Ko Propo EX-1 Mars User manual

1

2
Title Title Page Page
■ Table of Contents Click the page number to jump to that page.
■ Table of Contents 2
■ For Safe Operation 3
■ Getting Started 5
●Transmitter Assembly 5
●Transmitter Dismantling 5
■ Names of Parts 6
●ET Keys (1-5) and BT Button (1) 7
●Steering Wheel Adjustment 7
●Throttle Trigger Adjustment 7
●Throttle Trigger Position Adjustment 7
●ICS Port 7
●Headphone Jack 7
●Colored Grip and Pad Replacement 8
●Unit Connector 8
●Charger Jack 8
●Power Switch 8
■ Preparations 9
●Battery Installation 9
●Battery Level Warning 9
●Operation Alarm 9
●Battery Pack(Under Development) 9
●Countermeasures Against Noise 10
●Receiver Installation 11
●Pairing 11
●Fail safe Setting12
■ Procedures Prior to Operation 13
●Trim and Sub Trim Operation 14
■ Display and Control Method 15
●Basic Operations to Change Settings 15
●Startup Screen and Initial Screen 16
■Function Reference 17
●Main Menu 17
Model Menu(Model) 17
Model Select(MDL-Select) 18
Model Name(MDL-Name) 18
Model Copy(MDL-Copy) 19
Model Reset(MDL-Reset) 19
Steering Menu(Steering) 20
Steering Trim(ST-Trim) 20
Steering Travel(ST-Travel) 20
Steering Balance(ST-Balance) 21
Steering Sub Trim(ST-SubTrim) 21
Steering Trim Rate(TrimRate) 21
Steering Turn Speed(TurnSpeed) 22
Steering Return Speed(RetnSpeed) 22
Steering Punch(ST-Punch) 24
Steering Curve(ST-Curve) 23
Steering Reverse(ST-Reverse) 24
Travel Override(Travel Override) 24
Throttle Menu(Throttle) 25
Throttle Trim(TH-Trim) 25
Throttle High Point(TH-Point) 25
Throttle Brake(TH-Brake) 26
Throttle Sub Trim(TH-SubTrim) 26
Throttle Trim Rate(TH-TrimRate) 26
Throttle Turn Speed(TH-TurnSpeed) 27
Throttle Return Speed(TH-ReturnSpeed) 28
Throttle Punch(TH-Punch) 29
Throttle Curve(TH-Curve) 29
Throttle Reverse(TH-Reverce) 30
Throttle Drag Brake(TH-DragBrake) 30
Brake Override(Brake Override) 30
Throttle ABS(TH-ABS) 31
Throttle Acceleration(TH-Accel) 32
Throttle Auto-Start(TH-AutoStart) 33
Idle Up(IdleUp) 33
3CH/4CH Menu(3/4ch Menu) 34
Control Menu(Control Menu) 34
Control Mode(Control Mode) 34
2WAY(2WAY) 34
3WAY(3WAY) 35
5WAY(5WAY) 35
ANALOG(ANALOG) 36
4WS Mixing(4WSMix) 37
4WS Mixing Mode(4WSMix MODE) 37
4WS Mixing Left(4WSMix LEFT) 37
4WS Mixing Center(4WSMix CENTER) 37
4WS Mixing Right(4WSMix RIGHT) 38
4WS Mixing Travel(4WSMix TRAVEL) 38
4WS Mixing Reverse(4WSMix REVERCE) 38
4WS Mixing Key(4WSMix KEY) 38
Amp Mixing(AMP Mix) 39
Amp Mixing Mode(AMPMix MODE) 39
Amp Mixing Throttle Hold(AMPMix HOLD) 40
Amp Mixing High Point(AMPMix HIPOINT) 40
Amp Mixing Brake(AMPMix BRAKE) 40
Amp Mixing Reverse(AMPMix REVERSE) 41
Amp Mixing Trim(AMPMix TRIM) 41
Amp Mixing ET Mode Setting(AMPMix ET MODE SET) 41
Amp Mixing Key(AMPMix KEY) 41
Throttle Mixing(T-Mix) 42
Throttle Mixing Brake(T-Mix BRAKE) 42
Throttle Mixing Center(T-Mix CENTER) 42
Throttle Mixing High Point(T-Mix HIPOINT) 43
Throttle Mixing Reverse(T-Mix REVERCE) 43
Throttle Mixing Curve(T-Mix CURVE) 43
Throttle Mixing Delay(T-Mix DELAY) 43
Throttle Mixing Steering(T-Mix STEER) 44
Throttle Mixing On/Off(T-Mix ON/OFF) 44
Throttle Mixing Key(T-Mix KEY) 44
Quick Setup(QuickSetup) 45
Timer Menu(Timer Menu) 46
Stopwatch(StopWatch) 46
Countdown Timer(DownTimer) 47
Lap History(LapHistory) 47
Function Menu(Function Menu) 48
Monitor(Monitor) 48
LED Color(LEDcolor) 48
LCD Backlight(BackLight) 48
LCD Contrast(Contrast) 49
Sound Volume(SoundVol) 49
Buzzer(Buzzer) 49
Key Repeat(KeyRepeat) 49
System Menu(System Menu) 50
Response(Response) 50
Setup(Setup) 51
Direct Switch(DirectBT) 51
Adjust VR (ST)(SteeringAjustVR) 51
Adjust VR (TH)(ThrottleAjustVR) 52
Operation Timer(OP-Timer) 52
2.4G Band(2.4GBand) 52
Power Management(POWER MANAGEMENT) 53
All Reset(AllReset) 53
ICS(ICS) 53
Approval 53
●Warning Display 54
Battery Level Warning 54
■ Glossary 55
■ Specications 58

