KODA LM030008 Guide

CARE & USE INSTRUCTIONS
IMPORTANT, RETAIN FOR
FUTURE REFERENCE: READ CAREFULLY
For assistance with installation, parts, Wi-Fi connectivity issues or other technical questions,
please email us at [e-mail] or call us at 1-866-294-9244, Monday through Fri-
day, 8 am to 5 pm PT.
Please refer to the Troubleshooting section for common questions and answers, or visit the
Koda Help Center at https://help.horizon-brands.com/hc/en-us
2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626, USA
www.KodaBuilt.com
ITM. / ART. 1600034
Model: LM030008
LED LINKABLE SHOP LIGHT
WITH MOTION SENSOR AND REMOTE
LED UMBRELLA LIGHT
WITH SOLAR CHARGER
TM / MC / MR
@KodaBuiltOfficial

2
IMPORTANT SAFETY INSTRUCTIONS:
This product is suitable for use in home, ofce, warehouse, workshop, garage
and other damp locations. This light has the following unique features:
• Smart Sensor Control System: This light is operated by a Smart
Sensor Control to automatically turn on when motion is detected and will
turn off automatically after no movement has been detected.
• Convenient Wireless Remote: With the remote control, you can easily adjust the
brightness, sensor distance, the timer for auto dim, and the timer for auto-off.
• Linkable: This light can be linked up to 6 units of Koda model LM030008.
DANGER - To reduce the risk of electric shock:
Always unplug this product from the electrical outlet before cleaning.
WARNING: To reduce risk of re, electric shock, or injury to persons:
• Do not modify the power cord plug provided with the product.
• Do not use the light if the power cord or plug is damaged. If damaged, have it
repaired by a service facility before use. If the plug does not t the outlet, have a
proper outlet installed by a qualied electrician.
• Disconnect the power cord plug from the power source before making any
adjustment or changing accessories. Do not attempt to install the product while
plugged in.
• Do not abuse the power cord. Never use the power cord to carry the light or pull
the plug from an outlet. Keep the power cord away from heat, oil, sharp edges,
or moving parts.
• Not for use with dimmer packs, timing devices, motion detectors, or lighting
controllers other than supplied with this product.
• Store the product and remote out of reach of children.
• Only use product in its intended location.
• Close supervision is necessary when this product is used by, or near children,
invalids, or disabled persons.
• Always unplug the appliance from the electrical supply outlet when not in use.
• These portable luminaries have a polarized plug (one blade is wider than the
other) as a feature to reduce the risk of electric shock. This plug will t in a
polarized outlet only one way. If the plug does not t fully in the outlet, reverse
the plug. If it still does not t, contact a qualied electrician. Never use with an
extension cord unless plug can be fully inserted. Do not alter the plug.
• The receptacle is for connecting with the same model LM030008 only, and up to
maximum 6 units (including the rst one).
• Do not connect with other appliances, or connect more than 6 units of light
model LM030008.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT
SAVE THESE INSTRUCTIONS

3
WARNING:
• LED light output is strong enough to injure human eyes. Do not stare at the LED
light while it is illuminating.
• If the light is damaged, it shall be exclusively replaced by the manufacturer
or the service agent or qualied person in order to avoid a hazard.
• The warnings, precautions, and instructions discussed in this manual cannot
cover all possible conditions and situations that may occur. The operator must
understand that common sense and caution are factors which cannot be
built into this product, but must be supplied by the operator.
• Do not tamper with or attempt to repair the LED component or xture. The light
source is designed for this specic application and should not be serviced by
untrained personnel. Contact the customer service department if any servicing
is required.

4
PACKAGE CONTENTS:
1 x Measuring Template
2 x Mounting Brackets
1 x Wireless Remote 1 x Remote Control
Setting Label
2 x AAA Batteries
Screw Hooks
2 x Hanging Hooks2 x Mounting Chains
Tools Needed (not included)
Phillips Head
Screwdriver
Safety GlassesDrill and 2 mm /
5/64 inch Drill Bit
1 x LED Linkable Shop Light
Please lay out all parts and read the instructions prior to installation.
2 x Plastic Anchors 2 x Wood Screws 2 x Washers2 x Drywall Screws
AAA
AAA
30sec 10min 30min
30sec 10min 30min
3M
3M 3M
3M
3M
1 x Remote Holder 1 x 3MTM / MC / MR Tape
(for Remote Holder)
2 x Short Screws
(for Remote Holder)
2 x Short
Plastic Anchors
(for Remote Holder)
PA
PB
TA TB TC
PC PD PE
PF PG PH
PI PJ
PM PN PO PP
PL
TD
PK

