Kontron FusionView FV 156 User manual


USER GUIDE
FusionView
Doc-Rev.: 1.1
Doc ID: 1061-3671

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 2
This page has been intentionally left blank.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 3

FUSIONVIEW
- USER GUIDE
Disclaimer
Kontron would like to point out that the information contained in this user guide may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the user guide or any product characteristics
set out in the user guide. Kontron assumes no responsibility or liability for the use of the described product(s),
conveys no license or title under any patent, copyright or mask work rights to these products and makes no
representations or warranties that these products are free from patent, copyright or mask work right infringement
unless otherwise specified. Applications that are described in this user guide are for illustration purposes only.
Kontron makes no representation or warranty that such application will be suitable for the specified use without
further testing or modification. Kontron expressly informs the user that this user guide only contains a general
description of processes and instructions which may not be applicable in every individual case. In cases of doubt,
please contact Kontron.
This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this user guide is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this user guide only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
© 2018 by Kontron S&T AG
Kontron S&T AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 4
High Risk Applications Hazard Notice
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE
OR RESALE FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR
COMMUNICATION SYSTEMS FOR AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE
SUPPORT OR LIFE SUSTAINING APPLICATIONS, WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A
HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE PERFORMANCE, OR IN WHICH THE FAILURE OF
PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR SEVERE PHYSICAL OR
ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless otherwise
stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities and cannot
therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or for resale as
device in High Risk Applications. All application and safety related information in this document (including application
descriptions, suggested safety measures, suggested Kontron products, and other materials) is provided for reference
only.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue Author
1.0 Initial Issue 2018-Feb-01 hjs
1.1 corrected grounding information 2018-May-09 hjs
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths into
a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace of
mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 6
Symbols
The following symbols may be used in this manual
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE indicates a property damage message.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60 V) when touching
products or parts of them. Failure to observe the precautions indicated and/or prescribed by
the law may endanger your life/health and/or result in damage to your material.
Please refer also to the "High-Voltage Safety Instructions" portion below in this section.
ESD Sensitive Device!
This symbol and title inform that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
Hot surface!
This device will heat up during operation and if touched may cause burns.
This symbol indicates general information about the product and the user manual.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 7
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its
compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life
expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are
requested to conform with the following guidelines.
High Voltage Safety Instructions
As a precaution and in case of danger, the power connector must be easily accessible. The power connector is the
product’s main disconnect device.
Warning
All operations on this product must be carried out by sufficiently skilled personnel only.
Electric Shock!
Before installing a non hot-swappable Kontron product into a system always ensure that
your mains power is switched off. This also applies to the installation of piggybacks. Serious
electrical shock hazards can exist during all installation, repair, and maintenance operations
on this product. Therefore, always unplug the power cable and any other cables which
provide external voltages before performing any work on this product.
Earth ground connection to vehicle’s chassis or a central grounding point shall remain
connected. The earth ground cable shall be the last cable to be disconnected or the first
cable to be connected when performing installation or removal procedures on this product.
Special Handling und Unpacking Instruction
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity. Therefore, care
must be taken during all handling operations and inspections of this product, in order to
ensure product integrity at all times.
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is
otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is not
guaranteed, it is important for the user to be electrically discharged before touching the product with his/her hands
or tools. This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices,
jumper settings etc. If the product contains batteries for RTC or memory backup, ensure that the product is not placed
on conductive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage the
batteries or conductive circuits on the product.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 8
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or
modifications to the product, that are not explicitly approved by Kontron and described in this user guide or received
from Kontron Support as a special handling instruction, will void your warranty.
This product should only be installed in or connected to systems that fulfill all necessary technical and specific
environmental requirements. This also applies to the operational temperature range of the specific board version
that must not be exceeded. If batteries are present, their temperature restrictions must be taken into account.
In performing all necessary installation and application operations, only follow the instructions supplied by the
present user guide.
Keep all the original packaging material for future storage or warranty shipments. If it is necessary to store or ship
the product then re-pack it in the same manner as it was delivered.
Special care is necessary when handling or unpacking the product. See Special Handling and Unpacking Instruction.
Quality and Environmental Management
Kontron aims to deliver reliable high-end products designed and built for quality, and aims to complying with
environmental laws, regulations, and other environmentally oriented requirements. For more information regarding
Kontron’s quality and environmental responsibilities, visit http://www.kontron.com/about-kontron/corporate-
responsibility/quality-management.
Disposal and Recycling
Kontron’s products are manufactured to satisfy environmental protection requirements where possible. Many of the
components used are capable of being recycled. Final disposal of this product after its service life must be
accomplished in accordance with applicable country, state, or local laws or regulations.
WEEE Compliance
The Waste Electrical and Electronic Equipment (WEEE) Directive aims to:
Reduce waste arising from electrical and electronic equipment (EEE)
Make producers of EEE responsible for the environmental impact of their products, especially when the product
become waste
Encourage separate collection and subsequent treatment, reuse, recovery, recycling and sound environmental
disposal of EEE
Improve the environmental performance of all those involved during the lifecycle of EEE
Environmental protection is a high priority with Kontron.
Kontron follows the WEEE directive
You are encouraged to return our products for proper disposal.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 9
Table of Contents
Revision History..................................................................................................................................................................................................5
Symbols .................................................................................................................................................................................................................6
For Your Safety....................................................................................................................................................................................................7
