KOBOTIX REAL RACER User manual
page 1
WHAT’S INCLUDED
8+
1 x INSTRUCTION MANUAL
1 x REAL RACER™
1 x CONTROLLER
1 x LiPo BATTERY CHARGING CABLE
1 x RECHARGEABLE LiPo BATTERY PACK
1 x FPV HEADSET
INTRODUCTION
Thank you for purchasing KOBOTIX®REAL RACER™!
Get ready to race! The future of RC racing has arrived. REAL RACER™ puts you in the drivers seat.
Follow the instructions in the manual and you will be up and racing in no time!
CAUTION:
HAIR ENTANGLEMENT
Tie back and cover hair and secure loose
clothing prior to play.
WARNING:
CHOKING HAZARD
This product is not suitable for children
under 3 years because of small parts.
TM INSTRUCTION MANUAL
page 2
1
1 2
3
2
4
A
B
1. (A) Press the button at the bottom of the Controller
handle to release the Battery Cartridge.
(B) Insert 4 x AAA batteries (not included).
Ensure that the positive and negative polarities
match the illustration inside the Battery Cartridge.
2. Slide the Battery Cartridge back into the Controller
until it *clicks* into place.
1. Lay the REAL RACER™ Car down so that the Battery
Compartment faces upwards.
2. Using a Phillips screwdriver (not included), remove
the screw on the Battery Compartment Cover.
3. Connect the battery connectors together and insert
the Rechargeable LiPo Battery Pack (included) into
the Battery Compartment.
4. Replace the Battery Compartment Cover and tighten
screw using the screwdriver. Do not over-tighten.
POWERING REAL RACER™
INSTALLING THE LiPo BATTERY PACK
REPLACING BATTERIES IN THE CONTROLLER
page 3
1
3
2
1. Plug the charging cable into a powered USB outlet
such as a PC or mobile phone charger. The LED will
glow GREEN when connected to a USB outlet.
3. When the LiPo battery is fully charged, the charging
cable LED will glow GREEN. Charging time for a fully
discharged battery is approximately 60 minutes.
2. Plug the battery connector into the connector on the
charging cable. The LED on the charging cable will
glow RED to indicate charging in progress.
In extremely rare circumstances, there may be a risk of a battery leaking fluids that can cause a chemical burn injury
or ruin your product. To avoid battery leakage:
• Non-rechargeable batteries are NOT to be recharged.
• Rechargeable LiPo batteries are to be removed from the product before charging.
• Rechargeable LiPo batteries are only to be charged under adult supervision.
• You MUST charge the LiPo battery in a safe area away from any flammable materials.
• NEVER charge the battery unattended at any time. When charging the battery, remain in constant observation of
the battery to monitor the process and react immediately to any potential problems.
• DONOTexposebatteriestoextremeheatorre,batteriesmayleakorexplode.
• DO NOT short-circut the supply terminals.
• DO NOT drop or subject to strong impact.
• DO NOT allow the battery to get wet.
• Only charge the battery with the included battery charging cable.
• Dispose of batteries properly.
BATTERY SAFETY PRECAUTIONS
CHARGING THE LiPo BATTERY PACK
BATTERY INFORMATION
page 4
A.
B.
C.
A. Camera
B. Power Toggle
C. Battery Compartment
ABOUT THE REAL RACER™ CAR
TRANSMISSION RANGE: Approximately 30 metres (98.4 feet)
MAX SPEED: 20 km/h (12.4 mph)
CAMERA: HD 720p 30 FPS
CONNECTIVITY CONTROL LINK: 2.4 GHz RF
VIDEO LINK: Wi-Fi 802.11n (2.4 GHz)
1. Standard RC Racing experience without the app and headset. Your Real Racer™ is ready to go as soon as the
batteries are installed and both the Real Racer™ Car and Controller is powered on.
2. With the Real Racer™ App, experience the driver’s view and access the various features of your Real Racer™.
3. For a fully immersive Driver’s view RC experience - activate the Real Racer™ App, turn on the Headset function
and strap on the FPV Headset.
USING THE REAL RACER™ CAR
MANY WAYS TO DRIVE
TECHNICAL INFORMATION
page 5
A.
B.
E.
F.
G.
H.
I.
K.
L.
J.
D.
A. Capture Video
B. Steering Wheel
C. Throttle
D. Pistol Grip
E. Battery Cartridge Release
F. Steering Rate
SIDE VIEW
TOP VIEW
G. Take Picture
H. Bind
I. Steering Trim
J. Throttle Rate
K. AUX
L. Power Button
DRIVING REAL RACER™
ABOUT THE CONTROLLER
ATTACHING THE STEERING WHEEL
Place the hexagonal Steering Column (located on the
underside of the Steering Wheel) against the hexagonal
hole on the right side of the Controller and slowly rotate.
The Steering Wheel will automatically attach to the
Controller once correct alignment has been achieved.
Lightly press Steering Wheel into place.