5
PRODUCT SPECIFICATIONS:
1. Operating Voltage: 120 Vac, 60 Hz
2. Wattage: 48 W
3. Light Output: 4600 lumens
4. Color Temperature: 4000 K
5. LED Life Cycles: up to 50,000 hours
6. Operating Temperature: 0°C to 40°C / 32°F to 104°F
INSTALLATION PROCEDURES:
The product is intended to be connected to a plug and does not need to be
switched on/off as it is controlled by the motion sensor and the remote control.
Due to the sensor’s ability to detect movement through walls and doors, it is
recommended to disable the motion sensor (see page13) when installing the
light in small rooms (e.g. storage closet, pantry, etc.) so movement outside these
rooms cannot be picked up by the sensor. The light will operate through the main
switch in this scenario.
NOTE: The sensor may detect movement through walls and doors. If installing
multiple LED Linkable Shop Lights, keep at least 1 m / 3.2 ft between each LED
Linkable Shop Light to prevent sensor interference.
NOTE: The light can be linked with the same model LM030008 only, and can be
linked up to maximum 6 units (including the rst one).
CEILING HANGING WITH CHAINS:
This product is ETL/cETL Listed
1. Select a mounting location and make
sure the wooden surface is suitable for
supporting the light. Use the measuring
template to mark the hook locations
on the mounting surface, with each
location being 32 in / 81.3 cm apart from
each other.
Final installed illustration
116 cm / 45.6 in / 45,6 po
7.7 cm /
3 in /
3 po
11.6 cm /
4.5 in /
4,5 po
1
PE
PE

6
5. Clip mounting brackets onto
the light.
The light is intended to be installed
directly beneath a ceiling-mounted
receptacle. The excess power cord
should be kept out of the work space,
such as by securing it to one of the
supporting chains with a cable tie.
NOTE: The mounting brackets should
be at least 32 in / 81.3 cm apart. See
Mounting Diagram on the left for
installation.
2. Wear safety glasses before drilling
pilot holes. Drill two 2 mm diameter
pilot holes.
3. Screw in the screw hooks (not provided).
2 3
4a. Determine the desired hanging
height. Slip the hanging hook through
the chain .
4b. Insert the hanging hook into the
openings of the mounting bracket .
Repeat for the other mounting bracket.
4c. Connect the chain onto the screw
hook. Repeat for the other chain and
hook.
4 5
Mounting Diagram
32 in /
81.3 cm
6.9 in /
17.6 cm
6.9 in /
17.6 cm
TB
TD
4b
4a
4c
TD
PF
PF
PF
PH
PH
PH
PH
PG
PG
PG
PG
PA
TD

7
NOTE: The mounting brackets should
be at least 32 in / 81.3 cm apart. See
Mounting Diagram above for installation.
Mounting Diagram
32 in /
81.3 cm
6.9 in /
17.6 cm
6.9 in /
17.6 cm
CEILING FLUSH MOUNT:
Final installed illustration
2. Wear safety glasses before drilling
pilot holes. Drill two 2 mm diameter
pilot holes.
2
3. Screw the mounting bracket with
the wood screw provided. Repeat for
the second mounting bracket.
Note: For concrete or drywall, you may
use drywall screws along with plastic
anchors instead of wood screws.
3
4. Clip mounting brackets onto the light.
4
Clip Clip
1
TB
PG
PG
PE
PG
PG
PG
PA
1. Select a mounting location and make
sure the wooden surface is suitable for
supporting the light. Use the measuring
template to mark the hook locations
on the mounting surface, with each
location being 32 in / 81.3 cm apart from
each other.
PE
PK
PK

