Komatsu D65EX-18 Manual

BULLDOZER
TEN00653-01
D65EX -18
D65PX -18
D65WX -18
SERIAL NUMBERS
90001
and up
Komatsu has Operation & Maintenance Manuals
written in some other languages. If a foreign language
manual is necessary, contact your local distributor for
availability.
NOTICE
Unsafe use of this machine may cause serious injury or
death. Operators and maintenance personnel must read
this manual before operating or maintaining this machine.
This manual should be kept near the machine for
reference and periodically reviewed by all personnel who
will come into contact with it.
WARNING

FOREWORD
1-1

BEFORE READING THIS MANUAL
This manual gives details of the operation and methods of inspection and maintenance for this machine that
must be obeyed in order to use the machine safely. Most accidents are caused by the failure to follow funda-
mental safety rules for the operation and maintenance of machines.
Read, understand and follow all precautions and warnings in this manual and on the machine before performing
operation and maintenance. Failure to do so may result in serious injury or death.
Komatsu cannot predict every circumstance that might involve a potential hazard when the machine is used.
Therefore, the safety messages in this manual and on the machine may not include all possible safety precau-
tions.
If you perform any operation, inspection, or maintenance under conditions that are not described in this manual,
understand that it is your responsibility to take the necessary precautions to ensure safety. In no event should
you or others engage in the prohibited uses or actions described in this manual. It is dangerous to perform im-
proper operation and maintenance of the machine. It may cause serious injury or death.
If you sell the machine, be sure to give this manual to the new owner together with the machine.
Always keep this Operation and Maintenance Manual in the indicated location so that all relevant personnel can
read it at any time.
Operation and Maintenance Manual Storing Place:
It is provided on the back side of the operator's seat back.
If this manual is lost or damaged, contact Komatsu or your Komatsu distributor and tell them about the machine
model name and the serial No. immediately to arrange for its replacement.
For details regarding the machine model name and the serial No., see the machine serial No. plate. In order to
arrange the proper Operation and Maintenance Manual, you will need to provide the machine model name and
the serial No.
This manual uses the International System of Units (SI) for units of measurement. For reference, units that have
been used in the past are given in { }.
The explanations, values, and illustrations in this manual have been prepared based on the latest information
available as of the date of its publication. Continuing improvements in the design of this machine may lead to
additional changes that are not reflected in this manual. If there is any question or suggestion, consult your Ko-
matsu distributor.
The numbers in the illustrations correspond to the numbers in ( ) in the text. (Example: 1 → (1))
Komatsu delivers machines that comply with all applicable regulations and standards of the country to which it
has been shipped. If this machine has been purchased in another country, it may lack certain safety devices and
specifications that are necessary for use in your country. If there is any question about whether your product
complies with the applicable standards and regulations of your country, consult your Komatsu distributor before
operating the machine.
BEFORE READING THIS MANUAL FOREWORD
1-2

SAFETY INFORMATION
To enable you to use the machine safely, and to prevent personal injury to operators, service personnel or by-
standers, the precautions and warnings included in this manual and the safety signs attached to the machine
must always be observed.
To identify important safety messages in the manual and on the machine labels, the following signal words are
used.
The "Safety Alert Symbol" identifies important safety messages on machines, in manuals, and elsewhere. When
you see this symbol, be alert to the risk of personal injury or death. Follow the instructions in the safety mes-
sage.
This signal word indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
This signal word indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
This signal word indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury. It may also be used to alert against unsafe practices that may cause
property damage.
The following signal words are used to alert you to information that must be followed to avoid damage to the
machine.
If precautions described are not observed, the machine may be damaged or the service life may
be reduced.
This word is used for information that is useful to know.
FOREWORD SAFETY INFORMATION
1-3

INTRODUCTION
MAIN USE OF MACHINE
This Komatsu machine is designed to be used mainly for the following work:
• Dozing work
• Leveling work
• Cutting into hard or frozen ground or ditching
• Felling trees, removing stumps
For details of work procedure, see OPERATION, “RECOMMENDED APPLICATIONS (3-222)”.
DIRECTIONS OF MACHINE
In this Operation and Maintenance Manual, the directions of the machine (front, rear, right, left) are determined
according to the view from operator's seat (E) in the direction of travel (front) of the machine.
(A) Front
(B) Rear
(C) Left
(D) Right
(E) Operator's seat
(F) Sprocket
INTRODUCTION FOREWORD
1-4

