Kogan KA12LDGFRYC User manual

12L XXXL DIGITAL AIR
FRYER OVEN
KA12LDGFRYC

2
Safety & Warnings
3
Components
6
Overview
8
Before First Use
10
Operation
11
Cleaning & Care
19
Troubleshooting
20
FAQ
21
Specifications
22
Notes
23

3
When using an electrical appliance, basic safety precautions should always be followed,
including the following:
• Read and retain all instructions for future reference.
• Be sure to use on a heat resistant and even surface, such as a heatproof mat. Do not
place directly on a benchtop. Keep the appliance at least 20cm away from the wall,
furniture, or other flammables.
• Unplug from the power outlet when not in use and before cleaning. Allow cooling
before cleaning or handling, putting on or taking off parts.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against electrical shock, do not place any part of the Air Fryer Oven in water
or other liquids. See instructions for cleaning.
• This appliance should not be used by or near children or individuals with certain
disabilities.
• Do not operate any appliance with a damaged cord or plug or after the appliance has
malfunctioned, has been dropped or damaged in any way, or is not operating properly.
Contact help.Kogan.com for examination, repair, or adjustment.
• The use of accessory attachments not recommended by Kogan.com may cause injury.
• Do not use outdoors.
• Do not let the cord hang over the edge of tables or countertops or come into contact
with hot surfaces.
• Do not place the appliance on or near a hot gas or electric burner, or in a heated oven.
• Do not use this appliance for anything other than its intended purpose.
• Extreme caution should be exercised when using containers constructed of materials
other than metal or glass in the oven.
• To avoid burns, use extreme caution when removing appliance accessories or disposing
of hot grease.
• When not in use, always unplug the unit. Do not store any materials other than oven
proof accessories recommended by Kogan.com in this appliance.
• Do not place paper, cardboard, plastic, or similar materials inside the appliance.
Handle this product with care and inspect it regularly to ensure it is in good working
order.
If the product, power supply cord or plug shows any signs of damage: stop use,
unplug and contact help.Kogan.com for support.
SAFETY & WARNINGS

4
• Oversize foods and utensils must not be inserted into the appliance, as they may
present a risk of fire or electric shock.
• A fire may occur if the appliance is covered, or touching flammable materials such as
curtains, draperies, or walls when in operation. Do not store any items on top of the
appliance when in operation. Do not operate the appliance under wall cabinets.
• Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts, presenting a risk of electric shock.
• Do not attempt to dislodge food when the appliance is plugged into an electrical
outlet.
• Use the recommended temperature settings for all cooking/baking, roasting and air
frying.
• Do not rest cooking utensils or baking dishes on the glass door.
• Turn the time and temperature dials to the off position to turn off the appliance.
• Do not operate your appliance in a cupboard or under a wall cabinet. When storing in a
cupboard, always unplug the unit from the electrical outlet. Not doing so could create a
risk of fire, especially if the appliance touches the walls of the cupboard or the door
touches the unit as it closes.
• Extreme caution must be used when moving an appliance containing hot oil or other
hot liquids.
• To disconnect from power, turn both the time and temperature dials to “off”, then
remove the plug from the wall outlet.
• Fire may occur if the appliance is covered or touching flammable material, including
curtains, draperies, walls etc, when in operation. Do not store any item on top of the
appliance when in operation.
• A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
• Extension cords are available and may be used if care is exercised in their use. If an
extension cord is used, the marked electrical rating of the extension cord must be at
least as great as the electrical rating of the appliance and the longer cord should be
arranged so that it will not drape over edges.
• For household use only, not intended for commercial use.
• Do not cover the air intake vents while the unit is operating.
• Do not cover the air outlet vents while the unit is operating.
WARNING: To avoid the possibility of fire, NEVER leave the appliance
unattended during use.

5
• During the cooking process, the fry basket and other accessories will become very hot.
When you remove it to check on the progress, make sure you have a trivet or a heat-
resistant surface nearby to set it down on. Never place the fry basket directly on a
countertop or table.
• Cooking accessories will get hot during the air frying process. Wear oven mitts and
handle with care to avoid injury.
Important
• Before first use and after subsequent use, hand wash the Round Basket and other
cooking accessories. Then, wipe the outside and inside of the Unit with a warm moist
cloth and mild detergent. Finally, preheat the Unit for a few minutes to burn off any
residue.
• The cook-top may smoke the first time it is used. It is not defective and the smoke will
burn off within a few minutes.
Overheating Protection
Should the inner temperature control system fail, the overheating protection system will be
activated and the unit will not function. Should this happen, unplug the power cord. Allow
time for the unit to cool completely before repair or storing.
Automatic Shut-Off
The appliance has a built-in shut-off feature, that will automatically shut down the unit
when the Timer LED reaches zero. You can manually switch off the appliance by selecting
the power button. The fan will continue running for about 20 secs. To cool down the unit.
Electric Power
If the electrical circuit is overloaded with other appliances, your new unit may not operate
properly. It should be operated on a dedicated electrical circuit.
Electromagnetic Fields
This appliance complies with all standards regarding electromagnetic fields. If handled
properly and according to the instructions in this user guide, the appliance is safe to use
based on scientific evidence available today.

