Kodak DCS Pro Back Plus User manual

DCS Pro Back Plus
Quick Reference
Displaying and Navigating the Menu Bar
Using the Image LCD and Digital Buttons
Turn the Image LCD on .........................................Press the OK button.
Select a highlighted menu option ..........................Press the OK button.
Enable Region of Interest box (Zoom mode).........Press the OK button.
Implement a zoom (Zoom mode) ..........................Press the OK button.
Delete an image (Delete mode).............................Press the OK button.
Toggle the Menu bar on/off....................................Press the Menu button.
Turn the Image LCD off .........................................Press the Cancel button.
Dismiss a menu without implementing change .....Press the Cancel button.
Disable Region of Interest box (Zoom mode)........Press the Cancel button.
Navigate through images in all Display modes
(except Zoom mode when Region of
Interest box is on) .............................................Press the left or right side of the 4-way switch.
Using the Image LCD and Digital Buttons (continued)
Navigate the Menu bar and display menus ...........Press the left or right side of the 4-way switch.
Navigate a drop-down menu .................................Press the top or bottom of the 4-way switch.
Change to a different Display mode ......................Press the top or bottom of the 4-way switch.
Move the Region of Interest box (Zoom mode) .....Press any edge of the 4-way switch.
Connecting to a Computer with
Two IEEE 1394 Ports
IEEE
1394 cable
Computer AC AC adapter
DC
DCS Pro Back
Plus
Connecting to a Computer with
One IEEE 1394 Port
Connecting to a Computer Using Battery Power
Compatible
Battery
Computer
IEEE
1394 cable
Battery cable
DCS Pro Back Plus
Computer
AC adapter
DC
AC
IEEE
1394 hub
DCS Pro Back
Plus
IEEE
1394 cable
Folder icon
Menu icon
Status screen icon
Video icon
Tag icon
Contrast icon

EASTMAN KODAK COMPANY
Rochester, New York 14650
© Eastman Kodak Company, 2001
Kodak and Kodak Professional are trademarks.
Printed in U.S.A. P/N 6B5811 9/01
Rear
PWR CANCEL
MENU OK
DCS Pro Back Plus
Front (attaches to camera body)
Image LCD
Power button
Sides Inserting/Removing a CF Card
To Insert:
1. Open the Card door.
2. Insert a card in the slot and press firmly
until you feel the card seat. (When using
a single card, you can use either slot.)
3. Insert a second
card, if needed.
(The first card
inserted is the
active card.)
4. Close the Card
door.
To Remove:
1. Open the Card door.
CAUTION: Do not remove the card when
the Card Busy LED is flashing. Doing so
could destroy all the image files on the
card.
2. Press the Eject button next to the card
to be ejected.
Connecting to a Battery
in Portable Mode
Connecting to an AC Adapter
in Portable Mode
Battery Cable
Compatible
Battery
DCS Pro Back Plus
DC
AC
DCS Pro Back Plus
AC adapter
Camera Ready LED
Image LCD Tilt Latch
Cancel button
Menu button
Four-way switch
OK button
Filter Latch IR Filter*
Slots for connecting to camera
body or MAMIYA Interface Plate
*To obtain correct focus you must use either an IR filter or
an anti-aliasing filter which is available as an accessory.
Lens Sync
Cable jack
Flash Sync
Cable jack
IEEE 1394
Port
Battery
Connection
jack
Card1 Eject button
Card2
Busy LED
Card2 slot
Card1 slot
Card door
S-Video
Output jack
Card2 Eject
button
Card1 Busy
LED
Remote Shutter
release jack