VISIBILITY FROM OPERATOR'S SEAT
The visibility of this machine required by visibility standards (ISO 5006) are shown in the drawing below.
Proximity visibility
The figure below shows a visibility from the machine at a spot 1.0m (3 ft 3 in) away from outside the machine
and 1.5m (4 ft 11 in) above the ground. Shaded area (A) in the figure shows an area whose view is blocked by a
part of the machine when the machine is equipped with the mirrors and other visibility assistant devices. Be fully
aware that there is an area where the operator cannot see when operating the machine.
12m radius visibility
The figure below shows a visibility from the machine for a radius of 12m (39 ft 4 in). Shaded area (B) in the
figure shows an area whose view is blocked by a part of the machine when the machine is equipped with the
mirrors and other visibility assistant devices. Be fully aware that there is an area where the operator cannot see
when operating the machine.
FOREWORD INTRODUCTION
1-5

ACTIONS TAKEN TO MEET EXHAUST GAS REGULA-
TIONS
This machine conforms to either regulation of Tier4 Final (North America) or Stage IV (Europe).
This machine is equipped with the following two exhaust gas treatment systems:
• Komatsu Diesel Particulate Filter (hereafter KDPF): A device which captures soot in the exhaust gas to pu-
rify exhaust gas. This process performs the combustion of soot referred to as "regeneration".
• Urea SCR system: A device which decomposes the toxic nitrogen oxides (NOx) mixed in the exhaust gas
into harmless nitrogen and water. Spraying aqueous urea solution into the exhaust gas produces a reaction
between the nitrogen oxides and ammonia generated from the urea solution and decomposes the nitrogen
oxides into nitrogen and water.
Either AdBlue® or DEF may be used as the aqueous urea solution for the SCR system.
AdBlue® is a registered trade-mark of VDA (Verband der Automobilindustrie e.V.: Automobile Association of
Germany).
DEF is the abbreviation for Diesel Exhaust Fluid.
Commercial DEF that is API approved and meets all the requirements defined in ISO 22241-1.
This solution will be represented as AdBlue/DEF throughout this manual.
About AdBlue/DEF
AdBlue/DEF is necessary for the urea SCR system. AdBlue/DEF is a colorless transparent 32.5% aqueous urea
solution. Urea as main constituent is a material which is used for cosmetics, medical and pharmaceutical prod-
ucts, and fertilizer, etc.
If you add any additional additive agents or water to AdBlue/DEF and use it, the devices will not function proper-
ly, and conformance to the exhaust gas regulations will be lost. In addition, it will cause failure of the machine.
• In Europe, use AdBlue.
• In North America, use DEF (Diesel Exhaust Fluid) which is certified by API (American Petroleum Institute).
The certified DEF has the API DEF Certification Mark shown as follows. Look for the API DEF Certification
Mark when purchasing DEF.
API Diesel Exhaust Fluid Certification Mark is the trade
mark of API (American Petroleum Institute).
ACTIONS TAKEN TO MEET EXHAUST GAS REGULATIONS FOREWORD
1-6

PRODUCT INFORMATION
When requesting service or ordering replacement parts, inform your Komatsu distributor of the following items.
LOCATION OF PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERI-
AL NO. PLATE
This is at the bottom left at the front of the operator's seat.
The design of the nameplate differs according to the district.
LOCATION OF EPA REGULATIONS, ENGINE NUMBER PLATE
• This is located on top of the engine head cover on the right side of the machine.
EPA: Environmental Protection Agency, USA
FOREWORD PRODUCT INFORMATION
1-7

SERVICE METER LOCATION
This is displayed on the machine monitor.
YOUR MACHINE SERIAL NUMBERS AND DISTRIBUTOR
Machine serial No.
Engine serial No.
Product identification
number (PIN)
Distributor name
Address
Phone/Fax
Service personnel
PRODUCT INFORMATION FOREWORD
1-8

