Koldfront TWR327SZ User manual

Thermoelectric Wine Cooler
TWR327SZ
Owner’s Manual
For more information on other great Koldfront products on the web, go to http://www.edgestar.com

i
IMPORTANT SAFETY INFORMATION
Improper handling can cause serious damage to the Koldfront wine cooler and/or injury to the user. This wine cooler is
designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may
invalidate the warranty. Please review the ratings label located on the rear panel of the unit for electrical and other
technical data related to this unit. The unit must be used in a properly grounded wall outlet. Please read and follow the
safety information listed below to reduce the risk of fire, electric shock or injury.
Electrical Safety
Do not exceed the power outlet ratings.
It is recommendedthe wine cooler be connected
on its own circuit.
The unit must be installed in accordance with
state and local electrical codes.
A standard electrical supply (115V, 60Hz), that is
properly grounded in accordance with the
National Electrical Code and local codes and
ordinances is required.
Use outlets that cannot be turned off by a switch
or pull chain.
Always turn the unit off and unplug it from the
outlet when cleaning.
Unplug the unit if it is not going to be used for an
extended period of time.
Do not operate the unit with a power plug missing
the ground plug, a damaged cord or a loose
socket.
Be sure the wine cooler is properly grounded.
Never plug or unplug the unit with wet hands.
Do not bypass, cut or remove the grounding plug.
Do not use extension cords or unprotected power
strips with this unit. You may need to contact your
electrician if it is necessary to use a longer cord or
if you do not have a grounded outlet. Do not
modifythe power cord’s length or share the outlet
with other appliances.
Do not start or stop the unit by switching the
circuit’s power on and off.
If the power cord is damaged, it must be replaced
by the manufacturer or a qualified technician.
Never repair the unit while it is plugged in.
Immediately unplug the unit if it makes strange
sounds, emits smells or smoke comes out of it,
and contact customer service.
Do not remove any part of the casing unless
instructed by an authorized technician.
You should never attempt to repair the unit
yourself.
Contact customer service for service options if the
unit needs service.
General Safety
To prevent back and other types of injuries, use at
least two people to move and install the wine cooler.
This unit is not intended for use by persons,
including children, with reduced physical, sensory or
mental capabilities, unless they have been given
supervision or instruction concerning the use of the
appliance by the person(s) responsible for their
safety.
The temperature range for this cooler is optimized
for wine storage. Perishable food items mayrequire
a different storage environment.
Do not place hot or warm items into the cooler
before they cool down to room temperature.
This unit is designed to be installed indoors, and
protected from rain, sleet, snow and/or moisture.
This unit is not intended to be used by children.
Children should be supervised to ensure that they
do not play with this product.
Never allow children to crawl inside the wine cooler.
If disposing the unit, remove the door.
Do not use this cooler near flammable gas or
combustibles, such as gasoline, benzene, thinner,
etc.
Do not place the unit near heat sources such as
ovens, grills, or direct sunlight.
Only use in an upright position on a flat, level
surface and provide proper ventilation.
Do not pinch or kink the power supply line.
Do not leave any cleaning solutions in the unit
Do not use solvent-based cleaning agents or
abrasive solutions to clean the unit as they may
damage the interior and exterior.
Do not place any other appliances or allow anyone
to sit on top of the unit.
Do not operate the unit upside down, on its side, or
at an angle off level.
Do not move the unit without emptying the contents
and securing the door in a closed position.