High Voltage Safety Instructions ..................................................................................................................................................................7
Special Handling und Unpacking Instruction ............................................................................................................................................7
General Instructions on Usage...................................................................................................................................................................... 8
Quality and Environmental Management ................................................................................................................................................. 8
Disposal and Recycling.................................................................................................................................................................................... 8
WEEE Compliance.............................................................................................................................................................................................. 8
Table of Contents ...............................................................................................................................................................................................9
List of Tables......................................................................................................................................................................................................10
List of Figures ....................................................................................................................................................................................................10
1/ General Safety Instructions for IT Equipment ..........................................................................................................................13
1.1. Additional Safety Instructions for DC Power Supply Circuits .....................................................................................................13
1.2. Electrostatic Discharge (ESD)...............................................................................................................................................................14
1.2.1. Grounding Methods ...............................................................................................................................................................................14
2/ Scope of Delivery................................................................................................................................................................................15
2.1.1. Optional System Configuration..........................................................................................................................................................16
2.1.2. Accessory Parts......................................................................................................................................................................................16
3/ Technical Data.....................................................................................................................................................................................17
3.1. Electrical Specifications..........................................................................................................................................................................18
3.2. Mechanical Specifications.....................................................................................................................................................................18
3.2.1. Dimensions and weight .......................................................................................................................................................................18
3.2.2. Mechanical Dimensions of the Monitor ........................................................................................................................................19
3.2.3. Mechanical Dimensions of the PC Box.......................................................................................................................................... 25
3.3. Cooling.........................................................................................................................................................................................................26
3.4. Environmental Specifications .............................................................................................................................................................26
3.5. CE-Directives, Standards and Approvals.........................................................................................................................................26
3.6. Electromagnetic Compatibility (Class A Device)........................................................................................................................... 27
3.6.1. Electromagnetic Compatibility EU .................................................................................................................................................. 27
3.6.2. FCC Statement (U.S.A.) ....................................................................................................................................................................... 27
3.6.3. EMC-Compliance Canada .................................................................................................................................................................. 27
3.7. RFID Specification (Option)................................................................................................................................................................... 27
4/ Product Description..........................................................................................................................................................................29
4.1. Product Images of FusionView (shown as 21.5", other units similar) ....................................................................................30
4.2. Front View..................................................................................................................................................................................................32
4.2.1. Front Side ................................................................................................................................................................................................32
4.2.2. Display with Touch Screen ............................................................................................................................................................... 32
4.2.3. RFID Card Reader (Option)................................................................................................................................................................ 33
4.3. Bottom Side (with Interfaces).............................................................................................................................................................34
4.3.1. DC Power Input Connector..................................................................................................................................................................34
4.3.2. Grounding Stud..................................................................................................................................................................................... 35
4.3.3. Buttons and Indicators....................................................................................................................................................................... 35
4.3.3.1. Colors of Power LEDs ......................................................................................................................................................................36
4.3.4. USB 3.0 ....................................................................................................................................................................................................36
4.3.5. DisplayPort.............................................................................................................................................................................................36
4.3.6. Mounting Slots on the bottom Side of the Touch Display Unit ............................................................................................ 36
4.4. Rear Side ....................................................................................................................................................................................................38

