Kohl's WICKER SWIVEL EGG CHAIR User manual

PART LIST QUANTITY
A1 PC
B1PC
C1 PC
D4 PC + 1
E4 PC + 1
F4 PC + 1
G3 PC + 1
H4 PC + 1
I2 PC
J1 PC
K8 PC
L1 PC
FLAT WASHER+BOLT
M6*30mm
WICKER SWIVEL EGG CHAIR ASSEMBLY INSTRUCTIONS (CONTINUED)
WRENCH
WASHER+BOLT
M6*40mm
WASHER
C-SPRING WASHER
ADJUSTABLE LEVER
SAVE THESE INSTRUCTIONS
NUT
WICKER SWIVEL EGG CHAIR ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
BASE
DESCRIPTION
UPPER FRAME
BOTTOM FRAME
ALLEN WRENCH
SEAT CUSHION
Page 1/4

PART LIST QUANTITY
M1 PC
N2 PCS
FIGURE
DESCRIPTION
SMALL BACK CUSHIONS
LARGE BACK CUSHION
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
1-866-905-4107 OR WWW.YOTRIOINT.COM
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
Page 2/4

STEP 1
A. PLACE BOTTOM FRAME(A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. PLACE BASE (C) UPSIDE DOWN, ON TOP OF BOTTOM
FRAME (A).
C. CONNECT BASE (C) AND BOTTOM FRAME (A) WITH
FLAT WASHER AND BOLT (F), WASHER (D), C-SPRING
WASHER (E) AND NUT (H) AS ILLSTRATED. INSERT FLAT
WASHER AND BOLT (F) FROM BELOW, AND STACK
WASHER (D), C-SPRING WASHER (E) ON OTHERSIDE OF
ATTACHMENT. SECURE WITH NUT (H). TIGHTEN
COMPLETELY.
WICKER SWIVEL EGG CHAIR ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 3
A. ROTATE CHAIR TO UPRIGHT POSITION.
B. PLACE UPPER FRAME (B) ONTOP OF BOTTOM FRAME
(A). ALIGN BOLT HOLES.
C. CONNECT UPPER FRAME (B) AND BOTTOM FRAME (A)
WITH WASHER AND BOLT (G).
D. TIGHTEN ALL BOLTS COMPLETELY USING ALLEN
WRENCH (J).
Page 3/4

WICKER SWIVEL EGG CHAIR ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 5
A. ADJUST ALL LEVELERS (K) ON BASE TO ENSURE SEAT IS
LEVEL.
TO ASSIST YOU BETTER, PLEASE GATHER THE FOLLOWING INFORMATION BEFORE CALLING CUSTOMER SERVICE:
PRODUCT NAME AND STYLE NUMBER, DESCRIPTION AND OR IMAGES OF THE ISSUE, ORIGINAL STORE PURCHASE
WEIGHT LIMIT
300 LBS
CARE AND CLEANING
IN ORDER TO PROLONG THE LIFE OF YOUR CHAIR, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR
DURING INCLEMENT WEATHER.
WARRANTY
CUSTOMER SERVICE: PLEASE NOTE - DO NOT RETURN THIS ITEM TO THE RETAILER.
CUSTOMER SERVICE HOT LINE: 1-866-905-4107
1 YEAR LIMITED WARRANTY FOR FRAME.
SERVICE HOURS: 11:30 A. M. to 8:00 P. M. EASTERN STANDARD TIME /8:30 A. M. to 5:00 P. M. PACIFIC STANDARD TIME
WEBSITE: WWW.YOTRIOINT.COM
** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH (G) AND PERIODICALLY TIGHTEN ALL BOLTS.
STEP 6
A. PUT THE SEAT CUSHION (L), LARGE BACK CUSHION (M)
AND SMALL BACK CUSHIONS (N) ON THE EGG CHAIR.
B. ASSEMBLY IS COMPLETE.