ii
EdgeStar Thermoelectric Wine Cooler
TABLE OF CONTENTS
IMPORTANT SAFETY INFORMATION............................................................................. i
INTRODUCTION ............................................................................................................ 1
PARTS IDENTIFICATION................................................................................................ 2
FRONT VIEW..................................................................................................... 2
BACK VIEW ........................................................................................................... 2
INSTALLING THE WINE COOLER ................................................................................... 3
UNPACKING THE WINE COOLER .......................................................................... 3
TYPE OF INSTALLATION........................................................................................ 3
FREESTANDING INSTALLATION:................................................................................... 3
INSTALLATION CLEARANCE REQUIREMENTS....................................................... 3
ELECTRICAL REQUIREMENTS ...................................................................................... 4
RECOMMENDED GROUNDING METHOD..................................................................... 4
LEVELING THE WINE COOLER .............................................................................. 4
OPERATION .................................................................................................................. 5
INSTALLATION CHECKLIST BEFORE OPERATION.................................................. 5
ADJUSTING THE TEMPERATURE .......................................................................... 5
NORMAL SOUNDS................................................................................................ 6
DEFROSTING ........................................................................................................ 6
PREPARING THE WINE COOLER FOR STORAGE................................................... 6
CLEANING AND MAINTENANCE ................................................................................... 7
CLEANING THE AIR FILTER.................................................................................... 7
EXTERIOR CLEANING............................................................................................ 7
INTERIOR CLEANING ............................................................................................ 7
TROUBLESHOOTING ..................................................................................................... 8
SPECIFICATIONS............................................................................................................ 9
LIMITED WARRANTY .................................................................................................. 10
First Time Operating Instructions
Before use, make sure all packaging labels and materials are all removed from
the unit. Be sure to keep track of all included parts and pieces before discarding
packaging materials. It is advised that you keep the original box and packaging
materials in case you are ever to move or ship the appliance in the future.
Let the unit run for at least 24 hours before you use it. The instruction manual
should be read before using the wine cooler.
This owner’s manual is provided for reference use only. Specifications may
change without prior notice. Refer to the product label on the back of your
wine cooler for the latest technical information.
Koldfront Thermoelectric Wine Cooler

1
INTRODUCTION
Thank you for purchasing this Koldfront wine cooler. We are glad you
chose us.We believe that your purchase of this product opens a
relationship between you and Koldfront. We will provide the customer
support needed to nurture that relationship.
This manual contains important information regarding the proper
installation, use and maintenance of your wine cooler. Following this
manual will ensure that your product will work at its peak performance
and efficiency.
Please save the original product packaging in case you need to safely
transport your wine cooler.
For Your
Records:
Please write down the model number and serial number
below for future reference. Both numbers are located on
the ratings label on the back of your unit and are
needed to obtain warranty service. You may also want
to staple your receipt to this manual as it is the proof of
your purchase, and is also needed for service under
your warranty.
Model
Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer
service:
If you received a damaged product, immediately contact the
retailer or dealer that sold you the product.
Read and follow this instruction manual carefully to help you
install, use and maintainyour wine cooler.
Read the troubleshooting section of this manual as it will help you
diagnose and solve common issues.
Visit us on the web at http://www.edgestar.com to register your
product, download product guides, additional troubleshooting
resources and up-to-date information.
If you need warranty service, our friendly customer service
representatives are available via email at [e-mail]
or by telephone at 1 [phone].

PARTS IDENTIFICATION
FRONT VIEW
Top Right Hinge
Door
Door Handle
Control Panel
Wine Cooler Foot
BACK VIEW
Exhaust Vent
Tip: Gather the model
and serial numbers
from the product
label and write them
down before loading
the wine cooler.
Air Filter
Exhaust Fan
Power Cord
Power Plug
Koldfront Thermoelectric Wine Cooler
Water Pan
2

