Kobelt 7180 Series Instruction Manual

Kobelt Manufacturing Co. Ltd.
7180 Rudder Angle Indicator
Owner’s Operation, Installation &
Maintenance Manual
February 2019

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 2 of 24
NOTES:
RECORD DATA BEFORE INSTALLATION FOR FUTURE REFERENCE
Model #:
Serial #:
Date of Purchase:
Date of Installation:

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 3 of 24
TABLE OF CONTENTS
1Introduction ............................................................................................................ 4
1.1 Contact .................................................................................................................... 4
1.2 Safety....................................................................................................................... 4
2Product Description ................................................................................................. 6
2.1 Technical Data ......................................................................................................... 7
3Operation................................................................................................................ 8
4Installation .............................................................................................................. 9
4.1 Mechanical .............................................................................................................. 9
4.2 Electrical ................................................................................................................ 10
5Commissioning ...................................................................................................... 15
5.1 Electrical Check...................................................................................................... 15
5.2 Calibration and Adjustment ................................................................................... 15
5.3 Functional Test ...................................................................................................... 17
6Maintenance ......................................................................................................... 18
6.1 Preventative maintenance..................................................................................... 18
6.2 Recommended Spare Parts.................................................................................... 18
7Troubleshooting .................................................................................................... 19
8Warranty............................................................................................................... 20
9Appendix A: Installation Dimensions...................................................................... 21
10 Appendix B: Installation Cut-Out Template ............................................................ 23

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 4 of 24
1INTRODUCTION
1.1 CONTACT
Kobelt Manufacturing Co. Ltd.
8238 129th Street
Surrey, British Columbia
Canada, V3W 0A6
Sales Tel:
Fax:
Email:
Website:
[phone]
[phone]
[e-mail]
www.kobelt.com
This document is intended to clearly present comprehensive product data and provide
technical information to assist the end user in design applications. Kobelt reserves the right,
without notice, to change the design, or construction, of any products and to discontinue or
limit distribution of any products. Kobelt also reserves the right to change, or update, without
notice, any technical information contained within this document.
Kobelt recommends that customers visit our website to check for updates to this Manual.
Once a product has been selected for use, it should be tested by the user to ensure proper
function in all possible applications. For further instructions, please contact our distributors or
visit our website.
1.2 SAFETY
1.2.1 Safety Alerts
Throughout this manual, the following symbols, and their accompanying explanation, are
used to alert the user to special instructions concerning a service or operation that may be
hazardous if performed incorrectly or carelessly. The associated risk levels are stated below.
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
This symbol indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
This symbol indicates a hazardous situation, which if not avoided,
could result in minor or moderate injury.
This symbol informs the reader of events not related to personal
injury but which there is a risk of damage to property or equipment.
This symbol informs the reader of safety-related instructions or
procedures.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 5 of 24
1.2.2 Notice to Installer
Disregarding the following safety measures can result in an accident causing severe injury to
personnel and damage to material assets.
•Only use the product as directed in this manual.
•Never put the product into service if there is evidence of visible damage.
•Never put the product into service before fully completing installation and
commissioning.
•Do not carry out any modifications to the product.
•Only use authentic Kobelt spare parts.
•Observe all local regulations, directives and laws during the installation of this product.
•All installation, commissioning, and maintenance work must only be conducted by
qualified personnel. (For the purpose of this manual, qualified personnel are persons
who are familiar with the assembly, installation, commissioning, and operation of the
product and who have the qualifications necessary for their occupation.)
•Observe all specifications in this manual. If these guidelines are not followed and
damage occurs, the warranty will be voided.
1.2.3 Product Hazards
Disconnect Power: Turn off power at distribution panel before
beginning installation to protect installer from electrical hazards.
Voltage and Current Compatibility: Confirm that the power source
is compatible with the maximum voltage and current ratings of the
product variant. Failure to do so could result in damage or fire.
Remove Shipping Clip: Remove protection clip used for shipping
found between terminal posts before applying power to unit.
Disassembly and repair of this electronic unit should only be
performed by authorized service personal. Any modification of the
serial number or attempt to repair the original equipment or
accessories by unauthorized individuals will void the warranty.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 6 of 24
2PRODUCT DESCRIPTION
The 7180 Rudder Angle Indicator is a smaller version of the popular Kobelt 7175 Rudder Angle
Indicator. The 7180 is available in Master and Slave configurations in both 12 VDC and 24 VDC
offerings. Both the Master and Slave contain a backlight to illuminate the indicator during
dark operating hours.
The 7180 Rudder Angle Indicators will provide you with real-time visual display of the position
of your rudder while your vessel is underway. Whether you are manoeuvring, or your
autopilot is commanding your vessels, an accurate readout of your rudder position will be
displayed on this tri-colour two-inch diameter display indicator.
The unit indicates the PORT direction of travel in Red and the STBD direction of travel in
Green for easy and quick identification while steering. The system supports one Master
Indicator with up to a maximum of 5 Slave Indicators (or “repeater stations”) commanded by
a single input signal. The indicators are driven by a position transducer such as the Kobelt
7163, 7168, or 7174 Rudder Feedback Units (RFU).
Figure 1: Master and Slave Unit Back Views