TABLE OF CONTENTS
FOREWORD.................................................................................................................................................... 1-1
BEFORE READING THIS MANUAL ......................................................................................................... 1-2
SAFETY INFORMATION .......................................................................................................................... 1-3
INTRODUCTION ...................................................................................................................................... 1-4
MAIN USE OF MACHINE .................................................................................................................. 1-4
DIRECTIONS OF MACHINE.............................................................................................................. 1-4
VISIBILITY FROM OPERATOR'S SEAT ............................................................................................ 1-5
ACTIONS TAKEN TO MEET EXHAUST GAS REGULATIONS................................................................. 1-6
PRODUCT INFORMATION....................................................................................................................... 1-7
LOCATION OF PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERIAL NO. PLATE ........ 1-7
LOCATION OF EPA REGULATIONS, ENGINE NUMBER PLATE ..................................................... 1-7
SERVICE METER LOCATION ........................................................................................................... 1-8
YOUR MACHINE SERIAL NUMBERS AND DISTRIBUTOR.............................................................. 1-8
SAFETY........................................................................................................................................................... 2-1
SAFETY.................................................................................................................................................... 2-2
SAFETY LABELS ..................................................................................................................................... 2-4
LOCATION OF SAFETY LABELS...................................................................................................... 2-5
CONTENTS OF SAFETY LABELS .................................................................................................... 2-6
GENERAL PRECAUTIONS COMMON TO OPERATION AND MAINTENANCE .....................................2-11
PRECAUTIONS BEFORE STARTING OPERATION.........................................................................2-11
PREPARATIONS FOR SAFE OPERATION ......................................................................................2-11
PRECAUTIONS TO PREVENT FIRE............................................................................................... 2-13
PRECAUTIONS WHEN GETTING ON OR OFF MACHINE............................................................. 2-15
DO NOT GET CAUGHT IN WORK EQUIPMENT ............................................................................ 2-17
PRECAUTIONS RELATED TO PROTECTIVE STRUCTURES........................................................ 2-17
UNAUTHORIZED MODIFICATION .................................................................................................. 2-17
PRECAUTIONS RELATED TO ATTACHMENTS AND OPTIONS .................................................... 2-17
PRECAUTIONS WHEN RUNNING ENGINE INSIDE BUILDING..................................................... 2-18
PRECAUTIONS FOR OPERATION ........................................................................................................ 2-19
PRECAUTIONS FOR JOBSITE....................................................................................................... 2-19
START ENGINE............................................................................................................................... 2-22
PRECAUTIONS FOR OPERATION ................................................................................................. 2-25
PRECAUTIONS FOR TRANSPORTATION...................................................................................... 2-29
TOWING AND BEING TOWED........................................................................................................ 2-30
PRECAUTIONS FOR MAINTENANCE................................................................................................... 2-31
PRECAUTIONS BEFORE STARTING INSPECTION AND MAINTENANCE ................................... 2-31
PRECAUTIONS FOR INSPECTION AND MAINTENANCE............................................................. 2-35
PRECAUTIONS FOR AdBlue/DEF ......................................................................................................... 2-41
GENERAL CHARACTER AND PRECAUTIONS FOR HANDLING .................................................. 2-41
PRECAUTIONS FOR ADDING........................................................................................................ 2-41
PRECAUTIONS FOR STORING...................................................................................................... 2-41
PRECAUTIONS FOR FIRE HAZARD AND LEAKAGE .................................................................... 2-41
OTHER PRECAUTIONS.................................................................................................................. 2-41
OPERATION.................................................................................................................................................... 3-1
GENERAL VIEW....................................................................................................................................... 3-2
MACHINE EQUIPMENT NAME ......................................................................................................... 3-2
CONTROLS AND GAUGES NAMES................................................................................................. 3-4
EXPLANATION OF COMPONENTS......................................................................................................... 3-6
EXPLANATION OF MACHINE MONITOR EQUIPMENT ................................................................... 3-6
SWITCHES...................................................................................................................................... 3-95
CONTROL LEVERS AND PEDALS............................................................................................... 3-101
OTHER EQUIPMENT .....................................................................................................................3-111
MACHINE OPERATIONS AND CONTROLS ........................................................................................ 3-157
CHECKS AND ADJUSTMENT BEFORE STARTING ENGINE ...................................................... 3-157
METHOD FOR STARTING ENGINE.............................................................................................. 3-193
METHOD FOR OPERATIONS AND CHECKS AFTER STARTING ENGINE ................................. 3-198
FOREWORD TABLE OF CONTENTS
1-9