8
4a. Slip the hanging hook into the
screw hook . Repeat for the second
hanging hook.
4b. Insert the hanging hook into the
middle opening of the mounting bracket .
Repeat for the other mounting bracket.
5. Clip mounting brackets onto the
light.
2. Wear safety glasses before drilling
pilot holes. Drill two 2 mm diameter
pilot holes.
1. Select a mounting location and make
sure the wooden surface is suitable for
supporting the light. Use the measuring
template to mark the hook locations
on the mounting surface, with each
location being 32 in / 81.3 cm apart from
each other.
CEILING HANGING WITH HOOKS:
Final installed illustration
3
2
a
b
4
1
5
NOTE: The mounting brackets should be at
least 32 in / 81.3 cm apart. See Mounting
Diagram on the right for installation.
Mounting Diagram
32 in /
81.3 cm
6.9 in /
17.6 cm
6.9 in /
17.6 cm
PE
PE
TB
TD
PH
PH
PH
PG
PG
PG
PG
TD
TD
TD
3. Screw in the screw hooks (not provided).
TD
PA

9
WIRELESS REMOTE:
Before using the remote, please open the switch cover on the back and insert the
two AAA batteries provided.
Battery Safety Review:
• Clean batteries and battery contacts with a clean, dry cloth before inserting.
• Always use the correct size, grade, and type of batteries that are most suitable
for the intended use.
• Replace all batteries at the same time. Do not mix old and new batteries.
• Ensure the batteries are installed correctly according to polarity (+ and -).
• Remove batteries when they are not used for an extended period of time.
• Remove used batteries promptly when needing replacement.
When using the remote, you must point the remote directly at the light to ensure
the signals can be sent to the light. When the light receives the remote signal, the
light will blink once as a visual conrmation.
Note: This remote uses infrared (IR) to send commands to the LED Linkable Shop
Light. It is possible to control multiple LED Linkable Shop Lights from one remote
as long as the lights are within line-of-sight of the remote to receive commands.
1. Power Button
Press the button to turn the light on and off accordingly.
NOTE: When you press the power button to turn light off while the motion sensor
is set to ON, the light will turn ON automatically again when there is motion detected.
2. Night Mode
By pressing the button, the light will dim to 10% brightness.
3. Brightness
You can adjust the brightness from 10% to 100% by pressing the or button
continuously. Press the button to increase the brightness and
press the button to dim. You may also press the button to reach 100%
brightness instantly or the button to reach 10% brightness instantly.
REMOTE SETTINGS:
12
3
5
4
6
7
30sec 10min 30min
30sec 10min 30min

10
5. Time Until Off
This is the time for the light to turn OFF completely when there is no motion
detected. You can choose from Off, 30 seconds, 10 minutes, or 30 minutes.
Icon
Timer Off 30 seconds 10 minutes 30 minutes
The light will be turned OFF when there is no motion detected within the preset
time. Any movement detected within this period will restart the timer and the
light will be turned on again.
The timer of light will start counting the Time Until Dim function and then the
Time Until Off. (E.g. for both timer settings are 30 sec: the light will be dimmed
down when no motion has been detected for 30 seconds and the light will be
turned OFF when no motion is detected within 30 seconds after. Any movement
detected within this period will restart the timer, and the light will turn on again.)
You can select ‘OFF’ if you want to have the light turned ON at all times. By
selecting this mode, the Ambient Light Sensor function will be disabled.
NOTE: Total duration the light is on for includes Time Until Dim plus Time Until Off.
6. Ambient Light Sensor
Ambient Light Sensor refers to the surrounding area light level to keep light
OFF during the daytime regardless of any movement. You can choose from Off,
Overcast, Dusk or Night.
Setting
Ambient Light
Sensor Off Overcast Dusk Night
For example, if you set to Overcast, when the surrounding area is bright enough,
such as sunny day, the light will stay OFF even if motion has been detected. When
the surrounding area is less bright than overcast and there is motion detected
by the sensor, the light will turn ON. In ‘Night’ setting, the light will turn ON only
when the surrounding area is dark and there is motion detected by the sensor.
The ‘OFF’ mode is for usage where you want to disable the light sensor function,
i.e. the light is controlled by motion sensor only.
30sec 10min 30min
4. Time Until Dim
This is the time to dim the light when no movement is detected. You can choose
from Off, 30 seconds, 10 minutes, or 30 minutes.
Icon
Timer Off 30 seconds 10 minutes 30 minutes
The light will be dimmed to 50% of the preset brightness level setting if there is
no movement detected by the sensor. Any movement detected within this period
will restart the timer.
30sec 10min 30min
