Knightsbridge OP9R Instruction Manual

INSTALLATION & MAINTENANCE MANUAL
OP9R

These instructions should be read carefully and retained after installation by the
end user for future reference and maintenance.
These instructions should be used to aid installation of the following product:
OP9R
GENERAL INSTRUCTIONS
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring
Regulations (BS7671) and current Building Regulations. If in any doubt, consult a
qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this product is fitted) does not exceed
the rating of the circuit cable, fuse, or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location
for installation
• Do not overload this accessory or subject it to conditions outside its rating
• This product is Class I and must be earthed
• This product is IP66 rated

INSTALLATION & MAINTENANCE MANUAL
These instructions should be read carefully and retained after installation by the end user for future reference
and maintenance.
These instructions should be used to aid installation of the following product:
OP9R
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this product is fitted) does not exceed the rating of
the circuit cable, fuse, or circuit breaker
•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
•Do not overload this accessory or subject it to conditions outside its rating
•This product is Class I and must be earthed
•This product is IP66 rated
INSTALLATION
Note: the unit should be fixed to a rigid flat surface as unevenness could cause damage to the product or affect
operation
•Provide power to the required point of installation (refer to BS7671 for correct cabling methods)
•Remove the front assembly from the backbox and carefully lift off the gasket. Drill the required number
of fixing holes in the backbox (see Fig. 1)
•Using the backbox as a template, mark the location for, and drill the fixing holes ensuring not to
infringe with any gas/water pipes or electrical cables
Fig. 1
•The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is advised if the
unit is installed in a location subject to temperature fluctuations where a build-up of condensation may
occur. It is not advised if the unit will be subject to high-pressure jets, as drilling a drain hole will reduce
the IP rating. A 3-5mm hole should be drilled at the bottom back edge of the enclosure where marked.
If wiring in conduit to the bottom entry, then the drain hole should be drilled at the lowest point of the
conduit run not in the backbox
INSTALLATION
Note: the unit should be fixed to a rigid flat surface as unevenness could cause damage to
the product or affect operation
• Provide power to the required point of installation (refer to BS7671 for correct cabling
methods)
• Remove the front assembly from the backbox and carefully lift off the gasket. Drill the
required number of fixing holes in the backbox (see Fig. 1)
• Using the backbox as a template, mark the location for, and drill the fixing holes ensuring
not to infringe with any gas/water pipes or electrical cables
Fig. 1

Fig. 2
•Remove one or more of the pre-fitted blank plugs as required by pushing out from the inside and install
a suitable IP rated gland or adaptor (not supplied). For rear entry, cut or drill a 20/25mm hole where
marked and install a suitable IP rated grommet (not supplied). Unused cable entries must have the
blank plugs fitted
•Feed the mains cable into the unit and secure the base plate to the surface. The fixing holes are
slotted to allow some rotational adjustment
•Replace the gasket onto the backbox, then wire as shown in Fig. 3 ensuring that correct polarity is
observed: L - Live (brown), E - Earth (green/yellow), N - Neutral (blue)
Fig. 3
•An earth connection must be made to the earth terminal of the socket. Use green/yellow sleeving on
earth conductors that are not insulated. The earth terminal in the backbox is provided for convenience
and does not need to be connected
•Check all electrical connections are secure with no loose strands of cable
•Ensuring the gasket does not become damaged or pinched, fit the socket assembly onto the backbox,
taking care not to compress, damage or trap any cables, and secure with the screws provided - do not
overtighten
•Fit screw covers
•Switch on and check for correct operation
• The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is
advised if the unit is installed in a location subject to temperature fluctuations where a
build-up of condensation may occur. It is not advised if the unit will be subject to high
pressure jets as drilling a drain hole will reduce the IP rating. A 3-5mm hole should be
drilled at the bottom back edge of the enclosure where marked. If wiring in conduit to the
bottom entry, the drain hole should be drilled at the lowest point of the conduit run
not in the backbox
Fig. 2