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 7 of 24
2.1 TECHNICAL DATA
Table 1: 7180 Technical Data
MODEL
7180 SERIES
KOBELT PART #
7180-M
7180-M-24
7180-S
7180-S-24
NOMINAL VOLTAGE
12 VDC
24 VDC
12 VDC
24 VDC
MAXIMUM CURRENT, METER
20 mA
40 mA
--
RECOMMENDED DRIVING
POTENTIOMETER
1kΩ
--
MAXIMUM NUMBER OF SLAVE
UNITS
5
--
FACE DIAMETER
2”
BULB TYPE
T3-1/4 Wedge Type
MAXIMUM CURRENT, BULB
330 mA
60 mA
330 mA
60 mA
PROTECTION, TOP SIDE
EXPOSURE
IP66 *
PROTECTION, BOTTOM SIDE
EXPOSURE
IP20
MAXIMUM DASH THICKNESS
3/4" [19mm]
OPERATING TEMPERATURE
-13°F … 158°F [-25°C … 70°C]
PRODUCT WEIGHT
0.55 lb. [0.25kg]
* Requires a gasket or silicone between the meter and the dash surface.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 8 of 24
3OPERATION
The 7180 Rudder Angle Indicator system requires no direct user input to function. The system
is passive and responds to signals from a Rudder Feedback Unit or alternative signal sources
such as control levers. The signal commands the needle position on the Indicator. This
position can be calibrated to correspond to physical rudder position or the position of an
alternative signal source.
A single master unit can drive up to 5 slave units. The slave units directly follow the meter
movement of the master. Span configuration is done on the master unit. Zero adjustment is
available on both the master and slave units.
If a backlight dimmer is installed in the system, the operating instructions of the dimmer
manufacturer/installer shall be followed for adjustment of the dimmer.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 9 of 24
4INSTALLATION
4.1 MECHANICAL
All meter variants contain the same physical properties and dimensions. The gauge meters
are to be installed using a 2.1” round hole in the desired panel or dash location on the vessel
(refer to Appendix B: Installation Cut-Out Template, for a mounting template).
Figure 2: Mechanical Dimensions
Ensure proper clearance is provided behind the panel or dash
installation location to allow for securing the tightening clamps to
hold the unit securely.
4.1.1 Mounting
A pre-installed bracket and fasteners are included with 7180 gauges for mounting the units.
1. Loosen and remove nuts holding brace to unit.
2. Remove brace completely from unit.
3. Insert unit into cut-out hole in the mounting location.
4. Replace the brace on the back-side of the unit.
5. Replace the nuts and tighten to secure the unit to the mounting location.
Ensure that the terminals are properly isolated, by the isolating
washers that separate the terminals from the mounting brace,
before powering on the unit.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 10 of 24
4.2 ELECTRICAL
The 7180 gauges support a nominal supply voltage of either 12VDC or 24VDC. The supply
voltage to the meter is isolated from the supply voltage used for the illumination. This
isolation allows the illumination to be powered from a separate power source or connected
to a common dimming control circuit for all dash mounted instruments.
The unit contains a T3-1/4 Miniature Wedge Base incandescent bulb holder with a 12 VDC or
24 VDC bulb pre-installed as per the model ordered.
A circuit breaker of 2A is recommended between the vessel power
supply source and the indicator(s) as shown in the example
installation diagrams.
All terminal wire connections to the meter should use crimped ring
or ferrule terminals, as appropriate, to ensure a secure connection
for high-vibration environments.
Control signals shown in the following figures are provided by standard control levers. Please
review the Kobelt website for all options available.
Electrical installation of the 7180 should proceed as follows:
Disconnect Power: Turn off power at distribution panel before
beginning installation to protect installer from electrical hazards.
Proper Electrical Polarity: Damage to the indicator can occur if input
voltage connection is reversed. Ensure proper connection of the
Positive and Negative terminals.
1. Connect electrical cables and power wires according to one of the configurations shown
in Figure 4 through Figure 6, and the additional details in this section of the manual.
a. Verify supply breaker (or fusing) is correctly sized as per specifications in
Table 1.
b. Verify wires and cables used are of the required gauge sizes and types as per
local marine regulations and standards.
2. Visually inspect all wiring to ensure correct installation.
Remove Shipping Clip: Remove protection clip used for shipping
found between terminal posts before applying power to unit.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 11 of 24
4.2.1 Electrical Interfaces
The backside of the Master and Slave units contain the electrical connections for wiring of the
system. The Master and Slave units contain different wiring terminals and identifiers. Refer to
designators shown in Figure 3.
Table 2: Master Gauge Backside Connections
Master Gauge
Pin Designator
Pin Type
Function
GND
Power
Power Supply Common connection point.
V+
Power
Power Supply Source. Accepts either 12VDC or
24VDC.
R+
Output
Supplies power to the positive terminal of the
Rudder Feedback Unit potentiometer.
RW
Input
Receives feedback signal from the Rudder
Feedback Unit potentiometer.
Table 3: Slave Gauge Backside Connections
Slave Gauge
Pin Designator
Pin Type
Function
+
Input
Input current loop signal from Master unit.
(blank)
Output
Output current loop signal from Slave unit.
Figure 3: Master and Slave Unit Connector Views