METHOD FOR STOPPING ENGINE ............................................................................................. 3-202
METHOD FOR STARTING MACHINE (TRAVEL FORWARD AND REVERSE) AND STOPPING MA-
CHINE........................................................................................................................................ 3-204
SHIFT GEARS............................................................................................................................... 3-207
METHOD FOR SWITCHING BETWEEN FORWARD AND REVERSE.......................................... 3-213
METHOD FOR STEERING MACHINE........................................................................................... 3-214
RECOMMENDED WORKING MODES FOR WORKS ................................................................... 3-217
PRECAUTIONS FOR OPERATION ............................................................................................... 3-219
PRECAUTIONS WHEN OPERATING ON SLOPE......................................................................... 3-220
PRECAUTIONS FOR USING BRAKE ........................................................................................... 3-220
DO NOT OPEN DOOR WHILE OPERATING MACHINE ............................................................... 3-220
DO NOT MODIFY CAB GLASS IN ANY WAY THAT WILL OBSTRUCT THE VIEW ...................... 3-221
PRECAUTIONS FOR FLOATING OPERATION............................................................................. 3-221
PRECAUTIONS FOR BLIND SPOTS CAUSED BY CAB AND ROPS STRUCTURES .................. 3-221
RECOMMENDED APPLICATIONS................................................................................................ 3-222
METHOD FOR ADJUSTING WORK EQUIPMENT........................................................................ 3-224
TIPS FOR LONGER UNDERCARRIAGE LIFE.............................................................................. 3-234
METHOD FOR PARKING MACHINE............................................................................................. 3-237
METHOD FOR CHECKING AFTER FINISHING WORK................................................................ 3-239
LOCK............................................................................................................................................. 3-240
HANDLE AIR CONDITIONER............................................................................................................... 3-246
EXPLANATION OF AIR CONDITIONER EQUIPMENT.................................................................. 3-247
METHOD FOR OPERATING AIR CONDITIONER......................................................................... 3-253
HANDLING RADIO ............................................................................................................................... 3-261
EXPLANATION OF RADIO EQUIPMENT ...................................................................................... 3-261
METHOD FOR CONTROLLING RADIO ........................................................................................ 3-264
ANTENNA...................................................................................................................................... 3-266
TRANSPORTATION.............................................................................................................................. 3-267
TRAVEL ON ROAD........................................................................................................................ 3-267
PRECAUTIONS FOR TRANSPORTING MACHINE ...................................................................... 3-267
TRANSPORTATION PROCEDURE ............................................................................................... 3-267
METHOD FOR REMOVING WORK EQUIPMENT......................................................................... 3-267
LOADING AND UNLOADING WITH TRAILER .............................................................................. 3-268
METHOD FOR LIFTING MACHINE............................................................................................... 3-272
COLD WEATHER OPERATION............................................................................................................ 3-274
COLD WEATHER OPERATION INFORMATION ........................................................................... 3-274
PRECAUTIONS AFTER DAILY WORK COMPLETION ................................................................. 3-276
AFTER COLD WEATHER SEASON .............................................................................................. 3-276
PRECAUTIONS FOR LONG-TERM STORAGE ................................................................................... 3-277
PREPARATION FOR LONG-TERM STORAGE............................................................................. 3-277
MAINTENANCE DURING LONG-TERM STORAGE...................................................................... 3-277
STARTING MACHINE AFTER LONG-TERM STORAGE............................................................... 3-278
TROUBLES AND ACTIONS ................................................................................................................. 3-279
ACTIONS WHEN RUNNING OUT OF FUEL ................................................................................. 3-279
PRECAUTIONS FOR TOWING MACHINE.................................................................................... 3-280
PRECAUTIONS FOR DISCHARGED BATTERY ........................................................................... 3-281
OTHER TROUBLE......................................................................................................................... 3-286
MAINTENANCE............................................................................................................................................... 4-1
PRECAUTIONS FOR MAINTENANCE..................................................................................................... 4-2
CHECK SERVICE METER READING ............................................................................................... 4-2
KOMATSU GENUINE REPLACEMENT PARTS ................................................................................ 4-2
KOMATSU GENUINE LUBRICANTS................................................................................................. 4-2
ALWAYS USE CLEAN WASHER FLUID ............................................................................................ 4-2
FRESH AND CLEAN LUBRICANTS .................................................................................................. 4-2
CHECK DRAINED OIL AND USED FILTER....................................................................................... 4-2
PRECAUTIONS FOR REFILLING OIL OR FUEL .............................................................................. 4-2
PRECAUTIONS FOR ADDING AdBlue/DEF ..................................................................................... 4-2
WELDING INSTRUCTIONS............................................................................................................... 4-2
TABLE OF CONTENTS FOREWORD
1-10