Duetothenatureofradiocontrolledmodels,improperhandlingmayleadtodangeroussituations.Thereforeplease
readthefollowinginformationcarefullyinordertoensuresafeoperation.PleasealsounderstandthatKOPropois
notresponsibleforanyinjuriesordamagewhichresultfromnoncomplianceofthesecautionsandnotices.
●WhenInstallingComponents
●NotesforUsage
●Makesuremetalpartsonthemodel(carchassis/shiphull)donotcomeintocontact
witheachother.
※Contactbetweenmetalpartsmayresultinnoise,whichcouldcausethereceiverto
malfunctionandleadtoanuncontrollablemodel.
●Donotcutorbundletheantennacable.
※Thismaylowerthereceiver'ssensitivityandleadtoanuncontrollablemodel.
●Ensurecorrectpolaritywheninstallingtransmitterandreceiverbatteries.
※Incorrectpolaritymaydamagetheproduct.
●Within Japan, this product is limited to usage with models which operate on the
groundorinthewater.
※Donotuseforothernon-designatedpurposes.
●Ensurethatallconnectors(receiver,servo,switch,etc.)areconnectedsecurely.
※Ifconnectionsbecomelooseduetovibrations,itmayleadtoanuncontrollablemodel.
●Securely attach receiver with thick double-sided tape and ensure that it does not
makecontactwithotherparts.
※Strong shocks or contact with other parts due to vibrations may lead to an
uncontrollablemodel.
●Checkservooperationtoensurethepushrodisnotsubjecttoexcessiveloads.
※Excessiveloadsmaydamagetheservoorincreasebatterypowerconsumption.
●Makesuretousetherubbergrommetwhenattachingtheservoandthattheservo
doesnotcontacttheR/Cequipmenttray.
※Ifvibrationsaffecttheservo,itmayleadtodamageoranuncontrollablemodel.
●UseinconjunctionwithgenuineofficialKOPropoproducts.
※KOPropoisnotresponsibleforanydamagesorinjurieswhichresultfromuseofthis
productincombinationwithothermanufacturer'sproducts.
●Donotusewhenthereisthunder.
※Itispossibleforlightningtostriketheantenna.
●Donotuseintherainorinareaswherewaterhasaccumulated.
※Ifwaterenterstheproductitmayleadtoanuncontrollablemodel.
●Donotuseinthefollowinglocations:
1.NearR/Ccircuits(within3km)
2.Nearcrowds,onstreets,ornearactualvehiclesorships.
3.Nearhigh-voltagepowerlinesorcommunicationfacilities.
※If signal interference, etc. causes an uncontrollable model, a serious accident may
result.
●Do not use when your concentration levels are compromised by tiredness, alcohol,
medication,etc.
※Mistakesinjudgmentmayresultinseriousaccidents.
●Donotallowglowenginefuelorengineexhausttocontacttheproduct.
※Thesemayattacktheplasticanddamagetheproduct.
●Checktoensurethattheselectedmodelmemorymatchesthemodeltobecontrolled.
※Usinganincorrectmemorymayleadtoanuncontrollablemodel.
●Makesuretostoptheengine(disconnectmotorcables)beforechangingtransmitter
settings.
Warning! Improperhandling/
usagemayleadtoahighprobabilityofmaterialdamageaswellasapossibilityof
seriouspersonalinjuryorevendeath.
Notice! Improperhandling/
usagemayleadtopersonalinjuryormaterialdamage.
Warning!
Enforcementmatters
Warning!
Prohibitedmatters
Warning!
Prohibitedmatters
Warning!
Enforcementmatters
3
■ For Safe Operation