3
INSTALLING THE WINE COOLER
The wine cooler should be installed in accordance with local
electrical code requirements. The wine cooler should also be
placed in a location that is strong enough to support its total weight,
keeping in mind that it will weigh substantially more when fully
loaded than when empty.
Before you plug the wine cooler into a power supply, be sure to let it
stand upright for at least 24 hours to allow the temperature to
acclimate.
UNPACKING THE WINE COOLER
Important Notes:
•Choose a location that has
an ambient temperature
between60to85°F.
Operation outside of this
temperature may result in
lowered efficiency or cause
other adverse effects.
•This unit MUST be installed
indoors in an area protected
from the elements, e.g., wind,
rain, water spray or drips.
•The wine cooler should not
be located next to ovens,
grills or other high heat
sources.
Carefully remove the packaging materials. Remove any shipping
tape and glue from your wine cooler before using. Do not use sharp
instruments, rubbing alcohol, flammable fluids, or abrasive cleaners
to remove tape or glue. These products can damage the surface of
your wine cooler.
IMPORTANT: Do not remove any safety, warning, or product
information labels from your wine cooler.
TYPE OF INSTALLATION
This wine cooler has been designed for freestanding installation
only. There must be adequate ventilation space around the top,
back and sides of the unit.
FREESTANDING INSTALLATION:
A freestanding installation will allow you to install the wine cooler in
almost any place you desire. You must follow the stated instructions
for electrical requirements, installation clearance and leveling the
wine cooler.
WARNING: Do NOT install the wine cooler built-in or behind a
closed cabinet door.
INSTALLATION CLEARANCE REQUIREMENTS
• To ensure proper ventilation, allow at least 5” clearance at the
back, 4” at top and 4”at sides.
• The wine cooler should be installed on a firm and level surface
that will be able to support the entire weight of a fully loaded unit. It
is important for the wine cooler to be level in order to work properly.
If needed, you can adjust the height of the wine cooler by rotating
the feet. See the “Leveling the Wine cooler” section on page 4.
• A standard electrical supply (115V only, 60 Hz), properly
grounded in accordance with National Electrical Code and local
codes and ordinances is required.

4
Koldfront Thermoelectric Wine Cooler
ELECTRICAL REQUIREMENTS
Tip: Use a surge protector
to protect your wine cooler
from electrical surges.
ELECTRIC SHOCK HAZARD!
Plug into a grounded 3-prong outlet.
Never remove the grounding prong from the plug.
Never use an adapter to bypass the grounding prong.
DO NOT use an extension cord.
Failure to follow these instructions can result in fire,
electrical shock, or death.
Before you move your wine cooler into its final location, it is
important to make sure you have the proper electrical connection:
A standard electrical supply (115V, 60Hz), properly grounded in
accordance with the National Electrical Code and local codes and
ordinances, is required.
The fuse (or circuit breaker) size should be 3 Amps or greater.
RECOMMENDEDGROUNDING METHOD
For your personal safety, this appliance must be grounded. It is
equipped with a power supply cord having a 3-prong grounding plug.
To minimize possible shock hazard, the cord must be plugged into a
mating 3-pronged wall socket, and grounded in accordance with the
National Electrical Code and local codes and ordinances. If a mating
wall socket is not available, it is the personal responsibility of the
customer to have a properly grounded, 3-prong wall receptacle
installed by a qualified electrician.
LEVELING THE WINE COOLER
It is important for the wine cooler to be leveled in order to work
properly. It can be raised or lowered by rotating the plastic sheaths
around each of the feet on the bottom of the machine. If you find
that the surface is not level, rotate the feet until the wine cooler
becomes level. You may need to make several adjustments to level
it. We recommend using a carpenter’s level to check the machine.
1. Place a carpenter’s level on top of the product to see if the wine
cooler is level from front-to-back and side-to-side.
2. Adjust the height of the feet as follows:
Turn the leveling feet to the right to lower that side of the
refrigerator.
Turn the leveling feet to the left to raise that side of the refrigerator.
Note: You must adjust the feet to level the wine cooler.