DO NOT DROP THINGS INSIDE MACHINE ..................................................................................... 4-2
PRECAUTIONS FOR KDPF .............................................................................................................. 4-2
PRECAUTIONS FOR SCR ASSEMBLY ............................................................................................ 4-3
DUSTY JOBSITES............................................................................................................................. 4-3
AVOID MIXING OIL............................................................................................................................ 4-3
LOCK INSPECTION COVERS .......................................................................................................... 4-3
PRECAUTIONS FOR OPENING AND CLOSING ENGINE SIDE COVER......................................... 4-3
BLEED AIR FROM HYDRAULIC CIRCUIT ........................................................................................ 4-3
PRECAUTIONS WHEN INSTALLING HYDRAULIC HOSES ............................................................. 4-3
CHECKS AFTER INSPECTION AND MAINTENANCE...................................................................... 4-4
FUEL AND LUBRICANTS TO MATCH THE AMBIENT TEMPERATURE........................................... 4-4
OUTLINE OF MAINTENANCE.................................................................................................................. 4-5
HANDLE OIL, FUEL, COOLANT, AND PERFORMING OIL CLINIC .................................................. 4-5
HANDLE ELECTRICAL COMPONENTS ......................................................................................... 4-10
HANDLE HYDRAULIC COMPONENTS............................................................................................4-11
STANDARD TIGHTENING TORQUE FOR BOLTS AND NUTS.............................................................. 4-12
MAINTENANCE SCHEDULE.................................................................................................................. 4-14
MAINTENANCE SCHEDULE TABLE............................................................................................... 4-14
MAINTENANCE PROCEDURE .............................................................................................................. 4-16
WHEN REQUIRED .......................................................................................................................... 4-16
CHECKS BEFORE STARTING........................................................................................................ 4-52
EVERY 50 HOURS MAINTENANCE ............................................................................................... 4-53
EVERY 250 HOURS MAINTENANCE ............................................................................................. 4-54
EVERY 500 HOURS MAINTENANCE ............................................................................................. 4-62
EVERY 1000 HOURS MAINTENANCE ........................................................................................... 4-70
EVERY 2000 HOURS MAINTENANCE ........................................................................................... 4-81
EVERY 4000 HOURS MAINTENANCE ........................................................................................... 4-93
EVERY 4500 HOURS MAINTENANCE ........................................................................................... 4-97
EVERY 8000 HOURS MAINTENANCE ........................................................................................... 4-98
EVERY 9000 HOURS MAINTENANCE ........................................................................................... 4-99
SPECIFICATIONS ........................................................................................................................................... 5-1
SPECIFICATIONS .................................................................................................................................... 5-2
D65EX-18 SPECIFICATIONS ............................................................................................................ 5-2
D65PX-18 SPECIFICATIONS ............................................................................................................ 5-3
D65WX-18 SPECIFICATIONS ........................................................................................................... 5-4
ATTACHMENTS AND OPTIONS ..................................................................................................................... 6-1
GENERAL PRECAUTIONS ...................................................................................................................... 6-2
PRECAUTIONS FOR SAFETY.......................................................................................................... 6-2
HANDLE HYDRAULIC RIPPER................................................................................................................ 6-3
GENERAL VIEW................................................................................................................................ 6-3
EXPLANATION OF COMPONENTS.................................................................................................. 6-4
MACHINE OPERATIONS AND CONTROLS ..................................................................................... 6-5
TROUBLES AND ACTIONS .............................................................................................................. 6-8
HANDLE 3m WIDTH BLADE .................................................................................................................... 6-9
GENERAL VIEW................................................................................................................................ 6-9
MACHINE OPERATIONS AND CONTROLS ................................................................................... 6-10
TRANSPORTATION..........................................................................................................................6-11
CHECK AND MAINTENANCE ......................................................................................................... 6-13
SPECIFICATIONS ........................................................................................................................... 6-14
REPLACEMENT PARTS.................................................................................................................................. 7-1
PERIODIC REPLACEMENT OF DEFINED LIFE PARTS.......................................................................... 7-2
DEFINED LIFE PARTS LIST.............................................................................................................. 7-2
CONSUMABLE PARTS ............................................................................................................................ 7-3
CONSUMABLE PARTS ..................................................................................................................... 7-3
RECOMMENDED FUEL, COOLANT, AND LUBRICANT .......................................................................... 7-6
LUBRICATION CHART...................................................................................................................... 7-7
METHOD FOR USING FUEL, COOLANT AND LUBRICANTS ACCORDING TO AMBIENT TEMPERA-
TURE ............................................................................................................................................. 7-9
FOREWORD TABLE OF CONTENTS
1-11