●NotesAfterUsage
●
TransmitterBatteryHandlingandCharging(separatelyavailableoption)
Caution!
Enforcementmatters
Caution!
Enforcementmatters
Danger!
Enforcementmatters
Danger!
Enforcementmatters
●Donottouchengine,motor,ESC,etc.immediatelyafteruseastheymaybehot.
※Doingsomayleadtoburns.
●When switching on, always turn on the transmitter first, followed by the receiver.
Followthereverseorderwhenswitchingoff.
※Ifthewrongorderisfollowed,itmayleadtoanuncontrollablemodel.
●Dismantling or modifying the RF Module (internalized in the case of the EX-1) is
prohibitedandispunishablebylaw.
※Doing so may lead to accidents such as short circuits and KO Propo Customer
ServiceDepartmentmaynotacceptdismantled/modifiedproductsforrepair.
●Donotusethisproductinaircraft,hospitals,ornearfirealarmsormedicalequipment.
※Thismayleadtomalfunctionsandresultinseriousaccidents.Also,bylawyoumust
ceaseoperationiftheproductaffectsotherwirelessorelectricaldevices.
●2.4GHz transmitters must be registered with the Japan Radio Control Safety
Association.
※Thetransmitterwhichyouhavepurchasesisalreadyregistered.Productswhichdo
nothaveproofofregistrationareillegal.
●InthecaseofanR/Ccar,makesuretoremovethebatterypackafterdriving.
※Ifthecarisswitchedonaccidentally,itmayleadtoafireoranuncontrollablemodel.
●Keeptransmitters,batteries,andmodelsawayfromsmallchildren.
※Chemicalagentsandtheitemsthemselvesmaycausepersonalinjury.
●Removebatteriesfromtransmitterifitwillnotbeusedforaconsiderabletime.
※Ifbatteriesareleftinthetransmitter,batteryleakagemayresultindamage.
●Donotstoretransmitter/receiverinthefollowingconditions:
1.Extremelyhot(over40ºC)orcold(below10ºC)temperatures.
2.Locationsindirectsunlight.
3.Locationswithhighhumidity.
4.Locationssubjecttovibrations.
5.Locationswithlotsofdust.
※Theseconditionsmaycausethecasetodeformanddamagetheproduct.
●Nevershort-circuitthebatteryconnector.
※Thismayleadtoafireorexplosion.
●Donotdisposebatteriesinfires.
※Thisisverydangerousandmayleadtoanexplosion.
●UseKOPropochargerstochargethebatteryandusethecorrectcurrent(under1A).
※Incorrectcurrentmayleadtobatterydamage,overheating,orleakage.
※Othermanufacturer'schargersmaynothaveaautomaticcutofffunction.
●Donotsubjectthebatterytostrongshocks.
※Thismaydamagethebatteryandcauseleakageorashortcircuit.
●Donotdismantleormodifythebattery.
※Thismaycausedangerousleakageofbatteryfluids.
●Keepawayfromwater.Donotchargeawetbattery.
※Thismaycauseoverheatinganddamage.
●Donotchargealkalinebatteries.
※Alkalineandothersingle-usebatteriescannotberecharged.Doingsomayleadtofire
anddamage.
●Donotusewethandswhenplugginginthecharger'sACAdapter.
※Thismayresultinelectricalshocks.
※Ifthereisbatteryfluidleakage,avoidcontactwitheyesasitmayresultinblindness.Ifcontact
witheyesoccur,flushwithlargeamountsofwaterandseekmedicalattentionimmediately.
※Whendisposingbatteries,Ni-Cd,Ni-MH,Li-Po,andLi-Febatteriesshouldberecycledinorderto
helpprotecttheenvironment.
Warning!
Enforcementmatters
Caution!
Prohibitedmatters
4

①①
①
①
①
①
②
②
②
②
②
②
③
③
③③
5
■ Getting Started
Insert the Grip Unit into the Master Unit, then attach the
Steering Unit.
Detach the Steering Unit, then detach the Master Unit.
Tilt Display
(Raised Position) (Rotate to loosen)
Grip Unit
Master Unit
Master Unit
Steering Unit
Steering Unit
Antenna
●Transmitter Assembly ●Transmitter Dismantling
1.
1.
2.
2.
3. 4.
3.
Remove the connector cover before attaching.
If storing the transmitter in dismantled form, please remember to
attach the connector covers.
First detach the
antenna.
Steering Unit Release Button
Steering Unit Release Button
Steering Unit Lock Lever
Steering Unit Lock Lever
Grip Unit Lock Lever
Grip Unit Release Button
[Legend] P:Point :Notice

6
Antenna
Tilt Display
Direct Button
DBT 1-4(p.7)
Power Switch (p.8)
Charger Jack (p.8)
Multicolor LED
Steering Unit
Release Button (p.5)
Colored Grip
(p.8)
Colored Pad (p.8)
Guard Bar
Trigger Guard
Steering Unit
Lock Lever (p.5)
Back Key
Enter Key
Dial Guard
Jog Dial
Headphone Jack (p.7)
Open the cover
Open the cover
ICS Port (p.7)
Throttle Trigger (p.7)
Grip Unit Lock Lever
(p.5)
Grip Unit
Release Button (p.5)
Throttle Trigger
Position Adjuster (p.7)
Steering Wheel
(p.7)
ET1
(p.7)
BT1
(p.7)
ET2
(p.7)
ET4
(p.7)
ET5
(p.7)
ET3
(p.7)
■ Names of Parts
[Front View][Side View]
[Rear View]