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 10
4.4.1. VESA 75/100 Mounting Holes...........................................................................................................................................................39
5/ Installation Instructions..................................................................................................................................................................40
5.1. Installation by use of the Mounting Clamps ...................................................................................................................................40
6/ Starting Up...........................................................................................................................................................................................44
6.1. DC Power Terminal..................................................................................................................................................................................44
6.1.1. Cabling.......................................................................................................................................................................................................44
6.2. Connecting to Power ..............................................................................................................................................................................45
6.2.1. DC Power Connection..........................................................................................................................................................................45
6.2.2. AC Power Connection..........................................................................................................................................................................46
6.3. System Settings with On-Screen Display (OSD) Menu...............................................................................................................46
6.3.1. Buttons and Indicators........................................................................................................................................................................46
6.3.2. Starting OSD-Screens.........................................................................................................................................................................47
6.4. OSD Menu ..................................................................................................................................................................................................48
6.5. Windows-Software Soft-OSD..............................................................................................................................................................61
7/ Maintenance and Cleaning.............................................................................................................................................................64
7.1. Touch Screen Care and Cleaning.........................................................................................................................................................64
8/ Standard Interfaces – Pin Assignments .................................................................................................................................... 65
8.1.1. Power Input Connector........................................................................................................................................................................ 65
8.1.2. DisplayPort (DP)....................................................................................................................................................................................65
8.1.3. USB3.0 Port............................................................................................................................................................................................. 65
8.1.4. DVI Connector........................................................................................................................................................................................66
9/ Technical Support ............................................................................................................................................................................. 67
9.1. Returning Defective Merchandise...................................................................................................................................................... 67
Appendix B – List of Acronyms...................................................................................................................................................................68
About Kontron ..................................................................................................................................................................................................69
List of Tables
Table 1: FusionView - Scope of delivery....................................................................................................................................................15
Table 2: FusionView - System configuration options ..........................................................................................................................16
Table 3: FusionView – Optional Accessories...........................................................................................................................................16
Table 4: FusionView Technical Data ..........................................................................................................................................................17
Table 5: FusionView Power Consumption................................................................................................................................................18
Table 6: FusionView Dimensions ................................................................................................................................................................18
Table 7: Dimension of the touch display unit..........................................................................................................................................18
Table 8: FusionView SD Environmental Specifications ......................................................................................................................26
Table 9: FusionView CE Directive ...............................................................................................................................................................26
Table 10: FusionView Electrical Safety.....................................................................................................................................................26
Table 11: FusionView EMC............................................................................................................................................................................. 27
Table 12: Colors of the power LED indicate the system status........................................................................................................ 36
Table 13: FusionView - Specification for mounting..............................................................................................................................40
Table 14: Power Input Connector ............................................................................................................................................................... 65
Table 15: DP Pinout..........................................................................................................................................................................................65
Table 16: USB 3.0 Pinout................................................................................................................................................................................ 65
Table 17: DVI Pinout.........................................................................................................................................................................................66
List of Figures
Figure 1: Mechanical specification - Front view of the FV 121 ...........................................................................................................19
Figure 2: Mechanical specification - top view of the FV 121...............................................................................................................19
Figure 3: Mechanical specification - rear view of the FV 121 ............................................................................................................20
Figure 4: Mechanical specification - Front view of the FV 156.........................................................................................................20
Figure 5: Mechanical specification - Rear view of the FV 156............................................................................................................21

