Koblenz HV-12KB Guide

1
FEBRUARY 2017 HV-12KB
MODEL: HV-12KB
12 Volt Car Vaccum
MANUAL SERVICE
PARTS LIST
SERVICE

2
FEBRUARY 2017 HV-12KB
TABLE OF CONTENTS
ELECTRICAL RATING & ELECTRICAL DIAGRAM 2
OPERATION 3
EXPLODED VIEW 4
PARTS LIST 5
ELECTRICAL RATING & ELECTRICAL DIAGRAM
ELECTRICAL RATING: 12V
OPERATION
1. Plug in the power cord
2.
3.
4. To clean the dust cup, press the release button and empty, clean with soap and water if necessary.
NEVER USE CHEMICALS.
5. Remove the filter and shake it, if necessary wash it.
WARNING: NEVER USE THE VACCUM WITHOUT THE FILTER AND THE DUST CUP.
NOTE: The accesories is according to the model, please check them on the box panel
Put the accesory push-it firmly to inside the dust cup.
Push the switch on/off

3
FEBRUARY 2017 HV-12KB
EXPLODED VIEW HV-12KB
PARTS LIST HV-12KB
NO
PART NUMBER
DESCRIPTION
QUANTITY
1
01-0099-0
SCREW 4-24X1/2
7
2
13-3193-3
SWITCH BUTTON
1
3
11-0225-0
MOMENTARY SWITCH
1
4
13-3198-03-8
RIGHT TOP
1
5
28-1656-9
POWER CORD
1
6
46-3262-6
ASSY MOTOR
1
7
46-3232-03-3
ASSY DUST CUP
1
8
13-3192-5
INSURANCE BUTTON
1
9
13-3197-03-8
LEFT TOP
1
10
08-1981-3
CLOTH BAG
1
11
13-3199-0
CORNER ACCESORY
1

4
FEBRUARY 2017 HV-12KB
WHEN YOU ORDER PLEASE INCLUDE
PART NUMBER
DESCRIPTION
MODEL
NOTE:
THE DRAWING NUMBER´S ARE ONLY FOR IDENTIFICATION
Thorne Electric Co.
P. O. Box 18363
San Antonio, TX 78218-0363
Phone: [phone]
1 [phone]
THORNE ELECTRIC Co.
E-mail: [e-mail]
SERVICE