Fig. 2
•Remove one or more of the pre-fitted blank plugs as required by pushing out from the inside and install
a suitable IP rated gland or adaptor (not supplied). For rear entry, cut or drill a 20/25mm hole where
marked and install a suitable IP rated grommet (not supplied). Unused cable entries must have the
blank plugs fitted
•Feed the mains cable into the unit and secure the base plate to the surface. The fixing holes are
slotted to allow some rotational adjustment
•Replace the gasket onto the backbox, then wire as shown in Fig. 3 ensuring that correct polarity is
observed: L - Live (brown), E - Earth (green/yellow), N - Neutral (blue)
Fig. 3
•An earth connection must be made to the earth terminal of the socket. Use green/yellow sleeving on
earth conductors that are not insulated. The earth terminal in the backbox is provided for convenience
and does not need to be connected
•Check all electrical connections are secure with no loose strands of cable
•Ensuring the gasket does not become damaged or pinched, fit the socket assembly onto the backbox,
taking care not to compress, damage or trap any cables, and secure with the screws provided - do not
overtighten
•Fit screw covers
•Switch on and check for correct operation
• Remove one or more of the pre-fitted blank plugs as required by pushing out from the
inside and install a suitable IP rated gland or adaptor (not supplied). For rear entry, cut or
drill a 20/25mm hole where marked and install a suitable IP rated grommet (not supplied).
Unused cable entries must have the blank plugs fitted
• Feed the mains cable into the unit and secure the base plate to the surface. The fixing holes
are slotted to allow some rotational adjustment
• Replace the gasket onto the backbox, then wire as shown in Fig. 3 ensuring that correct
polarity is observed: L - Live (brown), E - Earth (green/yellow), N - Neutral (blue)
Fig. 3

• An earth connection must be made to the earth terminal of the socket. Use green/yellow
sleeving on earth conductors that are not insulated. The earth terminal in the backbox is
provided for convenience and does not need to be connected
• Check all electrical connections are secure with no loose strands of cable
• Ensuring the gasket does not become damaged or pinched, fit the socket assembly onto the
backbox, taking care not to compress, damage or trap any cables, and secure with the
screws provided - do not overtighten
• Fit screw covers
• Switch on and check for correct operation
• For security, and to prevent unwanted tampering with the product, a lug feature with a
6mm hole is provided to accept a padlock or similar locking security device (not included)
To pair a remote control:
• Press the left switch on the socket until the indicator starts flashing, then release
• Press the “A” button on the remote. This will enact the pairing procedure for both sockets
To unpair an existing remote:
• Press and keep the left switch pressed, the indicator will flash and then it will turn off
completely
Changing the battery:
• Using a small flat-head screwdriver, remove the cover from the remote and take out the PCB
• Remove the old batteries and insert two new CR2016 batteries (see Fig. 4)
REMOTE CONTROL

Fig. 4
WARNING
To ensure continued safe and proper weatherproof operation, the unit must not be left with
the cover raised open or the catch left unlocked.
This product must be disconnected from the circuit if subjected to any high voltage or
insulation resistance testing. Irre parable damage will occur if this instruction is not followed
Please note that we do not recommend our 13A sockets be used for Electric Vehicle (EV)
charging for prolonged periods.
•For security, and to prevent unwanted tampering with the product, a lug feature with a 6mm hole is
provided to accept a padlock or similar locking security device (not included)
Remote control
To pair a remote control:
•Press the left switch on the socket until the indicator starts flashing, then release
•Press the “A” button on the remote. This will enact the pairing procedure for both sockets
To unpair an existing remote:
•Press and keep the left switch pressed, the indicator will flash and then it will turn off completely
Changing the battery:
•Using a small flat screwdriver, remove the cover from the remote and take out the PCB
•Remove the old batteries and insert two new CR2016 batteries (see Fig. 4)
Fig. 4
WARNING
To ensure continued safe and proper weatherproof operation, the unit must not be left with the cover raised
open or the catch left unlocked.
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed
GENERAL
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
The batteries in the remote are Lithium Ion and must be disposed of correctly. Please contact the local
authorities for the disposal of this toxic waste.
To clean the external surfaces, securely close the cover and use a damp cloth with a mild solution of detergent
and warm water only, do not use aggressive cleaning products or solvents which may damage the product. If it
is necessary to clean inside the cover, use a soft dry cloth only.
Do not use any source of high-pressure washers to maintain or clean this product.

