Kohler®Diesel
Model KD350D
Relentless Power.
Legendary Performance.
© 2008 by Kohler Co.
PAGE: 1 OF 4
1 Cylinder »349 cc » 5.0 kW/6.7 HP »3600 RPM »12.2 ft. lbs@2400 RPM
Certication
EPA TIER 2
ECE R 24
Features
4-Stroke Air-Cooled Diesel Engine
SAE J609a Crankshaft
Counter-Clockwise Rotation
Direct Injection
Full-Pressure Lubrication with Oil Pump
Centrifugal Mass Governor
Built-In Full Flow Oil Filter
Oil Breathing Blow-By with Safety Device
Automatic Extra Fuel Starting Device
Self-Bleeding Fuel System
Torque Regulator
Automatic Compression Release
Die-Cast Aluminum Crankcase with Integral Cast-Iron Cylinder Liner
Aluminum Alloy Cylinder Head
Mounting Feet
Applications
Two-Wheel Tractor
Agricultural Mower
Agricultural Pump
High-Pressure Cleaner
Generator
Vibrating Plate
Hydraulic Power Pack
Arrowboard

Kohler®Diesel
Model KD350D
© 2008 by Kohler Co.
PAGE: 2 OF 4
Specications
Cylinders
Displacement
Bore
Stroke
Compression Ratio
Rating kW/HP
Max. Torque
Minimum Idling Speed
Fuel Tank Capacity
Oil Consumption
Oil Capacity
Min. Allowable Oil Pressure
Max. Allowable Angle of Operation (Peak Values)
Volume of Air Required for Correct Combustion @ 3600 RPM
Volume of Air Required for Correct Cooling @ 3600 RPM
Dry Weight
Recommended Battery
Minimum Pulley Diameters for Belt Drive
No. of cylinders 1
cc/cu. in. 349/21.3
mm/in. 82/3.2
mm/in. 66/2.6
20.3:1
N (80/1269/CEE) ISO 1585 5/6.7
NB ISO 3046 IFN 4.6/6.2
NA ISO 3046 ICXN 4.1/5.5
N�m/ft. lbs. @ 2400 RPM 16.6/12.2
950-1000
liters/quarts 4.3/4.5
kg/h/lb/h 0.0032/0.007
liters/quarts 1.2/1.3
bar/psi 1-1.5/14.5-21.8
25° (35°)
liters/min/cfm 540/19
liters/min/cfm 5000/177
kg/lbs. 33/72.7
V/Ah 12/44
3600 RPM3000 RPM2000 RPM1000 RPM
dB (A)
60
70
80
Sound Pressure Level dB (A)
Sound Pressure Level Polar Diagram
Open Field at 7 Meters - No Load
Running Engine.
D1820 (mm) ≥[55+L1N/n] N (kW)
n (RPM)
D2(mm) ≥ 860 [60+L2(mm)] N (kW)
n (RPM)
Max. Allowable Axial Load in Both Directions A-B = 200 kg/441 lbf

Kohler®Diesel
Model KD350D
PAGE: 3 OF 4
© 2008 by Kohler Co. KohlerEngines.com
HP kW Nm kgm
g/kWh g/CVh
RPM
Curves
N Power curve - 80/1269/CEE - ISO 1585 -
NB Power curve - ISO 3046/1 - IFN -
NA Power curve - ISO 3046/1 - ICXN -
MN Torque curve - (N curve)
MB (B curve - MA (A curve)
C Specific fuel consumption - (NB curve)

Relentless Power.
Legendary Performance.
Kohler®Diesel
Model KD350D
PAGE: 4 OF 4 KOHLER Co., Kohler, Wisconsin 53044 • Tel: [phone]
800-544-2441 • Fax: [phone] • KohlerEngines.com
Form TP-2610 5/08 © 2008 by Kohler Co. Printed in U.S.A.
188.5/7.42
185/7.28
373.5/14.70
444.5/17.49
328.25/12.92
295.25/11.74
8.0/0.31
54.0/2.12
97.0/3.81
14.0/0.55
11.0/0.43
43.0/1.69
5.5/0.21
5.5/0.21
8.0/0.31
90.0/3.54
25.0/0.98
21.0/0.82
5.0/0.19
4.0/0.15
120.0/4.72
120.0/4.72
105.0/4.13
23.0/0.90
33.0/1.29
8.0/0.31
4.0/0.15
Standard Equipment
Recoil Start with Automatic Compression Release
Fuel Tank
Fuel Filter
Dry Air Cleaner
Muffler with Guard
Accelerator and Stop Manual Control
12 V Electric Start with Control Panel
SAE J609a Ext 4 Crankshaft with Type A & B Mtg. Flanges
Fuel Valve Safety Shutdown for Low Oil Pressure
Accessories
Internal Dynamic Balancer
24 V Electric Start
Accelerator and Stop Remote Control
Key Start Panel with Shutdown Device
Fuel Lift Pump
Oil Temperature Switch
Glow Plug on Intake Manifold
SAE J609a Ext. 7, 9, 6, 3, and 4 Integral Crankshaft Options
with Type A & B Mounting Flanges
Technical Drawings
