Kogan KASOUPWZBLA User manual

SOUP & SMOOTHIE WIZARD
(BLACK / WHITE)
KASOUPWZBLA & KASOUPWZWHA

Read the operating instructions carefully before putting the appliance into operation and
keep the instructions including the warranty, the recipe and, if possible, the box with the
internal packing. If you give this device to other people, please also pass on the operating
instructions.
•The appliance is designed exclusively for private use and the envisaged purpose.
This appliance is not fit for commercial use. Do not use it outdoors. Keep it away
from sources of heat, direct sunlight, humidity (never immerse it in any liquid) and
sharp edges. Do not use the appliance with wet hands. If the appliance is humid or
wet, unplug it immediately.
•When cleaning or putting it away, switch off the appliance and pull out the plug
from the socket (pull the plug itself, not the lead) and remove the attached
accessories.
•Do not operate the machine without supervision. If you leave the room, you should
always turn the device off. Remove the plug from the socket when the product is
not in use.
•The device and the mains lead must be checked regularly for signs of damage. If
damage is found the device must not be used.
•Do not try to repair the appliance on your own. Always contact an authorised
technician. To avoid the exposure to danger, always have faulty cable be replaced
only by the Kogan.com with a cable of the same type.
•Use only original spare parts.
•To ensure the safety of children, please keep all packaging (plastic bags, boxes,
polystyrene etc.) out of their reach.
SAFETY & WARNINGS
WARNING:
•During cooking, the temperature of the touchable stainless-steel surface
may be very hot. Only touch the mixing appliance by its handle when in
use.
•Exercise extreme caution when opening the lid. Do not reach into the
filler opening in the lid.
•The mixer blades are sharp and present the risk of injury. Always take
extreme care when handling or cleaning the blades.

•Before replacement of accessories or additional parts which move during
operation, the device must be switched off and removed from mains power.
•Do not touch moving parts until they have come to a complete stop.
•Place the appliance on a firm and even surface, set it up so that it cannot tip over.
•The machine should only be used under supervision.
•Do not manipulate any of the safety switches. They prevent the appliance from
being operated without an attached mixing jug and a closed lid.
•Do not remove the lid during operation.
•Do not use the appliance without any content.
•Do not carry or lift the appliance during operation but turn it off first and then
disconnect the mains plug. Always carry the appliance with both hands! This
appliance can be used by children aged from 8 tears and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children without supervision.
This device is used for:
•Mixing of liquids
•Heating, cooking, and pureeing of dishes.
It is intended for household use and similar fields of application such as:
•In staff kitchens of shops, offices, and other work areas.
•By guests in hotel, motels, and other accommodation facilities.
•In bed and breakfast accommodation. It is not intended for use on agricultural
properties.
It is only to be used as instructed in this user manual. The appliance is not intended for
commercial use. Any other use shall be considered as not intended and can lead to
material damage or even personal injury.

1
2
3
4
5
6
1
Inner lid
2
Lid
3
SUS 304 jug
4
Handle
5
Housing
6
Control panel
Chunky
Smooth
Sauce
Steam
Juice
Blend
Ice
Pulse
On/Off
OVERVIEW

Before first use
•Remove the device from its packaging.
•Remove all packaging materials such as foils, filling materials, cable holders and
carton packaging.
•Check the appliance for possible transport damage to prevent hazards.
•Should the packaging contents be incomplete or should you notice any damage,
refrain from using the appliance and contact Kogan.com for assistance.
Attach the mixing jug
Place the mixing jug onto the base unit.
Put the lid on
1. Place the lid onto the mixing jug so that the latch with the lock is situated on the
right beside the handle.
2. Twist the lid clockwise toward the lock. The lock must sit securely in the handle of
the mixing jug. Pay attention to the symbols while doing so. The marking on the lid
and the marking on the handle must be aligned, and then turned clockwise to
close.
Note:
There may still be dust or production materials on the device when it is received. It is
recommended to you clean the device as outlined under “Cleaning & Care” before use.
ASSEMBLY
Note:
•Incorrect assembly will prevent the appliance from being operated.
•Always close the lid with the cap in place before mixing.

Before first use
It is important to clean the appliance before first use or if it has not been used for a long
period. See the “Cleaning” section for more information.
Before using the soup maker for the first time, wipe down the jug and lid with a damp cloth
and a mild detergent. Rinse carefully.
When first using the appliance, you may notice some smoke/vapour emitting from the lid;
this is normal and is simply grease that is used on some parts of the appliance applied
during the manufacturing process. After several uses, this effect will diminish.
Electrical connection
Check if the mains voltage of the wall outlet to be used matches that of the appliance. You
will find the information about this on the rating plate.
Only connect the appliance to a properly installed earthed socket. You will hear a beep
when the appliance is assembled correctly together with the lid.
Appliance functions
Main functions: Smooth, chunky, sauce, steam, juice, blend, ice, and pulse
1. Plug the appliance into the mains outlet and the on/off indicator will flash. Press
the button and all function buttons will illuminate, with the appliance entering
standby mode.
2. If the on/off button is pressed during standby mode, the appliance returns to a
dormant state and the on/off button indicator flashes. Any entered programs will
be cancelled. Unplug the power plug from the wall outlet, and the on/off indicator
will dim.
OPERATION
Control Panel