7
●Steering Wheel Adjustment
●Throttle Trigger Adjustment
●
Throttle Trigger Position Adjustment
●ICS Port
●Headphone Jack
●ET Keys (1-5) and BT Button (1)
Adjust the tension of the steering wheel spring.
Attach audio plugs from commercially available headphones,
etc. (sold separately) to the transmitter. This feature helps
users hear the transmitter's operation sounds while in a noisy
pit area.
Functions may be assigned to the keys/button.
This port is used for the ICS USB Adapter HS (sold separately),
which enables the transmitter to connect to a PC. Special
software, which can be downloaded from KO Propo's website,
enables the setting and modication of the transmitter's model
memory from a PC. It also enables numerous model memory
settings to be saved onto a PC. Refer to KO Propo's website
for details on how to use this feature.
( http://www.kopropo.co.jp/sys/ )
Adjust the position and angle of the brake trigger to your
preferences.
The position of the throttle trigger may be adjusted to match the
user's hands.
Insert a 1.5mm hex wrench referring to the image below.
Rotate clockwise to increase tension and counterclockwise to
decrease it.
[How to Adjust]
Loosen the hex screws on the throttle trigger with a 1.5mm
hex wrench.
Freely adjust the brake trigger position.
Tighten the hex screws to secure.
Loosen two screws on the rear side of the transmitter.
Slide the Throttle Trigger Position Adjuster as desired.
Tighten the loosened screws to secure.
[How to Adjust]
[How to Adjust]
Excessive counterclockwise rotation will result in the wheel being
unable to return to neutral position. In this case, rotate clockwise
until the wheel returns to neutral.
Even when headphones are plugged in, sounds will still be emitted
by the transmitter itself. The headphone jack is monaural.
The possible functions which each key/button may be assigned to
are different.
The trigger may be loosened due to temperature, strong shocks,
or prolonged use. In this case, cementing the trigger in position is
recommended. If looseness persists, contact KO Propo Customer
Service Department.
Hex Wrench
Audio Plug
(Sold Separately)
Connect to PC
Throttle Trigger
Brake Trigger
Screws
Hex Screws
Ball Joint
Throttle Trigger
Position Adjuster

8
●Charger Jack
●Unit Connector
●Power Switch
A rechargeable battery can be recharged via the charger jack.
This product may be dismantled and therefore each unit
features their respective connectors. Dirty or damaged
connectors may result in malfunctions, so please handle them
carefully.
This product features a safety lock. The Master Unit and Grip
Unit cannot be detached when the Power Switch is in the ON
position. Turn off the transmitter before dismantling.
Conrm that the power switch is in the OFF position. If only
using the Grip Unit, make sure that the connector cover is in
place.
Make sure the battery is securely connected. If the
connection is loose, the battery may not charge completely.
Securely connect the charger plug to the charger jack.
Begin charging using a current of less than 1A.
[How to Recharge]
Make sure the power switch is in the OFF position when charging.
If only using the Grip Unit, make sure that the connector cover is in
place. A short circuit may occur if the connector makes contact with
metal and lead to a serious accident. Use a current of less than 1A to
charge. Do not connect/disconnect the battery during charging. Take
note of the charger plug's polarity in order to avoid damage.
Do not attempt to charge if using alkaline batteries. Doing so
may result in battery leakage or cracking which will damage the
transmitter.
[Discharging the Battery Pack]
If using a battery pack, please note that it cannot be discharged via
the charger jack. Remove the battery pack from the transmitter to
discharge it.
Do not touch the unit connectors with your ngers. If connectors
become corroded due to grime, they may become inoperable.
If storing the transmitter in dismantled form, please remember
to attach the connector covers. After prolonged use, a black
residue may build up on the connectors. Use cotton swabs dipped
in cleaning alcohol to remove. KO Propo's Customer Service
Department also handles transmitter maintenance.
●Colored Grip and Pad Replacement
Users can choose to install grips and pads of other colors (sold
separately).
Remove the two screws on each side of the grip to detach the
grip plates, then attach the colored grip and pad.
[How to Replace]
The tabs on the colored grip and pad are to be inserted into holes.
Note the direction.
Make sure the battery box or battery pack is removed before
replacing the colored grip and pad.
Note direction of the of the colored grip and pad.
Colored Grip
Colored Pad
Screws
Screws
Grip Plate
Grip Plate
AC 100V Charger
(Available Soon)
Quick Charger (Sold Separately)
Power Switch
Connector Cover

①①
①
①
②
②
②
②
9
■ Preparations
●Battery Installation ●Battery Level Warning
●Operation Alarm
●Battery Pack(Under Development)
Battery Box
1.
2.
3.
R03/AAA/UM4
Batteries (4pcs.)
Battery Box Cover
Press the tab on the bottom of the transmitter to open
battery box cover.
Remove the lock to pull out battery
box.
Install four R03/AAA/UM4 alkaline
batteries while noting their polarity,
then replace
battery box.
Use batteries which have adequate remaining capacity. Weak
batteries mean lower transmitting power and may result in
malfunctions.
Do not install Ni-Cd or Ni-MH batteries in the battery box.
(These may cause the battery connectors to corrode.)
The power source used may be set in Power Management. A
warning will be displayed and an alarm will sound when low
battery voltage is detected. When you see this warning, stop
your model in a safe area and install new transmitter batteries.
An alarm will sound after 3 minutes of transmitter idleness.
Operating the steering wheel, ET Keys, BT Button, Direct
Buttons, etc. will disable the alarm.
A rechargeable battery pack specific to the EX-1 is under
development. An announcement will be made on the KO
Propo website when it is ready for release. Thank you for your
patience.
[Warning Display on Startup]
[Warning Display During Use]
Operation of the transmitter's jog dial, buttons, or levers will
temporarily disable the low-voltage warning sound. The warning
will be displayed again after a certain amount of time has passed.
Voltage value is not display and display "Low".
Make sure to fully charge the battery pack before installing it.

