Kohler PATIO URINAL User manual

PATIO
INSTALLATION INSTRUCTIONS
VITREOUS CHINA URINAL
-1-
1063245-T01-B
K18645A
A. How to use these instructions
• Please read these instructions carefully to familiarize yourself with the required tools, materials, and installation sequences. Follow the
sections that pertain to your particular installation. This will help you avoid costly mistakes. In addition to proper installation, read all
operating and safety instructions.
• All information in these instructions is based upon the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
• These instructions contain important care, cleaning, and warranty information - Please leave instructions for the consumer.
B. Notes
• Observe all local plumbing and building codes.
• Shut off the water supply.
• Carefully inspect the new fixture for any sign of damage.
• Be very careful while hand ling vitreous china products.
C. Required tools and materials
• Drill
• Open end/adjustable wrenches
• Measure tape
• Thread sealant tape
• Basin Wrench
• Screwdriver
• Sealant
• Touchless Urinal Sensor or other assy. for flow controlling (Recommended Kohler Touch-less urinal Sensor K-8787T-C02/K-8791T-C02).
• Recommend the no less than 9mm stainless steel twist pipe as inlet.
A. Install Urinal Sensor
Recommended Urinal Sensor Kohler Urinal Sensor 8787T-C02/8791T-C02
B. Install Outlet Connection
• Ascertain the position for outlet connection according to rough-in.
• Apply sealant on outlet pipe. and connect the outlet connection with outlet pipe. Insert gasket as shown in Fig.2.
• Fix outlet connection on the installing wall.
Note: Fig.2 may be different for different outlet connection.
Unit: mm
ROUGHING-IN
335
180
35
265 5
140
80
600 50 ext
145
70
642
300
95
370
G1/2
INSTALLATION
Fig.1

-2-
1063245-T01-B
2~10mm100
30
Fig.2
Fig.3
Fig.4
C. Install hook
D. Install inlet pipe
Insert gasket and nut into the uriral as shown. Connect the inlet connection with inlet pipe.
(See Fig.3)
Drill 2 mounting holes on the wall and install hook. Fix hook on the wall by tightening screws.
265
08
210
600
081
310 X
+
35
001

-3-
1063245-T01-B
Fig.5
E. Install urinal
(See Fig.5)
Lift up the urinal, level the installing hole with the hole on installing. The urinal on the hook secure.
F. Install beehive strainer
Ascertain the position for beehive strainer as shown. Fix the beehive strainer by tightening screw.
1. Urinal is designed for use with potable water. Avoid water that includes a lot of contaminants or with acid/alkali water
and impure water.
2. If you live in a hard water area, make certain that the holed in the toilet rim are kept clean to ensure proper bowl flushing, Toilet bowl
cleaners should be used at least once a week. Use a long-handled brush to clean the rim holes, and to clean as far into the trap as
possible to prevent mineral deposits from forming.
3. Most toilet bowl cleaners are not harmful to the surface of the urinal, please follow the bowl cleaner manufacturer’s instructions carefully.
4. Do not use abrasive cleaners for china surface.
5. Do not directly flush the wire connector of sensor with water.
6. Do not make Sensor Window near strong ultraviolet and electromagnetism.
7. Keep the sensor window clean. Do not attack the sensor. The sensor cover can be cleaned by the soft rag. (with neutral liquid detergent).
Do not use the eradicator, abrasive powder or the oil, acid or alkali liquid detergent. Do not sprit the air freshener, disinfectant or the other
kinds of odious smell remove, clean organic liquid to the sensor directly.
Fig.6
CONSUMER RESPONSIBILITIES

PATIO
SERVICE PARTS PAGE
VITREOUS CHINA URINAL
-4-
1058563
Inlet Pipe
1058564
Washer
1058565
Washer
1058562
Nut
1058566
Washer
1061478
Screw
1061479
Sheath
1058574
Hook
1057917
Hose
1057915
Screw
1057913
Beehive
1057916
Collar
1058568
Rubber Ring
1058567
Collar
1058569
Outlet Connection
1063245-T01-B
1057914
Washer
K-18645A