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 12 of 24
4.2.2 Master Unit Configuration
Figure 4: Master Unit Configuration

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 13 of 24
4.2.3 Master and Single Slave Unit Configuration
Figure 5: Master and Single Slave Unit Configuration

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 14 of 24
4.2.4 Master and Multiple Slave Units Configuration
Figure 6: Master and Multiple Slave Units Configuration

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 15 of 24
5COMMISSIONING
5.1 ELECTRICAL CHECK
Ensure that the unit is properly installed and secured before
powering on the 7180.
•Confirm that all electrical connections to the 7180 have been made.
•Confirm that a breaker has been installed correctly and is turned ON.
5.2 CALIBRATION AND ADJUSTMENT
The gauge may need to be adjusted to centre the pointer when the rudder is centred and to
adjust the overall range of the meter to align with the position of the rudders maximum
travel.
Follow these instructions to configure the zero point and span using the on-board zeroing
lever and trimpot.
To reduce the potential for electrical shock and to avoid damaging
the 7180 electronics, use a non-conductive screwdriver, or other
equivalent tool, to adjust the trimpot or zeroing lever.
Exercise caution when reaching in with the screwdriver. Do not let it
touch any components other than the trimpots.
Ensure no oil, dust, or other contamination enters the 7180 while its
cover is removed.
1. Turn OFF power to the 7180 prior to making adjustment.
2. If adjusting the zeroing lever, remove the red plug or lightbulb, if installed.
3. Use a non-conductive flathead or Phillips-head screwdriver to adjust the trimpot
or zeroing lever.
a. Refer to the sections below for functional details of the trimpot and
zeroing lever
4. Turn ON power.
5. Move rudder through its range to verify desired response.
6. Repeat as necessary, until the 7180 functions as desired.
7. Replace the red plug or lightbulb, if installed.
Default position for the configuration trimpot is at centre (pointing upward).

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 16 of 24
Figure 7: Master Unit Calibration Trimpot Arrangement
5.2.1 Span Trimpot
The span trimpot adjusts the range of the meter when slave units are added in series.
Do not press down on the potentiometer as this can damage the
circuitry.
5.2.2 Zero Adjustment
The zero-adjustment lever is located inside the lightbulb cavity and can be accessed by
removing the red plug or the lightbulb, if installed. The zero point is adjusted by moving the
small lever inside the meter. Calibration of the zero point should be done when the rudder is
at dead-center.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 17 of 24
Zero adjustment should be done by qualified personnel only.
5.3 FUNCTIONAL TEST
Before commencing normal operations with the installed unit(s). A functional test be
conducted to ensure proper operation of the system as per the intended application and
configuration.
Functional testing should be done by qualified personnel only. The
system functionality should be fully tested dockside before an open
water sea trail is performed to ensure proper response of the
system based on rudder commands.
After installation perform the following function tests:
1. Center the rudder
a. Ensure that the meter displays 0°. If not, adjust the zero lever
until it is centered at 0°
2. Move the rudder to hard-over
a. Ensure that the meter displays the hard-over angle. If not, adjust
the ‘Span’ trimpot until it is at the correct angle.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 18 of 24
6MAINTENANCE
6.1 PREVENTATIVE MAINTENANCE
•Quarterly (4 times per year)
oVisually inspect all wire connections for signs of wear.
•Every year
oInspect top and internal enclosure to ensure no adverse wear due to
environment.
oConfirm all electrical connections are secure.
oEnsure calibration and zero point of unit.
6.2 RECOMMENDED SPARE PARTS
As a minimum Kobelt recommends the following spare parts are on-hand:
Table 4: Recommended Spares
RECOMMENDED SPARES
QTY
ITEM
KOBELT PART #
1
T3-1/4 BULB, 24V* (ANSI Model: 656)
6001-3647
1
T3-1/4 BULB, 12V* (ANSI Model: 193)
6001-3633
* Select the spare bulb based on the desired operating voltage.
It is recommended that any required service work on a Kobelt unit
be performed by a factory authorized service representative. Please
contact the nearest Kobelt authorized distributor for assistance.