5
OPERATION
INSTALLATION CHECKLIST BEFORE OPERATION
1. Have all packing materials and tape been removed from the
interior and exterior of the wine cooler?
2. Have the installation instructions been followed, including
connecting the machine to electricity? And has proper grounding
been installed for the wine cooler?
3. Has the machine been leveled?
4. Is the wine cooler in a site where the ambient temperature is
between 60 and 85ºF all year round?
5. Is there a clearance of at least 5” at the rear, 4” at the top and
4” at the sides for proper air circulation?
ADJUSTING THE TEMPERATURE
Front panel controls
Display Up Down Light
Notes: Allow at least 24
hours before storing your
wines and to allow the
temperature to acclimate.
Radio devices may interfere
with the touch sensitive
controls and cause the
temperature settings to
change. Move radio devices
away from the wine cooler.
This wine cooler features a touch-sensitive control panel. You may
adjust the temperature of the wine cooler using the front panel
controls. The display temperature is in Fahrenheit. The wine cooler
has a temperature range from 46°F to 66°F. Whether your wine
cooler can reach the actual set temperature depends on the
ambient environmental conditions.
Adjusting the temperature:
Press the and buttons on the control panel to increase and
lower the temperature, respectively. The set temperature will
flash for a few seconds, and then the display will revert to the
ambient inner temperature of the wine cooler.
Press the button to turn on and off the inner LED lights.

6
Koldfront Thermoelectric Wine Cooler
NORMAL SOUNDS
Your new wine cooler may make sounds that are not familiar to you.
Most of the new sounds are normal. Hard surfaces such as the floor
and walls can make the sounds seem louder than they actually are.
The following describes the kinds of sounds that might be new to
you and what may be making them.
Humming noises may come from the inner and outer fans that
are continuously running.
A low-pitched fan noise from the inner and outer fans is normal.
DEFROSTING
This wine cooler does NOT have an automatic defrost feature.
Therefore, in a colder environment and settings, frost may build up
frequently. Additionally, the more humid the ambient conditions, the
more frost may build up. Keep the door closed as much as possible
and avoid opening the door unnecessarily to minimize frost build-
up.
If frost is preventing the door from closing properly, you may need
to power the unit off until the frost melts. Use a soft, absorbent
towel to dry the unit.
The unit has a built-in water pan that collects the condensate.
The water pan is not removable.
WARNING: Never attempt to remove frost with a sharp object!
PREPARING THE WINE COOLER FOR STORAGE
If the wine cooler will not be used for a long time, or is to be moved
to another place, it will be necessary to defrost the unit and dry the
interior.
IMPORTANT:
•Do not touch the power plug
when your hands are wet.
•Never unplug the unit by
pulling on the plug.
1. Disconnect the cooler from the power supply by removing the
power plug from the wall socket.
2. Leave the door open to allow for air circulation and to prevent
mold, mildew and unpleasant smells.
CAUTION: Store the unit out of the reach of children. If you have
children, you may want to take additional precautions such as
removing the door to prevent a child from being trapped inside the
cooler.

CLEANING AND MAINTENANCE
Periodic cleaning and proper maintenance will ensure efficiency,
top performance, and long life.
CLEANING THE AIR FILTER
Your wine cooler has two exhaust fans that are protected from lint,
dust, and dirt by air filters. To clean the air filters, follow the steps
below:
1) Power off the unit and remove the air filter located on the back of
the unit.
2) Use a vacuum cleaner or tap the filter lightly to remove loose dust
and dirt, then rinse thoroughly under lukewarm running water (below
104°F). You may use a mild soap and water solution if needed.
Allow the air filter to air dry in a cool and shaded place. Dry
thoroughly before reinstalling.
Clean the air filter periodically. If the unit is used in a dusty
environment you may need to clean it on a weekly basis.
EXTERIOR CLEANING
The door and cabinet may be cleaned with a mild detergent and
lukewarm water solution such as 2 tablespoons of baking soda to 1
quart of water.
Do not use solvent based or abrasive cleaners. Use a soft sponge
and rinse with clean water. Wipe with a soft clean towel to prevent
water spotting. Because the door panel is stainless steel, it can
discolor when exposed to chlorine gas and moisture. Clean
stainless steel with a cloth dampened with a mild detergent and
warm water solution. Never use an abrasive or caustic cleaning
agent.
INTERIOR CLEANING
The wine cooler interior should be cleaned occasionally.
1. Disconnect power to the unit.
2. Open the door and remove the contents and shelves.
3. Wait until the unit defrosts.
4. With a clean cloth, wipe down the interior of the unit.
5. Reinsert the shelves and wines.
6. Reconnect power to the unit.
WATER PAN AND CONDENSATION
Occasionally, the water pan may collect water in high humidity
environments. If the pan appears to be getting full, do the
following:
1. Disconnect power to the unit.
2. Use a soft absorbent towel to wipe the water pan’s water.
3. Reconnect power to the unit.
7