3. When the lid is opened or the jug is taken out during operation, the alarm will
sound, and operation will cease.
Ingredients
Cut up ingredients into 2cm squares before placing them into the jug. It is recommended to
use a ratio of 2 parts food to 3 parts of water. This will help the soup maker operate more
efficiently and will sustain the life of the appliance. A maximum quantity of 700ml of food is
recommended per mixing session.
Mixing container capacity
Always observe the maximum capacity on the mixing jug:
COLD: Max. 1750ml - 700ml of food maximum
SOUP: Max. 1500ml - 600ml of food maximum
Select a program
1. Smooth soup
Press the Smooth Soup button, and then press the on/off button to enter this program.
The Smooth soup program is intended for soup recipes requiring a smooth consistency,
such as roast tomato soup. The program ensures the ingredients are blended to the right
consistency and gently cooked at the correct temperature. The programme lasts for 25
minutes before the soup is ready to serve.
Note:
The appliance can only be worked when mixing jug is closed with the lid in place.
Note:
Foamy liquids require a larger volume. Reduce the quantity of liquids that foam
excessively.

2. Chunky soup
Press the Chunky Soup button, and then press the on/off button to enter this program.
The chunky soup programme is intended for rustic soup recipes requiring a chunkier
consistency, such as lamb & lentil broth. The programme allows the ingredients to be
heated for longer to ensure the chunky ingredients are fully cooked. The programme lasts
for 26 minutes before the soup is ready to serve.
For chunky soup, there is no blending process, just heating. It is therefore recommended
that you cut any vegetables into small diced pieces. If your soup is a little too chunky after
cooking, select the blend function to gain your desired consistency.
3. Sauce
Press Sauce button, and then press the on/off button to enter this program.
The Sauce programme is intended for sauces and jams such as apple jam, orange jam and
so on; the programme lasts for 25 minutes.
4. Steam
Press Steam button and then press the on/off button to enter this program.
The hot soup readies once the indicators dim. The appliance only heats during this function,
and the process will take approximately 30 minutes.
5. Juice
Press Juice button, and then press the on/off button to enter this program.
The juice setting is intended for making smoothies or milkshakes from fresh ingredients. The
programme lasts for 2 minutes before the drink is ready to serve. The juice setting does not
heat the ingredients, so this function works well for ice-cold drinks in hot weather.
6. Blend
Press Blend button, and then press the on/off button to enter this program.
The blend setting allows you to further blend the soup to your desired consistency if
required. This function works without additional heating of the soup and can also be used to
clean the jug. The blending function operates for 3 minutes.

7. Pulse
The appliance will blend for as long as the Pulse button is held down.
Do not use the blending mode for more than 20 seconds without letting the appliance
cooled down sufficiently afterwards.
8. Ice
Press the Ice button, and then press the on/off button to enter this program.
This setting is designed for crushing ice, and the appliance will operate for 50 seconds.
WARNING:
•The blend function is not suitable for raw meat.
•Do not blend dry ingredients: some liquid must be added before
blending.

For cleaning the outside of the machine, use only a damp washing-up cloth.
Mixing jug
1. Fill the mixing jug with 1.5-litres of water and add a few drops of dishwashing liquid.
CAUTION: Water with dishwashing liquid will foam up during heating and mixing.
2. Select the Blend function.
3. Allow the water to cool before cleaning the inside wall of the mixing jug.
4. Clean the mixing jug from the inside with a sponge.
5. Rinse off the mixing jug with clean water and carefully dry it off.
CLEANING & CARE
WARNING:
•Before cleaning, always disconnect the unit from the mains power
supply
•Under no circumstances should you immerse the device in water for
cleaning purposes. This presents the risk of electric shock or fire.
•The mixer blades are sharp and present the risk of injury. Always take
extreme care when handling or cleaning the blades.
CAUTION:
•Do not use a wire brush or any abrasive items.
•Do not use acidic or abrasive detergents.
•The mixing jug is not dishwasher safe.
•The base of the mixing jug contains electronic components that must
not get wet. Should water penetrate the base of the mixing jug, allow
it to dry completely before using the appliance again.

Lid and cover
•Clean these components in a rinsing bath.
•Rinse with clean water.
•Dry the parts off.
Storage
•Clean the device as described. Let the accessories dry completely.
•It is recommended to store the device in its original packaging when it is not to be
used for an extended period. Always store the device at a well ventilated and dry
place outside the reach of children.
Power supply
220
～
240V, 50/60Hz
Power consumption of motor
500W
Power consumption of heater
700-900W
Capacity
1.5L for hot soup/1.75L for cool drinks
SPECIFICATIONS

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