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 19 of 24
7TROUBLESHOOTING
If you encounter problems with the operation of your product, please refer to the trouble-
shooting suggestions before contacting Kobelt for assistance. If the steps below do not
resolve your issue, please reach out either Kobelt directly or our Dealers in your area.
Table 5: Common Solutions
Problem
(Issue encountered)
Cause
(What it means)
Corrective Action
(What to do)
7180 indicator(s) not
operational
Blown fuse/circuit
breaker
Check and replace fuse or reset circuit
breaker
Wiring issue
Check for proper wiring
7180 unit does not
illuminate
Lightbulb not
correctly installed
Check the lightbulb installation and
ensure that all connections have been
properly made.
Dimming is turned
down all the way (if
installed)
Adjust the dimming knob (if installed)
until the 7180 unit is adequately
illuminated.
Master indicator moves
in opposite direction to
rudder
Potentiometer
power wires are
reversed
Reverse the wiring at the positive and
negative terminals of the potentiometer.
Correct the wiring following the
examples in Section 4.2.
Slave indicator moves
in opposite direction to
rudder
Input wires are
reversed
Reverse the wiring at the input terminals
of Slave.
Correct the wiring following the
examples in Section 4.2.
Port and Starboard
hard-over are not equal
Rudder angle
feedback unit (or
alternative source)
is not installed or
adjusted properly
Confirm correct installation and
adjustment of the rudder angle
feedback unit (or alternative source).
Indicator(s) movement
not in sequence with
rudder movement
Scale range is
uncalibrated
Adjust span trimpot as described in
Section 5.2 to adjust scale.
Indicator(s) reading is
not correct with slave
units installed
Span trimpot needs
adjustment
Adjust span trimpot as described in
Section 5.2
Rudder center angle
does not read zero
Zero adjustment is
required
Adjust zeroing lever as described in
Section 5.2

7180 Rudder Angle Indicator Kobelt Manufacturing Co. Ltd.
Rev B MNL_7180 20 of 24
8WARRANTY
Kobelt Manufacturing Co. Ltd. (“Kobelt”) warrants the Products and Parts manufactured by
Kobelt to be free from defects in workmanship or material and that said products are
designed mechanically and functionally to perform to specifications.
This warranty is effective providing:
•The equipment is used within the intended operating conditions and in accordance with
Kobelt recommendations
•The equipment is installed according to equipment diagrams, specifications and
recommendations which Kobelt has provided
This warranty becomes invalid if the factory supplied serial number has been removed or
altered on the product. This warranty does not cover cosmetic damage or damage caused by
an act of God, accident, misuse, abuse, negligence or modification of any part of the product.
This warranty does not cover damage due to improper operation or maintenance, connection
to inappropriate equipment or attempted repair by anyone other than an authorized Kobelt
representative.
Upon identification of a potential issue or defect with a Kobelt Product or Part, the Warranty
Applicant (“Applicant”) must immediately contact Kobelt and describe the issue in writing, by
letter, fax, email or other electronic conveyance. Kobelt will then assess the cause of the
defect, and determine warranty applicability and appropriate remediation.
If any part is found to be defective, Kobelt will replace said part FOB the Kobelt factory
provided that any such defective part is returned by the Buyer with freight and applicable
forwarding charges prepaid by the Buyer. Kobelt’s sole obligation to the Applicant will be to
repair or replace the defective part with same or similar product, to a maximum value of the
list price of the product or part. The Kobelt warranty does not cover labour charges, travel or
any other associated expenses.
All Products and Parts manufactured by Kobelt, are subject to a warranty against
manufacturer’s defects in materials or workmanship for a period of two (2) years from the
date of purchase.
Kobelt will be responsible for all Products or Parts sold by Kobelt but manufactured by 3rd
party manufacturing companies. However, these products and parts are subject to applicable
3rd party warranties, and may not be the same as the Kobelt warranty.
