INSTALLATION & MAINTENANCE MANUAL
FLFxx / FLFxxW Series
IP
65
230V
50Hz

These instructions should be read carefully and retained after installation by the end user for future
reference and maintenance.
These instructions should be used to aid installation of the following products;
FLF10 / FLF20 / FLF30 / FLF50 / FLF80 / FLF100 / FLF20W / FLF30W / FLF50W
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• Installation of this luminaire should only be carried out by a qualified electrician or competent
person to the latest Building and current IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress of Protection) rating of this luminaire when deciding the location for
installation
• This product is Class I and requires an earth
• This product is non-dimmable
• This product is IP65 rated
• Provide power to the required point of installation. Suitable IP rated junctions boxes should be
used where required
• Remove the bolts either side of the base mounting bracket and remove bracket (see Fig 1)
• Using the mounting bracket as a template, mark the location of the fixing holes and drill the
holes ensuring not to infringe with any joists, gas / water pipes or electrical cables
• Carefully wire as shown in Fig 2
Fig1
Bolt
Mounting bracket

• Attach luminaire to the base mounting bracket and adjust to the desired angle
• Switch on and check for correct operation
GENERAL
WARRANTY
WARNING
The LEDs fitted in this product are non-replaceable. The unit should be recycled in the correct
manner when it reaches the end of its life. Check local authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the product.
If this luminaire is being used with an external PIR sensor, please confirm with the manufacturer of
the sensor that they are compatible with LED luminaires.
This product has a warranty of 3 years from date of purchase. Failure to install this product in
accordance with the current edition of the IEE Wiring Regulations, improper use, or removal of
the batch codes will invalidate the warranty. If this product should fail within its warranty period it
should be returned to the place of purchase for a free of charge replacement. ML Accessories does
not accept responsibility for any installation costs associated with the replacement product. Your
statutory rights are not affected. ML Accessories reserve the right to alter product specification
without prior notice.
This product must be disconnected from the circuit if subjected to any high voltage or insulation
resistance testing. Irreparable damage will occur if this instruction is not followed.
This product is unsuitable for installation in or near coastal and marine environments.
Do not use any source of high pressure washers to maintain or clean this luminaire.
Live (brown)
Neutral (blue)
Earth (green & yellow)
Fig2
