Kolibri Bishop User manual

USER MANUAL

H
This manual contains important information on safety
measures and operational features of the Kolibri
Bishop. Please read it carefully before operating your
counterfeit detector and keep it handy for future
reference.

Kolibri Bishop Counterfeit Detector 1
Table of contents:
1. INTRODUCTION
1.1 About the Kolibri Bishop __________________________________________________ 2
1.2 Box contents_____________________________________________________________ 2
1.3 Front and rear views______________________________________________________ 3
1.4 Specications ____________________________________________________________ 4
1.5 Important safety notes ___________________________________________________ 4
2. GETTING STARTED
2.1 Powering up _____________________________________________________________ 5
2.2 Checking a bill’s condition________________________________________________ 5
2.3 Changing the direction of ejection________________________________________ 5
2.4 Authenticating a bill______________________________________________________ 6
3. MAINTENENCE AND WARRANTY
3.1 Maintenance ___________________________________________________________ 7
3.2 Troubleshooting_________________________________________________________ 8
3.2 Warranty _______________________________________________________________ 9
3.3 Shipping________________________________________________________________ 9
3.4 Contact information ____________________________________________________ 9

Count on Kolibri
2
1.1 About the Kolibri Bishop
Thank you for purchasing the Kolibri Bishop, a powerful tool for identifying
counterfeit bills. The Kolibri Bishop veries infrared security marks, the most reliable
anti counterfeit protection available for paper currency. With its advanced
sensors, the Kolibri Bishop also veries magnetic marks and UV signatures.
1.2 Box contents
• Kolibri Bishop counterfeit detector
• DC power converter with AC power cord
• User manual
INTRODUCTION
1.

Kolibri Bishop Counterfeit Detector 3
1.3 Front and rear views
2
1
3
4
5
5
2
13 4
1 Front slot
2 Display
3 Currency Button
4 Function Button
5 Reset Button
1 Rear slot
2 PC connection jack
3 AC adaptor power jack
4 ON/OFF power switch

Count on Kolibri
4
1.4 Specications
Weight 1.2 Lbs
Dimensions 6.3” x 5.7” x 2.7”
Sensors Internal IR, UV, and MG Sensors
Power Consumption >10W
Power Supply AC/DC adapter, 12V 650mA
Applicable Currency United States Dollar
1.5 Important safety notes
When operating this unit, please observe the following basic safety procedures:
• Use only the AC/DC adapter provided with the unit. The use of other AC/
DC adapters may result in electrical shock, re, or cause serious damage
to the unit
• Do not use the unit if the power cord is damaged or if the plug socket
contact is loose. Failure to follow these instructions may result in electrical
shock or re
• Do not use this unit in areas where it may be exposed to water or any other
liquids
• Unplug the unit from the wall outlet before cleaning
• To reduce the risk of electrical shock, do not disassemble this product.
Opening or removing covers may expose you to dangerous voltages or
other risks. Incorrect reassembly can cause electrical shock when the unit
is used again
• When service or repair is required, take the unit to a qualied service
technician
• Do not operate the unit in areas with high temperatures or high humidity as
these conditions may prevent it from working properly
• When not in use for an extended period of time, remove the power plug
from the wall outlet

Kolibri Bishop Counterfeit Detector
OPERATION
2.
2.1 Powering up
Connect the AC/DC adapter to the Kolibri Bishop and plug the adapter plug
into the power outlet. Turn the Kolibri Bishop on by ipping the ON/OFF switch on
the rear of the unit. The unit will beep and conduct a short self-test. The screen
will display the default count screen, indicating it is ready to operate.
2.2 Checking a bill’s condition
Avoid inserting bills that are torn, heavily worn or crumpled. Do not insert bills that
have have staples attached or bills that are covered by adhesive tape. Do not
insert wet or heavily stained bills.
You can change the direction that the Bishop ejects bills from front to back by
pressing and holding down the function button for approximately 4 seconds until
you hear a beep.
5
2.3 Changing the direction of ejection

Count on Kolibri
6
2.4 Authenticating a bill
After the bill is positioned in the insertion slot, the detector will automatically feed
and scan the bill. If a bill is recognized as authentic, the following will occur:
1. The machine will emit a single con rmation beep
2. The count will increase by 1 and the value of the bill will be added (If in
count mode)
3. The value of the scanned bill will be displayed (If in value mode)
4. The bill will be ejected
If the Bill is NOT recognized, the following will occur:
1. The machine will emit three beeps
2. An error code will be displayed
3. The bill will be ejected

Kolibri Bishop Counterfeit Detector
MAINTENANCE AND WARRANTY
3.
3.1 Maintenance
Regular maintenance will ensure accurate operation of the unit and will
prolong its service life. Use an air duster to remove dust from the sensors. Insert
approximately ¼ inch of the duster nozzle through the front bill insertion slot to
blow away any debris that may have accumulated inside the unit.
Do not insert the nozzle more than ¼ inch into the unit as it may damage the
sensor mechanisms inside the Kolibri Bishop unit.
7

Count on Kolibri
8
3.2 Troubleshooting
Because of the printing method used by the US Mint, bills are not exactly
identical. This will occasionally cause a bill to not be recognized on the rst run in
an automatic detector. This may also occur if a bill is inserted with even a slight
deviation from the required pathway. The Kolibri Bishop is an advanced machine
and will never accept a counterfeit bill. If it recognizes a bill after the second or
third attempt, you can be assured that the bill is genuine.
Several factors can cause the Kolibri Bishop to not recognize a genuine bill:
• Overly wrinkled, overly creased and overly worn bills
• A physical shock
• A sudden change in temperature or humidity
• Extended period of non-use.
If the Bishop consistently refuses to recognize genuine bills, turn the unit off, unplug
it from the wall. Reinsert the plug and turn the machine on to perform a reset.

Kolibri Bishop Counterfeit Detector
3.2 Warranty
The Kolibri Bishop is warranted for a period of one year from the date of purchase.
In most cases a unit malfunction can easily be corrected by performing a
thorough cleaning. This requires disassembly of the unit to clean each individual
sensor. This cleaning is not covered by warranty and should be performed only
by a qualied technician.
3.3 Shipping
The warranty does not cover the cost of shipping to Kolibri’s Technical Service
Center.
3.4 Contact information
www.kolibriusa.com/#support
9
