Kodak DryView
8300/8600/8610 LASER IMAGING SYSTEMS
Service Bulletins

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
©Eastman Kodak Company, 2004 Eastman Kodak Company Restricted Pub No. 7F6652
SERVICE BULLETIN NO. 884 June 2004
Kodak DryView 8300 LASER IMAGER
Service Codes: 1425, 1426, 1427
New Solution for EC 27 or EC 28
Caused by FILM Stalling in the PROCESSOR
Purpose
The purpose of this Service Bulletin is to communicate that the cause of, and solution for, FILM
stalling in the PROCESSOR has been determined.
Description
The main cause of FILM stalling in the PROCESSOR is the inability of the RUBBER IDLER
ROLLER at the entrance to the PROCESSOR to turn freely as FILM enters the PROCESSOR. This
condition causes the FILM to slip and after some time, the software times out and displays EC 27 or
EC 28.
Note: EC 28 is usually caused by FILM slipping at the entrance to the PROCESSOR. However, the
EC is displayed when the FILM does not exit in the time expected by the software. This is
because if the FILM gets a slow start into the PROCESSOR, the FILM may eventually pass
through the PROCESSOR, but the FILM still does not exit in the time expected by the
software.
Solution
If an IMAGER experiences repetitive EC 27 or EC 28 errors, replace the gray plastic BUSHINGS
that hold the RUBBER IDLER ROLLER in place with a pair of METAL BALL BEARING
BUSHINGS (7E9722). Replace the gray plastic BUSHINGS only at the PROCESSOR entrance.

Printed in the USA. Pub No. 7F6652
©Eastman Kodak Company, 2004
Rochester, NY 14650 HEALTH IMAGING
Service Information
Gary Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-62
Oakdale, MN 55128-3414, USA
1-800-328-2910
Kodak and DryView are trademarks of Eastman Kodak Company.

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
Eastman Kodak Company, 2004 Eastman Kodak Company Restricted Pub No. 7F6199
SERVICE BULLETIN NO. 860 APRIL 2004
Kodak DryView 8300 LASER IMAGER
Service Codes: 1425, 1426, 1427
ProComm Plus COMMUNICATIONS PROGRAM To Be Used When Uploading System
Software
Purpose
The purpose of this Service Bulletin is to communicate that the Hyperterminal
COMMUNICATIONS PROGRAM does not function adequately when used with the newest models
of LAPTOP COMPUTERS.
Description
The inefficiency of the Hyperterminal COMMUNICATIONS PROGRAM, when used with the new
higher-speed LAPTOP COMPUTERS, can cause it to take up to four hours to upload new system
software into the Kodak DryView 8300 LASER IMAGER. The Pro Comm Plus
COMMUNICATIONS PROGRAM is a more sophisticated program that will allow software
uploads to take no longer than 10-12 minutes. In addition, the ProComm Plus
COMMUNICATIONS PROGRAM will provide an estimate of the total time required for a software
upload as well as a progress gauge.
Procedure
The next time you install a software upgrade in a Kodak DryView 8300 LASER IMAGER, follow
the procedure in paragraph 2-9-2 in the SERVICE MANUAL for the Kodak DryView 8300
LASER IMAGER.

Printed in the USA. Pub No. 7F6199
©Eastman Kodak Company, 2004
Rochester, NY 14650 HEALTH IMAGING
Gary Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-62
Oakdale, MN 55128-3414, USA
1-800-328-2910
Kodak and DryView are trademarks of Eastman Kodak Company.

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
SERVICE BULLETIN NO. 26 NOVEMBER 2003
1425, 1426, 1427 Kodak DryView 8300 LASER IMAGER
Procedure to Reduce Film Errors (EC33)
Purpose
The purpose of this Service Bulletin is to communicate that there is a relatively easy way to reduce
the number of film-feed retries and failures that result in EC 33. On your next service call, examine
the Error Log, which can be accessed from the Test Menu (911). If there are EC 33s listed in the log,
perform the procedure below.
Details
Excessive pressure applied to the film by the registration foam, on the left side of the FILM TRAY,
can cause film-feed retries and failures. The easiest way to reduce this pressure is to remove the
middle third of the six-inch foam that holds the film in place.
Procedure
With a ruler and a sharp knife, measure, cut and remove the middle two inches of the registration
foam as shown in the illustration. Be sure to remove only the middle two inches of foam. Clear the
FILM TRAY of all foam debris resulting from the cuts.
Removing Middle Two-Inch Section of Registration Foam
Eastman Kodak Company, 2003 Pub No. 7F3182

