KODA LM030007 Guide

CARE & USE INSTRUCTIONS
IMPORTANT INFORMATION.
PLEASE READ CAREFULLY AND RETAIN
FOR FUTURE REFERENCE.
For assistance with assembly, installation, parts or customer service,
please contact us:
ITM. / ART. 1224697
Model: LM030007
LINKABLE MULTIPURPOSE
LED LIGHTS
LED UMBRELLA LIGHT
WITH SOLAR CHARGER
TM
@KodaBuiltOfficial kodabuilt.com
[e-mail]
1-866-294-9244, Monday to Friday, 8am to 5pm Pacific Time
2975 Red Hill Ave., Suite 100, Costa Mesa, CA 92626, USA

2
IMPORTANT SAFETY INSTRUCTIONS:
Create your own lighting masterpiece with the Koda Linkable Multipurpose
LED Lights. This versatile light can be congured to t any room or application,
whether you’re looking for a square, straight line or your own custom shape. The
Koda Linkable Multipurpose LED Lights are capable of having up to 6 units linked
together on one plug, enabling a cleaner look and application without all the
messy cables.
You can ush mount Koda Linkable Multipurpose LED Lights on ceilings for your
most optimal lighting needs. When setup, you’ll be able to enjoy a bright 1300
lumens LED light (each linkable unit) that produces a 3500K color output with an
estimated 50,000* hour life on each LED.
Improve your interior lighting with the Koda Linkable Multipurpose LED Lights,
and embrace lighting the way you want it.
This product is suitable for use in home, ofce, warehouse, workshop, garage
and other indoor locations.
DANGER - To reduce the risk of electric shock:
Always unplug this product from the electrical outlet before cleaning.
WARNING - To reduce risk of re, electric shock, or injury to persons:
• Do not modify the power cord plug provided with the product.
• Do not use the light if the power cord or plug is damaged. If damaged, have it
repaired by a service facility before use. If the plug does not t the outlet, have a
proper outlet installed by a qualied electrician.
• Disconnect the power cord plug from the power source before making any
adjustment or changing accessories. Do not attempt to install the product while
plugged in.
• Do not abuse the power cord. Never use the power cord to carry the light or pull
the plug from an outlet. Keep the power cord away from heat, oil, sharp edges,
or moving parts.
• Not for use with dimmer packs, timing devices, motion detectors, or lighting
controllers other than supplied with this product.
• Store the product and remote out of reach of children.
• Only use product in its intended location.
• Close supervision is necessary when this product is used by or near children,
disabled or elderly persons.
• These lights have a polarized plug (one blade is wider than the other) as a
feature to reduce the risk of electric shock. This plug will t in a polarized outlet
only one way. If the plug does not t fully in the outlet, reverse the plug. If it
still does not t, contact a qualied electrician. Never use with an extension cord
unless plug can be fully inserted. Do not alter the plug.
• The receptacle is for connecting with the same model LM030007 only, and up
to maximum 6 units (including the rst one).

3
• Do not connect with other appliances, or connect more than 6 units of light
model LM030007.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT
SAVE THESE INSTRUCTIONS
WARNING:
• LED light output is strong enough to injure human eyes. Do not stare at the LED
light while it is illuminating.
• If the light is damaged, it shall be exclusively replaced by the manufacturer
or the service agent or qualied person in order to avoid a hazard.
• The warnings, precautions, and instructions discussed in this manual cannot
cover all possible conditions and situations that may occur. The operator must
understand that common sense and caution are factors which cannot be
built into this product, but must be supplied by the operator.
• Do not tamper with or attempt to repair the LED component or xture. The light
source is designed for this specic application and should not be serviced by
untrained personnel. Contact the customer service department if any servicing
is required.

4
PACKAGE CONTENTS:
1 x Measuring Template
4 x Mounting Brackets
Tools Needed (not included)
#2 Phillips Head
Screwdriver
Safety GlassesDrill and 2 mm /
5/64 inch Drill Bit
2 x Linkable Multipurpose LED Lights
2 x Detachable Power Cord Sets
Please lay out all parts and read the instructions prior to installation.
4 x Plastic Anchors4 x Wood Screws
4 x Washers
4 x Drywall Screws
PA
PB
PH
TA TB TC
PC
PF
PE
PG
PD
Measuring template
90°
90°
45°
45°
0°

5
PRODUCT SPECIFICATIONS:
1. Operating Voltage: 120 Vac, 60 Hz
2. Wattage: 21 W
3. Light Output: 1300 lumens
4. Color Temperature: 3500 K
5. LED Life Cycles: up to 50,000 hours
6. Operating Temperature: 0°C to 40°C / 32°F to 104°F
INSTALLATION PROCEDURES:
NOTE: The light can be linked with the same model LM030007 only, and can be
linked up to maximum 6 units (including the rst one).
The on/off switch at the rst light would be served as the main switch. If you
turn off the on/off switch at the rst light, the light(s) linked together will also be
turned off.
CAUTION: Never remove the Outlet Protection Bracket
from the light unless you want to link up other lights.
This product is ETL/cETL Listed
WITH SINGLE LIGHT:
Final installed illustration
1
PH
1. Select a mounting location and make
sure the wooden surface is suitable for
supporting the light. Use the measuring
template to mark the mounting
bracket locations on the mounting
surface, with each location being
15 in / 38 cm apart from each other.
PH
PC
2 in /
5 cm
30 in / 76.2 cm
1.6 in / 4 cm
Outlet
Protection
Bracket

