Kogan KGNDPFC8 User manual

0
8” Digital Photo Frame
KGNDPFC8
Instruction Manual

0
TABEL OF CONTENTS
SAFETY INFORMATION……………..….…………1
PACKAGE CONTENTS……………..….………….1
SPECIFICATION SUMMARY…………….…………2
DPF I NT RODUCTION……………… …....………3
Q U I C K S TA R T … … … … … … . . ………… … … … 5
OPERATION GUIDE……………..………..………5
Movie Display………….…………………………. 6
Music Display…….………………………………6
Picture Display……….…………………………….7
Combo Display…… .…………….……….………7
Edit…………………………….……………..……..8
C o m p ut e r c o nn e c t i on……….…….……………9
S e tu p … ..… …… … … ………… … … … …… . . …. . 9
Calendar / Clock / Alarm....................................10
OSD MENU FUNCITONS………………………………10
FAQ………………………….………………..………12

1
Safety Information:
Keep away from water, moisture and dusty areas.
Working temperature 0-40°C. Never store in a hot or very
cold place.
Be careful not to drop or knock the photo frame.
Never try to open the case yourself, always seek technical
support.
Connect the AC adaptor to both the DC IN jack and to the
power outlet. (mains socket)
Only use attachments / accessories approved by the
manufacturer.
When left unused for a long period of time, the unit should
be unplugged from the household AC outlet
Warning: To reduce the risk of fire or electric shock, do not
expose to rain, moisture, dripping or splashing.
Package Contents:
Digital Photo Frame Remote Control Adapter

2
Specification Summary
Main Features:
Plays digital photos as slide shows with background music
Play Music and videos
Display calendar and clock with alarm
Rotate and zoom photos
Brightness, contrast and color adjustable
Easy to use on-screen menus & button controls
Supported Memory Card Formats
Secure Digital (SD)
Multi Media Card (MMC)
Memory Stick (MS), MS Pro, MS Duo, MS Pro Duo
Secure Digital High Capacity (SDHC)
Compact Flash (CF)
MS Duo adaptor required
Specifications
Pictures: JPEG up to 16 megapixel resolution
Vedio:MPEG-1\2\4, Motion JPEG
Audio: MP3
USB ports - USB 2.0 Device
- USB 2.0 Host
AC adapter
-Input AC 100V240V. 50-60Hz
-Output DC12V-1.5A

3
DPF Introduction

4
Remote Control
Note: a) To edit or adjust, press MENU on the remote control;
or you can instead press button Mon the frame for 3
seconds.
b) To go back a step or go to the main menu, press
EXIT on the remote control; or you can instead
press button Mon the frame.

5
Quick Start
Insert the jack of the DC adaptor into the digital photo frame, and
then plug the DC adaptor into a standard power outlet.
Operation Guide
1. Main Menu
1) Card select: Show which card you insert into frame
2) Setup: adjust frame settings
3) Calendar: display a calendar with time and alarm settings
2. Memory Select
1) Movie: Select to play movie files
2) Music: Select to play music files
3) Picture: Select to play photo as a slideshow
4) Combo: Slideshow pictures with music background
5) Edit: Select to copy or delete files

6
2.1 Movie Display
Choose movie icon, all the movie files will list on the screen
Press [][] to choose movie and press ENTER to play
Press [MENU]during movie playback, the info bar appears on
the screen
Press []/[] and ENTER to make selection on the info bar
2.2 Music Display
Choose music icon, all the music files will list on the screen
Press [][] to choose music and press [ENTER] to play
Note: Press [][] on remote control to increase or decrease
volume.

7
2.3 Picture Display
Choose picture icon, all the pictures will list on the screen
Press [][][][] to choose picture and press[ENTER] to
play
Press [MENU] during display pictures, the info bar appears on
the screen
Press []/[] and [ENTER] to make selection on the info bar
2.4 Combo Display
Choose combo icon, all the combo files will list on the screen
Press[][] to choose music or picture and press [ENTER]
to play

8
Edit
Select EDIT icon
All the files and folders will be listed on the screen
Press [][] to choose different files
Press [] to select one file, a √will be marked beside the file
To deselect the file by pressing [] again
COPY
After file selected, press [MENU] and select “copy”
Press [][]and [ENTER] to select the copy destination
Press ENTER, copy finished.
DELETE
After file selected, press [MENU] and select “delete”
Press [ENTER] to select “delete”
Select then Press [ENTER] to delete selected file.

9
3. Computer connection
Connecting the frame to computer by using USB cable
Edit files in computer
4. Set up
Select the setup icon from the main menu to setup your frame
Operation method:
[][]button: Shift items or choose parameters
[]/[]button: change the parameters
[ENTER] button: confirm the setup result
[EXIT]button: back to item list

10
5. Calendar / Clock / Alarm
Press [][] to move to the previous or next year,
Press []/[] to change to the previous or next month Press to
change the year
6. OSD Function
OSD Menu
SUB-Menu & Function Description
Function Menu
Music
Movie
Combo
Edit
Calendar
Picture Slideshow
MP3 display
Movie display
Combo display
Copy/ Delete
Calendar/ Clock / Alarm
Memory Menu
SD/MMC
MS
CF
USB
Different memory device

11
Settings
Language
Multi language
Slideshow Time
3/5/15 seconds, 1/15min, 1 hour
Slideshow Mode
14 mode
Music Repeat Mode
Repeat all/ one/ off
Movie Repeat Mode
Repeat all/ one/ off
Display Mode
Original--preserves dimension ratios of
original picture
Stretch -- stretches picture to fit screen
Crop-- full screen picture, preserves
dimension ratios, but crops
picture to do so.
Time
Set time ( Year/ month/day/hour/minute)
Alarm
Set alarm
Brightness
Brightness adjust
Contrast
Contrast adjust
Saturation
Saturation adjust
Auto Power on Time
Set time to power on automatically
Auto Power off Time
Set time to power off automatically
Splitscreen Function
Several photos display on screen the same
time
Auto Play
Picture/music/movie/calendar/main menu
Default
Restore to the factory settings.

12
7. Frequently Asked Questions
Q. Why can’t the Digital Photo Frame play all images or movie
files?
A: The Digital Photo Frame can support JPEG, MP3 and some
video format depending on the product specification. It may not
read some files downloaded from the internet.
Q. I have a memory card in the Digital Photo Frame, but it’s not
reading the card, what should I do?
A: First, make sure that you are using a memory card that is
supported by the Digital Photo Frame. Second, ensure that the
memory card is inserted all the way into the correct slot. Third,
choose the correct card icon which you want to play.
Q. Why do some pictures load faster than others?
A: Higher resolution pictures usually load slower due to the larger
amount of data transfer that is required to render the image.

13
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end
of its life separately from your household waste. There are
separate collection systems for recycling in the EU. For more
information, please contact the local authority or your retailer
where you purchased the product.
NOTE: All rights for modifications reserved
 The above settings are subject to change if the product
specifications are modified. APAM09V1.1