CarbonFiberChassis
Noiseisgeneratedinanyareawherealargeamountof
electric current is flowing. Position the receiver and
antennacableasfarawayfromthemotor,battery,ESC,
andtheirassociatedcablesaspossible.(Metalorcarbon
fiber chassis components will also conduct electricity
andgeneratenoise.)
SinceR/Cmodelsarecontrolledviaradiosignals,taking
appropriate measures against noise generated by
on-board equipment is of utmost importance. Take
adequatemeasuresagainstnoisesothatyourmachine
canfullyrealizeyourdrivingpotential.

BatteryPack
Receiver
ESC SiliconCables
Motor
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Keepantennacableawayfromallsourcesofnoise!
When installing the receiver to the chassis or R/C
equipmentdeck/tray,usetwoormorepiecesofthick
double-sidedtapetoraisethereceiveroffthechassis
surface. By increasing the separation between the
receiverandthenoise-generatingcarbon-fiberchassis
components,theeffectsofnoisecanbedecreased.
Raisetheantennacableverticallyfromashighapositionaspossible.Inserttheantennacableintotheantenna
pipesothatthetipoftheantennaalignswiththeendofthepipe.Makethelengthofcablewhichrunsbetween
thereceiver and the pipeas short as possibleandposition the antenna holderas close to thereceiver as
possible. Position the antenna cable away from sources of noise such as the chassis and R/C equipment
deck/tray.Useanantennapipeandantennamountthataremadefromplastic,sincemetalpartswillconduct
noise.
Engine vibrations may damage the receiver. Make sure to attach a
grommet(receiverholder)toreduce theeffects ofsuch vibrations.Do
not attach the receiver directly to the chassis or R/C equipment
deck/tray with double-sided tape. Also position the receiver so that it
doesnotcontacttheheatandexhaustoftheengineandmuffler.
PlasticAntennaPipe PlasticAntennaPipe
PlasticAntennaHolder
Grommet
AluminumAntennaHolder
AluminumAntennaHolder
PianoWire
Double-SidedTape
AntennaCable
SignalReceivingSection
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Noise
Noise
(AcceptablewithFRP
orplasticchassis)
SolderedLugPlate
●ReceiverInstallationonaCarbonFiberChassis
●AntennaInstallation
●InstallingOntoaGlowEngineCar
※InstallthereceiversothatitsLEDsarevisible.
※InstallthereceiversothatitsLEDsarevisible.
※Donotbendorcuttheantennacable.
(Thismaybreaktheantennawireanddeteriorateits
performance.)
10
●Countermeasures Against Noise

BATT
11
●Receiver Installation ●Pairing
1.
2.
3.
4.
5.
Install the receiver, servo, and ESC (in the case of an
electric car) onto your machine and connect them. Install
the receiver while taking noise into consideration (p.10).
Install batteries into the transmitter's battery box (p.9).
In the case of an electric car, install battery pack. In the
case of a glow engine car, install battery for receiver.
For 2.4GHz systems, conduct pairing of the transmitter
and receiver (see right column).
In order for the receiver to operate, it must store the
transmitter's unique ID in its memory in a process called
“pairing.” Even if a single transmitter is used to control
multiple receivers, each receiver must go through the
pairing process with the transmitter before being used for
the rst time.
Adjust steering(p.20)and throttle/braking(p.25).
Set the Fail-Safe Function.
Preparing the Receiver
Connect the receiver power source
while pressing the setup button.
Check that the receiver's LED has lit
up, then release the setup button.
Check that the receiver's LED lights up
again (indicating pairing completion)
When pairing is complete, pressing
the ENTER key on the transmitter
will return the screen to the previous
[2.4Gband] menu.
Switch off the receiver, then switch it
back on again for normal operations.
The preparations below are to be carried
out following the pairing procedure.
Preparations for Operation
Switch off the receiver.
Press the ENTER key on the
transmitter, then press the BACK key
twice to return to the initial screen.
Switch on the receiver and check
that the receiver LED is lit. If the LED
ashes, the receiver is not getting
the transmitter signal and the pairing
procedure should be repeated.
Preparing the Transmitter
Switch on the transmitter.
Press the ENTER key at the startup screen. (Main Menu
display)
Use the jog dial to move the cursor to [System], then press
the ENTER key.
Move the cursor to [2.4Gband] on the System Menu
screen, then press the ENTER key.
Move the cursor to (START) on the 2.4Gband screen, then
press the ENTER key.
Images of the transmitter and receiver will display and the
arrow ow can be checked. (In this state, the transmitter is
transmitting the pairing signal.)
Carefully read the instructions included with the servo and
ESC before installing and using them.
During this process, your car may become uncontrollable if the
ESC has not been adjusted. As a precaution, set your car so that its
wheels do not touch the ground.
Pairing procedures may not go smoothly if there are wireless LAN,
microwave ovens, or other users conducting pairing procedures
nearby. In this case, move some distance away or wait a while
before attempting the pairing procedure again.
For items which are not included in this product, please refer to the
KO Propo website for a list of compatible products. (http://www.
kopropo.co.jp)
This transmitter is only compatible with digital servos. Correct
operation is not possible when used with analog servos.
1.
2.
3.
See p.52 regarding the 2.4Gband menu.
P
Lit LED
Lit LED
Flashing LED
●For an Electric Car
●For a Glow Engine Car
●Battery Pack
(Sold Separately)
●Motor
(Sold Separately)
●ESC (CH2)
(Sold Separately)
●Receiver (KR-411FH)
●Steering Servo (CH1)
(Sold Separately)
●Steering Servo (CH2)
(Sold Separately)
●Battery for Receiver
(Sold Separately)
●Receiver
(KR-411FH)
●Steering Servo (CH1)
(Sold Separately)