C.
page 6
234
A.
B.
A. Release Button
B. Capacitive Touch Button
C. Optical Distance Dial
D. Focal Adjustment Dial
E. Phone Compartment
F. Optical Lens
G. Adjustable Headstrap
D.
G.
F.F.
E.
C.
Note: The FPV Headset is designed for
devices between 4.7” - 6.2”.
1. Connect REAL RACER™ to your device, launch the REAL RACER™ App and activate the HEADSET Mode.
2. Open the Phone Compartment on your headset and insert your phone with the screen facing the optical lens.
Close the compartment and make sure that it is securely locked.
3.Weartheheadsetandadjuststrapstomakesureittsyourheadsecurelyandcomfortably.
4. Adjust the optical lens’ until you see clearly. The Optical Distance Dial on top adjusts optical spacing and the
Focal Adjustment Dials on both sides adjust focus.
5. You are now in the driver’s seat. Pick up the Controller and you are ready to race!
ABOUT THE FPV HEADSET
WEARING THE FPV HEADSET
THE FPV HEADSET
page 7
DEVICE LIST
kobotix.com/devices
SAFETY PRECAUTIONS:
• Keep hands, hair and loose clothing away from the wheels when power switch is turned ON.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Keep moving parts clean.
• Keep parts dry.
• Always let parts cool after use before touching.
• Turn off controller and vehicle when not in use.
• Remove battery(s) from controller when not in use.
• Parental guidance is recommended.
• Users should keep strict accordance with the instruction manual while operating the product.
• The product must only be used with the recommended controller.
BATTERY SAFETY INFORMATION:
• New alkaline batteries are recommended for use in controller.
• Do not mix old and new batteries, different types of batteries [standard (Carbon-Zinc), Alkaline or rechargeable] or rechargeable batteries of different capacities.
• Replacement of batteries must be done by adults.
• Follow the polarity (+/-) diagram in the battery compartment.
• Remove exhausted batteries from the toy.
• Dispose of used batteries properly.
• DO NOT incinerate used batteries.
•DONOTdisposeofbatteriesinre,asbatteriesmayexplodeorleak.
• DO NOT recharge non-rechargeable batteries.
• DO NOT short-circuit the supply terminals.
• Remove batteries from the toy when it is not being used for a long period of time.
OVERHEATING:
The product may start to overheat if operating under extreme temperature conditions for a period of time.
The product will automatically turn OFF if an overheated condition is detected. Let the product cool down to room temperature before playing again.
WARNING! This product is not suitable for children under 3 years because of small parts - choking hazard.
Contains 1 x 3.7V/800mAh LiPo battery pack and requires 4 x 1.5V AAA batteries (not included). Batteries or battery packs must be recycled or disposed of properly.
Protect the environment by not disposing of this product with household waste [2012/19/EU]. Check your local authority for recycling advice and facilities.
To connect REAL RACER™:
1. Go to the Settings menu of your smartphone, open the Wi-Fi settings, then select “KOBOTIX_XXXXX” from the list
of available networks.
2. Enter the default password “12345678” then press “join”. You can change this password in the settings menu of
the REAL RACER™ App.
3. Launch the REAL RACER™ App and follow the on-screen instructions.
DOWNLOADING & CONNECTING TO THE REAL RACER™ APP
THE REAL RACER™ APP
Please check if your device is compatible with the app.
Download the REAL RACER™ App on your smart device. Follow the QR codes below for direct links or search for
“KOBOTIX REAL RACER” on Google Play™ or the App Store®.
CONNECTING TO THE APP
♻
page 8
INFO
FCC STATEMENT
WARRANTY
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular Installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try and correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or experienced radio/TV technician for help
Your purchase comes with a one-year limited warranty in the US. For consumers who are covered by consumer
protectionlaws orregulationsin theircountry ofpurchaseor,ifdifferent,theircountryof residence,thebenets
conferred by this warranty are in addition to all rights and remedies conveyed by such consumer protection laws
and regulations. The warranty covers against manufacturing defects. It does not cover abuse, alteration, theft, loss,
unauthorized and/or unreasonable use, or normal “wear and tear.” During the warranty period, Kobotix®will make
sole determination of a defect. If Kobotix®determines a defect, Kobotix®, at its sole discretion, will repair or replace
the defective part or product with a comparable part. This does not affect your statutory rights. For full details, safety
updates, or support, see kobotix.com/contact
Valid only in U.S.A.
© 2018 KOBOTIX®. All rights reserved.
REAL RACER™ & KOBOTIX®, and the REAL RACER™ & KOBOTIX®logos are registered trademarks of KOBOTIX®
Unit 1303A, Henley Industrial Centre,
9-15 Bute Street, Mong Kok, Kowloon, Hong Kong.
App Store®is a service mark of Apple Inc.
Android™ and Google Play™ are trademarks of Google Inc.
Wi-Fi is a registered trademark of Wi-Fi Alliance®.
Made in China
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement