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 11
Figure 6: Mechanical specification - top view of the FV 156 ..............................................................................................................21
Figure 7: Mechanical specification - Front view of the FV 185......................................................................................................... 22
Figure 8: Mechanical specification - Rear view of the FV 185 .......................................................................................................... 22
Figure 9: Mechanical specification - Top view of the FV 185............................................................................................................ 23
Figure 10: Mechanical specification - Front view of the FV 215 ....................................................................................................... 23
Figure 11: Mechanical specification - Rear view of the FV 215..........................................................................................................24
Figure 12: Mechanical specification - Top view of the FV 215 ..........................................................................................................24
Figure 13: Mechanical specification - Side view of the PC Box......................................................................................................... 25
Figure 14: Mechanical specification - Bottom view of the PC Box.................................................................................................. 25
Figure 15: Airflow direction...........................................................................................................................................................................29
Figure 16: Bottom view ..................................................................................................................................................................................30
Figure 17: Right view.......................................................................................................................................................................................30
Figure 18: Front view .....................................................................................................................................................................................30
Figure 19: Left view ........................................................................................................................................................................................30
Figure 20: Top view.........................................................................................................................................................................................30
Figure 21: Rear view.........................................................................................................................................................................................31
Figure 22: Front view of FusionView SD ..................................................................................................................................................32
Figure 23: Bottom side of the FusionView (interface side of a 21.5" display) .............................................................................34
Figure 24: Detail of the DC Power connector shown without Phoenix terminal ........................................................................34
Figure 25: FusionView - Buttons and Indicators................................................................................................................................... 35
Figure 26: Bottom side of the touch display unit with installed mounting clamps (enlarged, in circle)........................... 36
Figure 27: Rear side of the FusionView shown as FV 215...................................................................................................................38
Figure 28: Rear view with holes (M4 - depth 8 mm) for VESA 75/100 mounting...................................................................... 39
Figure 29: Wall/panel cutout dimensions for FusionView systems...............................................................................................41
Figure 30: Wall/panel mounting of the FusionView by use of the mounting clamps..............................................................42
Figure 31: Phoenix power plug terminal ..................................................................................................................................................44
Figure 32: FusionView - Buttons and Indicators...................................................................................................................................46
Figure 33: Main Menu of the user interface by pressing on Menu Button................................................................................... 47
Figure 34: On-Screen Display (OSD) Menu .............................................................................................................................................47
Figure 35: System Setting by pressing on Set Button.........................................................................................................................47
Figure 36: Main Menu: Input Select...........................................................................................................................................................48
Figure 37: Main Menu: Input Select, Sub Menu: Main picture channel ..........................................................................................48
Figure 38: Main Menu: Input Select, Sub Menu: Scan Inputs ............................................................................................................49
Figure 39: Main Menu: Image Adjustments ............................................................................................................................................49
Figure 40: Main Menu Image Adjustments, Sub Menu Backlight....................................................................................................49
Figure 41: Main Menu Image Adjustments, Sub Menu Brightness..................................................................................................50
Figure 42: Main Menu Image Adjustments, Sub Menu: Contrast ....................................................................................................50
Figure 43: Main Menu Image Adjustments, Sub Menu: Sharpness ................................................................................................50
Figure 44: Main Menu Image Adjustments, Sub Menu: Gamma.......................................................................................................51
Figure 45: Main Menu Color Adjustment, Sub Menu Theme..............................................................................................................51
Figure 46: Main Menu Color Adjustment, Sub Menu Color Temp.....................................................................................................51
Figure 47: Main Menu Color Adjustment, Sub Menu Red................................................................................................................... 52
Figure 48: Main Menu Color Adjustment, Sub Menu Green .............................................................................................................. 52
Figure 49: Main Menu Color Adjustment, Sub Menu Blue ................................................................................................................. 52
Figure 50: Main Menu Color Adjustment, Sub Menu Saturation...................................................................................................... 53
Figure 51: Main Menu Color Adjustment, Sub Menu Hue.................................................................................................................... 53
Figure 52: Main Menu VGA Settings .......................................................................................................................................................... 53
Figure 53: Main Menu VGA Settings, Sub Menu Auto Adjust.............................................................................................................54
Figure 54: Main Menu VGA Settings, Sub Menu Auto Color Adjust.................................................................................................54
Figure 55: Main Menu VGA Settings, Sub Menu Clock .........................................................................................................................54
Figure 56: Main Menu VGA Settings, Sub Menu Phase........................................................................................................................ 55
Figure 57: Main Menu VGA Settings, Sub Menu Hor. Position........................................................................................................... 55
Figure 58: Main Menu VGA Settings, Sub Menu Ver. Position........................................................................................................... 55
Figure 59: Main Menu OSD Settings ..........................................................................................................................................................56
Figure 60: Main Menu OSD Settings, Sub Menu OSD Timeout ......................................................................................................... 56
Figure 61: Main Menu OSD Settings, Sub Menu OSD Hor. Pos. ......................................................................................................... 56
Figure 62: Main Menu OSD Settings, Sub Menu OSD Ver. Pos...........................................................................................................57
Figure 63: Main Menu OSD Settings, Sub Menu OSD Blend................................................................................................................57
Figure 64: Main Menu OSD Settings, Sub Menu OSD Orientation ....................................................................................................57