Gary J. Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-62
Oakdale, MN 55128-3414, USA
1-800-328-2910
Kodak and DryView are trademarks.
Printed in the USA. Pub No. 7F3182
©Eastman Kodak Company, 2003
Rochester, NY 14650
HEALTH IMAGING

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
ãEastman Kodak Company, 2002 Pub No. 8E7557
SERVICE BULLETIN NO. 25 November 2002
1425, 1426 and 1427 Kodak DryView 8300 LASER IMAGER
GAS SHOCK ABSORBER May Allow TOP COVER to Close
Purpose
The purpose of this service bulletin is to communicate that if the GAS SHOCK ABSORBER becomes weak,
it may allow the TOP COVER to close even if the operator does not want it to close.
Procedure
On the next service call and then during each PM call thereafter, check the operation of the GAS SHOCK
ABSORBER (SP78-8100-0495-8) that is used to keep the TOP COVER open. If it fails to securely hold the
TOP COVER in its full open position, replace it.

Printed in the USA. Pub No. 8E7557
©Eastman Kodak Company, 2002
Rochester, NY 14650 HEALTH IMAGING
Gary Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-62
Oakdale, MN 55128-3414, USA
1-800-328-2910
Kodak and DryView are trademarks.

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
ãEastman Kodak Company, 2002 Pub No. 8E6997
SERVICE BULLETIN NO. 24 October 2002
1425, 1426 and 1427 Kodak DryView 8300 LASER IMAGER
Scratch Reduction Tool Available
Purpose
The purpose of this service bulletin is to provide information about a new tool that can be used to reduce
repetitive scratching caused by particles or nicks on the FILM GUIDE SCOOP.
Procedure
To assist in the removal of repetitive scratches caused by particles or nicks on the lower FILM GUIDE
SCOOP order the CROCUS CLOTH KIT 8E2083.
The CROCUS CLOTH is inserted manually onto the SCOOP, in the same manner as a piece of film would
travel on the scoop. It is then rubbed against the entire length of the SCOOP so that it reaches the top edge,
near the CAPSTAN ROLLER.
Once the polishing process is complete, clean the SCOOP thoroughly with an alcohol wipe such as a
TX-1065 to remove any particles that were dislodged by the CROCUS CLOTH.

Printed in the USA. Pub No. 8E6997
©Eastman Kodak Company
Rochester, NY 14650 HEALTH IMAGING
Gary Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-62
Oakdale, MN 55128-3414, USA
1-800-328-2910
Kodak and DryView are trademarks.

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
ãEastman Kodak Company, 2002 Pub No. 8E6688
SERVICE BULLETIN NO. 23 AUGUST 2002
1425, 1426 and 1427 Kodak DryView 8300 LASER IMAGER
Instructions for Grounding the PROCESSOR ASSEMBLY to Eliminate EC88s
Purpose
The purpose of this service bulletin is to provide instructions for grounding the PROCESSOR ASSEMBLY
using the PROCESSOR GROUNDING HARDWARE KIT, 8E2003.
Procedure
1. Remove the SPRING CLIPS from the FRAME and CLAMSHELL of the PROCESSOR
ASSEMBLY (see Fig. 1).
2. Attach one end of the WIRE (supplied in the KIT) to the STRIPPER ASSEMBLY using the right
mounting SCREW of the STRIPPER ASSEMBLY (see Fig. 2).
3. Attach one end of 1 small STRAP (supplied in the KIT) along with the loose end of the WIRE
referred to in Step 2, to the FRAME where the CLIP was removed in Step 1 (see Fig. 2).
4. Remove the SCREW holding the ROLLER ASSEMBLY MOUNTING ROD, and using the supplied
SPACER and SCREW, attach the loose end of the small STRAP to the ROLLER ASSEMBLY
MOUNTING ROD (see Fig. 2).
5. Repeat Steps 3 and 4 to attach the remaining small STRAP to either side of the CLAMSHELL
portion of the PROCESSOR ASSEMBLY.

Page 2 Pub No. 8E6688
Figure 1
Figure 2
1. Remove
2. Connect WIRE to
STRIPPER ASSEMBLY
3. Connect WIRE to one
end of STRAP
4. Add STRAP, SPACER and
SCREW to ROLLER
ASSEMBLY

Pub No. 8E6688 Page 3
Gary Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-62
Oakdale, MN 55128-3414, USA
1-800-328-2910

SERVICE BULLETIN
Health Imaging Products
Eastman Kodak Company, Health Imaging, Rochester, NY 14650
ãEastman Kodak Company, 2002 Pub No. 8E6674
SERVICE BULLETIN NO. 22 AUGUST 2002
1425, 1426 and 1427 Kodak DryView 8300 LASER IMAGER
Clicking Sound Coming From Left Side of IMAGER
Purpose
The purpose of this service bulletin is to communicate what causes, and how to correct the intermittent
clicking sound that may be heard in the left side of the IMAGER.
Cause
The BEARINGS inside the COMPOUND PULLEY are loose causing them to move in and out. The
BEARING ASSEMBLIES are supposed to be glued into the COMPOUND PULLEY so that they can’t be
removed.
Solution
Replace the COMPOUND PULLEY 78-8100-0410-7. Before installing it into the IMAGER, be sure that
both BEARINGS are firmly in place within the COMPOUND PULLEY.