B
1
2
3
4
Transmitter ON
Receiver ON
Full brake
Neutral Hold the throttle
to the position
On the transmitter, hold the
throttle to the position you
would like it to be set to.
12
●Fail-Safe Setting
Fail-safe is when the receiver loses the radio signal of the transmitter
and the function keeps channel 2 (throttle) in an optional position.
The conguration is usually full brake or neutral.
This function works for only 2nd channel.
Turn on the transmitter.
Turn on the receiver and verify operation.
Recommended positions are the following :
Full Brake
●GP car
●EP car
(forward / Brake)
Neutral
●EP car
(forward / Back)
(forward / Brake / Back)
Press for 3 seconds
While holding the position, press
the setup button on the receiver
for 3 seconds.
Hold the setup button on the
receiver until the LED light goes
off and release the button. Fail-
safe setting is complete.
LED light goes off
Transmitter OFF
Turn off the transmitter. And the
device that connected into 2nd
Channel will move to the position
that you set up.
Please be sure to set the fail-safe.
If you change the position of the fail-safe operation, please set
again. We recommend to set it again even if you modify the car
engine brake linkage.

13
■ Procedures Prior to Operation
1.Switching On
After ensuring that it is safe to do so, switch on the transmitter followed by the receiver.
2.Model Conrmation
Conrm the model which will be used.
3.Checking Movements
With the model's wheels lifted off the ground, operate transmitter to check for proper
movement. While driving, use steering and throttle trims to make ne adjustments. Drive in a
gure 8 pattern to check steering balance.
This product uses the FHSS transmission system, which switches between frequencies in the2.4GHz range at a high speed.
FRANCE Mode needs to be selected if this product is to be used in France, while other countries should use GENERAL Mode.
(If the mode is switched between GENERAL and FRANCE, pairing procedure must be done with the receiver again.)
4.Switching Off
After a driving session, switch off the receiver, followed by the transmitter. Remove the
battery pack from the model.
After switching off, wait at least 5 seconds before switching on again to ensure proper operation.
An alarm will sound if the controls are idle for **minutes. Operate the transmitter to stop the alarm.
See[Trim and Sub Trim Operation] on the following page.
P
Use the [Quick Setup] function to easily arrange the initial settings.
P
Stand
Figure 8 Pattern
Trim

14
The sub trim is a convenient feature but it could also complicate the setting process if used incorrectly. Use the sub trim in the correct
manner while also referring to the sub trim operation instructions on p.21 and p.26.
[Purpose of the Trim]
When a servo is to be mounted onto a model, it is usually connected to the
receiver temporarily to enable the transmitter to check its neutral position
before it is installed. However, upon running the model it is often the case
that it does not run in a straight line and the steering servo's neutral position
has to be readjusted. This adjustment function is known as the “trim,” but trim
adjustment is not only done at the beginning, but it also must be done during
model operation to account for factors such as tire wear and chassis warp.
However, using the normal trim to make these intermediary adjustments could
cause other problems. In the case of the steering trim, it could lead to different
turning radii for the left and right wheels. For throttle trims on glow engine cars,
the point of maximum braking, the full open position of the carburetor, etc.
would be shifted. For this reason, the normal trims are designated as “center
trims” that only adjust the neutral position, while a new function called sub trim
is used in conjunction to enable the most optimal settings.
[Purpose of the Sub Trim]
The effect of the sub trim is illustrated in the image on the right. Adjusting
the sub trim also moves the left/right angle range. In contrast, the center
trim moves the neutral position without changing the angle range position.
However, trying to compensate the neutral position while making large sub
trim adjustments may throw off the model's left/right balance.
[Actual Setting Sequence]
When installing R/C equipment, the servo's neutral position is set first,
then nal adjustments would be made with the sub trim after installation.
However, if the sub trim setting value is high, adjust the neutral position
again.
Test run to conrm neutral position. Adjustments during this time should also
be made with the sub trim. After neutral position is xed, adjust steering
balance (p.21) so that the left and right wheels have the same turning
radius and use steering travel (p.20) to adjust overall steering angle.
During the course of practice or racing, use the center trim to correct slight
changes to the neutral position. If the setting value becomes high, correct
in conjunction with the sub trim so that the center trim value is zero.
Use the sub trim to adjust settings prior to driving instead of the center trim.
P
Install R/C equipment when the sub trim setting value becomes low.
P
If the neutral position becomes slightly off during driving, use center trim to correct.
P
●Trim and Sub Trim Operation
Left/Right angle range and neutral position can be
both be adjusted.
●Sub Trim
●Trim (Center Trim)
Left/Right movement range
is xed.
Adjusting neutral position only.
The sub trim is accessed via the function menu,
but the steering trim can be assigned to one of
the ET keys in SETUP.
P
Initially, steering trim and throttle trim are
assigned to ET1 and ET2 respectively.
P

