wall
Floor
Wall
Floor
➠
➠
➠
➠
➠
➠
➠
➠
➠
➠
➠
Ceiling (edge)
➠
Mounting options
➠
➠
Ceiling (centre) ➠
➠
Ceiling (centre)
➠
➠
Caspian EXT
➠
Floor
➠
CASPIAN EXT
CEILLING
FLOOR
Wall mounted
thermostat
1.5m
Wall mounted
thermostat position -
1.5m from oor
1.5m
*
Control options depend upon the product
location.
Flush mounted and Internal mounted control
options are suitable for floor standing and other
low applications.
Wall mounted remote control option should be
used for *wall and ceiling mounted applications.
It is possible to have reverse air flow on low level
units (Entering air in via the upper grille top and
exiting air out via the lower grille) a wall mounted
remote control option should be used in this
instance.
Wall mounted remote controllers should be
positioned 1.5metres from the floor without
direct solar radiation or other heat or
refrigeration sources
*
*
*
*
*
*
*

Issue 001 - April 2020 | SmithsEP.co.uk | 13
Notes

14 | SmithsEP.co.uk | Issue 001 - April 2020
1. Unlock the front access panel
Unlock and lower the front access panel using the
keys supplied. The keys come cable tied to the
back of the heater.
2. Fix unit to wall or ceiling
Fix the unit to the ceiling or wall via suitable
xings. If tted to suspended ceilings or similar
then suitable means of support such as threaded
rods or chains must be used.
3. Connect the pipes
Connect the heating system ow and return
pipes to the heater pipe work. Pipe entry/exit can
be made through either the back of the unit or
by using the pipe knockouts on the bottom of
the unit. Do not use soldered ttings to connect
the heater pipe work as the heat generated may
cause damage to internal wiring and components.
Compression ttings should be used. Pipework
must only enter in intended cut outs or knockouts
on the header connection side of the heater.
Note: 15mm pipework suitable for heating
outputs up to 12kW, 22mm should be used
where output exceeds 12kW (this is subject to
compliance with CIBSE recommendations).
Installation
Note: The system must be ushed prior to tting
this heater. Failure to comply with this may effect
the warranty.
Isolating valves must be tted. We recommend the
use of full-ow service valves. The valves should
be accessible after completion of the installation.
We also advise the tting of an air vent at the
highest point on either the ow or return pipe
to remove any air trapped within the system.
Valves must have the ability to regulate ow for
balancing.
4. Open the service valves
Having lled the heating system with water, open
the full ow service valves and check for water
leaks. Remove any trapped air from the unit via
the built in bleed screws as shown in the diagram
below.

Issue 001 - April 2020 | SmithsEP.co.uk | 15
Installation -
Remote smart controller
for Smart ush and integral control models
continue to page 16.
1. Ensure power supply is switched off
2. Remove the mounting plate from the controller
by inserting a small screwdriver into slots at
base of controller. See Fig 2.
3. Fix the mounting plate to the wall using either
a recessed or surface mounted back box using
the screws provided. See g 3.
4. Connect power supply, connect wires into the
appropriate terminals on the controller.
See Fig 4.
F3 F2 F1 V2 V1 NL
SALUS
FC600
S2 COM S1
60
44
87
56
87
47
50
17
30
OR
ON OFF ON OFF
ON
OFF
F3 F2 F1 V2 V1
NL
SALUS
FC600
S2 COM S1
UP
60
Fig. 4
Fig. 1 Fig. 2
Fig. 3
Fig. 5 Fig. 6
3 Amp
fused spur
Supply
LN
5. Electrical supply and electrical
connection
Electrical supply to the unit must be nominal
230VAC 50~Hz.
Electrical connection to the product is via a 3 way
terminal block inside the product (L, N, E), on
electrical panel.
Connect the power supply from the fused spur (3
Amp) to the heater terminal block marked Supply
E N L via the cable entry hole in the top chassis of
the heater.
The fused spur must not be directly below the
heater and must be accessible after the installation
is complete.
All electrical work should be carried out in
accordance with current IEEE regulations.
5. Fasten body of thermostat and the mounting
plate. See Fig 5.
6. When using external pattress box assemble as
shown. See Fig 6.

16 | SmithsEP.co.uk | Issue 001 - April 2020
Commissioning
1. Turn on the electrical supply at the fused spur.
2. Set the thermostat to maximum using the
increase button on the controller.
3. Turn on the central heating system.
4. Balance the central heating system to ensure
the correct system ow rate is achieved.
5. If the installation is working correctly
remember to reset the thermostat control to
its normal setting.
6. Set the fan speed control to the desired setting
(low, medium or high) using the fan speed
button on the controller.
7. Internal mounted (tamper proof) models only.
Close the front access panel, ensure this is
secure and locked in place with the keys
provided.
8. This Installation and User Guide must be left
with the user for future reference.
Remote sensor wiring
Remote sensor may be used where the thermostat
will remain internally to the unit. See wiring
diagram S2 and C connections.
Master/slave wiring, hard wire
A number of units may be controlled from one
thermostat. For connection details please see
wiring diagram on page 9.
Note:
Maximum units: 4
Maximum total distance (Cable): 40 metres Heating operation
Ensure the central heating system is ON. Switch on
the power supply to the unit. Set the thermostat
control to the desired temperature.
Providing the water temperature in the central
heating system is more than 38°C (Standard LTC
only) and the thermostat is calling for heat the
product will switch on.
Connecting remote smart
controller to the heater
1. Feed the connector end of the wire harness
through the cut outs in the back or underside
of the unit.
2. Plug in the wire harness connector block to the
female connector block situated on the heater
electrical; panel as shown in Fig 7.
3. Connect the earth connector to the earth tag
on the wiring panel adjacent to the connector
block as shown in Fig 7.
Fig. 7