6
Air fryer
Baking tray
Rolling cage
Drip tray
Rotisserie spit assembly
Spit removal tool
1. Air Fryer / Control Panel
Allows you to control the functions of the unit.
2. Baking Tray
Can be used not only for dehydration but also to cook crispy snacks or reheat items like
pizza.
3. Round Basket
Great for fries, roasted nuts and other snacks. Use spit removal tool to place basket into
unit.
4. Drip Tray
Keep in place for easy clean-up.
5. Rotisserie Spit Assembly
Used for roasts and whole chicken. Force shaft lengthwise through meat and centre.
Slide forks onto shaft from either end into meat, then lock in place with set screws.
There are indentations on the shaft for the set screws. You can adjust the screws closer
to the middle if needed but never outward towards the ends.
COMPONENTS

7
6. Spit Removal Tool
Use to remove cooked roasts and chicken that have been prepared using the rotisserie
or skewer methods. Place under rotisserie spit and lift then gently extract the food.
Note:
Ensure roast or chicken is not too large to rotate freely within the oven. Chicken 2kgs
roast: up to 2.5-3kgs (depending on the diameter of the meat. Up to 15cm diameter).
WARNING: Forks, skewers and other metal parts with this unit are
sharp and will get extremely hot during use.
Great care should be taken to avoid personal injury. Wear protective
oven mitts or gloves.

8
Control Panel
1. Power/Stop Button
Once the unit is plugged in, the power button will light up. Press the power button once
will cause the full panel to be illuminated.
Pressing the power button at any time during the cooking process will shut down the
unit, causing the display to turn off immediately the running light to go dark within 20
seconds. The fan will continue running for 20 seconds to cool down the unit.
2. Internal Light
Press this button to check on the cooking progress while unit is in operation.
3. Start Button
Press this button to commence the cooking process at the default temperature of
185°C and a time of 15 mins.
OVERVIEW
Note:
Opening the door during the cooking process will pause the unit. Internal light will
illuminate if the door is opened.

9
4. Rotation Button
Select this function when cooking anything using the rotisserie spit. This function can
be used with any of the presets. The icon will blink during operation.
5. Temperature Control Buttons
These buttons enable you to raise or lower cooking temperature in 5°C increments
ranging from 80-200°C.
6. Time Control Buttons
These buttons enable you to select exact cooking time to the minute, from 1-90 mins. in
all modes except when dehydrating, which uses 30-min. intervals and an operating
time of 2-24 hrs.
7. LED Digital Display
The display will switch between temperature and time Remaining during the cooking
process.
8-17. Cooking Presets
Selecting any preset button sets the time and temperature to the preset's default
values. The cooking process automatically starts 5 seconds after the preset has been
selected or the power button can be pressed after the preset button to start
immediately. Note: You may override these presets with time and temperature
buttons.
18. Fan icon
This icon will blink during cooking and continue blinking up to 20 seconds once the unit
has been shut down.

10
1. Read this user guide material along with all warning stickers and labels.
2. Remove all packing materials, labels and stickers.
3. Wash all parts and accessories used in the cooking process with warm soapy
water.
4. Wipe the inside and outside of the cooking unit with a clean, moist cloth.
Preparing for Use
Place the appliance on a stable, level, horizontal and heat-resistant surface.
BEFORE FIRST USE
Notes:
• Never wash or submerge the unit in water.
• When using this unit, never fill any cooking vessel with oil or liquid of any kind. This
unit cooks with hot air only.
Note:
Before initial use and after subsequent use, hand wash the fry basket and other
cooking accessories. Then, wipe the outside and inside of the Unit with a warm moist
cloth and mild detergent. Finally, preheat the unit for a few minutes to burn off any
residue.
Note:
Only the accessories are dishwasher safe.

