Koldfront TWR181ES User manual

Thermoelectric Wine Cooler
Owner’s Manual
For more information on other great Koldfront by EdgeStar products on the web, go to http://www.edgestar.com
TWR181ES

i
Important Safety Information
Improper handling can cause serious damage to the EdgeStar wine cooler and/or injury to the user. This wine
cooler is designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other
use may invalidate the warranty. Please review the ratings label located on the rear panel of the unit for
electrical and other technical data related to this unit. The unit must be used in a properly grounded wall
outlet.
Please read and follow the safety information listed below to reduce the risk of fire, electric shock or injury.
Electrical Safety
Do not exceed the power outlet ratings.
It is recommended the wine cooler be connected on
its own circuit.
The unit must be installed in accordance with state
and local electrical codes.
A standard electrical supply (115 V, 60Hz), that is
properly grounded in accordance with the National
Electrical Code and local codes and ordinances is
required.
Use outlets that cannot be turned off by a switch or
pull chain.
Always turn the unit off and unplug it from the outlet
when cleaning.
Unplug the unit if it is not going to be used for an
extended period of time.
Do not operate the unit with a power plug missing
the ground plug, a damaged cord or a loose socket.
Be sure the wine cooler is properly grounded.
Never plug or unplug the unit with wet hands.
Do not bypass, cut or remove the grounding plug.
Do not use extension cords or unprotected power
strips with this unit. You may need to contact your
electrician if it is necessary to use a longer cord or if
you do not have a grounded outlet. Do not modify
the power cord’s length or share the outlet with other
appliances.
Do not start or stop the unit by switching the circuit’s
power on and off.
If the power cord is damaged, it must be replaced by
the manufacturer or a qualified technician.
Never repair the unit while it is plugged in.
Immediately unplug the unit if it makes strange
sounds, emits smells or smoke comes out of it, and
contact customer service.
Do not remove any part of the casing unless
instructed by an authorized technician.
You should never attempt to repair the unit yourself.
Contact customer service for service options if the
unit needs service.
General Safety
To prevent back and other types of injuries, use at
least two people to move and install the wine cooler.
This unit is not intended for use by persons, including
children, with reduced physical, sensory or mental
capabilities, unless they have been given supervision
or instruction concerning the use of the appliance by
the person(s) responsible for their safety.
The temperature range for this cooler is optimized for
wine storage. Perishable food items may require a
different storage environment.
Do not place hot or warm items into the cooler before
they cool down to room temperature.
This unit is designed to be installed indoors, and
protected from rain, sleet, snow, and/or moisture.
This unit is not intended to be used by children.
Children should be supervised to ensure that they do
not play with this product.
Never allow children to crawl inside the wine cooler. If
disposing the unit, remove the door.
Do not use this cooler near flammable gas or
combustibles, such as gasoline, benzene, thinner, etc.
Do not place the unit near heat sources such as ovens,
grills, or direct sunlight.
Only use in an upright position on a flat, level surface
and provide proper ventilation.
Do not pinch or kink the power supply line.
Do not leave any cleaning solutions in the unit
Do not use solvent-based cleaning agents or abrasive
solutions to clean the unit as they may damage the
interior and exterior.
Do not place any other appliances or allow anyone to
sit on top of the unit.
Do not operate the unit upside down, on its side, or at
an angle off level.
Do not move the unit without emptying the contents
and securing the door in a closed position.

Thermoelectric Wine Cooler ii
Table of Contents
IMPORTANT SAFETY INFORMATION......................................................................I
INTRODUCTION .....................................................................................................1
PARTS IDENTIFICATION .........................................................................................2
EXTERIOR VIEW .....................................................................................................2
INTERIOR VIEW-(WITHOUT DOOR)..........................................................................2
INSTALLING THE WINE COOLER ......................................................................3
UNPACKING THE WINE COOLER..............................................................................3
TYPE OF INSTALLATION............................................................................................3
Free-standing installation: ..........................................................................3
INSTALLATION CLEARANCE REQUIREMENTS ...............................................................3
ELECTRICAL REQUIREMENTS ....................................................................................4
Recommended grounding method ........................................................4
LEVELING THE WINE COOLER..................................................................................4
OPERATION..........................................................................................................5
INSTALLATION CHECK LIST BEFORE OPERATION..........................................................5
ADJUSTING THE TEMPERATURE .................................................................................5
NORMAL SOUNDS .................................................................................................6
DEFROSTING .........................................................................................................6
PREPARING THE WINE COOLER FOR STORAGE ..........................................................6
CLEANING AND MAINTENANCE........................................................................7
EXTERIOR CLEANING .............................................................................................7
INTERIOR CLEANING ..............................................................................................7
WATER PAN AND CONDENSATION..........................................................................7
MAINTENANCE......................................................................................................8
TROUBLESHOOTING ..............................................................................................9
SPECIFICATIONS .................................................................................................10
EDGESTAR LIMITED WARRANTY ...................................................................11
First Time Operating Instructions
Before use, make sure all packaging labels and materials are all removed
from the unit. Be sure to keep track of all included parts and pieces
before discarding packaging materials. It is advised that you keep the
original box and packaging materials in case you are ever to move or
ship the appliance in the future.
Let the unit run for at least 24 hours before you use it. The instruction
manual should be read before using the wine cooler.
This owner’s manual is provided for reference use only. Specifications may
change without prior notice. Refer to the product label on the back of
your wine cooler for the latest technical information.

1
Introduction
Thank you for purchasing this EdgeStar wine cooler. We are glad you
chose us. We believe that your purchase of this product opens a
relationship between you and EdgeStar. We will provide the customer
support needed to nurture that relationship.
This manual contains important information regarding the proper
installation, use and maintenance of your wine cooler. Following this
manual will ensure that your product will work at its peak performance
and efficiency.
Please save the original product packaging in case you need to safely
transport your wine cooler.
For Your Records:
Please write down the model number and serial number
below for future reference. Both numbers are located
on the ratings label on the back of your unit and are
needed to obtain warranty service. You may also want
to staple your receipt to this manual as it is the proof of
your purchase, and is also needed for service under
your warranty.
Model Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer
service:
If you received a damaged product, immediately contact the
retailer or dealer that sold you the product.
Read and follow this instruction manual carefully to help you install,
use and maintain your wine cooler.
Read the troubleshooting section of this manual as it will help you
diagnose and solve common issues.
Visit us on the web at http://www.edgestar.com to register your
product, download product guides, additional troubleshooting
resources and up-to-date information.
If you need warranty service, our friendly customer service
representatives are available via email at [email protected]om
or by telephone at 1 [phone].

Thermoelectric Wine Cooler 2
Parts Identification
Exterior View
Interior View- (Without Door)
PART KEY
1- Air Vent (vents are
located on each side
and in rear of unit)
2- Chrome Shelves
3- Display Panel
4- Cabinet
5- Upper Hinge
6- Door
7- Upper Interior Light
8- Upper Interior Fan
9- Light Switch
10- Lower Interior Light
11- Lower Interior Fan
12- Leveling Foot
1
2
2
3
4
5
6
7
8
11
12
9
10
TIP:
Gather the model
and serial number
from the product
label and write them
down before loading
the wine cooler.