8
Koldfront Thermoelectric Wine Cooler
TROUBLESHOOTING
Before Calling for Help
If the unit appears to be malfunctioning,read through the OPERATION
section of this manual first. If the problem persists, check the
Troubleshooting Guide below. The problem could be something that can
easily be solved or explained.
Symptoms
Possible causes
Solutions
The wine cooler turns on
and off frequently, or
does not maintain the
temperature.
The room temperature is
higher than the
recommended ambient
temperature (85ºF or cooler).
Run the cooler at the appropriate ambient temperature.
The door is being opened
often.
Minimize the number of times the door is opened.
The door is not completely
closed.
Make sure the door is completelyclosed.
The door gasket is not
sealing properly.
Make sure the door gasket is properlysealing.
The cooler does not have
the suggested ventilation.
Read and follow the “Installation Clearance Requirements”
section.
The wine cooler does not
turn on.
There is a power failure.
Ensure the cooler is plugged in and the power outlet has
power.
The cooler is not plugged in.
Plug the unit in to a power outlet that has sufficient
amperage.
A house fuse has blown or
the circuit breaker is tripped.
Replace the broken fuse in your fuse box or reset the
breaker.
The wine cooler will not
reach the desired
temperature
The cooler is placed too
close to a heat source.
Keep the cooler away from direct sun light or other heat
sources.
The cooler does not have
sufficient ventilation.
Read and follow the “Installation Clearance Requirements”
section.
The door is opened too
frequently or for a long
period of time.
Close the door tightly and do not open the door too
frequently or for a long period of time.
The wine cooler is
making strange noises
Certain sounds are normal.
Read the “Normal Sounds”section.
The unit is not level or is
touching another appliance.
Check to make sure that the cooler is level, and that it is
not in contact with another appliance or furniture.
The body of the wine
cooler is electrified.
The unit is not grounded
properly.
Contact your local electrician to test your electrical
grounding system.
Frost is forming in the
wine cooler.
The environment is humid or
the ambient temperature is
too low.
Manual defrosting is required; unplug the unit to allow the
frost to melt. If frost builds up frequently, you can move the
unit to a location with a warmer temperature, minimize the
number of times you open the door, or check the door
gasket for a good seal. Read the “Defrosting”section.
The door gasket is not
installed properly.
The door is being opened
too frequently.
The door will not shut
properly.
Your cooler is not level.
Make sure the cooler is on a level surface.
The door gasket is dirty.
Clean the door gasket.
The door gasket is not
installed correctly.
Make sure the door gasket is properly installed.
The shelves are incorrectly
installed.
Correctly install the shelves.

Specifications
Description of product
Thermoelectric Wine Cooler
Model
TWR327SZ
Voltage/Frequency
AC 115 V / 60Hz
Amperage
1.9 Amps
Input Power
140 Watts
Color
Black Cabinet; Stainless Steel
Door
Storage Capacity
32 Bottles*
Dimensions
(Width x Height x Depth)
15.7” x 33.4” x 20.3”
Weight
56.9 lbs.
Note: Technical data and performance
information is provided for reference only.
Specifications are subject to change. Check the
rating label on the wine cooler for the most
accurate information.
*Note on wine storage capacity:
The wine cooler can store 32 standard 750mL
wine bottles. Capacity may vary for other bottle
sizes.