11
Placing Drip Tray into Unit
1. Insert drip tray into the bottom of the unit.
2. Using the drip tray in place will make for an easy clean-up.
Placing Baking Trays into unit
1. Place the baking trays into the side grooves of the unit.
2. Place baking trays closer to the top heating element for faster cooking and added
crisp.
Note:Use oven mitts when oven is hot.
Rotisserie Spit & Skewers Racks
1. Place the two skewer racks at each end of the rotisserie shaft. Ensure the set
screws are on the outer side of the rotisserie shaft.
2. Slightly tighten the set screws, do not over tighten as you may need to adjust the
tightness after inserting the skewers.
3. Carefully place the skewers through the food.
4. Insert each skewer through the holes on the left skewer rack.
5. Squeeze the clip end of each skewer as you insert into the opposite skewer rack
slot to secure the food in place.
OPERATION

12
6. Repeat steps 3-6 in a uniform manner around the skewer rack. Ensure skewers are
evenly spaced.
7. Tighten the set screws to ensure everything is securely in place.
8. Use caution while inserting the spit into the unit to prevent being poked by the
Skewer ends.
9. Open the door of the unit. Slide the rotisserie spit onto the rails in the centre of the
unit.
Placing Rolling Cage & Rotisserie Spit into Unit
1. Open the door of the unit.
2. Insert the left side of the assembled rolling basket or spit into the rotisserie spit
socket. Be sure the rotisserie shaft is placed correctly to engage rotation.
3. Place the right side onto the hanger.
Left side

13
Removing Rolling Cage & Rotisserie Spit from Unit
1. Open the door of the unit to pause cooking cycle or turn unit off by pressing the
power button.
2. Insert spit removal tool beneath the rotisserie shaft.
3. Lift the right side of the spit removal tool at a slight angle to clear the bracket, then
shift to the right until the left side of the shaft slides out of the rotisserie shaft
socket.
4. Carefully remove the rolling cage or rotisserie spit from the unit.

14
Using the Fry Basket
1. With the latch off the basket handle, compress the handle and place it between
the slots on the fry basket and release the handle.
2. Close the latch on the basket handle over the top of the handle, pressing down on
the latch to ensure that it is completely secure.
3. The door cannot close with the basket handle still on the fry basket. Remove
handle before closing.
Note:
The fry basket can be inserted into the unit by hand, but the basket handle must be
used when removing the basket from the unit.

15
Cooking Presets
Cooking time for whole roasted chicken will vary with weight. Use a meat thermometer to
check internal temperature as per chart below.
Preset Button
Temperature
Time
8. French Fry
200°C
15 mins
9. Steaks/Chops
175°C
25 mins
10. Fish
165°C
15 mins
11. Shrimp
160°C
12 mins
12. Pizza
180°C
15 mins
13. Chicken
185°C
40 mins
14. Baking
160°C
30 mins
15. Rotisserie
190°C
30 mins
16. Dehydrator
30°C
2 hours
17. Reheat
115°C
12 mins
Internal Temperature Meat Chart
This chart should be used to check the internal temperature of cooked meats.
Food
Type
Internal Temperature
Beef & Veal
Ground
70°C
Steaks, Roasts: Medium
70°C
Steaks, Roasts: Rare
63°C
Breasts
75°C
Chicken & Turkey
Ground, stuffed
75°C
Whole bird, legs, thighs, wings
75°C
Fish & Shellfish
Any type
63°C
Ground
70°C
Lamb
Steaks, Roasts: Medium
70°C
Steaks, Roasts: Rare
63°C
Pork
Chops, ground, ribs, roasts
70°C
Fully cooked ham
60°C

16
Manual Cooking
Once you are familiar with your air fry oven, you may want to experiment with your own
cooking times and temperatures.
1. Place the ingredients on a baking tray, on one of the rotisserie accessories or in the
fry basket.
2. Place the tray, fry basket or rotisserie spit into the unit and shut the oven door. Plug
the power cord into an electrical outlet.
3. Once the food is in place, press the power button once.
4. Set the temperature and then the time.
5. The unit will automatically start the cooking cycle a few seconds after a function is
selected. Alternatively, you can press the power button to begin the cooking
process immediately.
Tips:
• Foods that are smaller in size usually require a slightly shorter cooking time than larger
ones.
• Large quantities of food only require a slightly longer cooking time than smaller
quantities.
• Flipping or turning smaller sized foods halfway through the cooking process ensures
that all the pieces are evenly cooked.
• Misting a bit of vegetable oil on fresh potatoes is suggested for a crispier result. When
adding a little oil, do so just before cooking.
• Snacks normally cooked in an oven can also be cooked in this air fryer.
• Place a baking tin or oven dish in the air fryer when baking a cake or quiche. A tin or dish
is also suggested when cooking fragile or filled foods.
WARNING: Never use a cooking vessel filled with cooking oil or any
other liquid with this unit! Fire hazard or personal injury could result.
Notes:
You may open the oven door to view the rotisserie at any time during the process to
check the progress.