Issue 001 - April 2020 | SmithsEP.co.uk | 17
A SALUS FC600 is a device suitable for controlling
your Caspian unit in 2 pipe systems and for
managing the temperature in your home and/or
working environment. For an internet connection
(Online Mode), this product must be used with
the SALUS Universal Gateway Hub (UG600/
UGE600) - available as an accessory product code:
HACA33130 and SALUS Smart Home App
You can also use the SALUS FC600 without an
internet connection (ofine mode). Go to
https://salus-controls.com/uk/product/fc600/#downloads
for the full PDF version of the manual.
Quick user guide for Wi-Fi
Thermostat Key Function
Increase Button
Decrease Button
Fan Speed Low, Medium, High, Auto, Off
Mode
Button
Short press Long press
(2sec)
Digital Heat/Cool/Eco
selection Offset, Time
Program-
mable
Permanent override
AUTO
Heat/Cool/Eco
selection
Programmable
scedule
Offset
Time&Date
Short press: Conrm function
Long press (2 sec): Activate/deactivate standby mode
Button functions
M
M
M
M
M
Complete setup instructions for the control can be
found at:
https://salus-controls.com/uk/product/fc600/#downloads

18 | SmithsEP.co.uk | Issue 001 - April 2020
1 2 3 4 5 6
13
1718 16 15 14
725
24
23
22
21
20
19
12
10
11
9
8
1. Auto heat/cool selection
2. Schedule icon
3. Permanent/temporary override
4. Fan is running(icon is animated)
5. Fan speed (low, medium, high, Auto, OFF)
6. Wireless communication with the Universal
Gateway
7. FC600 is connected to the Universal Gateway
and Internet
8. Temperature unit
9. Heating Mode ON
10. Cooling Mode ON
11. Standby mode
12. Occupancy/vacancy sensor
13. Lock function
14. AM/PM
15. Eco Mode
16. Current day of the program
17. Filter needs to be replaced
18. Current time
19. Sensor indicators
20. Timer icon
21. Program number
22. Sensor indicators
23. Sensor indicators
24. Room/setpoint temperature
25. Setpoint temperature indicator
Schedule
Mode
Temporary
Override
Permanent
Override
M
M
M
LCD Icon descriptions Getting started
All units are factory congured in off-line stand
alone mode and tested for function when built.
Should your unit require setup from storage or
reconguration to “Smart Home” App control
follow the steps below to ensure successful setup
and operation.
1. Setup as stand alone control
(Conrm unit function)
2. Connect to “Smart Home” App
Requires Universal Gateway Hub (UG600)
available as an accessory product code:
HACA33130
Note: These instructions demonstrate settings
and setup required to work with our appliance.
Complete setup instructions for the control can
be found at:
https://salus-controls.com/uk/product/fc600/#downloads
or use the QR code below:

Issue 001 - April 2020 | SmithsEP.co.uk | 19
M
M
M
M
10
11 12
You are now in
Standby Mode.
Press UP/DOWN to
select the operating
mode to .
Press to conrm.
Success!
Installation completed.
3
9
2 Sec
1. When powered for the rst time the control
will boot (Software version will appear) after a
sort time the display will change to show
“U9 - Yes”
2. This should be “U9 – No” by pressing the up
arrow, followed by the tick/conrm button.
See image 1 and 2.
M
M
M
M
8
65
7
MM
3 4
4
5. Select the thermostat mode, although this unit
is heating only by setting heating and cooling
allows the use of fan only/ventilation
if required. See images 9 and 10.
M
M
M
M
M
3. The next screen display “USE – 2 Pipe”
Change this to “4 Pipe” and conrm
parameters (Note: 4 Pipe setting is required to
allow fan only function). See images 3 and 4.
MM
1 2
4. Set the S1 and S2 parameters as shown:
S1 - noFN (No Function)
S2 - S2sens (External Temperature Sensor)
Press and hold for
2 seconds
M
M
M
M
M

20 | SmithsEP.co.uk | Issue 001 - April 2020
Changing from ofine
mode to online mode
If you want to use the internet App and the
Universal Gateway Hub UG600 (available as an
accessory product code: HACA33130), you need
to change your thermostat settings from ofine
mode to online mode. For that please follow the
steps below:
M
2
2 Sec
2 Sec
2 Sec
M
1
M
6
M
5
4
MM
3
M
M
Press from the App and
follow the on screen instructions.
You’re now in
Standby Mode.
Set up your device
on the App.
7 8
Note: To view detail of set up, operation and
parameters, please consult the full manual at:
https://salus-controls.com/uk/product/fc600/#downloads
Temporary override
M
2
Note: The temporary
override will be
active until the next
program starts.
You can cancel the
temporary Override
by pressing
M
M
1
3
M
5
M
4
M
Press OK once then press and hold 3 buttons
for 2 seconds.
The digits on the screen will ash. Using the up/
down keys enter pass 55 then click OK.
Press Ok and then short press button to
conrm pairing.
Scan for equipment
To temporarily override and cause the heater to
function follow steps 1-5. This should be used
during the commissioning process.
