Kobold DAG-M1V Series User manual

Operating Instructions
for
Digital Indicating Units
Standard signals 0/4-20 mA, 0-10 VDC
Model: DAG-M1V…, 48 x 24 mm

DAG-M1V
page 2 DAG-M1V K07/0323
We don’t accept warranty and liability claims neither upon this publication nor in
case of improper treatment of the described products.
The document may contain technical inaccuracies and typographical errors. The
content will be revised on a regular basis. These changes will be implemented in
later versions. The described products can be improved and changed at any time
without prior notice.
© Copyright
All rights reserved.
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 4
3.Instrument Inspection .................................................................................... 4
4.Regulation Use ............................................................................................. 4
5.Brief description ............................................................................................ 5
6.Assembly ...................................................................................................... 6
7.Electrical Connection .................................................................................... 7
8.Function and operation description ............................................................... 9
9.Setting up the device ................................................................................... 10
9.1Switching on ...................................................................................... 10
9.2Standard parameterization ................................................................. 10
9.3Programming interlock RUN .............................................................. 14
9.4Extended parameterization ................................................................ 15
10.Reset to factory settings .............................................................................. 30
11.Alarms / Relays ........................................................................................... 31
12.Sensor calibration Offset / Final value ......................................................... 33
13.Technical Information .................................................................................. 34
14.Order Codes ............................................................................................... 34
15.Dimensions ................................................................................................. 34
16.Safety advices ............................................................................................. 34
17.Error elimination .......................................................................................... 36
18.Disposal ...................................................................................................... 37
19.EU Declaration of Conformance ................................................................. 38

DAG-M1V
DAG-M1V K07/0323 page 3
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

DAG-M1V
page 4 DAG-M1V K07/0323
2. Note
Please read these operating instructions before unpacking and putting the unit into
operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar with
these operating instructions and in accordance with local regulations applying to
Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC machinery directive.
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of the
delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Digital Indicating Unit model: DAG-M1V
4. Regulation Use
Any use of the device, which exceeds the manufacturer’s specification, may
invalidate its warranty. Therefore, any resulting damage is not the responsibility of
the manufacturer. The user assumes all risk for such usage.

DAG-M1V
DAG-M1V K07/0323 page 5
5. Brief description
The panel meter DAG-M1V is a 5-digit device for direct current/direct voltage
signals and a visual threshold value monitoring via the display. The configuration
happens via four front keys. An integrated programming interlock prevents
unrequested changes of the parameters and can be unlocked again by an
individual code. Optional the following functions are available: a supply for the
sensor, a digital input for triggering of Hold (Tara) or an analog output for further
processing in the equipment. By use of the two optional galvanic insulated
setpoints, free adjustable threshold values can be controlled and reported to a
superior master display. The electrical connection is carried out on the back side
via plug- in terminals. Selectable functions like e.g. the request of the min/max-
value, an average determination of the measuring signals, a nominal preset
respectively setpoint preset, a direct change of threshold value in operation mode
and additional measuring supporting points for linearization complete the modern
device concept.

DAG-M1V
page 6 DAG-M1V K07/0323
6. Assembly
Please read the Safety advices on page 34 before installation and keep this user
manual for future reference.
1. After removing the fixing elements, insert the device.
2. Check the seal to make sure it fits securely.
3. Click the fixing elements back into place and tighten the clamping screws by
hand. Then use a screwdriver to tighten them another half a turn.
CAUTION! The torque should not exceed 0.1 Nm!
Change signs of the physical unit before assembly via a channel at the side
of the front! The change can only be done from the outside before
assembly!

DAG-M1V
DAG-M1V K07/0323 page 7
7. Electrical Connection
Type DAG-M1V0 Type DAG-M1V3
With a supply of 100-240 VAC With a supply of 24 VDC
Connection examples
Below you find three connection examples, which demonstrate some practical
applications for devices with voltage or current input, without sensor supply:

DAG-M1V
page 8 DAG-M1V K07/0323
DAG-M1V devices
With current respectively voltage input in combination with a 24 VDC sensor
supply.

DAG-M1V
DAG-M1V K07/0323 page 9
8. Function and operation description
Operation
The operation is divided into three different levels.
Menu level (delivery status)
This level is for the standard settings of the device. Only menu items which are
sufficient to set the device into operation are displayed. To get into the professional
level, run through the menu level and parameterize “prof” under menu item RUN.
Menu group level (complete function volume)
Suited for complex applications e.g. linkage of alarms, setpoint treatment, totalizer
function etc. In this level function groups which allow an extended parameterization
of the standard settings are available. To leave the menu group level, run through
this level and parameterize “uloc” under menu item RUN.
Parameterization level
Parameter deposited in the menu item can here be parameterized. Functions, that
can be changed or adjusted, are always signalized by a flashing of the display.
Settings that are made in the parameterization level are confirmed with [P] and
thus saved. By pressing the [0]-key (zero-key) it leads to a break-off of the value
input and to a change into the menu level. All adjustments are saved automatically
by the device and it changes into operating mode, if no further key operation is
done within the next 10 seconds.

DAG-M1V
page 10 DAG-M1V K07/0323
Function chart:
9. Setting up the device
9.1 Switching on
Once the installation is complete, you can start the device by applying the voltage
supply. Before, check once again, that all electrical connections are correct.
Starting sequence
For 1 second during the switching-on process, the segment test (8 8 8 8 8) is
displayed followed by an indication of the software type and, after that, also for 1
second the software version. After the starting sequence, the device switches to
operation / display mode.
9.2 Standard parameterization
To parameterize the display, press the [P] key in operating mode for 1 second. The
display then changes to the menu level with the first menu item TYPE.

DAG-M1V
DAG-M1V K07/0323 page 11

DAG-M1V
page 12 DAG-M1V K07/0323

DAG-M1V
DAG-M1V K07/0323 page 13

DAG-M1V
page 14 DAG-M1V K07/0323
9.3 Programming interlock RUN

DAG-M1V
DAG-M1V K07/0323 page 15
9.4 Extended parameterization
9.4.1 Signal input parameters

DAG-M1V
page 16 DAG-M1V K07/0323

DAG-M1V
DAG-M1V K07/0323 page 17

DAG-M1V
page 18 DAG-M1V K07/0323
9.4.2 General device parameters

DAG-M1V
DAG-M1V K07/0323 page 19

DAG-M1V
page 20 DAG-M1V K07/0323