17
Cooking Chart
The table below will help you select the correct temperature and time for best results. As
you become more familiar with the air fryer cooking process, you may adjust these settings
to suit your own personal tastes.
Food Item
Min-Max
Time
Temperature
Comments
Thin Frozen
Fries
1 1/4-3 cups
15-16 mins
200°C
Thick Frozen
Fries
1 1/4-3 cups
15-20 mins
200°C
Homemade
Fries
1 1/4-3
1/4cups
10-16 mins
200°C
Add 1/2 tbsp.
oil
Homemade
Potato
Wedges
1 1/4-3
1/4cups
18-22mins
182°C
Add 1/2 tbsp.
oil
Homemade
Potato Cubes
1 1/4-3 cups
12-18mins
182°C
Add 1/2 tbsp.
oil
Hash Browns
1 cup
15-18mins
182°C
Potato Gratin
2 cups
15-18mins
200°C
Steak
1/4-1.1lb
8-12 mins
182°C
Pork Chops
1/4-1.1lb
10-14mins
182°C
Hamburger
1/4-1.1lb
7-14 mins
182°C
Sausage Roll
1/4-1.1lb
13-15mins
200°C
Chicken
Drumsticks
1/4-1.1lb
18-22 mins
182°C
Chicken
Breast
1/4-1.1lb
10-15mins
182°C
Spring Rolls
1/4-3/4 lb
15-20mins
200°C
Use oven-
ready
Frozen
Chicken
Nuggets
1/4-1.1lb
10-15mins
200°C
Use oven-
ready
Frozen Fish
Sticks
1/4-1.1lb
6-10 mins
200°C
Use oven-
ready
Mozzarella
Sticks
1/4-1.1lb
8-10 mins
182°C
Use oven-
ready
Stuffed
Vegetables
1/4-1.1lb
10 mins
160°C

18
Cake
1 1/4 cups
20-25 mins
160°C
Use baking
tin
Quiche
1 1/2 cups
20-22 mins
182°C
Use baking
tin/oven dish
Muffins
1 1/4cups
15-18 mins
200°C
Using baking
tin
Sweet Snacks
1 1/2cups
20mins
160°C
Use baking
tin/oven dish
Frozen Onion
Rings
1lb
15 mins
200°C
Tip:
• Set the timer to half the time needed for the recipe and the timer will alert you when it's
time to flip your food.
• Add 3 minutes to cooking time when starting with a cold appliance.
Note:
These settings are intended to be guidelines, because ingredients differ in origin, size,
shape and brand, it cannot guarantee the best settings for your ingredients.

19
Cleaning
• Clean the air fryer after each use.
• The fry basket and other accessories are made of durable stainless steel and are
dishwasher safe.
• Never use abrasive cleaning materials or utensils on these surfaces.
• Caked-on food should be soaked for easy removal in warm, soapy water.
Remove the power cord from the outlet and be certain the appliance is thoroughly cooled
before cleaning.
1. Wipe the outside of the appliance with a warm, moist cloth and mild detergent.
2. To clean glass, open the door of the Unit.
3. Clean the inside of the appliance with hot water, a mild detergent and a non-
abrasive sponge.
4. If necessary, remove unwanted food residue from the upper screen with a cleaning
brush.
Storages
1. Unplug the appliance and let it cool thoroughly.
2. Make sure all components are clean and dry.
3. Place the appliance in the clean, dry place.
Disposal
This marking indicates that this appliance should not be disposed with
other household wastes. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.
CLEANING & CARE

20
Problem
Possible Cause
Solution
Air fryer will not start
cooking
1. The appliance is not
plugged in.
2. You have not turned the
Unit on by setting the
preparation time
temperature.
1. Plug power cord into
wall socket.
2. Set the temperature
and time check that
door is closed.
Food not cooked
1. The fry basket ls
overloaded.
2. The temperature ls set
too low.
1. Use smaller batches for
more even frying.
2. Raise temperature and
continue cooking.
Food is not fried evenly
Some foods need to be
turned during the cooking
process.
See ‘Operation’ section in
this user guide.
White smoke coming from
unit
1. Oil is being used.
2. Accessories have excess
grease residue from
previous cooking.
1. Wipe down to remove
excess oil.
2. Clean the fry basket
after each use.
French fries are not fried
evenly
1. Wrong type of potato
being used.
2. Potatoes not blanched
properly during
preparation.
1. Use fresh. firm potatoes.
2. Pat dry to remove
excess starch.
Fries are not crispy
Raw fries have too much
water.
Dry potato sticks properly
before misting oil. Cut
sticks smaller. Add a bit
more oil. Blanch cut
potatoes.
Display shown
Possible cause
Solution
E1
Broken circuit of the
thermal sensor
Contact help.Kogan.com
for support.
E2
Short circuit the thermal
sensor
Contact help.Kogan.com
for support.
TROUBLESHOOTING
