Kohl's SONOMA CAMERON 3 DRAWER STORAGE TOWER User manual

PART LIST QUANTITY
A 1 PC
B 1 PC
C 1 PC
D 3 PCS
E 3 PCS
F 3 PCS
G 16 PCS + 1 PC
H 16 PCS + 1 PC
I 8 PCS + 1 PC
J 1 PC
LEFT SIDE FRAME
BOLT
SHELF
BASKET
BASKET BOTTOM
FLAT WASHER
WOOD DOWEL
ALLEN WRENCH
SAVE THESE INSTRUCTIONS
STYLE#: 53SNR4201HAZ, 53SNR4201WHT, 73SNRST01BLK
ASSEMBLE ON A FLAT, PROTECTED SURFACE
FIGURE
DESCRIPTION
TOP
RIGHT SIDE FRAME
SONOMA CAMERON 3 DRAWER STORAGE TOWER ASSEMBLY INSTRUCTIONS
1

STEP 1
A. PLACE TOP (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. INSERT WOOD DOWELS (I) INTO DOWEL HOLES
IN TOP (A) AS SHOWN.
STEP 2
A. INSERT WOOD DOWELS (I) INTO THE DOWEL
HOLES IN SHELVES (D) AS SHOWN.
STEP 3
A. PLACE SIDE FRAME (B) ON A FLAT, PROTECTED
SURFACE.
B. ATTACH RIGHT SIDE FRAME (B) TO TOP (A) AND
SHELVES (D) WITH BOLTS (G) AND FLAT WASHERS
(H) USING ALLEN WRENCH (J). DO NOT TIGHTEN
COMPLETELY.
ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE#: 53SNR4201HAZ, 53SNR4201WHT, 73SNRST01BLK
J
H
2

ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE#: 53SNR4201HAZ, 53SNR4201WHT, 73SNRST01BLK
STEP 6
A. INSERT BASKET BOTTOMS (F) INTO BASKETS (E).
B. IF ANY BASKET BUMPERS OR PADS WERE BENT
OR DISLODGED DURING TRANSIT, GENTLY
REPOSITION SO THE BUMPERS ARE LEVEL WITH
THE BOTTOM OF THE BASKET AND THE PADS ARE
CENTERED ON THE BUMPERS.
STEP 4
A. ALIGN THE LEFT SIDE FRAME (C) TO TOP (A) AND
SHELVES (D) AS SHOWN.
STEP 5
A. CAREFULLY ROTATE THE ASSEMBLED UNIT
UPSIDE DOWN ON A FLAT, PROTECTED SURFACE.
B. ATTACH TOP (A) AND SHELVES (D) TO LEFT SIDE
FRAME (C) WITH BOLTS (G) AND FLAT WASHERS (H)
USING ALLEN WRENCH (J).
C. TIGHTEN COMPLETELY ALL BOLTS (G).
C
3

WEIGHT LIMIT:
CARE AND CLEANING
WIPE CLEAN WITH A SOFT, DRY CLOTH AS NEEDED.
BASKETS: DO NOT BRING IN CONTACT WITH WATER OR LIQUIDS.
DO NOT SIT, STAND, OR CLIMB ON STORAGE TOWER.
INTENDED FOR INDOOR USE ONLY.
** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH AND PERIODICALLY TIGHTEN ALL BOLTS.
TOP: 40 LBS, SHELVES: 20 LBS EACH, BASKETS: 20 LBS EACH.
ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE#: 53SNR4201HAZ, 53SNR4201WHT, 73SNRST01BLK
STEP 7
A. ROTATE THE ASSEMBLED UNIT TO UPRIGHT
POSITION.
B. PLACE THE ASSEMBLED BASKETS ONTO THE
SHELVES AS SHOWN.
C. ASSEMBLY IS COMPLETE.
4