RECOMMENDED BRANDS AND QUALITIES OTHER THAN KOMATSU GENUINE OILS ............ 7-10
INDEX.............................................................................................................................................................. 8-1
TABLE OF CONTENTS FOREWORD
1-12

SAFETY
Please read and make sure that you fully understand the precautions descri-
bed in this manual and the safety labels on the machine. When operating or
servicing the machine, always follow these precautions strictly.
2-1

SAFETY
SAFETY LABELS ............................................................................................................................................ 2-4
LOCATION OF SAFETY LABELS............................................................................................................. 2-5
CONTENTS OF SAFETY LABELS ........................................................................................................... 2-6
GENERAL PRECAUTIONS COMMON TO OPERATION AND MAINTENANCE ............................................2-11
PRECAUTIONS BEFORE STARTING OPERATION................................................................................2-11
ENSURE SAFE OPERATION ...........................................................................................................2-11
UNDERSTAND THE MACHINE........................................................................................................2-11
PREPARATIONS FOR SAFE OPERATION .............................................................................................2-11
PRECAUTIONS FOR SAFETY-RELATED EQUIPMENT ..................................................................2-11
INSPECT MACHINE.........................................................................................................................2-11
WEAR WELL-FITTING CLOTHES AND PROTECTIVE EQUIPMENT..............................................2-11
KEEP MACHINE CLEAN ................................................................................................................. 2-12
PRECAUTIONS FOR INSIDE OPERATOR'S COMPARTMENT ...................................................... 2-12
PROVIDE FIRE EXTINGUISHER AND FIRST AID KIT ................................................................... 2-12
IF ANY PROBLEM IS FOUND ......................................................................................................... 2-12
PRECAUTIONS TO PREVENT FIRE...................................................................................................... 2-13
ACTIONS IF FIRE OCCURS ........................................................................................................... 2-13
PREVENT FIRE............................................................................................................................... 2-13
PRECAUTIONS WHEN GETTING ON OR OFF MACHINE.................................................................... 2-15
USE HANDRAILS AND STEPS WHEN GETTING ON OR OFF MACHINE..................................... 2-15
NO JUMPING ON OR OFF MACHINE............................................................................................. 2-16
NO PEOPLE ON ATTACHMENTS................................................................................................... 2-16
PRECAUTIONS WHEN STANDING UP FROM OPERATOR'S SEAT.............................................. 2-16
WHEN LEAVING MACHINE ............................................................................................................ 2-16
EMERGENCY EXIT FROM OPERATOR'S CAB.............................................................................. 2-17
DO NOT GET CAUGHT IN WORK EQUIPMENT ................................................................................... 2-17
PRECAUTIONS RELATED TO PROTECTIVE STRUCTURES............................................................... 2-17
UNAUTHORIZED MODIFICATION ......................................................................................................... 2-17
PRECAUTIONS RELATED TO ATTACHMENTS AND OPTIONS ........................................................... 2-17
PRECAUTIONS WHEN RUNNING ENGINE INSIDE BUILDING............................................................ 2-18
PRECAUTIONS FOR OPERATION ............................................................................................................... 2-19
PRECAUTIONS FOR JOBSITE.............................................................................................................. 2-19
INVESTIGATE AND CONFIRM JOBSITE CONDITIONS................................................................. 2-19
PRECAUTIONS WHEN WORKING ON LOOSE GROUND............................................................. 2-19
DO NOT GO CLOSE TO HIGH-VOLTAGE CABLES........................................................................ 2-20
ENSURE GOOD VISIBILITY............................................................................................................ 2-20
CHECK SIGNS AND SIGNALMAN'S SIGNALS............................................................................... 2-21
BEWARE OF ASBESTOS DUST..................................................................................................... 2-21
START ENGINE...................................................................................................................................... 2-22
USE WARNING TAGS ..................................................................................................................... 2-22
CHECKS AND ADJUSTMENT BEFORE STARTING ENGINE ........................................................ 2-22
PRECAUTIONS WHEN STARTING ENGINE .................................................................................. 2-23
IN COLD WEATHER........................................................................................................................ 2-23
START ENGINE WITH JUMPER CABLES ...................................................................................... 2-24
PRECAUTIONS FOR OPERATION ........................................................................................................ 2-25
CHECKS BEFORE OPERATION..................................................................................................... 2-25
PRECAUTIONS FOR TRAVELING IN FORWARD OR REVERSE .................................................. 2-25
PRECAUTIONS WHEN TRAVELING............................................................................................... 2-26
PRECAUTIONS WHEN TRAVELING ON SLOPES ......................................................................... 2-27
WHEN OPERATING ........................................................................................................................ 2-27
PROHIBITED OPERATIONS ........................................................................................................... 2-27
METHOD OF USING BRAKES........................................................................................................ 2-27
PRECAUTIONS WHEN OPERATING ON SNOW OR FROZEN SURFACES.................................. 2-28
PRECAUTIONS WHEN PARKING MACHINE ................................................................................. 2-28
PRECAUTIONS FOR TRANSPORTATION............................................................................................. 2-29
PRECAUTIONS WHEN LOADING AND UNLOADING.................................................................... 2-29
SAFETY SAFETY
2-2