19
EdgeStar Limited Warranty
One (1) Year Parts & Ninety (90) Days Labor
This product is warranted by EdgeStar to be free from defective workmanship and materials, subject to any conditions
set forth as follows:
WHAT IS COVERED:
LABOR: For a period of NINETY (90) DAYS from the date of original purchase, labor will be performed free of charge at
an authorized EdgeStar repair facility. At its option, EdgeStar will repair the product with new or remanufactured parts,
or exchange the defective product with a new, refurbished, or remanufactured product. If a product is replaced, it will
carry the remaining warranty of the original product. After the ninety (90) day period, EdgeStar will no longer be
responsible for labor charges incurred. All defective products and parts covered by this warranty will be repaired or
replaced on a mail-in basis to an EdgeStar authorized repair facility.
PARTS: For a period of ONE (1) YEAR from the date of original purchase, EdgeStar will supply new, rebuilt, or
refurbished parts free of charge. EdgeStar may request a defective part be returned in exchange for the replacement
part. All replacement parts or products will be new, remanufactured, or refurbished. All products and parts replaced by
EdgeStar under warranty service become the property of EdgeStar.
This warranty applies to the original purchaser only, and only covers defects in workmanship experienced during
operation of the product under normal service, maintenance, and usage conditions. This warranty applies to the
purchase and use of this product in residential settings within the United States of America.
WHAT IS NOT COVERED:
The following limitations apply to the coverage of this warranty. This warranty does not cover:
Labor charges for installation, setup or training to use the product.
Shipping damage, and any damage caused by improper packaging for shipment to an authorized service center, and any
damaged caused by improper voltage or any other misuse, including abnormal service, handling, or usage.
Cosmetic damage such as scratches and dents.
Normal wear and tear on parts or replacement of parts designed to be replaced, e.g. filters, cartridges, batteries.
Service trips to deliver, pick-up, or repair, install the product, or to instruct in proper usage of the product.
Damages or operating problems resulting from misuse, abuse, operation outside environmental specifications, uses
contrary to instructions provided in the owner’s manual, accidents, acts of God, vermin, fire, flood, improper installation,
unauthorized service, maintenance negligence, unauthorized installation or modification, or commercial use.
Labor charges incurred 91 days or more after the date of original purchase.
The use of EdgeStar products in commercial settings.
Optional accessories, attachments, and appearance items.
Products that have been modified to perform outside of specifications without the prior written permission of EdgeStar.
Products lost in shipment, or theft.
Products sold AS IS or from an unauthorized reseller.
Products that have had their serial numbers removed or defaced. Products with serial numbers that have been invalidated.
OBTAINING WARRANTY SERVICE:
If you believe your product is defective, contact EdgeStar Customer Support for troubleshooting assistance and
warranty service at 1-866-319-5473. Please have your serial number and proof of purchase available. Once an
EdgeStar authorized representative has confirmed that your product is defective and eligible for warranty service, the
product must be returned to an EdgeStar repair facility. The purchaser is solely responsible for prepaying all shipping
related costs to and from the repair facility. EdgeStar is not responsible for damage resulting from shipper mishandling
or improper packaging. Do not return a defective product to the place of purchase. Products received without a return
authorization number will be refused.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMITATION,
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED
WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER
THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS,
OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. SOME STATES DO NOT ALLOW THE
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE.

By
EdgeStar Products
500 N. Capital of TX Hwy, Bldg 5
Austin, TX 78746-3448
Toll Free: 1-866-319-5473
Web: http://www.edgestar.com
E-mail: [email protected]
Register your product, download owner’s manuals, access additional
troubleshooting resources, and obtain more information on other great
EdgeStar & Koldfront products on the web at: http://www.edgestar.com
Product contents and specifications may change without notice.
Copyright © 2014 Living Direct, Inc.