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 12
Figure 65: Main Menu OSD Settings, Sub Menu OSD Language.......................................................................................................58
Figure 66: Main Menu System Settings ...................................................................................................................................................58
Figure 67: Main Menu System Settings, Sub Menu Info .....................................................................................................................58
Figure 68: Main Menu System Settings, Sub Menu Mode Info......................................................................................................... 59
Figure 69: Main Menu System Settings, Sub Menu Color Controls ................................................................................................ 59
Figure 70: Main Menu System Settings, Sub Menu Save User Defaults ....................................................................................... 59
Figure 71: Main Menu System Settings, Sub Menu Reset Factory Default...................................................................................60
Figure 72: Screen Connection of Soft-OSD ..............................................................................................................................................61
Figure 73: Screen Image of Soft-OSD........................................................................................................................................................62
Figure 74: Screen OSD of Soft-OSD ...........................................................................................................................................................62
Figure 75: Screen VGA of Soft-OSD............................................................................................................................................................63

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 13
1/ General Safety Instructions for IT Equipment
Please read this chapter carefully and take careful note of the instructions, which have been
compiled for your safety and to ensure to apply in accordance with intended regulations. If
the following general safety instructions are not observed, it could lead to injuries to the
operator and/or damage of the product; in cases of nonobservance of the instructions
Kontron is exempt from accident liability, this also applies during the warranty period.
The product has been built and tested according to the basic safety requirements for low voltage (LVD) applications
and has left the manufacturer in safety-related, flawless condition. To maintain this condition and also to ensure safe
operation, the operator must not only observe the correct operating conditions for the product but also the following
general safety instructions:
The product must be used as specified in the product documentation, in which the instructions for safety for the
product and for the operator are described. These contain guidelines for setting up, installation and assembly,
maintenance, transport or storage.
The on-site electrical installation must meet the requirements of the country's specific local regulations.
If a power cable comes with the product, only this cable should be used. Do not use an extension cable to connect
the product.
To guarantee that sufficient air circulation is available to cool the product, please ensure that the ventilation
openings are not covered or blocked. If an air filter is provided, this should be cleaned regularly. Do not place the
system close to heat sources or damp places. Make sure the system is well ventilated.
Only devices or parts which fulfill the requirements of SELV circuits (Safety Extra Low Voltage) as stipulated by
IEC 60950-1 may be connected to the available interfaces.
Before opening the device, make sure that the device is disconnected from the mains.
Switching off the device by its power button does not disconnect it from the mains. Complete disconnection is
only possible if the power cable is removed from the wall plug or from the device. Ensure that there is free and
easy access to enable disconnection.
The device may only be opened for the insertion or removal of add-on cards (depending on the configuration of
the system). This may only be carried out by qualified operators.
If extensions are being carried out, the following must be observed:
•All effective legal regulations and all technical data are adhered to.
•The power consumption of any add-on card does not exceed the specified limitations.
•The current consumption of the system does not exceed the value stated on the product label.
Only original accessories that have been approved by Kontron can be used.
Please note: safe operation is no longer possible when any of the following applies:
•The device has visible damages.
•The device is no longer functioning.
In this case the device must be switched off and it must be ensured that the device can no longer be operated.
1.1. Additional Safety Instructions for DC Power Supply Circuits
To guarantee safe operation of devices with DC power supply voltages larger than 60 volts DC or a power
consumption larger than 240 VA, please observe that:
•The device is set up, installed and operated in a room or enclosure marked with “RESTRICTED ACCESS”, if there
are no safety messages on product as safety signs and labels on the device itself.
•No cables or parts without insulation in electrical circuits with dangerous voltage or power should be touched
directly or indirectly.
•A reliable protective earthing connection is provided.
•A suitable, easily accessible disconnecting device is used in the application (e.g. overcurrent protective device),
if the device itself is not disconnectable.
•A disconnect device, if provided in or as part of the equipment, shall disconnect both poles simultaneously.
•Interconnecting power circuits of different devices cause no electrical hazards.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 14
A sufficient dimensioning of the power cable wires must be selected – according to the maximum electrical
specifications on the product label – as stipulated by EN60950-1 or VDE0100 or EN60204 or UL508 regulations.
The devices do not generally fulfill the requirements for “centralized DC power systems“ (UL 60950-1, Annex
NAB; D2) and therefore may not be connected to such devices!
1.2. Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices or micro-
circuitry.
Therefore proper packaging and grounding techniques are necessary precautions to prevent damage. Always take the
following precautions:
1. Transport boards in ESD-safe containers such as boxes or bags.
2. Keep electrostatic sensitive parts in their containers until they arrive at the ESD-safe workplace.
3. Always be properly grounded when touching a sensitive board, component, or assembly.
4. Store electrostatic-sensitive boards in protective packaging or on antistatic mats.
1.2.1. Grounding Methods
By adhering to the guidelines below, electrostatic damage to the device can be avoided:
1.
Cover workstations with approved antistatic material. Always wear a wrist strap connected to workplace. Always
use properly grounded tools and equipment.
2.
Use antistatic mats, heel straps, or air ionizers for more protection.
3.
Always handle electrostatically sensitive components by their edge or by their casing.
4.
Avoid contact with pins, leads or circuitry.
5.
Turn off power and input signals before inserting and removing connectors or connecting test equipment.
6.
Keep work area free of non-conductive materials such as ordinary plastic assembly aids and Styrofoam.
7.
Use only field service tools which are conductive, such as cutters, screwdrivers, and vacuum cleaners.
8.
Always place drives and boards PCB-assembly-side down on the foam.

