VI1x6
Six room speaker-stereo interface
Installation instructions
Warning: To be installed and/or used in accordance with appropriate local electrical
codes and regulations.
Description: The Knöll VI1x6 six-channel speaker-stereo interfaces can safely
power two to six rooms of stereo speakers from one stereo amplifier or receiver.
Speakers can be similar or dissimilar and each will sound their best.
The VI1x6 stereo interface is also used to set individual volumes in each room.
Parallel or series speaker wiring is acceptable. Maximum power input is 150 watts
per channel. The VI1x6 features an incredible "ultra" music quality frequency
response of DC to 500,000 Hz +/-0.1dB at all power levels up to 200 watts due to
its transformer-freetopology.
Depending on the quantity and type of speakers chosen, the VI1x6 may offer the
amplifier impedance as low as 4 ohms,
so we suggest that your amplifier (or receiver) be rated for
4-ohm (or lower) operation. The VI1x6 is usually but does not have to be stacked
with the stereo equipment and does not need a power supply.
Basic System Layout and Pre-Wiring: The VI1x6 is usually stacked with the
stereo equipment. It may get warm or a bit hot, so it needs ventilation for maximum
power and longest life. Don’t cover or block the vent holes. Take care to mount it
away from anything that can be damaged by heat.
From each speaker run a fire rated two-conductor speaker wire, ideally 16 gauge or
larger for runs up to 33’ (10m) and 14 gauge or larger for longer runs to the VI1x6
stereo interface (or volume control then to the interface). To save time and money,
many installers run a four-conductor speaker wire from the volume control to the
stereo interface. If there is more than one pair of speakers connected to a single
VI1x6 room connection, wire the speakers in series or parallel whichever makes the
impedance closest to 4 or 8 ohms.
Do not attempt to make the final combined
speaker impedance less than 4 ohms.

If the VI1x6 is not
located next to
the stereo, run a
single fire rated
four-conductor (or
two two-
conductor) 14-18-
gauge speaker wire
from the stereo to
the VI1x6.
Connection to
Stereo Equipment:
Remove the VI1x6
four-position
speaker
connectors. The
stereo amplifier or receiver outputs (left and right) are connected to the VI1x6
connector labeled “INPUT”. Be very careful to observe the correct polarity. The
VI1x6 uses independent floating grounds so bridged amplifiers can be used safely.
Connection to Speakers: Remove the remaining VI1x6 four-position speaker
connectors. Connect the speakers or volume control inputs to any of the six
connectors labeled “ROOM” again strictly observing polarity. Check out or web site
www.knollsystems.com for information on series and parallel speaker wiring.
Operation: Except for individual volume control adjustments, the Knöll VI1x6 is
completely automatic and does not need any user adjustments after installation.
The VI1x6m can turn rooms of speakers on and off and set individual volumes as
desired in any combination.
Specifications:
Peak RMS power rating: 300 watts per channel (5 seconds)
Continuous RMS power: 150 watts per channel
Frequency Response: DC to 500,000 Hz at all power levels
to 350 watts +/- 0.1dB
Speaker types: Most speaker types are acceptable. Similar and dissimilar
speakers can be used on one interface and each will sound
their best.
Speaker wiring method: Series or parallel wiring is acceptable.
Speaker impedance: 4-16 ohms (single or multi-speakers)
Stereo Amplifier or
Stereo Receiver
"Speaker Outputs"
Room 6 with
stereo volume
control
Room 4
direct
connection
CAUTION:
VI1x6 MAY BE
WARM
Speakers
ROOM1
ROOM2
ROOM3
ROOM4ROOM5
ROOM6
R>
L> +
-
+
-
INPUT
+L- -R+

Grounds: Independent left/right grounds for
safe connection of all amplifier types
except tube or valve amps. See below.
Connection: Detachable screw terminals capable of 12-22 awg wire
Dimensions: 17" x 12" x 1.75" (43 x 30 x 4.5 cm)
Color: Black
Note: When using tube or valve amps, we suggest adding 150 ohm 3 watt resistors
in parallel across each amplifier left and right output.
Warranty
Knöll Systems warrants its products sold in the USA and Canada by authorized Knöll dealers to be free of defects in
materials and workmanship. This warranty extends for two full years from the date of purchase by the original
consumer. Any products returned to Knöll Systems and found to be defective by Knöll Systems within the warranty
period will be repaired or replaced at Knöll Systems option, at no charge. Knöll Systems will not be responsible for the
actual cost of installation or removal of the product, nor for any incidental or consequential damages. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to
you. This warranty gives you specific legal rights. You may have additional legal rights that vary from state to state.
The VI1x6 has no user replaceable parts.
Knoll Systems
145 Tyee Drive Point Roberts, WA 98281
11791 Machrina Way, #120 Richmond BC V7A 4V3