WARRANTY
This product has a warranty of 1 year from the date of purchase. Failure to install this
product in accordance with the current edition of the IEE Wiring Regulations (BS7671),
improper use, or removal of the batch code will invalidate the warranty. If this product
should fail within its warranty period, it should be returned to the place of purchase for a
free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML
Accessories reserve the right to alter product specification without prior notice.
GENERAL
This product should be recycled in the correct manner when it reaches the end of its life.
Check local authorities for where facilities exist.
The batteries in the remote are Lithium Ion and must be disposed of correctly. Please
contact the local authorities for the disposal of this toxic waste.
To clean the external surfaces, securely close the cover and use a damp cloth with a mild
solution of detergent and warm water only, do not use aggressive cleaning products or
solvents which may damage the product. If it is necessary to clean inside the cover, use a
soft dry cloth only.
Do not use any source of high-pressure washers to maintain or clean this product.

Manufacturers Declaration of Conformity
For ML Accessories (Knightsbridge)
Electrical products in accordance with CE marking
ML Accessories Ltd. Declare that all products have been designed, manufactured, and tested in
accordance with the requirements of the relevant legislation
CE marking legislation
In Accordance with the following Directives:
2014/35/EU Low Voltage Directive
2014/30/EU EMC Directive
2014/53/EU Radio Equipment Directive
Including Legislation
1907/2006 REACH
2015/863 RoHS
2021/341 ERP
Safety Standards
Full individual declarations and specific safety standards applicable to relevant product series can be found on
our website www.mlaccessories.co.uk
We hereby declare that the equipment named above has been designed to comply with the relevant
sections of the above referenced specifications. The product complies with all essential requirements of
the directives.
Scott Brewer Catherine Connolly
Technical Manager CEO
ML Accessories Ltd. Unit E Chiltern Park, Boscombe Road, Dunstable. Bedfordshire, LU5 4LT
This declaration becomes invalid if technical or operational modifications are introduced without ML Accessories Ltd. written consent.

Manufacturers Declaration of Conformity
For ML Accessories (Knightsbridge)
Electrical products in accordance with UKCA marking
ML Accessories Ltd. declare that all products have been designed, manufactured, and tested in
accordance with the requirements of the relevant legislation
UKCA marking legislation
UK SI 2016 No. 1091 Electro Magnetic Compatibility Regulations 2016
UK SI 2016 No. 1101 The Electrical Equipment (Safety) Regulations 2016
UK SI 2012 No. 3032 Restriction of the use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012
UK SI 2017 No. 1206 Radio Equipment regulations 2017
UK SI 2021 No. 1095 The Ecodesign for Energy-Related Products and Energy
Information (Lighting Products) Regulations 2021
Included Legislation
UK SI 2008 No. 2852 UK REACH
UK SI 2013 No. 3113 WEEE
Safety Standards
Full individual declarations and specific safety standards applicable to relevant product series can be found on
our website www.mlaccessories.co.uk
We hereby declare that the equipment named above has been designed to comply with the relevant
sections of the above referenced specifications. The products comply with all essential requirements of
the directives.
Scott Brewer Catherine Connolly
Head of Technical CEO
ML Accessories Ltd. Unit E Chiltern Park, Boscombe Road, Dunstable. Bedfordshire, LU5 4LT
This declaration becomes invalid if technical or operational modifications are introduced without ML Accessories Ltd. written consent.

AVJUN22_V2
11
Supplied By:
(UK) Manufacturer
ML Accessories Ltd, Unit E Chiltern Park, Boscombe Road, Dunstable LU5 4LT,
www.mlaccessories.co.uk
(EU) Authorised Representative
nnuks Holding GmbH, Niederkasseler Lohweg 18,
40547 Düsseldorf, Germany,
Email: [email protected]om