6
Clip Clip
NOTE: The mounting brackets should be at least
15 in / 38 cm apart from each other.
2. Wear safety glasses and drill two
5/64 inch diameter pilot holes.
2
3. Screw the mounting bracket with
the wood screw provided. Repeat for
the second mounting bracket.
Note: For concrete or drywall, you may
use drywall screws along with plastic
anchors instead of wood screws.
CAUTION: Never plug in or turn on the light when
the Outlet Protection Bracket is missing.
3
5. Clip mounting brackets onto the light.4. Ensure the power cord set is
installed properly by rmly pressing
into the light socket .
54
TB
PC
PC
PC
PB
PA
PCPB
PA
PC
PA
PD
PD
Mounting Diagram
7.5 in / 19 cm 7.5 in / 19 cm15 in / 38 cm

7
4. Wear safety glasses and drill two
5/64 inch diameter pilot holes.
2. Unscrew and pull out the Outlet
Protection Bracket horizontally and
then downward from the rst light.
4
2
1
5. Screw the mounting bracket with
the wood screw provided. Repeat for
the second mounting bracket.
Note: For concrete or drywall, you may
use drywall screws along with plastic
anchors instead of wood screws.
5
5. Clip mounting brackets onto the light.
TB
PC
PC
PD
PD
INSTALL ADDITIONAL LIGHT:
Final installed illustration 1. Unplug the rst light.
3. Use the measuring template , with
alignment of the light socket position of
rst light, to mark two more mounting
bracket locations next to the rst light,
with each location being 15 in / 38 cm
apart from each other.
PH
PC
3
PH

8
Clip Clip
6. Connect the second light to the outlet
of the rst light, then clip mounting
brackets onto the second light.
6
MAINTENANCE:
CLEANING INSTRUCTIONS: When cleaning, make sure you have unplugged the
light and allow it to cool to room temperature. The light can be cleaned with a
feather duster or a soft damp cloth.
You should only plug in the light after it has been completely dried.
TROUBLESHOOTING:
PROBLEM POSSIBLE CAUSE SOLUTION
Light does not
illuminate.
Light does not turn
on.
The light is not plugged in or the main
switch is OFF. Plug in and turn on the main switch.
The light on/off switch is OFF.
Turn ON the light on/off switch. If
you turn off the on/off switch at the
rst light, the light being linked
together would be turned off along.
PA
PC PC

9
WARRANTY:
KODA
This Koda product carries a 5-year warranty against defects in workmanship
and materials. This product is not guaranteed against wear or breakage due to
misuse and/or abuse.
NOTE: Warranty only applies for North American customers of purchases made
in North America.
CONDITIONS OF WARRANTY
If during the 5-year warranty period your new product is found to be defective,
Koda will repair such defect, or replace the product, without charge for parts or
labor subject to the following conditions:
• All repairs must be performed by Koda.
• All warranty claims must be accompanied by a copy of the sales receipt or bill
of sale.
• The equipment must not have been altered or damaged through negligence,
accident, improper operation, or failure to follow the product instructions for
installation, use, or care.
• The replacement of parts is excluded from the warranty when replacement is
necessary due to normal wear and tear.
• Repair or replacement parts supplied by Koda under this warranty are
protected only for the unexpired portion of the original warranty.
• This is a “repair or replace” warranty only, and does not cover the costs
incurred for the installation, removal or reinstallation of the product.
OWNER’S RESPONSIBILITIES: Koda will make every effort to provide warranty
service within a reasonable period of time. SHOULD YOU HAVE ANY QUESTIONS
ABOUT SERVICE RECEIVED OR IF YOU WOULD LIKE ASSISTANCE IN OBTAINING
SERVICE, PLEASE CALL TOLL FREE 1.866.294.9244 DURING REGULAR BUSINESS
HOURS MONDAY THROUGH FRIDAY 8:00AM TO 5:00PM PST.
NOTE: Toll-free number is for North American customers ONLY. See customer
service section for customer contact numbers for other regions/ofces.
For customer service and technical support, please call us at 1.866.294.9244 or
email us at [e-mail]. If at that time it is determined that a replacement
unit is needed, the support representative will issue a Return Authorization and
instruct on how to get a new unit.
Koda makes no other warranty of any kind aside from the limited express
warranty stated herein.

10
Linkable Multipurpose LED Lights
Model: LM030007
Responsible Party:
Koda
Address: 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626, USA
Tel: [phone]
This device complies with Part 15 of the FCC rules and Industry Canada.
Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modications or change to this equipment. Such modications or
change could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY
AND WARRANTY OF FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS
SPECIFICALLY SET FORTH HEREIN, NO WARRANTY OR REPRESENTATION,
EXPRESS OR IMPLIED, IS MADE AS TO THE LINKABLE MULTIPURPOSE LED
LIGHTS. KODA AND/OR ITS AFFILIATES EXPRESSLY DISCLAIMS, WITHOUT
LIMITATION, ANY STATUTORY WARRANTIES AND ALL IMPLIED WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
FCC / IC COMPLIANCE STATEMENT:

11
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-005(B) / NMB-005(B)
The Facebook logo is a trademark of Facebook, Inc.
The Instagram logo is a trademark of Instagram, Inc.
YouTube and the YouTube logo are registered trademarks of Google Inc.
MADE IN CHINA

12
Have a comment or question? Email us at inf[email protected]
or visit us online at www.KodaBuilt.com
A Horizon Brands Company
2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626, USA | Tel: [phone]
© 2020 Koda. All rights reserved.
ML-030007_V1