TOWING AND BEING TOWED............................................................................................................... 2-30
PRECAUTIONS FOR TOWING AND BEING TOWED..................................................................... 2-30
PRECAUTIONS FOR MAINTENANCE.......................................................................................................... 2-31
PRECAUTIONS BEFORE STARTING INSPECTION AND MAINTENANCE .......................................... 2-31
DISPLAY WARNING TAG DURING INSPECTION AND MAINTENANCE ....................................... 2-31
KEEP WORK PLACE CLEAN AND TIDY ........................................................................................ 2-31
SELECT SUITABLE PLACE FOR INSPECTION AND MAINTENANCE .......................................... 2-31
ONLY AUTHORIZED PERSONNEL................................................................................................. 2-31
APPOINT LEADER WHEN WORKING WITH OTHERS .................................................................. 2-31
STOP ENGINE BEFORE CARRYING OUT INSPECTION AND MAINTENANCE ........................... 2-32
2 WORKERS FOR MAINTENANCE WHEN ENGINE IS RUNNING ................................................ 2-33
PRECAUTIONS WHEN INSTALLING, REMOVING, OR STORING ATTACHMENTS...................... 2-33
PRECAUTIONS FOR WORKING AT HIGH PLACES ...................................................................... 2-33
WORK ON MACHINE...................................................................................................................... 2-34
PRECAUTIONS WHEN WORKING UNDER MACHINE OR WORK EQUIPMENT .......................... 2-34
USE PROPER TOOLS .................................................................................................................... 2-34
PRECAUTIONS FOR INSPECTION AND MAINTENANCE.................................................................... 2-35
TURN BATTERY DISCONNECT SWITCH TO OFF POSITION....................................................... 2-35
PRECAUTIONS FOR WELDING ..................................................................................................... 2-35
HANDLE BATTERY ......................................................................................................................... 2-35
PRECAUTIONS WHEN USING HAMMER ...................................................................................... 2-36
PRECAUTIONS FOR HIGH-TEMPERATURE COOLANT ............................................................... 2-36
PRECAUTIONS FOR HIGH-TEMPERATURE OIL........................................................................... 2-36
PRECAUTIONS FOR HIGH-TEMPERATURE PARTS..................................................................... 2-37
HIGH-PRESSURE OIL .................................................................................................................... 2-37
PRECAUTIONS FOR HIGH-PRESSURE FUEL .............................................................................. 2-37
HANDLE HIGH-PRESSURE HOSES AND PIPING ......................................................................... 2-37
PRECAUTIONS FOR HIGH VOLTAGE............................................................................................ 2-38
PRECAUTIONS FOR NOISE........................................................................................................... 2-38
PRECAUTIONS FOR HIGH-PRESSURE GREASE WHEN ADJUSTING TRACK TENSION .......... 2-38
DO NOT DISASSEMBLE RECOIL SPRING .................................................................................... 2-39
