Knightsbridge LEDFR2 Instruction Manual

1
57
INSTALLATION & MAINTENANCE MANUAL
LEDFR2
IP
20
12V

2
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following product:
LEDFR2
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• Installation of this LED controller should only be carried out by a qualified electrician or competent
person to the latest Building and current IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit (including when this product is fitted) does not exceed the rating
of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress of Protection) rating of this product when deciding the location for
installation
• This product is Class III
• This product is IP20 rated
• Provide power to the required point of installation
• Position controller inbetween the LED driver and CCT LED Flex
• Using the power connector provided (CONDC), terminate to the secondary side of the driver
ensuring correct polarity is observed [positive (red +) negative (black -)]
• Plug the driver into the LEDFR2 controller via the provided power connector (CONDC)
• Terminate the CCT LED Flex to the secondary side of the LEDFR2 controller using the provided
push-fit connector (see Fig 1)
LEDFR2
Icons required; 12V and 24V, IP20
Image LEDFR2 (image from 15/12/17) and will need revised controller labels
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following product:
LEDFR2
SAFETY
•Installation of this LED controller should only be carried out by a qualified electrician or competent person
to the latest Building and current IEE Wiring Regulations (BS7671)
•Please isolate mains prior to installation/maintenance
•Check the total load on the circuit (including when this product is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
•Please note the IP (Ingress of Protection) rating of this product when deciding the location for installation
•This product is Class III
•This product is IP20 rated
INSTALATION
•Provide power to the required point of installation
•Position controller inbetween the LED driver and CCT LED Flex
•Using the power connector provided (CONDC), terminate to the secondary side of the driver ensuring correct
polarity is observed [positive (red +) negative (black -)]
•Plug the driver into the LEDFR2 controller via the provided power connector (CONDC)
•Terminate the CCT LED Flex to the secondary side of the LEDFR2 controller using the provided push-fit connector
(see Fig 1)
Fig 1
•Ensure the CCT LED Flex does not exceed the maximum wattage of the LEDFR2 controller
24V CCT LED Flex - up to 72W
•Switch on power supply and test for correct operation
Mains 230V
24V LED
driver
Fig 1

• Ensure the CCT LED Flex does not exceed the maximum wattage of the LEDFR2 controller
12V CCT LED Flex - up to 72W
24V CCT LED Flex - up to 144W
Please note: this controller contains 2 channels at a max. of 3A each
• Switch on power supply and test for correct operation
NOTE - LED driver voltage is dependent on the LED Flex requirement
3
REMOTE INTERFACE
SUPPLIED WITH
• 1 x control unit with connector - compatible with Knightsbridge LED Flex
• 1 x remote control
• 1 x 3V CR2025 battery (for remote)
WARNING
GENERAL
This product must be disconnected from the circuit if it subjected to any high voltage or insulation
resistance testing. Irreparable damage will occur if this instruction is not followed.
The unit should be recycled in the correct manner when it reaches the end of its life. Check local
authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the product.

4
ML Accessories Limited
LU5 5TA
www.mlaccessories.co.uk DEJUL18_V2
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in
accordance with the current edition of the IEE Wiring Regulations, improper use, or removal of
the batch codes will invalidate the warranty. If this product should fail within its warranty period it
should be returned to the place of purchase for a free of charge replacement. ML Accessories does
not accept responsibility for any installation costs associated with the replacement product. Your
statutory rights are not affected. ML Accessories reserve the right to alter product specification
without prior notice.