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 15
2/ Scope of Delivery
Please check that your package is complete, and contains the items below (according to the ordered unit
configuration). If you discover damaged or missing items, please contact your dealer.
Table 1: FusionView - Scope of delivery
FusionView system in the configuration ordered:
FV 121 (with 12.1" display)
FV 156 (with 15.6" display)
FV 185 (with 18.5" display)
FV 215 (with 21.5" display)
DC power terminal
Mounting clamps with Allen screws for front panel of system
(delivered and mounted to the front panel of the FusionView)
Number of mounting clamps depends on the model ordered
Safety instruction for IT equipment

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 16
2.1.1. Optional System Configuration
Table 2: FusionView - System configuration options
Option Description
RFID wireless access e.g. for Authentication
2.1.2. Accessory Parts
Table 3: FusionView – Optional Accessories
Adaptor Description
External AC/DC adaptor (90-264 V AC/24 V DC), including power cable for EU
and US.
Mating connector (DC power terminal for DC power supply) is supplied with
the system.
EU USA

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 17
3/ Technical Data
Table 4: FusionView Technical Data
System FV 121 FV 156 FV 185 FV 215
TFT LCD Display
Size (diagonal) 12.1" 15.6" 18.5" 21.5"
Active area
(H x V) [mm]
261.1 x 163.2 344.2 x 193.5 409.8 x 230.4 476.6 x 268.1
Resolution
(H x V) [pixel]
1280 x 800 1366 x 768
(WXGA)
1366 x 768
(WXGA)
1920 x 1080
(Full HD)
Pixel Pitch
(H x V) [
µ
m]
204 x204 252 x 252 300 x 300 248 x 248
Colour Depth 16.7 M colors 16.7 M colors 16.7 M colors 16.7 M colors
Backlight LED LED LED LED
Brightness
[cd/m2]
400 400 450 300
Control Signal 24 bit/s LVDS 24 bit LVDS 24 bit LVDS 24bit LVDS
Viewing Angle
[°]
(r / l / u / d)
88/88/88/88 85/85/80/80 85/85/80/80 89/89/89/89
Contrast ratio 1000:1 500:1 1000:1 5000:1
Response Time
[msec]
10 8 5 25
Touch Screen Projected
Capacitive
Projected
Capacitive
Projected
Capacitive
Projected
Capacitive
External interfaces
1x USB (3.0) Type B
1x DisplayPort
1x DVI, 1x VGA
1x Power input
LED Indicators Power LED, Graphic source LED
DC IN Power Plug
(on the bottom side) 3-pin Phoenix connector on the bottom side
Power supply DC: external 15 to 30 V power source (limited power source), max. specified input
power 75W
VESA 75/100 Mounting On the rear
Protection Class IEC IP20 with VESA mount
IEC IP65 front (only mounted to a wall/panel)
Driver support Windows/Linux
Touch controller options