Printed in the USA. Pub No. 8E6674
©Eastman Kodak Company, 2002
Rochester, NY 14650 HEALTH IMAGING
Gary Ketch, Service Engineer-Oakdale
For more information please contact:
Eastman Kodak Company
Health Imaging
1 Imation Way
Discovery Building 3B-61
Oakdale, MN 55128-3414, USA
1-800-328-2910
Kodak and DryView are trademarks.

Health Imaging
Technical Bulletin 8300
Eastman Kodak Company
1 Imation Way
Oakdale, MN 55128
Health Imaging Products
http://www.kodak.com Printed in the U.S.A.
© Kodak 2000 Sept.
5-9/00 Clicking Sound from Left Side of Imager
Problem:
Intermittent clicking sound from the left side of the imager.
Cause:
The Compound Pulley (78-8100-0410-7), which transfers power from the main drive belt to the Separator
Assembly, is made up of a black plastic pulley housing and two bearings. If one of the bearings starts to
deteriorate, it will cause the pulley to emit an intermittent clicking sound.
Solution:
Replace the bad bearing. The bearings are the same Common Bearing (78-8113-2008-0) used throughout
the imager, and can be replaced individually. If the Pulley Mounting Shaft (78-8100-0614-4) has been
damaged by the bearing, it also can be easily replaced.
6-9/00 Thumping Sound from Left Side of Imager
Problem:
Occasional thumping sound from the left side of the imager.
Cause:
The main drive belt, which connects the main stepper motor to the Separator Assembly and the Processor
Assembly, can skip a tooth from time to time, causing the thumping sound. This skipping of teeth, which
can be caused by a loose belt, results in belt wear. The belt wear is evidenced by a buildup of black
“powder” (belt particles) on the left side frame and base plate. If the problem condition has existed for a
long time, the black powder can build up on the teeth of the Compound (two part) Pulley. This buildup on
the pulley can cause the belt to continue to skip, even after its tension has been adjusted.
Solution:
Tighten the tension of the main drive belt, as necessary, by adjusting the eccentric. Check for powder
buildup on the Compound Pulley, and clean the pulley, as necessary. (The Compound Pulley is black, so
the powder buildup is not easy to see.)

2
7-9/00 Thin Horizontal Line Across Width of Film
Problem:
A horizontal line appears across the film, about 5-1/2 inches from the top. It may look like image data is
missing in one or two scan lines. The line, which may be intermittent, occurs across the entire width of the
film, traversing both the image and the borders.
Cause:
The operator may have removed a jam and attempted to snap the upper film guide back into place, but only
one side got latched. The line is caused by the film hesitating while it is being imaged, as it enters the
processor assembly.
Solution:
As a phone fix, ask the operator to reseat the upper film guide and ensure that it is snapped into place on
both sides.

Model 8300 Technical Bulletins
7-2/98
ATL HDI DICOM Print Setup
Currently the HDI 3000 and 5000 have DICOM print available, but the HDI 1000 does not. Use the
following procedures to change the DICOM print parameters on the HDI 3000 and 5000.
All options are selected by moving the cursor with the trackball to the appropriate menu item and
pressing the Select key.
Network Printer Configuration Parameters
1. Press the Setups key to access the Setups Options directory.
2. Select Access Link Directory.
3. Select Configuration Files.
4. Select Edit.
5. Select Host Table.
6. Scroll to and select Image Parameters.

Model 8300 Technical Bulletins
Use the keyboard to insert the 8300 network printer configuration parameters as follows:
Alias IP Address Port Number Model ID AE Title
3M8300_254 Determined by System
Administrator 104 3m_8300_Printer_v1 3M_8300
7. Close the menu
Device File Table
The 8300 device file is not in the system software because the memory overflow problem had not
been resolved when the DICOM print software for the HDI 3000 was released. ATL plans an 8300
disk that will be used to install the table on the HDI 3000 and 5000. The table can also be installed
manually.
1. Press the Setups key to access the Setups Options directory.
2. Select Access Link Directory.
3. Select Configuration Files.
4. Select Edit.
5. Select Devices.