15
Basic Operation 1: Selecting from a Menu This explanation uses [Steering] as an example.
Use Jog Dial to move cursor over [Steering].
Press ENTER key to change to the Steering Menu screen.
Basic Operation 2: Changing a Setting Value
This explanation uses [TURN 1] on the Steering Speed screen as an example.
Use Jog Dial to move cursor over the 100% value next to [TURN 1].
Press ENTER key to select it for modication.
Once selected, the cursor will blink. Now use the Jog Dial to change the value.
After changing the value, press ENTER key again to conrm the change.
If you wish to cancel the change, press the BACK key at this time instead of the ENTER key .
■ Display and Control Method
●Basic Operations to Change Settings
BACK Key
ENTER Key
Jog Dial
Control of setting adjustments is done via the Jog Dial, ENTER key, and BACK key.
Jog Dial:Used to move cursor between menu choices and change setting values.
Clockwise Rotation:Raising value (for L/R cases: raising toward R); Proceed to next item
Counterclockwise Rotation:Lowering value (for L/R cases: raising toward L); Return to previous item
ENTER Key:Selecting item to be modied; Conrming change
BACK Key:Returning to previous screen; Canceling change
ENTER Key

16
●Startup Screen and Initial Screen
When the transmitter is switched on, the startup screen will display, followed by the initial screen.
Pressing the ENTER key during the startup screen will allow you to proceed to the initial screen.
Model Number:Displays the currently selected model number.(p.18)
Model Name:Displays the name of the currently selected model number.(p.18)
Steering Trim Monitor:Displays the position of the steering trim.(p.20)
Throttle Trim Monitor:Displays the position of the throttle trim.(p.25)
Function Monitor:Functions that are in active will be lit up.
Power Source Type:Displays the type of battery being used.(p.53)
Voltage:Displays the current power source voltage.
Operation Time:Displays how long the transmitter has been used. (p.52)
2.4G Band:Displays the 2.4G Band Mode. (p.52)
Response Mode:Displays the Steering (S) and Throttle (T) Response (p.50)
Control Mode:Displays 3CH (3) and 4CH (4) control mode. (p.34)
Direct Button:Displays the functions assigned to each of the 4 buttons.(p.51)
Version Information:
Displays the version of the program that is installed in the Master Unit's
CPU.
This product's performance may be upgraded via paid or free upgrades. Check the KO
Propo website for information regarding such upgrades. (http://www.kopropo.co.jp)
Startup Screen
Initial Screen
AUT:Throttle Auto Start
ABS:Throttle ABS
SOR:Steering Travel Override
TIM:Timer Activated (including Throttle Start Ready)
ADV:Advanced High Speed HSPD:Super High Speed NORM:Normal Speed
IUP:Idle Up
ACC:Throttle Acceleration
BOR:Brake Override
DBK:Drag Brake
LP:Li-Po
LF:Li-Fe
DR:R03/AAA/UM4 Alkaline Batteries
NI:Ni-MH
--:OFF
2WAY: 2WAY
3WAY: 3WAY
5WAY: 5WAY
ANLG: ANALOG
4WS:4WS Mixing
AMP:Amp Mixing
TH-M: Throttle Mixing
G:GENERAL F:FRANCE
Notice) If you switch battery types, make sure to also change the [Battery Management] setting.
Press the ENTER key to proceed to [Main Menu].
On the 4CH response output will be displayed.