HANDLE ACCUMULATOR .............................................................................................................. 2-39
PRECAUTIONS FOR COMPRESSED AIR...................................................................................... 2-39
MAINTENANCE OF AIR CONDITIONER ........................................................................................ 2-39
PRECAUTIONS FOR DISPOSING OF WASTE MATERIALS .......................................................... 2-40
METHOD FOR SELECTING WINDOW WASHER FLUID................................................................ 2-40
PERIODIC REPLACEMENT OF DEFINED LIFE PARTS................................................................. 2-40
PRECAUTIONS FOR AdBlue/DEF ................................................................................................................ 2-41
GENERAL CHARACTER AND PRECAUTIONS FOR HANDLING ......................................................... 2-41
PRECAUTIONS FOR ADDING............................................................................................................... 2-41
PRECAUTIONS FOR STORING............................................................................................................. 2-41
PRECAUTIONS FOR FIRE HAZARD AND LEAKAGE ........................................................................... 2-41
OTHER PRECAUTIONS......................................................................................................................... 2-41
SAFETY SAFETY
2-3

SAFETY LABELS
kk
WARNING
Be sure that you fully understand the correct position, content and how to avoid a danger shown in the
safety labels.
Handle the warning signs and safety labels used on this machine as follows.
• Always keep the safety labels clean so that you can read it properly. When cleaning the safety labels, do
not use organic solvents or gasoline. These may cause the labels to peel off.
• If the safety labels are damaged, lost, or cannot be read properly, replace them with new ones. For details
of the part numbers for the safety labels, see this manual or the actual label, and place an order to your
Komatsu distributor.
• There are also other labels in addition to the warning signs and safety labels. Handle those labels in the
same way.
SAFETY LABELS SAFETY
2-4

LOCATION OF SAFETY LABELS
1. Caution for operation, inspection and maintenance
2. Caution before moving in reverse
3. Caution when leaving the operator's seat
4. Caution for high-temperature coolant
5. Caution for high-temperature oil
6. Caution for handling accumulator
7. Caution for adjusting track tension
8. Caution for handling cable
9. Stop rotation during inspection and maintenance
10. Caution for approaching while moving machine
11. Prohibition of start by short-circuiting
12. Caution for handling battery
13. Caution for handling ROPS/FOPS
14. Caution for blast site
15. Caution for high-temperature parts
16. Caution for handling AdBlue/DEF
SAFETY SAFETY LABELS
2-5

CONTENTS OF SAFETY LABELS
Caution for operation, inspection and maintenance
(09651-03001)
Caution for safety at rear (09802-13000)
Caution when leaving the operator's seat (09654-33001)
SAFETY LABELS SAFETY
2-6

Caution for high-temperature coolant (09668-03001)
Caution for high-temperature oil (09653-03001)
Caution for handling accumulator (09659-53000)
Caution for adjusting track tension (09657-03003)
This safety label is attached to the back of the track adjustment
window cover.
SAFETY SAFETY LABELS
2-7
