Kogan KA6BWRTIKBA User manual

6-IN-1 BABY WALKER & TRIKE
(BLACK & GREY)
KA6BWRTIKBA & KA6BWRTIKGA

Improper use may cause accidents, so read this guide carefully and retain it for future
reference.
•Keep small parts away from children to avoid choking hazards or other accidents.
•Do not use in hazardous areas such as on slopes, roads, and steps.
•Keep hands and feet clear of the wheels and other moving parts.
•Do not expose the product to the sun for an extended period, as this may cause
discolouration.
•Do not let the child stand on the saddle.
•The product must be checked by the supervising adult for loose screws or other
faults before children may ride the product.
•When cornering, the pedals may rotate; pay attention to ensure safe use.
•Do not store the product in a moist or high-temperature area.
•Do not use on roads with traffic.
•Screws may loosen after prolonged use.
SAFETY & WARNINGS
Note:
To ensure safety each product is assembled, each component of the product has
been tested, so there may be minor scratches at the point of assembly.
WARNING: The tape, plastic, packing belt and other packing materials are
not toys and should be disposed of immediately.

Product assembly must be carried out by a parent or guardian.
1. Pull the handle to unlock and then pull down on the seat to unfold the product.
2. Pull the seat down and then open the clamp on the back of the seat by
unscrewing.
ASSEMBLY

3. Thread the steering rod through the clamp on the back of the seat and then close
the clamp with the rotary screw. Fix the steering rod in place with the thread under
the reverse control lever.
4. Align the awning with the slots at the rear of the seat.
5. Insert both ends with the ‘L’ and ‘R’ indications on the guard rail into the matching
slot that is behind it. If the ‘L’ and ‘R’ indications are not aligned correctly, the safety
barrier will not lock into place.

6. Pull the down on the pedals to unlock them.
7. Press the button to adjust the angle of the steering rod.
8. To fold up the product:
•Place the brakes on both wheels.
•Lift the safety barrier and pull the pedals back.
•Press and hold the button on the steering rod to fold it down.
•Pull up on the handle to release the locking mechanism.
•Fold the product until it locks into place once more.

Brake system
The front wheel has a clutch function that can be engaged by pushing the button shown to
lock it in place. When engaged, the pedals and wheel are linked and will rotate
simultaneously. When the button is pressed to free the clutch, the pedals and wheel will
rotate separately.
Both rear wheels have brakes which can be engaged by pressing down on the levers with
the feet. Press the lever again to release the brake

Bike configuration
Install the push bar behind the seat and attach it with screws.
A backpack can be hung from the rear.
Install the pedal on the frame and attach it with screws.

Install the restraining bar clips into the slots on the body to attach.
Open the restraining bar and insert it through the openings in front of
the seat. Close the bar and with the buckle and attach the headrest
with Velcro.

Attach the cover by inserting it into the slots behind the main body.

Material
P P, ABS
Age suitability
1.5 - 5years
Weight limit
30kg and below
Height requirements
80 to 100cm
Frame
Cover
Safety guardrail
Bag
Steering rod
Assembled vehicle
SPECIFICATIONS
IN THE BOX

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