17
Model Menu (Model) (p.17)
Operations such as selecting or copying a model.
Steering Menu (Steering) (p.20)
Modify settings related to steering.
Throttle Menu (Throttle) (p.25)
Modify settings related to the throttle.
3CH/4CH Menu (3/4ch) (p.34)
Modify settings related to 3CH and 4CH
Quick Setup Menu (QuickSetup) (p.45)
Modify settings required for initial setup.
Timer Menu (Timer) (p.46)
Operating timer-related functions.
Function Menu (Function)(p.48)
Modify settings such as the monitor and buzzer.
System Menu (System) (p.50)
Modify system-related functions such as key assignment
and pairing.
■Function Reference
●Main Menu
Model Menu(Model)
Save various settings as model memories Up to 40 model
memories can be named and stored.
This an index which displays the 8 different function menus. To
switch between function menus, use the direct keys or do so via
the main menu. (If you wish to use the direct keys, they must
rst be assigned.)
Model Select
Switch between different model memories.
Model Name
Names the model memories.
Model Copy
Copies model memories.
Model Reset
Resets model memories.
[Functions]
[Legend] P
:Operating Procedure
(see p.15 for basic operation)
:Point :Notice

18
Switch between different model memories.
Model Select(MDL-Select)
Select the model to be used.(Basic Operation p.15)
All of the various settings are registered under a model memory.
P
Switching model memory while driving may cause setting
mismatches and lead to an uncontrollable model. Please place the
car on a stand or switch if off before switching model memories.
Example
If you have multiple cars, it is convenient to have a separate
model memory for each one. Even in the case of only one car,
you could save specic settings for different courses as different
model memories as well.
This function is used to name the model memory that is
currently in use. Distinguish each model memory with different
names, which may also be edited. The set model name will be
displayed on the initial screen and model select screen.
[Selectable Characters]
Model Name(MDL-Name)
To delete a character, overwrite the character to be deleted by
using the blank space at the end of each page of characters.
P
Choose one character at a time from the right side.
(Basic Operation p.15)
Setting Range MODEL:01 - 40 Setting Range Maximum 16 characters.
The settings which will be switched by Model Select are...
1)Steering Setting
2)Throttle Setting
3)3CH Setting
4)4CH Setting
5)Steering and Throttle Response
6)Setup Functions
(ET1-ET5, BT1 function assignments)
7)LED Color
8)Model Name
9)Stopwatch Settings
10)Countdown Timer Settings
P

19
Model Copy(MDL-Copy) Model Reset(MDL-Reset)
Copies the current model memory to a different model memory. Return the current model memory to default setting values.
After reset is nished, [COMPLETE] will ash on the screen before
returning to the menu.
P
Deleted data cannot be recovered. Be careful to avoid undesired
resets.
The contents of the model memory that is being copied to will be
overwritten. Overwritten data cannot be recovered, so be careful
to avoid undesired memory overwrites.
Example
When changing settings on the same car to match driving
conditions, it is convenient to copy the original memory before
modifying it. This function also allows you to try out new settings
while keeping your original one.
Select the model memory to copy to, then hold the ENTER key
to copy.(Basic Operation p.15)
Select [YES] (hold ENTER key) to reset. Select [NO] to cancel
and return to the menu. (Basic Operation p.15)
When selecting the model memory to copy to, that model
memory's name will be displayed.
P
Setting Range MODEL:01 - 40
The settings which will be switched by Model Select are...
1)Steering Setting
2)Throttle Setting
3)3CH Setting
4)4CH Setting
5)Steering and Throttle Response
6)Setup Functions
(ET1-ET5, BT1 function assignments)
7)LED Color
8)Model Name
9)Stopwatch Settings
10)Countdown Timer Settings
P
The settings which will be switched by Model Select are...
1)Steering Setting
2)Throttle Setting
3)3CH Setting
4)4CH Setting
5)Steering and Throttle Response
6)Setup Functions
(ET1-ET5, BT1 function assignments)
7)LED Color
8)Model Name
9)Stopwatch Settings
10)Countdown Timer Settings
P

20
Steering Menu(Steering)
Adjusts the neutral/center position of the steering angle range.
Also refer to Trim and Sub Trim Operation.(p.14)
Settings related to steering control.
Setting Range L50 - 0 - R50(
Default
:0)
Steering Trim(ST-Trim)
Setting adjustments prior to driving should be carried out with the
sub trim, not the trim.
P
The setting range cannot exceed what is set by [Steering Travel] or
[Steering Balance].
P
Trim Position Travel Position
Steering Trim
Modify the neutral position of the steering angle.
Steering Travel
Modify the overall amount of steering movement.
Steering Balance
Modify the left/right steering angles.
Steering Sub Trim
Modify the overall steering angle range.
Steering Trim Rate
Modify the amount of movement which corresponds to one
click of the Trim button.
Steering Turn Speed
Modify the speed of the steering's turn movement.
Steering Return Speed
Modify the speed of the steering's return movement.
Steering Punch
Modify how much the steering initially turns from neutral
position.
Steering Curve
Modify the movement speed ratio which corresponds to
steering angle.
Steering Reverse
Modify the steering direction.
Travel Override
Setting or switching the steering angle.
[Functions]
(N:Neutral L:Left R:Right)
(N:Neutral L:Left R:Right)
Adjust the overall amount of steering servo movement when the
steering wheel is at full lock.
Setting Range 0 - 150(
Default
:100)
Steering Travel(ST-Travel)
Since the Balance setting value is a ratio of the Travel setting
value, if the latter is modified the actual movement value and
the displayed graphic will also change.(the Travel value will not
change).
P
Balance Position Travel Position
Steering will not operate if the Travel value is set to 0.