(only on demand)
Glove Support, Palm Rejection Support, Water rejection Mode
Glass 4 mm thickness, Glass is chemically hardened with the C-shape of the edge
Options
RFID LF/125kHz, EM4100/EM4050 HF/13.56kHz, ISO15693

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 18
3.1. Electrical Specifications
Hint for DC power connection: The FusionView must be connected only to a LPS (Limited
Power Supply) DC mains power supply complying with the requirements of EN 60950-1.
Hint for AC power connection: Use only a LPS (Limited Power Supply) power supply
complying with the requirements of EN 60950-1 to connect the FusionView to an AC power
source.
Table 5: FusionView Power Consumption
FusionView FV 121 FV 156 FV 185 FV 215
Power 15 to 30 V DC
Power consumption 3.0 A max. 3.0 A max. 3.5 A max. 3.5 A max.
3.2. Mechanical Specifications
3.2.1. Dimensions and weight
For detailed mechanical dimensions, please see the outline dimensions drawings on the web site www.kontron.com.
Table 6: FusionView Dimensions
FusionView FV 121 FV 156 FV 185 FV 215
Height 266 mm (10.47") 298 mm (11.73") 337 mm (13.27") 373 mm (14.69")
Width 328 mm (12.91") 414 mm (16.3") 480 mm (18.9") 545 mm (21.46")
Depth (total) 67,6 mm (2.66") 67,6 mm (2.66") 67,6 mm (2.66") 67,6 mm (2.66")
Depth (without
front plate)
61,6 mm (2.42") 61,6 mm (2.42") 61,6 mm (2.42") 61,6 mm (2.42")
Weight 3.75 kg (8.2 lbs) 5.05 kg (11.13 lbs) 6.4 kg (14.1 lbs) 7.6 kg (16.75 lbs)
Touch unit PCAP or protective glass
Chassis Aluminum with fins and holes for VESA75/100 mounting
Table 7: Dimension of the touch display unit
FusionView FV 121 FV 156 FV 185 FV 215
Front bezel (W x H) 328 x 266 [mm]
(12.91" x 10.47")
414 x 298 [mm]
(16.3" x 11.73")
480 x 337 [mm]
(18.9" x 13.27")
545 x 373 [mm]
(21.46" x 14.69")
Frontal cut out for
display (W x H)
261.1 x 163.2 [mm]
(10.28" x 6.43")
344.2 x 193.5
[mm] (13.55" x
7.62")
409.8 x 230.4
mm] (16.13" x
9.07")
476.6 x 268.1
[mm] (18.76" x
10.56")
Wall/panel
mounting cut out
(W x H)
312 x 250 [mm]
(12.28" x 9.84")
398 x 282 [mm]
(15.67" x 11.02")
464 x 321 [mm]
(18.27" x 12.64")
529 x 357 [mm]
(20.83" x 14.06")

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 19
3.2.2. Mechanical Dimensions of the Monitor
Figure 1: Mechanical specification - Front view of the FV 121
Figure 2: Mechanical specification - top view of the FV 121

FusionView – User Guide Doc-Rev.: 1.1
www.kontron.com // 20
Figure 3: Mechanical specification - rear view of the FV 121
Figure 4: Mechanical specification - Front view of the FV 156
